Pyle PLVW56MN Specifications

Whole indication & illumination
Receiving sensor
Active Display Area
1> POWER: Power On /Off
2> TIMER: Timer power off set up. Every press the TIMER key, the
revolving time change selectable. The longest it can keep is 180 minutes
¡ œ ¡ œ ¡ œ
15 30 45
3> DISPLAY : press this key and display the situation of video, press again
and display logo, it exit as if press again.
4> MUTE key: Press this key, sound disappear; press again or VOL -/+ key,
the sound return normally
5> P.P press once Form settle
again) soft ( press again) brightness, four
kinds of forms, can choice according to your interesting.
£º
Russia Shape , press “GAME” will introduce menu
6> GAME Named
function of operation , additional press “SYSTEM” start or stop.
7> CALENDAR: From 1900 to 2099(two hundred years), press “CH+/-” to
adjust the year number, press “VOL+/-” to adjust the month number.
8> AV/TV: press this key, monitor display the signal of AV1
£º
9> VOL +/- Control the volume and also as a function to adjust the menu
10> MODE: Press once, the menu can revolving to select, then press “VOL-
or VOL+” to adjust the item number
VOL+
VOL+
VOL-
VOL- MODE
Power Light
MENU
INVERT
INVERT
Power Switch
POWER
S terminal
DC+12V
Remote control
DC-
Remote Control
¡ œ ¡ œ ¡ œ ¡ œ
60 90 120 150 180
s
press again Standard,
11>
CH +/-: Menu option select
12>
SYSTEM/INVERT: picture up/down,left/right reverse function
13> LANGUAGE: OSD menu font with Chinese, English, Arabic, Russian,
German are selectable to display.

Technical Specification

*power voltage 12V DC 10% 650mA
*power consumption 7.8W
*Video input 1Vp-p(PAL NTSC)
*pixel format 960(W)X234(H)
Audio in
*color system PAL NTSC
Video in
*overall dimension 172X116X29(mm)
*viewing area
*screen size 5.6
*operate temperature 0 ~ 60
*net weight 490g 20g
¡ œ
¹Ø
OFF
Accessories
*TFT Color Monitor
* TFT color monitor booklet
* DC/Audio/Video line(compose )
* Remote control SPR-N56
( press
* Plastic stand
Maintenance
To avoid electrical shock, do not open the enclosure .high voltage is
present. No user serviceable parts inside the enclosure
Do not use any chemical solvent. Cleaning angent or corrosive detergent
to clean away dirt on the surface of the screen. To clean off dirt or finger print,
we recommend use a soft damp lens cleaning cloth.
Should there be requirement to replace blown fuse, do remember to
disconnect all power supply and switched off the unit before replacing it with
a new one . use only correct rating fuse to avoid damaging the unit.
BRIGHT COLOR CONTRAST
115X84 (mm)
storage temperatur
1 pc
1 pc
1 pc
1 pc
1 pc
HUE
¡¢ ¡¢ ¡¢ ¡¢
10 ~ 85
