OWNER'S MANUAL
VACUUM CLEANER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
A9T********
MFL69883694
Rev.01_102521
Copyright © 2021 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG A9T-CORE
Summary of Contents for LG A9T-CORE
- Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH A9T******** www.lg.com MFL69883694 Rev.01_102521 Copyright © 2021 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
OPERATION Getting Started ....................18 Charging the Battery ..................20 Using the Mop Nozzle ..................21 Using the Nozzles and Tools................24 SMART FUNCTIONS Using LG ThinQ Application................28 Smart Diagnosis Function................30 MAINTENANCE Cleaning the Appliance ...................31 Cleaning the Nozzles ..................34 TROUBLESHOOTING Before Calling for Service................38... -
Page 3: Safety Instruction
SAFETY INSTRUCTION SAFETY INSTRUCTION READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 If the appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return it to an LG Electronics service centre. • Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners.
- Page 5 SAFETY INSTRUCTION • When disposing of this appliance, follow regulations for disposal of rechargeable lithium-ion batteries. • Follow all local ordinances and regulations when handling or disposing of the battery. • Prevent unintentional starting. Ensure the switch is in the off position before connecting to the battery pack, picking up or carrying the appliance.
- Page 6 • Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug. Take it to an authorized LG Electronics service centre or dealer for assistance. • Do not apply excessive force to the power cord to bend it, or place it under a heavy object as this will damage it.
- Page 7 • Do not cover the power cord with a rug or carpeting. • Push the power plug firmly into the wall outlet so that it is not loose. • If the product has been submerged, contact an LG Electronics service centre or dealer for instructions before resuming use.
- Page 8 • If the earth leakage breaker is tripped when the product is put on the charging station, immediately remove the appliance from the charging station. Contact an LG Electronics customer service centre. • Use extra care when cleaning on stairs.
- Page 9 SAFETY INSTRUCTION Maintenance • Make sure to unplug the power cord when cleaning or maintaining the charging station. • Do not wash the inlet port or the dust bin with water or detergent. • Do not use detergents, polishes or air fresheners to clean the dust bin.
-
Page 10: Caution
SAFETY INSTRUCTION CAUTION CAUTION • To reduce the risk of injury to persons, malfunction, or damage to the product or property when using the appliance, follow basic safety precautions, including the following: Operation • This appliance has a built-in safety device to prevent damage from overheating. - Page 11 SAFETY INSTRUCTION • Do not use the mop nozzle to clean the same spot repeatedly for an extended period of time. The water injection at the mop nozzle may cause water to get into the dust inlet and damage the appliance. •...
-
Page 12: Installation Product Overview
INSTALLATION INSTALLATION Product Overview The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. Front View *1 This feature is only available on some models. Product Body Extension Pipe Nozzle... - Page 13 INSTALLATION NOTE • Use the vacuum cleaner only with the provided charging station. Using a charging station other than the one designed to be used with the vacuum cleaner, as improper sealing of the chagring station may result and dust not being emptied from vacuum cleaner.
- Page 14 Mop Pads for General Cleaning Nozzles Measuring Cup NOTE • The mop pads, batteries, exhaust filter and the pre-filter will eventually need to be replaced. Contact an LG Electronics customer service centre. Multi-Surface Nozzle Slim Hard Floor Nozzle Bedding Nozzle...
-
Page 15: Storing The Accessories
Individually measured data would be different from a lab test result. • Battery run time is the result of using a fully charged battery according to the LG Electronics test standard. Results may be different depending on actual use environment and period of use. - Page 16 INSTALLATION • To detach the extension pipe, press the • To open the nozzle hooks, press on the right side. Be careful not to pinch fingers when extension pipe release button opening. Put the product body on the charging station. •...
- Page 17 INSTALLATION Open the right door and insert the combination tool , the crevice tool and the cleaning brush for storage. NOTE • Before moving the product, unplug it and remove the vacuum cleaner, nozzles, and accessories. • To carry the product, open both doors and hold the areas shown.
-
Page 18: Operation Getting Started
The nozzles and tools can accumulate on the appliance. Please contact LG also be attached to the end of the extension Electronics customer information centre if the pipe problem persists. - Page 19 • This indicator blinks when the appliance is Suction Power Up (+) Button / Turbo Mode connecting to the LG ThinQ application or • Press the + button to increase the suction home Wi-Fi network, and the indicator lights up when the connection is complete.
-
Page 20: Charging The Battery
OPERATION • As the product is charging, bars light up on combination tool or the crevice tool, if either the battery level indicator to indicate the level happens to be fitted of charge. • If you don't hear a beep, reload the •... -
Page 21: Using The Mop Nozzle
• Do not use a soiled mop pad to clean floors. • Use only authorized LG Electronics mop pads. • Empty the dust bin and clean the fine dust filter and the pre-filter after using the mop nozzle. - Page 22 OPERATION • If the water inlet cap is not closed properly, CAUTION water may leak. • If you use the mop nozzle for a long time with the suction off, the motor may overheat (recommended duration of use: 80 minutes). When the moter overheats, the overheating prevention function is activated and the appliance is automatically turned off.
- Page 23 OPERATION Using with the Mop Nozzle or improperly may affect the cleaning results. Attach the water tank and mop pads to the mop nozzle. Set the water adjustment button to the STOP position. Press the Power button to start cleaning. Attach the mop nozzle to the appliance.
-
Page 24: Using The Nozzles And Tools
OPERATION Shake the water tank to remove the remaining • Storing mop pads in a damp state can result water. in an unpleasant odour. Set the pads in a well-ventilated area out of direct sunlight for at least 24 hours or until completely dry. Using the Nozzles and Tools Leave the 2 water inlet caps open and allow the... - Page 25 OPERATION Multi-surface Nozzle • Lower the suction level when vacuuming bedding such as duvet covers to avoid the thin Use this nozzle to clean carpets or rugs. fabric getting sucked into the nozzle. • If used on hard flooring, this nozzle will be noisy. Hard Floor Nozzle Use this nozzle to clean hard floor surfaces.
- Page 26 OPERATION - To convert modes, press the adjustment vehicles or in narrow spaces under and behind furniture where an angled tool is needed. button and push forward. Using the Brush Hard Dirt Tool To convert the tool from crevice to brush mode, press in on the sides of the brush head and pull Firm bristles remove solidified dirt from hard...
- Page 27 OPERATION Multi-angle Tool This tool has a soft brush that can be adjusted to a variety of angles, making it especially useful for cleaning vehicle consoles or the tops of furniture. Flexible Hose Extension Connect this flexible, extendable hose between the product body and the tools to clean hard to reach areas.
-
Page 28: Smart Functions
• If you change your wireless router, Internet wireless router manual. service provider, or password, delete the • LG ThinQ is not responsible for any network connected appliance from the LG ThinQ connection problems or any faults, application and connect it again. - Page 29 Select your appliance on menu by pressing the Add a Product (+) button. Follow instructions in the LG • The wireless network name (SSID) should be a ThinQ to connect your appliance.
-
Page 30: Smart Diagnosis Function
Statement • Once set, the default operation mode is RF Radiation Exposure Statement This equipment maintained until the setting is changed in the LG complies with radiation exposure limit (<4.0 W/kg ThinQ application. for extremity (hand) exposure condition) set forth for an uncontrolled environment. -
Page 31: Maintenance
MAINTENANCE MAINTENANCE Cleaning the Appliance battery from the product body and remove the foreign objects before resuming use of the appliance. Before Cleaning the Appliance • Check the inside of the product body, above the To maintain the optimum suction power, the Kompressor working plate, the extension pipe, cyclonic mesh filter, the exhaust filter and the pre- inlets, exhaust filter, pre-filter and cyclonic mesh... - Page 32 MAINTENANCE Remove the battery from the product body • Do not force the Kompressor lever down if before cleaning the dust bin. foreign objects are caught around the working plate of the Kompressor system. Doing so may cause product damage. Push down the Kompressor lever several times to collect and compact the dust from the...
- Page 33 MAINTENANCE Cleaning the Filters Turn the product body over and lift the Kompressor lever up to clean the inside of the working plate with the provided cleaning Clean the exhaust filter and the pre-filter when the brush. filter cleaning icon lights up.
-
Page 34: Cleaning The Nozzles
MAINTENANCE Lift out the pre-filter from the product body. Align the lock position of the exhaust filter cover with the letter "H" of the PUSH button on the exhaust filter. Use the combination tool to clean any dust off the motor. •... - Page 35 MAINTENANCE dust from the brush and the bottom of the CAUTION nozzle. • Always separate the nozzle from the product body or remove the battery before cleaning. If the nozzle starts to operate during cleaning, it could cause an injury. •...
- Page 36 MAINTENANCE Press the nozzle release button to remove • Wrap the handle of the cleaning brush with the nozzle from the extension pipe or product a wet towel or cloth and use it to clean the body. rotating brush and nozzle. Turn the nozzle upside down and rotate the cover lock slot counterclockwise.
- Page 37 MAINTENANCE dust from the brush and the bottom of the Attach the crevice tool to the product body and nozzle. use the vacuum to remove foreign objects and dust from the bottom of the nozzle. Use a damp towel or cloth to remove any remaining foreign objects and dust from the bottom of the nozzle.
-
Page 38: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service Operation Symptoms Possible Cause & Solution The appliance does not Battery is fully discharged. operate. • Charge the battery. Appliance is turned off. • Press the Power button to turn on the appliance. Suction power is too Dust bin is full of dust. - Page 39 LG customer information centre for service. repeatedly. Foreign object is in the product body, extension pipe, inlet port or nozzle.
- Page 40 TROUBLESHOOTING Mop Nozzle Symptoms Possible Cause & Solution The mop pad Mop pads are improperly installed. attachment plate does • Remove the mop pads, clean them if necessary and attach them again. not rotate. Mop nozzle is pressed too hard against the floor. •...
- Page 41 Your home appliance Battery is fully discharged. and smartphone are • Charge the battery, then register your appliance on LG ThinQ. not connected to the Wi-Fi network. The password for the Wi-Fi that you are trying to connect to is incorrect.
