- Page 1 Hartland Installation Manual Model: 50312 Indigo Blue 50313 Noble Bronze 50656 Matte Silver Fan weight ±2 lbs: 22.3 lbs (10.1 kg) ©2020 Hunter Fan Co. PG3880 r021120...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
-
Page 4: Choosing The Right Installation Location
Installing the Ceiling Bracket You have two options for installation. Pick which one works best for your location. Remove any existing bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. Do this first! -
Page 5: Hanging The Fan
1886 Hanging the Fan 3/8” 8” The wires can be cut, but leave at least 8” extending from the top of the canopy. Place the slots over the ceiling Raise the fan and align the slots in the plate hooks to hang the fan. canopy with the hooks on the ceiling plate. -
Page 6: Wiring The Fan
If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualified electrician. You are going to need these: Hunter Pro Tip: Here is how to connect the wires: 4 Wire Nuts (these are in the... - Page 7 1886 Hanging the Fan (Continued) 2 of 3 Canopy Screws Swing the fan up to align the canopy screw holes with the mounting holes on the ceiling plate. Hold the canopy up with the screw holes Note: The slots in the canopy must aligned.
-
Page 8: Installing The Blades
1886 Installing the Blades: Insert grommets found in the hardware bag into the holes in the blades, then secure each blade to a blade arm with screws found in the hardware bag. Blade Screw Grommet IMPORTANT Repeat x5 Note: NOTE: Follow the instructions on the blade. Installing it Fan style may vary. - Page 9 Install the socket rings onto the sockets. Tighten them by turning clockwise with the socket ring glass tool. Repeat x3 WARNING Hunter Pro Tip: Want to install your fan without a light kit? GLASS FALL HAZARD Note: Go to www.HunterFan.com/FAQs...
- Page 10 1886 Installing the Pull Chains Light Pull Chain Fan Pull Chain Remove and discard the plastic connectors from the ends of the pull chains (if necessary), then connect the appropriate pull chain pendant to each of the short chains coming from the switch housing.
-
Page 11: Troubleshooting
Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,...
