D I M E N S I O N S
37 3/8"
[949mm]
25 3/8" [645mm]
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : G AT- 1 5 0 - M H - 1 2 0 - 3 3 - U U A - B Z
Product
Lamp
Lamp Type
Family
Wattage
MH=Metal
GAT=Architectural
50=50W
Halide
70=70W
HPS=High
85=85W
1
Pressure
100=100W
Sodium
150=150W
QL=Electrodeless
175=175W
Fluorescent
250=250W
400=400W
2, 3
E.P.A. 2.1
Options
10
F=Single Fuse (120, 277 or 347V)
FF=Double Fuse (208, 240 or 480V)
P=Polycarbonate Refractor
11
R=Internal NEMA photocontrol Receptacle
D=Downlight Reflector
L=Lamp Included
NOTES: 1 85W QL Electrodeless Fluorescent only. 120 or 240V only. 2 Not available in 480V. 3 400W available in Metal Halide only. Requires reduced envelope ED-28
lamp. 4 Medium-base lamps standard for 150W and below Metal Halide. 5 Product also available in non-US voltages and 50Hz for international markets. Consult
factory for availability and ordering information. 6 Multi-Tap ballast is 120/208/240/277V wired 277V. 7 Triple-Tap ballast is 120/277/347V wired 347V. 8 Avenue
Cage must be ordered with Avenue Top and Architectural Finial. Top is available without Avenue Cage. 9 Other finish colors available, including a full line of RAL
color matches. Consult your Cooper Lighting Representative. 10 Add as suffix in the order shown. 11 Polycarbonate parts used with Metal Halide lamps will
eventually yellow. 12 Order separately, replace XX with color suffix. 13 Specifications and dimensions subject to change without notice.
Refractor
Top Type
Voltage
5
Type
U=Avenue
120=120V
4
33=Type III
208=208V
55=Type V
240=240V
277=277V
347=347V
480=480V
1
MT=Multi-Tap
6
TT=Triple-Tap
7
Accessories
12
AA2000=House Side Shield—Mogul-Base Lamp
AA2001=House Side Shield—Medium-Base Lamp
OA/RA1016=NEMA Twistlock Photocontrol—Multi-Tap
OA/RA1027=NEMA Twistlock Photocontrol—480V
OA1201=NEMA Twistlock Photocontrol—347V
MCGRAW-EDISON
D E S C R I P T I O N
The Generation Series Avenue
provides updated styling and a
smooth exterior appearance,
providing a contemporary feel to
any setting. Refractive globe
provides superior photometrics,
maximum pole spacing, excellent
roadway illumination and
uniformity.
8
Cage Type
8
Color
9
U=Avenue
AP=Grey
X=None
BZ=Bronze
BK=Black
GN=Hartford Green
Finial Type
8
WH=White
A=Architectural
DP=Dark Platinum
M=Modern
GM=Graphite Metallic
AVENUE
POST TOP
5 0 - 4 0 0 W
M e t a l H a l i d e
H i g h P r e s s u r e S o d i u m
E l e c t r o d e l e s s
F l u o r e s c e n t
D E C O R AT I V E L U M I N A I R E
• All hard mount tops are
made of spun aluminum.
Top provided with
toolless access for ease
Options &
Accessories
of maintenance. Finials
(See Below)
are cast aluminum
• Globe is available in 9"
high efficiency acrylic or
optional polycarbonate
refractive design. Internal
and external prisms work
in conjunction to provide
excellent vertical and
horizontal illumination
• Two (2) uprights are
manufactured of cast
aluminum. Banding is
spun aluminum. All cage
assemblies are mounted
to the exterior of the
housing via four (4) allen
head stainless steel
fasteners
• Ballast assembly is
mounted on a removable
tray with quick
disconnects for ease of
installation and
maintenance
• Optional NEMA PCR is
provided with quick
disconnects for ease of
maintenance
• Post top mount fits 3"
O.D. tenons. Four (4)
stainless steel fasteners
standard
• Approximate net weight:
50 lbs. (23 kgs.)
COOPER LIGHTING
®
GAT
1179
