Chapter 1
Name
(5 GHz Wireless)
(Internet)
(Ethernet)
(USB)
(WPS)
1 2 2

Back Panel

The following parts (view from left to right) are located on the back panel.
Button and Port Explanation
Item
LED Button
Status
On The 5 GHz wireless band is enabled.
Off The 5 GHz wireless band is disabled.
Green On Internet service is available.
The router's Internet port is connected, but the internet service
Orange On
is not available.
Off The router's Internet port is unplugged.
At least one powered-on device is connected to the router's
On
Ethernet port.
Off No powered-on device is connected to the router's Ethernet port.
On The inserted USB device is ready to use.
Blinking A USB device is being identified.
Off No device is plugged into the USB port.
Off This light turns off when a WPS connection is established.
Blinking WPS connection is in progress. This may take up to 2 minutes.
Press the LED button for 1 second to turn on or off the LEDs of your router.
Get to Know About Your Router
Indication
Description
