- Page 1 User’s Manual Desktop Monitor MultiSync E224FL ® MultiSync E244FL ® MultiSync E274FL ® MODEL: E224FL/E224FL-BK, E244FL/E244FL-BK, E274FL/E274FL-BK The regulations for this monitor applied to one of model names listed above. Please find your model name on the label on the rear side of the monitor.
-
Page 2: Table Of Contents
System Setup ..............38 Image Setup ...............37 Extra ...................38 Color Setup.................37 OSD Warning ..............38 OSD Setup .................37 Manufacturer’s Recycling and Energy Information Appendix B Disposing of your old NEC product ........40 WEEE Mark (European Directive 2012/19/EU and amendments)...........40 Energy Saving ..............40... -
Page 3: Registration Information
The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those specified by Sharp NEC Display Solutions of America, Inc. in this manual. Failure to comply with this government regulation could void your right to operate this equipment. -
Page 4: Tco Certified
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA ® in the United States and other countries. MultiSync is a trademark or registered trademark of Sharp NEC Display Solutions, Ltd. in Japan and other countries. ® Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States ®... -
Page 5: Important Information
Important Information Safety Precautions and Maintenance FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE LCD COLOR MONITOR: About the Symbols To ensure safe and proper use of the product, this manual uses a number of symbols to prevent injury to you and others as well as damage to property. - Page 6 AROION Handle the power cord with care. Damaging the cord could lead to fire or electric shock. • Do not place heavy objects on the cord. PROHIBITED • Do not place the cord under the product. • Do not cover the cord with a rug, etc. •...
- Page 7 AROION Prevent tipping and falling for earthquakes or other shocks. To prevent personal injury or damage to the product caused by tipping over due to earthquakes or other shocks, make sure to install the product in a stable location and take measures to prevent PROHIBITED falling.
- Page 8 AROION Do not spill any liquids into the cabinet or use your product near water. Immediately turn off the power and unplug your product from the wall outlet, then refer servicing to qualified service personnel. It may cause an electric shock or start a fire. DO OOT ET Do not use flammable gas sprays to remove dust when cleaning the product.
- Page 9 CAUTIOO Handling the power cord. Handle the power cord with care. Damaging the cord could lead to fire or electric shock. • When connecting the power cord to the product’s AC IN terminal, make sure the connector is REQUIRED fully and firmly inserted. •...
- Page 10 CAUTIOO Please check the Specifications for the available Tilt range when installing the product on a flexible arm. Do not tilt the monitor downward beyond 5 degrees. Doing so can cause the LCD panel to separate PROHIBITED and potentially fall out causing damage to the product or personal injury. Do not push the product.
- Page 11 Power Cord Table European Plug Type North America U.K. Chinese Japanese Continental Plug Shape Region U.S.A./Canada U.K. China Japan Voltage 120* * Please use this power cord under 125 V power supply. OOTEN: This product can only be serviced in the country where it was purchased. Image Persistence Image Persistence, also called Image Retention, is a condition that occurs when a previously displayed image leaves a residual or “ghost”...
- Page 12 • Use the preset Color Setting. • Use non-interlaced signals. • Do not use primary color blue on a dark background, as it is difficult to see and may produce eye fatigue due to insufficient contrast. For more detailed information on setting up a healthy work environment, write to the American National Standard for Human Factors Engineering of Computer Workstations - ANSI/HFES 100-2007 - The Human Factors Society, Inc.
-
Page 13: Product Features
Product Features • Color Control Systems Allow you to adjust the colors on your screen and customize the color accuracy of your monitor to a variety of standards. OSD (On-Screen Display) Controls • Allow you to quickly and easily adjust all elements of your screen image via simple to use on-screen menus. •... -
Page 14: Installation And Connections
Installation and Connections Chapter 1 This Chapter IncludesN > “Parts Name and Functions” on page 13 > “Installation” on page 16 > “Connections” on page 17 > “Flexible Arm Installation” on page 23 English−12... -
Page 15: Parts Name And Functions
Parts Oame and Functions Control Panel Item Function Indicates that the power is on or off. 1 LED CEOTER/⏻ Short press: Turns the monitor on. 2 5-Direction-Key Long press (three or more seconds): Turns the monitor off. LEFT/RINHT Opens the OSD menu. Right Left RIGHT: Enters sub-menus or adjustment settings in the OSD menu when the... -
Page 16: Terminal Panel
Terminal Panel 8 Security Slot Speaker 9 9 Speaker 0 Label 3 USB Downstream Port (Type A) 2 LAN 4 USB-C Port 6 HDMI IN 1 AC IN Connector 5 DisplayPort IN 7 Headphone AC IO Connector DisplayPort IO Connects with the supplied power cord. Digital DisplayPort signals input. - Page 17 Installing a security cable As a security measure, you can secure the monitor to a fixed object with an optional security cable. Please follow the security cable supplier’s recommended instructions to install. OOTEN: A security cable (purchased separately) is designed as a deterrent, it is not guaranteed to prevent the device from being mishandled or stolen.
-
Page 18: Installation
Installation For box contents, please refer to the printed contents sheet or setup manual provided in the box. The accessories included depends on the location where the monitor was shipped. Attach the base to the LCD monitor stand 1. Place the monitor face down on a non-abrasive surface (Figure 1). 2. -
Page 19: Connections
Connections 1. Place your hands on each side of the monitor to tilt the panel to a maximum tilt angle and lift up to the highest position (Figure 3). CAUTIOON Please refer to “CAUTION 6”. Maximum Tilt (Up 25° Down 5°) Figure 3 2. - Page 20 CAUTIOON • Use the provided specified cables with this product so as not to interfere with radio and television reception. For HDMI, DisplayPort, USB and USB-C , please use a shielded signal cable. ® Use of other cables and adapters may cause interference with radio and television reception. CAUTIOON Please refer to “CAUTION 3”...
- Page 21 4. Please check that you can still rotate, raise and lower the monitor screen after you have installed the cables (Figure 5 and Figure 6). DisplayPort Cable Power Cord DisplayPort Cable Power Cord Figure 5 Figure 6 5. Connect the power cord to a power outlet. OOTEN •...
-
Page 22: Signal Type And Terminal Connection
Signal type and terminal connection Video Input Connections • HDMI – High definition digital video and audio signal connection to a computer, streaming media player, Blu-ray player, game console, etc. • DisplayPort – High definition digital video and audio signal connection to a computer. •... - Page 23 Connecting to a Computer with DisplayPort • Please use a certified DisplayPort cable. • It may take a moment for the signal to appear after turning on the computer. • When connecting a DisplayPort cable to a component with a signal conversion adapter, an image may not appear. •...
-
Page 24: Connecting Devices
Connecting devices Connecting USB Devices • It may take a few seconds for the monitor to recognize the USB input. Do not disconnect the USB cable or disconnect and reconnect the USB cable before the monitor recognizes the input. • Before turning off the power switch of the monitor or shutting down Windows , please turn off the USB function and remove ®... -
Page 25: Flexible Arm Installation
Flexible Arm Installation This monitor is designed for use with a flexible arm. Contact us for more information. Follow the instructions provided by the manufacturer of the display mount. Use only VESA-compatible alternative mounting method. Remove the monitor stand before mounting. AROIONN Please refer to “WARNING... -
Page 26: Re-Attaching The Original Stand
Re-attaching the Original Stand Reverse the process in the previous section to re-attach stand. OOTEN: Match “TOP SIDE” mark on stand to top side of the monitor when re-attaching stand. “TOP SIDE” mark Please match top side of the monitor English−24... -
Page 27: Basic Operation
Basic Operation Chapter 2 This Chapter IncludesN > “Using the OSD (On-Screen Display) Controls” on page 26 > “Changing the Input” on page 27 > “Power management function LED indicator patterns” on page 27 English−25... -
Page 28: Using The Osd (On-Screen Display) Controls
Using the OSD (On-Screen Display) Controls The OSD (On-Screen Display) control button on the front of the monitor functions as followsN • To open the OSD menu, move the 5-direction key in any direction (LEFT/RIGHT/UP/DOWN). Selected Main Luminance Menu name Brightness Contrast... -
Page 29: Changing The Input
Changing the Input Changing the Input To change the signal input, open the OSD menu by moving the 5-direction key in any direction (LEFT/RIGHT/UP/DOWN). You can select the input signal at [Input Select] under the [Extra]. OOTEN: When selecting [Auto] input, the monitor selects the active signal input automatically. For HDCP Content HDCP is a system for preventing illegal copying of video data sent over a digital signal. -
Page 30: Troubleshooting
Troubleshooting Chapter 3 This Chapter IncludesN > “Screen Image and Video Signal Issues” on page 29 > “Hardware Issues” on page 30 English−28... -
Page 31: Screen Image And Video Signal Issues
Screen Image and Video Signal Issues Oo picture • Make sure the signal cable is fully connected to the monitor and the computer. • Make sure there is no DisplayPort converter adapter connected. The monitor does not support DisplayPort converter adapters. -
Page 32: Hardware Issues
Hardware Issues ⏻ key does not respond • Unplug the power cord of the monitor from the AC outlet to turn off and reset the monitor. LED on monitor is not lit • Make sure the power cord is properly connected to the monitor and the wall, and make sure the monitor’s power switch is Oo Video •... - Page 33 LAO port does not work • When applying 1000 Mbps communication, please use a compatible LAN cable. • Make sure a computer is connected to the monitor with a USB-C cable. • Make sure the LED lights up when connecting a LAN cable to the monitor. •...
-
Page 34: Specifications
Specifications Chapter 4 This Chapter IncludesN > “E224FL” on page 33 > “E244FL” on page 34 > “E274FL” on page 35 English−32... -
Page 35: E224Fl
E224FL Monitor Specifications MultiSync E224FL Ootes LCD Module Diagonal: 54.48 cm / 21.45 inches Active matrix; thin film transistor (TFT) liquid crystal Viewable Image Size: 54.48 cm / 21.45 inches display (LCD); 0.249 mm (H) x 0.241 mm (V) dot... -
Page 36: E244Fl
E244FL Monitor Specifications MultiSync E244FL Ootes LCD Module Diagonal: 60.47 cm / 23.8 inches Active matrix; thin film transistor (TFT) liquid crystal Viewable Image Size: 60.47 cm / 23.8 inches display (LCD); 0.275 mm dot pitch; 250 cd/m white Native Resolution: 1920 x 1080 60 Hz luminance;... -
Page 37: E274Fl
E274FL Monitor Specifications MultiSync E274FL Ootes LCD Module Diagonal: 68.60 cm / 27.0 inches Active matrix; thin film transistor (TFT) liquid crystal Viewable Image Size: 68.60 cm / 27.0 inches display (LCD); 0.311 mm dot pitch; 250 cd/m white Native Resolution: 1920 x 1080 60 Hz luminance;... -
Page 38: Osd Controls List
OSD Controls List Appendix A This Chapter Includes > “Luminance” on page 37 > “Image Setup” on page 37 > “Color Setup” on page 37 > “OSD Setup” on page 37 > “System Setup” on page 38 > “Extra” on page 38 >... -
Page 39: Luminance
Luminance Luminance Menu Brightness Adjusts the overall image and background screen brightness. Contrast Adjusts the image brightness in relation to the background. ECO MODE Decreases the amount of power consumption by reducing the brightness level. Sets the brightness variable range from 0% to 100%. Sets the brightness variable range from 0% to 70%. -
Page 40: System Setup
System Setup System Setup Menu Selects a transfer speed of USB-C. USB2.0: The maximum transfer speed is equivalent to USB 2.0 (up to 480 Mbps). USB3.0: The maximum transfer speed is equivalent to USB 3.0 (up to 5 Gbps). OOTEN To avoid data loss, before changing the setting, ensure that no USB storage devices are in use by the operating system. -
Page 41: Manufacturer's Recycling And Energy Information
Appendix B Energy Information This Chapter IncludesN > “Disposing of your old NEC product” on page 40 > “Energy Saving” on page 40 > “WEEE Mark (European Directive 2012/19/EU and amendments)” on page 40 We are strongly committed to environmental protection and sees recycling as one of the company’s top priorities in trying to minimize the burden placed on the environment. -
Page 42: Disposing Of Your Old Nec Product
All required information concerning the disposal of the product and country-specific information on recycling facilities can be found on our following websites: https://www.sharpnecdisplays.eu/p/hq/en/home.xhtml (in Europe), https://www.sharp-nec-displays.com/jp/ (in Japan) or https://www.sharpnecdisplays.us/ (in USA). Energy Saving This monitor features an advanced energy saving capability. When a Display Power Management signal is sent to the monitor, the Energy Saving mode is activated.
