Summary of Contents for Pyle PLTK100N
-
Page 2: System Features And Controls
TV TUNER BOX System features and controls: Remote control functions TV/CATV interchange TV/AV Channels convertible(CH) Volume control buttons (Useless with Main Monitor) TV/CATV TV/AV MUTE POWER Power MUTE 1 2 3 4 Number Pad 5 6 7 8 FM/AM SETUP SETUP Monitor FUNC... - Page 3 Tuner Installation and electrical connections 1. Find a suitable location for the tuner unit and mount it securely in place. Be sure to place it in an area away from moisture and dirt, and where incoming cables will not be walked on or pulled accidentally. 2.
- Page 4 Operating your system in a safe and legal manner When operating a motor vehicle, it should always be your highest priority to maintain safe driving habits. It is illegal in many areas of the country to drive with the TV or monitor turned on, when it is visible to the driver.
-
Page 5: Selecting The Input Mode
Powering up the system 1. Press and hole the POWER On/Off button on the remote until the green LED on the front of the monitor is illuminated. The On Screen Display will show the position of the system at the time it was last turned off (for example, if you were watching CATV Channel 38 when you last turned the power off, the system will display "CATV CH 38"). -
Page 6: Adjusting The Sound
Adjusting the sound The tuner system permits you to adjust many viewing parameters easily. These are: Audio Mute: Pressing the MUTE button will disable the audio output, and will display "MUTE" on the upper right corner of the monitor screen. To cancel the muting function, press MUTE again. -
Page 7: Specifications
Specifications 1. Signal system 2. Audio/Video Inputs 3. Audio/Video Outputs 4. FM Modulator 5. TV Channel NTSC Audio R/L x2, Video x 2 Audio R/L x2, Video x 1 20 Channels: FM 88.1 MHz to FM 91.9 MHz By channel step 0.2 MHz Channels 2~125...
