- Page 1 MODULAR OUTDOOR KITCHEN BBQ1000101S BASE MODULE INCL. SCREW SET ASSEMBLY INSTRUCTIONS REV 1.0 Video guide 03/2023 ...
-
Page 2: Table Of Contents
BBQ1000101S BASE MODULE incl. screw set TABLE OF CONTENTS KEY POINTS FOR ASSEMBLY FOR YOUR SAFETY CARE AND MAINTENANCE IMPORTANT FOR THE FOUNDATION DESCRIPTION OF SYMBOLS SCOPE OF DELIVERY ASSEMBLY... -
Page 3: Key Points For Assembly
BBQ1000101S BASE MODULE incl. screw set KEY POINTS FOR ASSEMBLY These assembly instructions show the assembly of the outdoor barbecue kitchen. Read these assembly instructions carefully before commissioning! Failure to observe the risks, warnings and safety precautions set out in these assem- bly instructions may result in injuries or property damage. -
Page 4: Scope Of Delivery
BBQ1000101S BASE MODULE incl. screw set SCOPE OF DELIVERY BBQ2000102 base module – left side BBQ2000103 base module – right side BBQ2000101 base module – optional bottom BBQ2000240 bottom with cut out (for base module) BBQ1000700 panel, closed or other BBQ2000104 base module –... -
Page 5: Assembly
BBQ1000101S BASE MODULE incl. screw set ASSEMBLY ACCESSORIES – BBQ1100100A: Adjustable feet available in various heights 4 pcs. BBQ2000213 adjustable foot, 80 mm 1 pc. BBQ2000186 5 mm Allen key for adjustable feet 32 pcs. BBQ2000200 truss head screws M4x10 DIN 7380-1 A2 Tx 20 4 pcs. - Page 6 BBQ1000101S BASE MODULE incl. screw set Instead of a back panel, you can attach 2 closed Attach the right side panel to the underside of the front panels to the inside using 8 truss head base bottom with 4 truss head screws M4x10.
- Page 7 BBQ1000101S BASE MODULE incl. screw set Align the base module using the spirit level. To do this, turn the adjustable feet until the base module is level. DONE ...
- Page 8 BBQ1000101S BASE MODULE incl. screw set Connection of a base module to an attachment kit You can connect a base module to the barbecue attachment kit with 4 truss head screws.
- Page 9 BBQ1000101S BASE MODULE incl. screw set Connection of multiple base modules You can connect multiple base modules with 4 truss head screws and 4 M4 stainless steel nuts.
