Cooper Lighting METALUX 15/ASY Specification Sheet

METALUX
®
OPEN
FROSTED ACRYLIC LENS
HEAVY DUTY WIREGUARD
TBW
ASYMMETRIC LOUVER
Items listed are the major options and accessories available on Metalux Recessed (Parabolic and Recessed) and Surface Fixtures. Additional options and accessories are available.
Consult Pre Sales Technical Support for additional information.
F-BAY I5 & I8 DOORFRAMES & WIREGUARDS
D E S I G N AT I O N
Blank= No Guard
D E S I G N AT I O N
I5-FRM/FL= Frosted Acrylic Lens & Frame (use
with general distribution reflector, I5 only)
I5-FRM/CL= Clear Acrylic Lens & Frame (use
with general distribution reflector, I5 only)
D E S I G N AT I O N
I5/WG= Heavy Duty Wireguard
D E S I G N AT I O N
I5/TBW= Thin White Baffle (for I5)
I8/TBW= Thin White Baffle (for I8)
D E S I G N AT I O N
I5/ASY= Asymmetric Directional Louver (use with
general distribution reflector)
Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX 770.486.4801
D E S C R I P T I O N
For maximum light output
D E S C R I P T I O N
In white doorframe w/"Herringbone"
patterned end rail
D E S C R I P T I O N
Finished in white. Can be used alone
or in combination with other shielding
D E S C R I P T I O N
Thin Blade White Baffle w/23˚
longitudinal shielding
D E S C R I P T I O N
Can be oriented in either direction for
flexibility
Visit our web site at www.cooperlighting.com
1/08 ADF060835
