QOLSYS QW9104-840 Quick Manual

QUICK GUIDE-IQ REMOTE
Secondary tablet
for the IQ Panel 2
The IQ Remote is a 7" secondary tablet that can be installed to create additional
access to the IQ Panel 2. You can pair up to three (3) IQ Remotes with the IQ
Panel 2.
IN THE BOX
12:55 PM
H 70°
L 56°
07/10/17
SYSTEM
DISARMED
IQ Remote
OPTION 1: WALL MOUNTING
Choose your
location
OPTION 2: TABLE STAND
Choose your
location
12:55 PM
H 70°
L 56°
07/10/17
SYSTEM
DISARMED
Wall Mount Bracket
and Screws
Secure wall mount to
the wall with
provided hardware
Connect table stand to upper
holes on the back of the
device and snap into place
NEED HELP?
(855) 4-QOLSYS
TECHSUPPORT@QOLSYS.COM
INFORMATION
Document#: IQR-QG-11-18
Revision#: 11/28/18
Issue Date: NOV 2018
Qolsys Part #: QW9104-840
Software : 2.3.0
Additional documentation located
on
Power Supply
Connect power
supply to the back
Connect your power
supply
qolsys.com
Optional Table Stand
Slide IQ Remote onto
wall mount bracket
