Cooper Lighting Luminous Triple Ring 293-S Specification Sheet

D E S C R I P T I O N
293-S Luminous Triple Ring features a soft "halo" of indirect
illumination.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Cold rolled steel mounting pan
and rings with a matte white
acrylic diffuser.
F i n i s h
Standard: Matte White (MW).
Premium: Polished Chrome (PC),
Satin Chrome (SC), Natural
Aluminum (NA) [Sustainable
Design], Satin Brass (SB),
Polished Brass (PB), Lacquered
Satin Aluminum (SAL), Polished
Copper (PCP), Satin Copper
(SCP), Oxidized Brass (OBRS),
Satin Nickel (SN), Polished Nickel
(PN), Lacqurered Satin Chrome
(SCL), Lacquered Satin Nickel
(SNL) or Custom Color (CC).
Note: For PC, PCP , PN and PB the
upper ring faces are satined to
reduce reflections of inner
hardware. The edges are
polished.
Custom Decorative Metals:
(Specify a Color & Pattern)
Colors - Clear (CLR), Cabernet
(CBT), Sapphire (SPE), Sage
(SGE), Brass (BRS), Copper
(CRP), Black Pearl (BPL), Slate
Green (SGN), Champagne (CMP),
Chocolate (CLE), Indigo (IDO),
O R D E R I N G I N F O R M AT I O N
Sample Number: 293-S-T5C/1/40-277V-PCP
Series Lamp
T5C/1/22
293-S Triple Ring =
Surface
T5C/1/40
Notes:
1
For polished finishes the bottom
inside edge of the ring is satin to
prevent upper ring reflections.
2
Supplied by others.
3
Interior applications only.
Royal Blue (RBE), or Pewter
(PWR). Patterns - Coral (COL),
Seashell (SHL) or Smooth (SMT).
Minimum quantity is 10 of one
color/pattern. Contact the factory
for lead-time.
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
L a m p / S o cke t
One (1) 22W or 40W T5 circular
fluorescent lamp. Socket
injection molded plastic. Lamps
furnished by others.
I n s t a l l a t i o n
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
O p t i o n s
Hand Painted Faux Alabaster
1
Voltage Finish
Standard
120V
MW Matte White =
277V
347V Premium
CC Custom Color =
NA Natural Aluminum
=
OBRS Oxidized Brass =
PB Polished Brass =
PC Polished Chrome =
PCP Polished Copper =
PN Polished Nickel =
=
SAL Lacquered
Satin Aluminum
SB Satin Brass =
SC Satin Chrome =
SCL Lacquered
=
Satin Chrome
SCP Satin Copper =
SN Satin Nickel =
SNL Lacquered =
Satin Nickel
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
Bowl (FB), Hand Painted Faux
Linen Bowl (LNB), Frosted Acrylic
Center Ring (ACR), Remote
Emergency Battery - Supplied by
others (REM), Damp Location
(DL): All Painted Finishes,
Lacquered Satin Chrome (SCL)
and Lacquered Satin Nickel (SNL)
finishes only. MRI Applications
(INC only) - Contact Factory.
Energy Star Rating- Contact
Factory. Dimming available with
55W T5 - Contact factory.
L a b e l s
U.L. and C.U.L. approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard surface
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Finish Options
(Custom Metals Only)
ACR Frosted Acrylic =
Colors
Center Ring
CLR Clear =
DL Damp Location =
CBT =Cabernet
FB Hand Painted Faux =
SPE =Sapphire
Alabaster Bowl
SGE =Sage
LNB Hand Painted =
BRS=Brass
Faux Linen Bowl
CPR=Copper
REM Remote =
BPL=Pearl Black Emergency
Battery
SGN =Slate Green
CMP =Champagne
CLE=Chocolate
IDO=Indigo
RBE=Royal Blue
PWR=Pewter
Pattern
COL=Coral
SHL=Seashell
SMT=Smooth
shaperlighting.com
293-S SERIES
S u r f a c e L u m i n a i r e
L u m i n o u s Tr i p l e
New Custom
Decorative Metals Finish
SUSTAINABLE
DESIGN
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
3
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
MAGNETIC
RESONANCE
IMAGING (MRI)
2
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
ENERGY
STAR
Shaper now offers a wide variety of
fixtures that can be provided with an
Energy Star Rating.
Refer to the Icon Legend
Link on shaperlighting.com.
Type
Date
R i n g B o w l
ADS042717
