Page 1 TABLE OF CONTENTS Information on the hybrid system and adjusting and op- Before driving erating features such as door locks, mirrors, and steer- ing column. When driving Driving, stopping and safe-driving information. Interior Air conditioning and audio systems, as well as other features interior features for a comfortable driving experience.
Page 2: Table Of Contents
TABLE OF CONTENTS Index 1-6. Refueling Before driving Opening the fuel tank cap........121 1-1. Hybrid system 1-7. Theft deterrent system Hybrid system ...... 30 Immobilizer system..... 126 Alarm ........130 1-2. Key information Theft prevention labels ..133 Keys ........42 1-8.
Page 3 2-2. Instrument cluster Interior features Gauges and meters .... 191 Indicators and warning lights ......... 193 3-1. Using the air Multi-information display ..197 conditioning system and defogger 2-3. Operating the lights and Front manual air wipers conditioning system..256 Headlight switch....
Page 4 TABLE OF CONTENTS Index 3-3. Using the rear audio system 3-5. Using the interior lights Rear seat entertainment Interior lights list....371 system features....311 • Personal/interior light main switch....... 372 Using the DVD player • Personal/interior lights ..372 (DVD video)......
Page 5: Maintenance And Care
Maintenance and care When trouble arises 4-1. Maintenance and care 5-1. Essential information Cleaning and protecting Emergency flashers.... 492 the vehicle exterior.... 414 If your vehicle needs to Cleaning and protecting be towed......493 the vehicle interior..... 417 If you think something is wrong......
Page 6 TABLE OF CONTENTS Index Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.) ... 540 Fuel information ....554 Tire information ....557 6-2. Customization Customizable features ..569 6-3. Initialization Items to initialize....572 For owners Reporting safety defects for U.S.
Page 8 Pictorial index Exterior Windshield wipers P. 212  Moon roof P. 118 Outside rear view mirrors P. 114 Headlights P. 207 Hood P. 430 Parking and side marker lights P. 207 Front turn signal lights P. 188  Fog lights P.
Page 9  Rear window defogger P. 277  Back door P. 78 Glass hatch P. 87 Side doors P. 74 Rear window wiper P. 214 License plate lights P. 207 Tires Tail and side marker ●Rotation P. 449 lights P. 207 ●Replacement P.
Page 10 Pictorial index Interior Console box P. 376 Front seats P. 89 Seat belts P. 104 Bottle holders P. 382 Head restraints P. 101 SRS driver airbag Power window switches P. 116 P. 136 Rear seats P. 92 SRS driver knee air- P.
Page 11 Cup holders P. 378 Cup holders P. 378 Shift lever P. 186 Shift lock override button P. 526 Power outlet P. 390 “ECON” switch P. 187 “EV” switch P. 184...
Page 12 Pictorial index Interior Inside door lock button P. 74 Window lock switch P. 116 Power window switches P. 116 Door lock switch P. 74...
Page 13 Vanity mirrors P. 388 Sun visors P. 387  Garage door opener switches P. 403  Moon roof switches P. 118 Personal/interior lights P. 372  Rear seat entertainment system P. 311  Interior light P. 373  Personal/interior lights P.
Page 14 Pictorial index Interior Air conditioning  system Cup holders P. 378 P. 271, 274 Console box P. 376...
Page 15 Auxiliary box P. 383 Side table P. 385 Cup holders P. 378  : If equipped...
Page 16 Pictorial index Instrument panel Power (ignition) switch P. 180 Rear view monitor system (vehicles without navigation Windshield wiper and system) P. 218 washer switch P. 212 Multi-information Rear window wiper and display P. 197 washer switch P. 214 Power back door Fog light switch P.
Page 17 Instrument panel light control dial P. 192  Windshield wiper de-icer Power back door switch  switch P. 279 P. 78  Outside rear view Power outlet main switch P. 390 mirror switches P. 114  : If equipped...
Page 18 Pictorial index Instrument panel Audio remote control switches P. 309  Climate remote control switches P. 280 “DISP” switch P. 197 Cruise control switch  Telephone switch P. 345 P. 215  Talk switch P. 345...
Page 19 Vehicles without navigation system Audio system P. 281 Security indicator P. 126, 130 Emergency flasher switch P. 492 Vehicles with navigation system Rear view monitor/navigation system Security indicator P. 126, 130 Emergency flasher switch P. 492  : If equipped : Refer to “Navigation System Owner's Manual”.
Page 20 Pictorial index Instrument panel Vehicles with a front manual air conditioning system Rear window and outside rear view mirror defogger  switch /rear window defogger switch P. 277 Air conditioning system P. 256 Vehicles with a front automatic air conditioning system Rear window and outside rear view mirror defogger Air conditioning ...
Page 21 Vehicles without seat heater AUX adapter P. 307 Power outlet P. 390 Auxiliary box P. 383 Vehicles with seat heater AUX adapter P. 307 Power outlet P. 390 Seat heater knobs P. 393  : If equipped...
Page 22 Pictorial index Luggage compartment  A/V input adapter P. 331  Power outlet P. 390 Power outlet P. 390  Luggage cover P. 399 Auxiliary box P. 397 Cargo hooks P. 397 Grocery bag hooks P. 397...
Page 23  Power back door switch P. 78 Back door strap P. 78  : If equipped...
Page 24 A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available on the market. You should know that these parts are not covered by Toyota warranty and that Toyota is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 25 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 26 In the event of that your vehicle must be disposed of, the hybrid battery must be disposed of your Toyota dealer or a qualified service shop. If the hybrid battery is not disposed of properly, they may cause electric shock that can result in death or serious injury.
Page 27 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 29: Before Driving
Before driving 1-1. Hybrid system 1-5. Opening and closing the windows and moon roof Hybrid system ....30 Power windows ....116 1-2. Key information Moon roof......118 Keys ........42 1-6. Refueling 1-3. Opening, closing and Opening the fuel tank cap .........
Page 30: Hybrid System
1-1. Hybrid system Hybrid system Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.
Page 31 30 minutes or 10 miles (16 km). If the hybrid battery becomes fully discharged and you are unable to jump-start the vehicle with the 12-volt battery, contact your Toyota dealer. ● If the shift lever is in N, the hybrid battery (traction battery) will not be charged.
Page 32 After the 12-volt battery has discharged or has been changed or removed The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Toyota dealer. ■...
Page 33 1-1. Hybrid system High voltage components Air conditioning compressor Service plug Power control unit and DC/ High voltage cables DC converter Front electric motor (traction Hybrid battery (traction bat- motor), transaxle and motor tery) generator Rear electric motor (traction Caution label motor) Take care when handling the hybrid system, as it contains a high volt- age system (about 650 V at maximum) as well as parts that become...
Page 34 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Energy monitor/consumption screen You can view the status of your hybrid system on the multi-infor- mation display (P.
Page 35 1-1. Hybrid system ■ Energy monitor ● How to display on the navigation system screen (if equipped): Press “INFO”. STEP Touch “Trip information” on the STEP Information screen. If the “Consumption” screen is displayed, touch ● How to display on the multi-information display: Press the “DISP”...
Page 36 1-1. Hybrid system Multi-information Navigation system screen display When the vehi- cle is powered by both the gas- oline engine and the electric motor (traction motor) When the vehi- cle is powered by the gasoline engine When the vehi- cle is charging the hybrid bat- tery (traction battery)
Page 37 1-1. Hybrid system ■ Consumption screen (navigation system only) Press “INFO”. STEP Touch “Trip information” on the STEP Information screen. If the “Energy Monitor” screen is displayed, touch Regenerated energy in the past 30 minutes One symbol indicates 50 Wh. Up to 4 symbols are shown.
Page 38 12-volt battery is disconnected The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. ■ When refueling, the fuel filler door may take a few moments to open As part of emission system operation, it may take up to 10 seconds for the fuel filler door to automatically release after the opener switch is pressed.
Page 39 1-1. Hybrid system ■ Hybrid battery (traction battery) The hybrid battery (traction battery) has a limited service life. The lifespan of the hybrid battery (traction battery) can change in accordance with driving style and driving conditions. CAUTION ■ High voltage precautions The vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem.
Page 40 1-1. Hybrid system CAUTION ■ Road accident cautions Observe the following precautions to reduce the risk of injury. ● Pull your vehicle off the road, put the shift lever in P, apply the parking brake, and turn the hybrid system is off. ●...
Page 41 1-1. Hybrid system NOTICE ■ Hybrid battery air vents ● Do not put foreign objects over the air vents. The hybrid battery (traction battery) may overheat and be damaged. ● Clean the air vents regularly to prevent the hybrid battery (traction battery) from overheating.
Page 42: Key Information
Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (P. 527)
Page 43 1-2. Key information ■ When riding in an aircraft When bringing a electronic key onto an aircraft, make sure you do not press any buttons on the electronic key while inside the aircraft cabin. If you are carrying a electronic key in your bag etc, ensure that the buttons are not likely to be pressed accidentally.
Page 44: Opening, Closing And Locking The Doors
1-3. Opening, closing and locking the doors Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Locks unlocks doors (P.
Page 45 1-3. Opening, closing and locking the doors Opens the glass hatch (P. 47) Locks unlocks doors (P. 45) Unlocking and locking the doors Front door handles Grip the handle to unlock the doors. Make sure to touch the sensor on the back of the handle.
Page 46 1-3. Opening, closing and locking the doors Press the lock button to lock the doors. Back door handle Press the button to unlock the door. The door cannot be unlocked for 3 seconds after the door is locked. Lock the back door again when you leave the vehicle.
Page 47 1-3. Opening, closing and locking the doors Opening the glass hatch (if equipped) Press and hold the button to open the glass hatch. The glass hatch will pop up. The glass hatch can be unlocked only when the back door is closed.
Page 48 1-3. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handles.
Page 49 1-3. Opening, closing and locking the doors ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from operating properly.
Page 50 1-3. Opening, closing and locking the doors The setting changes each time an operation is performed, as shown below. (When changing the setting continuously, release the buttons, wait for at least 5 seconds, and repeat step 2.) Multi-information Unlocking doors Beep display Hold the driver's door han-...
Page 51 1-3. Opening, closing and locking the doors ■ Electronic key battery depletion ● The standard battery life is 1 to 2 years. (The battery becomes depleted even if the electronic key is not used.) If the smart key system or the wireless remote control function does not operate, or the detection area becomes smaller, the battery may be depleted.
Page 52 1-3. Opening, closing and locking the doors ● The doors may unlock if a large amount of water splashes on the door handle, such as in the rain or in a car wash. (The doors will automatically be locked after approximately 60 seconds if the doors are not opened and closed.) ●...
Page 53 1-3. Opening, closing and locking the doors ● When an alarm sounds: Take appropriate measures according to the following table. Alarm Situation Correction procedure Tried to lock the doors and Retrieve the elec- the glass hatch using the tronic key from the entry function while the passenger compart- electronic key is still inside...
Page 54 1-3. Opening, closing and locking the doors Alarm Situation Correction procedure Tried to close the driver’s door after carrying the key Shift the shift lever to Interior and exte- outside the vehicle with the P, turn the “POWER” rior alarms sound “POWER”...
Page 55 1-3. Opening, closing and locking the doors ■ Customization that can be configured at Toyota dealer It is possible to deactivate the smart key system etc. (Customizable features P. 569) ■ Certification for the smart key system For vehicles sold in the U.S.A.
Page 56 1-3. Opening, closing and locking the doors...
Page 57 1-3. Opening, closing and locking the doors...
Page 58 1-3. Opening, closing and locking the doors...
Page 59 1-3. Opening, closing and locking the doors For vehicles sold in Canada NOTE: Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, includ- ing interference that may cause undesired operation of the device.
Page 60 1-3. Opening, closing and locking the doors...
Page 61 1-3. Opening, closing and locking the doors...
Page 62 1-3. Opening, closing and locking the doors...
Page 63 1-3. Opening, closing and locking the doors...
Page 64 (P. 47) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves. Then, consult your doctor to see if you should disable the entry function.
Page 65: Wireless Remote Control
1-3. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors.
Page 66 (P. 130) ■ Conditions affecting operation P. 49 ■ Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control) can be changed. (Customizable features P. 569) ■ Reversing the operation of the power back door Pressing the wireless remote control switch again while the power back door is operating will cause the operation to reverse.
Page 67 1-3. Opening, closing and locking the doors ■ Certification for wireless remote control For vehicles sold in the U.S.A. NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 68 1-3. Opening, closing and locking the doors...
Page 69 1-3. Opening, closing and locking the doors...
Page 70 1-3. Opening, closing and locking the doors For vehicles sold in Canada NOTE: Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, includ- ing interference that may cause undesired operation of the device.
Page 71 1-3. Opening, closing and locking the doors...
Page 72 1-3. Opening, closing and locking the doors...
Page 73 1-3. Opening, closing and locking the doors...
Page 74: Side Doors
1-3. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. ■ Entry function P. 44 ■ Wireless remote control P. 65 ■ Door lock switch Locks all doors Unlocks all doors ■...
Page 75 1-3. Opening, closing and locking the doors Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Page 76 ■ Using the mechanical key The doors can also be locked and unlocked with the mechanical key. (P. 528) ■ Customization that can be configured at Toyota dealer Settings (e.g. door unlocking function) can be changed. (Customizable features P. 569)
Page 77 1-3. Opening, closing and locking the doors CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
Page 78: Back Door
1-3. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following procedures. ■ Locking and unlocking the back door Door lock switch P. 74 Entry function P. 45 Wireless remote control P.
Page 79 1-3. Opening, closing and locking the doors ■ Opening the back door from inside the vehicle (vehicles with power back door) Push and hold the switch to open/close. Pressing switch again while the power back door is operating will cause the opera- tion to reverse.
Page 80 1-3. Opening, closing and locking the doors Canceling the power back door system (vehicles with power back door) Turn the main switch in the glove box off to disable the power back door system. The back door cannot be opened even with the wireless remote control power...
Page 81 1-3. Opening, closing and locking the doors ■ If the back door opener is inoperative The back door can be operated from the inside. Remove the cover. STEP Turn the lever. STEP ■ The power back door can be opened when ●...
Page 82 ■ Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control) can be changed. (Customizable features P. 569) CAUTION ■...
Page 83 1-3. Opening, closing and locking the doors CAUTION ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in seri- ous injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
Page 84 1-3. Opening, closing and locking the doors CAUTION ● Do not attach any accessories other than genuine Toyota parts to the back door. Such additional weight on the back door may cause the back door to fall closed again after it is opened.
Page 85 ● Do not attach any accessories other than genuine Toyota parts to the back door. The power back door may not operate, causing itself to malfunction, or the back door may fall closed again after it is opened.
Page 86 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the back door. ● Do not place your hand on the damper stay or apply lateral forces to it.
Page 87: Glass Hatch
1-3. Opening, closing and locking the doors  Glass hatch The glass hatch can be opened using the glass hatch opener. Press and hold the button to pop up the glass hatch. Raise glass hatch opened only when the back door is closed.
Page 88 1-3. Opening, closing and locking the doors CAUTION ■ Operating the glass hatch ● Do not open the glass hatch while the vehicle is moving. ● Do not open the glass hatch while the rear wiper is switched on. (If the rear wiper is switched on while the glass hatch is opening, the wiper motor drive disc is swinging at the door panel.) ●...
Page 89: Adjustable Components (Seats, Mirrors, Steering Wheel)
1-4. Adjustable components (seats, mirrors, steering wheel) Front seats Manual seat Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s side only) Seat cushion (front) angle adjustment knob (driver’s side only) Pull up the lever until the lock is completely released.
Page 90 1-4. Adjustable components (seats, mirrors, steering wheel) Power seat Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle adjustment switch (driver’s side only) Vertical height adjustment switch (driver’s side only) Driver’s seat leg support adjustment switch (if equipped) Seat lumbar support adjustment switch (driver’s side only) Active head restraints When the occupant’s lower back...
Page 91 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Active head restraints Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may appear the head restraint inner structure. These do not indicate problems. During rear-end collision...
Page 92: Rear Seats
1-4. Adjustable components (seats, mirrors, steering wheel) Rear seats ■ Second seats Seat position adjustment lever Seatback angle adjustment lever Pull up the lever until the lock is completely released.
Page 93 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Third seats (if equipped) The third seats do not have a seat adjustment function. Moving a second seat for third seats access (vehicles with third seats) ■ Getting in the vehicle (right side only) Pull up the lever and fold down the seatback.
Page 94 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Getting out of the vehicle (right side only) Lift the lever on the side of the seatback and fold down the seat- back. The seat will slide forward. Move the seat to the front-most position.
Page 95 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Folding down the second seats From inside Pull the lever to unlock the seat- back and then fold the seatback down. From outside (if equipped) Pull the lever. L: Left side and center second seats R:Right side second seat ■...
Page 96 1-4. Adjustable components (seats, mirrors, steering wheel) Folding down the third seats (vehicles with third seats) ■ Before folding down the third seats Stow the third seat belt buckles. STEP Pass the seat belts through the STEP seat belt hangers. This prevents the shoulder belt from being damage.
Page 97 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Folding down the third seats Pull the strap on the third seat- back fold-down lever toward you to fold down the seatback. Removing the second center seat ■ Before removing the second center seat Take out the side table from the STEP console box.
Page 98 1-4. Adjustable components (seats, mirrors, steering wheel) Pull the lock release lever to STEP remove the second center seat. Stow the second center seat in STEP the console box. STEP Make sure that the seat is securely locked in position and close the console box door.
Page 99 1-4. Adjustable components (seats, mirrors, steering wheel) Installing the second center seat ■ Before installing the second center seat Take out the second center seat STEP from the console box. STEP Remove the side table, if used, from the second seat. (P.
Page 100 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ When adjusting a rear seat or removing the second center seat ● Be careful that the seat does not hit passengers or luggage. ● Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt.
Page 101: Head Restraints
1-4. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. ■ Adjusting the head restraints Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pushing the lock release Lock release button button.
Page 102 1-4. Adjustable components (seats, mirrors, steering wheel) ■ When using the third seat head restraints (vehicles with third seats) To use To fold ■ Adjusting the height of the head restraints (except second center seat and third seats) Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
Page 103 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Installing the front and second seat outer head restraints Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint.
Page 104: Seat Belts
1-4. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 105 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the belt (front seats) Down Move the height adjuster up and down as needed until you hear a click. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to...
Page 106 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 107 1-4. Adjustable components (seats, mirrors, steering wheel) ■ When not using the rear seat belts Second seat belts Pass the outer seat belts through the seat belt hangers and secure the seat belt plates to prevent the shoulder belts from being damaged.
Page 108 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 109 ● Do not attempt to install, remove, modify, disassemble or dispose of the seat belts. Have any necessary repairs carried out by your Toyota dealer. Inappropriate handling of the pretensioner may prevent it from operating properly resulting in death or serious injury.
Page 110 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Using a seat belt extender ● Do not wear the seat belt extender if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of an accident.
Page 111: Steering Wheel
1-4. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. STEP Hold steering wheel and press the lever down. STEP Adjust to the ideal position by moving the steering wheel hori- zontally and vertically.
Page 112: Anti-Glare Inside Rear View Mirror
1-4. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light.
Page 113 1-4. Adjustable components (seats, mirrors, steering wheel) ■ To prevent sensor error (vehicles with auto anti-glare inside rear view mirror) To ensure that the sensors operate prop- erly, do not touch or cover them. CAUTION ■ Caution while driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, resulting in death or serious injury.
Page 114: Outside Rear View Mirrors
1-4. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch when the “POWER” switch is in ACCESSORY or ON mode. Select a mirror to adjust. STEP Left Right Adjust the mirror. STEP Right Down...
Page 115 1-4. Adjustable components (seats, mirrors, steering wheel) ■ When the mirrors are fogged up (vehicles with outside rear view mirror defoggers) Turn on the mirror defoggers to defog the mirrors. (P. 277) CAUTION ■ When driving the vehicle Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an acci- dent, resulting in death or serious injury.
Page 116: Opening And Closing The Windows And Moon Roof
1-5. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing (driver’s window only) Opening One-touch opening (driver’s window only) : Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 117 1-5. Opening and closing the windows and moon roof ■ The power windows can be operated when The “POWER” switch is in ON mode. ■ Operating the power windows after turning the hybrid system off (driver’s window only) The power windows can be operated for approximately 45 seconds even after the “POWER”...
Page 118: Moon Roof
1-5. Opening and closing the windows and moon roof  Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open The moon roof stops slightly before the fully opened posi- tion.
Page 119 1 second. Then it will tilt down, open and close. Check to make sure that the moon roof is completely closed and then release the switch. If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer.
Page 120 1-5. Opening and closing the windows and moon roof ■ Jam protection function If an object is detected between the moon roof and the frame while closing or tilting down, travel is stopped and the moon roof opens slightly. ■ To reduce wind noise Drive with the moon roof opened to slightly before the fully open position as driving with the moon roof opened fully will cause wind noise.
Page 121: Refueling Opening The Fuel Tank Cap
1-6. Refueling Opening the fuel tank cap The fuel tank of your vehicle has a special structure, which requires a reduction in fuel tank pressure before refueling. After the opener switch has been pressed, it will take several seconds until the vehi- cle is ready for refueling.
Page 122 1-6. Refueling Hang the fuel tank cap on the STEP back of the fuel filler door. Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. ■ Fuel types Use unleaded gasoline. (Octane rating 87 [Research Octane Number 91] or higher) ■...
Page 123 1-6. Refueling ■ If the fuel filler door opener is inoperable If the fuel filler door opener switch cannot be operated, contact your Toyota dealer. In the event that urgent refueling is required, follow the procedure below. Open the fuel filler door using the lever in STEP the luggage compartment.
Page 124 ■ When replacing the fuel cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury. ■...
Page 125 1-6. Refueling NOTICE ■ Refueling ● Finish refueling within 30 minutes. If more than 30 minutes passes, the internal valve closes. In this condition, fuel may spill out if you continue to refuel the vehicle. About 5 minutes after the valve is closed, a message “CLOSE FUEL LID”...
Page 126: Theft Deterrent System
1-7. Theft deterrent system Immobilizer system The vehicle's keys have built-in transponder chips that prevent the hybrid system from starting if the key has not been previously regis- tered in the vehicle's on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles without navigation system The indicator light flashes after the “POWER”...
Page 127 1-7. Theft deterrent system ■ Certifications for the immobilizer system ● For vehicles sold in the U.S.A. FCC ID: NI4TMIMB-1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 128 1-7. Theft deterrent system...
Page 129 1-7. Theft deterrent system NOTICE ■ To ensure the system correctly Do not modify and remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.
Page 130: Alarm
1-7. Theft deterrent system  Alarm The system sounds the alarm and flashes the lights when forcible entry is detected. ■ Triggering of the alarm The alarm is triggered in the following situations. ● A locked door is unlocked or opened in any way other than using the wireless remote control door lock function or entry function.
Page 131 1-7. Theft deterrent system ■ Setting the alarm system Vehicles without navigation system Close the doors and hood, and lock all doors using the wireless remote control door lock function or entry function. The system will be set auto- matically after 30 seconds. The indicator light changes from being on to flashing when the system is set.
Page 132 1-7. Theft deterrent system ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following. ● Nobody is in the vehicle. ● The windows and moon roof are closed before the alarm is set. ●...
Page 133: Theft Prevention Labels
1-7. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law.
Page 134: Safety Information
1-8. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (P. 89) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 135 1-8. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver's seat while driving. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 136: Srs Airbags
1-8. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 137 1-8. Safety information Airbag system components Curtain shield airbags SRS warning light Side airbags Driver airbag Front passenger airbag Driver’s seat position sen- Side and curtain shield air- bag sensors Driver’s seat belt buckle switch Front airbag sensors Driver knee airbag Front passenger’s seat belt buckle switch Airbag sensor assembly...
Page 138 1-8. Safety information The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. The airbag sensor assembly consists of a safing sensor and an airbag sensor. In certain types of severe frontal or side impacts, the SRS airbag sys- tem triggers the airbag inflators.
Page 139 1-8. Safety information ■ SRS airbag deployment conditions (front airbags) ● The front SRS airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to a 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 140 1-8. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
Page 141 1-8. Safety information ■ Types of collisions that may not deploy the SRS airbag (side airbags and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
Page 142 1-8. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Do not disconnect the 12-volt battery cables before contacting your Toyota dealer. ● Any of the SRS airbags have been inflated.
Page 143 1-8. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
Page 144 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are...
Page 145 1-8. Safety information CAUTION ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 146 Wash off any residue as soon as possible to prevent skin irritation. ● If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer.
Page 147 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 148: Front Passenger Occupant Classification System
1-8. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. Vehicles without navigation system Vehicles with navigation system SRS warning light...
Page 149 1-8. Safety information Conditions and operation of the front passenger occupant classification system ■ Adult* “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ SRS warning light warning light Front passenger's seat belt reminder Flashing* light Front passenger airbag Side airbag on the front passenger seat Devices...
Page 150 1-8. Safety information ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” Not illumi- indicator lights nated Indicator/ SRS warning light warning light Front passenger's seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Curtain shield airbag in the front Activated...
Page 151 1-8. Safety information : Never install a rear-facing child restraint system on the front pas- senger seat. A forward-facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (P. 155) : In case the indicator is not illuminated, consult this manual as for installing the child restraint system properly.
Page 152 1-8. Safety information CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger's seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 153 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 154: Child Restraint Systems
1-8. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 155 1-8. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Rear facing  Infant seat/convertible seat Forward facing  Convertible seat Booster seat...
Page 156 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 157 1-8. Safety information CAUTION ■ Child restraint precautions ● Do not use the seat belt extender when installing a child restraint system on the front or rear passenger seat. If installing a child restraint system with the seat belt extender connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or seri- ous injury to the child or other passengers in the event of a sudden stop, sudden swerve or accident.
Page 158: Installing Child Restraints
1-8. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 159 1-8. Safety information Second seat: Anchor brackets (for top tether strap) Anchor brackets are provided for the second seats.
Page 160 1-8. Safety information Installation with LATCH system Fold the seatback while pulling STEP the lever. Return the seatback and secure it at the 1st lock posi- tion (most upright position). Adjust the seatback to the 3rd lock position. (P. 92) 1st lock position 3rd lock position Type A...
Page 161 1-8. Safety information Type B Latch the buckles onto the STEP LATCH anchors. The bars are installed in the clearance between the seat cush- ion and seatback. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchors.
Page 162 1-8. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing Infant seat/convertible seat ■ Place the child seat on the rear STEP seat facing the rear of the vehi- cle. Run the seat belt through the STEP child seat and insert the plate into the buckle.
Page 163 1-8. Safety information While pushing the child seat STEP down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 164 1-8. Safety information While pushing the child seat into STEP the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 165 1-8. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap (second seat only) Secure the child restraint using STEP the seat belt or lower anchors, and adjust the head restraint to the upmost position.
Page 166 1-8. Safety information Outside seat: Open the anchor STEP bracket cover, latch the hook Front of vehicle onto the anchor bracket and tighten the top tether strap. Center seat: Latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched.
Page 167 1-8. Safety information CAUTION ■ When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode. (P. 106) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
Page 168 1-8. Safety information CAUTION ■ When installing a child restraint system ● When installing a child restraint system in the rear center seat, adjust both seat cushions to the same position and align seatbacks at the same angle. The seatbacks must be adjusted to the same angle. Otherwise, the child restraint system cannot be securely restrained and this may cause death or serious injuries in the event of sudden braking, sudden swerving or an accident.
Page 169: When Driving
When driving 2-1. Driving procedures 2-4. Using other driving systems Driving the vehicle.... 170 Cruise control....215 Power (ignition) switch ..180 Rear view monitor EV-Drive Mode....184 system ......218 Transmission....186 Driving assist systems ..222 Turn signal lever ....188 Hill-start assist control..
Page 170: Driving Procedures
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the hybrid system P. 180 ■ Driving STEP With the brake pedal depressed, shift the shift lever to D. (P. 186) STEP Release the parking brake.
Page 171 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodi- cally or whenever the parking brake shoes and/or drums are replaced. Have your Toyota dealer perform the bedding-down. ■ Operating your vehicle in a foreign country Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel.
Page 172 2-1. Driving procedures ■ For efficient use ● Put the shift lever into D when driving In the N position, the gasoline engine operates but electricity cannot be generated. The hybrid battery (traction battery) will be discharged requir- ing unnecessary engine power to recharge. ●...
Page 173 If they do not work well, depress the brake pedal firmly. If the brake system warning light comes on, immediately stop your vehicle and contact your Toyota dealer. In the following conditions, you may hear a sound in the engine compart- ment.
Page 174 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. ●...
Page 175 2-1. Driving procedures CAUTION ● Do not shift the shift lever to R while the vehicle is moving forward. Doing so can damage the transmission and may result in a loss of vehicle control. ● Do not shift the shift lever to D while the vehicle is moving backward. Doing so can damage the transmission and may result in a loss of vehicle control.
Page 176 2-1. Driving procedures CAUTION ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle, resulting in an accident. ● Sudden changes in braking force, such as engine braking and regenera- tive braking caused by shifting the shift lever to the B position, may cause the vehicle to skid, resulting in an accident.
Page 177 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 178 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage can result if the pads are not replaced when needed.
Page 179 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. ● Brake function ●...
Page 180: Power (Ignition) Switch
2-1. Driving procedures Power (ignition) switch ■ Starting the hybrid system Performing the following operations when carrying the electronic key on your person starts the hybrid system or changes “POWER” switch modes. STEP Check that the parking brake is set. STEP Check that the shift lever is set in P.
Page 181 2-1. Driving procedures ■ Changing “POWER” switch modes Modes can be changed by pressing the “POWER” switch with the brake pedal released. (The mode changes each time the switch is pressed.) OFF* The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
Page 182 ■ When the “POWER” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If the “READY” indicator does not come on If the “READY” indicator does not come on when you press the “POWER”...
Page 183 Do not leave the “POWER” switch in ACCESSORY or ON mode for long periods without the hybrid system on. ■ When starting the hybrid system ● Do not race a cold hybrid system. ● If the hybrid system becomes difficult to start, have the hybrid system checked immediately by your Toyota dealer.
Page 184: Ev-Drive Mode
2-1. Driving procedures EV-Drive Mode In EV-Drive Mode the electric motor (traction motor), powered by the hybrid battery (traction battery), is used to drive the vehicle. On/off When EV-Drive Mode is turned on, the EV-Drive Mode indica- tor will come on. Pressing the switch when in EV-Drive Mode will return to normal driving (using the gasoline engine and...
Page 185 2-1. Driving procedures ■ Automatic cancelation of EV-Drive Mode When driving in EV-Drive Mode, the gasoline engine may automatically restart in the following situations. When EV-Drive Mode is canceled, a buzzer will sound and the EV-Drive Mode indicator will flash and go off. ●...
Page 186: Transmission
2-1. Driving procedures Transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever While the “POWER” switch is in ON mode, depress the brake pedal and move the shift lever. ■ Shift position uses Shift position Function Parking the vehicle or starting the hybrid system Reversing...
Page 187 2-1. Driving procedures ■ Selecting Eco Driving Mode Use Eco Driving Mode to help achieve low fuel consumption driving trips that involve frequent accelerating and braking. On/off When Eco Driving Mode is turned on, the “ECON” indica- tor will come on. Press the switch once more to cancel the Eco Driving Mode.
Page 188: Turn Signal Lever
2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change. The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
Page 189: Parking Brake
2-1. Driving procedures Parking brake Sets the parking brake* (Depress pedal again U.S.A. Canada releases the parking brake.) *: Fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot. ■ Usage in winter time See “Winter driving tips”...
Page 190: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (P.
Page 191: Instrument Cluster Gauges And Meters
2-2. Instrument cluster Gauges and meters The following gauges and meters illuminate when the “POWER” switch is in ON mode. Power meter Displays the instantaneous output from the hybrid system in approxi- mate kilowatts. Engine coolant temperature gauge Displays the engine coolant temperature. Fuel gauge Displays the quantity of fuel remaining in the tank.
Page 192 2-2. Instrument cluster Odometer/Trip meter Odometer Displays the total distance the vehicle has been driven. Trip meter Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different distances independently.
Page 193: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster Center panel (vehicles without navigation system)
Page 194 2-2. Instrument cluster Center panel (vehicles with navigation system) ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Headlight indicator (P. 188) (P. 207) Headlight high beam Tail light indicator indicator (P.
Page 195 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer for details. ■ Warning lights Warning lights inform the driver of malfunctions in any of the vehicle’s systems.
Page 196 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 197: Multi-Information Display
2-2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data, including the current outside temperature and clock. ● Outside temperature Indicates the outside tempera- ture. The temperature range that can be displayed is from -40°F (-40°C) to 122°F (50°C).
Page 198 2-2. Instrument cluster ● Warning messages (P. 511) Automatically displayed when a malfunction occurs in one of the vehicle’s systems. Trip information Push the “DISP” button to dis- play trip information. Display items can be switched by pressing the “DISP” button. ■...
Page 199 2-2. Instrument cluster ■ Average fuel consumption Displays the average fuel consumption since the function was reset. This function can be reset by pressing the “DISP” button for longer than one second when the average fuel consumption is displayed. ■ Driving distance Displays the driving distance since the hybrid system was started.
Page 200 2-2. Instrument cluster Setting up the displays Display the set up screen on the STEP multi-information display when the vehicle is stopped. Press and hold the “DISP” button to display the set up screen. Select the desired item on the STEP menu screen.
Page 201 2-2. Instrument cluster Press the “DISP” button to adjust STEP the minutes. After adjusting the minutes, wait 5 seconds to allow the minutes to be automatically input. ■ Setting the display STEP Select “DISPLAY” on the menu screen. Press and hold the “DISP”...
Page 202 2-2. Instrument cluster ● Setting the brightness STEP Select “BRIGHTNESS” on the menu screen. Press and hold the “DISP” button until the display changes. Press the “DISP” button to adjust STEP the brightness. +: Brighter -: Darker After adjusting the brightness, wait 5 seconds to allow the bright- ness to be automatically input.
Page 203 2-2. Instrument cluster ■ Setting the tire inflation pressure information display It is possible to set the tire inflation pressure information display so that it is displayed when the hybrid system is first turned on. STEP Select “TIRE MONITOR INFO.” on the menu screen. Press and hold the “DISP”...
Page 204 2-2. Instrument cluster Setting up the rear view monitor display Display the set up screen on the STEP multi-information display when the vehicle is stopped and the rear view monitor is turned on. Press and hold the “DISP” button to display the set up screen. Select the desired item on the STEP menu screen.
Page 205 2-2. Instrument cluster ■ Setting the contrast STEP Select “CONTRAST” on the menu screen. Press and hold the “DISP” button until the display changes. Press the “DISP” button to adjust STEP the contrast. +: Strengthen -: Weaken After adjusting the contrast, wait 5 seconds to allow the contrast to be automatically input.
Page 206 When stopped, or driving at low speeds (less than 12 mph [20 km/h]), the correct outside temperature may not be displayed, or the display may take longer than normal to change. ■ Customization that can be configured at Toyota dealer Setting of language selection can be changed. (Customizable features P. 569) NOTICE ■...
Page 207: Operating The Lights And Wipers
2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Type A The side marker, park- ing, tail, license plate and instrument panel lights turn on. The headlights and all lights listed above turn U.S.A.
Page 208 2-3. Operating the lights and wipers Type B The side marker, park- ing, tail, license plate and instrument panel lights turn on. The headlights and all lights listed above turn The headlights and parking lights turn on and off automatically. (When the “POWER”...
Page 209 2-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off. Pull the lever toward you to turn on the high beams.
Page 210 To turn the lights on again, change the “POWER” switch to ON mode, or turn the headlight switch off and then back to ■ Customization that can be configured at Toyota dealer Settings (e.g. daytime running light system) can be changed. (Customizable features P. 569) NOTICE ■...
Page 211: Fog Light Switch
2-3. Operating the lights and wipers  Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on in low beam. Front fog lights on ...
Page 212: Windshield Wipers And Washer
2-3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation. Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency...
Page 213 2-3. Operating the lights and wipers Wash/wipe operation Wipers operate automatically. ■ The windshield wipers and washer can be operated when The “POWER” switch is in ON mode. ■ If no windshield washer fluid sprays Check that the washer nozzles are not blocked and if there is washer fluid in the windshield washer fluid reservoir.
Page 214: Rear Window Wiper And Washer
2-3. Operating the lights and wipers Rear window wiper and washer Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion ■ The rear window wiper and washer can be operated when The “POWER” switch is in ON mode. NOTICE ■...
Page 215: Using Other Driving Systems
2-4. Using other driving systems Cruise control Use cruise control to maintain a set speed without using the acceler- ator. Indicator Cruise control switch ■ Set the vehicle speed STEP Turn the “ON-OFF” button on. Press the button once more to deactivate the cruise control.
Page 216 2-4. Using other driving systems ■ Adjusting the speed setting Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed can be made by lightly pushing the lever up or down and releasing it.
Page 217 Turn the “ON-OFF” button off once, and then reactivate the system. If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Contact your Toyota dealer and have your Toyota inspected. CAUTION ■...
Page 218: Rear View Monitor System
2-4. Using other driving systems Rear view monitor system Vehicles with navigation system Refer to the “Navigation System Owner's Manual”. Vehicles without navigation system The rear view monitor system assists the driver by displaying an image of the area behind the vehicle. The image is displayed in reverse on the screen.
Page 219 2-4. Using other driving systems ■ Displayed area The area covered by the camera is lim- ited. Objects that are close to either corner of the bumper or under the bumper cannot be seen on the screen. The area displayed on the screen may vary according to vehicle orientation or road conditions.
Page 220 2-4. Using other driving systems ■ Smear effect If a bright light, such as sunlight reflected off the vehicle body, is picked up by the camera, a smear effect* char- acteristic to the camera may occur. *: Smear effect A phenomenon that occurs when a bright light is picked up by the camera;...
Page 221 Conditions which may affect the rear view monitor system ● If the back of the vehicle has been hit, the camera’s position and mounting angle may have changed. Have the vehicle inspected by your Toyota dealer. ● Rapid temperature changes, such as when hot water is poured on the vehicle in cold weather, may cause the system to function abnormally.
Page 222: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 223 2-4. Using other driving systems When the VSC/TRAC systems are operating If the vehicle is in danger of slip- ping, rolling backwards when starting on an incline, or the four wheels spin, the indicator flashes to indicate that the VSC/TRAC systems have been engaged.
Page 224 2-4. Using other driving systems ■ Reduced effectiveness of EPS The effectiveness of EPS is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time. The steering wheel may feel heavy as a result. Should this occur, refrain from excessive steering input or stop the vehicle and turn the hybrid off.
Page 225 The ABS and VSC systems will not function correctly if different tires are fit- ted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the VDIM, and may cause the system to malfunction.
Page 226: Hill-Start Assist Control
2-4. Using other driving systems Hill-start assist control Hill-start assist control helps to prevent the vehicle from rolling backwards when starting on incline or slippery slope. To engage hill-start assist con- trol, further depress the brake pedal when the vehicle is stopped completely.
Page 227 2-4. Using other driving systems ■ Hill-start assist control buzzer ● When hill-start assist control is activated, the buzzer will sound once. ● In the following situations, hill-start assist control will be canceled and the buzzer will sound. • No attempt is made to drive the vehicle within approximately 2 seconds of releasing the brake pedal.
Page 228: Driving Information
2-5. Driving information Utility vehicle precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity. Utility vehicle feature ● Specific design characteristics give it a higher center of gravity than ordinary passenger cars.
Page 229 2-5. Driving information CAUTION ■ Utility vehicle precautions Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 230 2-5. Driving information Off-road driving Your vehicle is not designed to be driven off-road. However, in the event that off-road driving cannot be avoided, please observe the fol- lowing precautions to help avoid the areas prohibited to vehicles. ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 231 2-5. Driving information CAUTION ■ Off-road driving precautions Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
Page 232 2-5. Driving information NOTICE ■ To prevent the water damage Take all necessary safety measures to ensure that water damage to the hybrid battery, hybrid system or other components does not occur. ● Water entering the engine compartment may cause severe damage to the hybrid system.
Page 233: Cargo And Luggage
2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the luggage compartment whenever possible. Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
Page 234 2-5. Driving information (6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Example on your vehicle Cargo capacity Total load capacity...
Page 235 2-5. Driving information CAUTION ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compart- ment. ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions ● Do not place cargo or luggage in or on the following locations as the item may get under the brake or accelerator pedal and prevent the pedals from being depressed properly, block the driver’s vision, or hit...
Page 236 Roof luggage carrier precautions To use the roof rails as a roof luggage carrier, you must fit the roof rails with two or more genuine Toyota cross rails or their equivalent. When you load cargo on the roof luggage carrier, observe the following: ●...
Page 237: Vehicle Load Limits
2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. ■ Total load capacity: 1200 lb. (544 kg) Total load capacity means the combined weight of occupants, cargo and luggage. ■...
Page 238: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 239 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. ■ When parking the vehicle Park the vehicle and move the shift lever to P without setting the parking brake.
Page 240 2-5. Driving information ■ Tire chains Observe the following precautions when installing and removing chains. ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires. ● Install tire chains following the instructions provided in the accompanying manual.
Page 241 NOTICE ■ Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 242: Trailer Towing
The vehicle stability and braking performance are affected by trailer stability, brake setting and performance, and the hitch. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional...
Page 243 2-5. Driving information Weight limits Confirm that the gross trailer weight, gross vehicle weight, gross axle weight and trailer tongue load are all within the limits. Towing capacity: 3500 lb. (1500 kg) ● The gross trailer weight must never exceed towing capacity described in the table above.
Page 244 2-5. Driving information Towing related term Towing related term Meaning The maximum allowable gross vehicle weight. The gross vehicle weight is the total weight of the vehicle. When towing GVWR (Gross Vehicle a trailer, it is the sum of the vehicle Weight Rating) weight (including the occupants, cargo and any optional equipment installed on...
Page 245 2-5. Driving information Trailer tongue load ● A recommended tongue load varies in accordance with the types of trailers or towing as described below. ● In order to ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. The trailer cargo load should be distributed so that the tongue load is 9 to 11% of the gross trailer weight, not exceeding 350 lb.
Page 246 2-5. Driving information Hitch Trailer hitch assemblies have different weight capacities established by the hitch manufacturer. Even though the vehicle may be rated for towing a higher weight, the operator must never exceed the maxi- mum weight rating specified for the trailer hitch. Trailer towing tips Your vehicle will handle differently when towing a trailer.
Page 247 2-5. Driving information ● Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a larger than normal turning radius. ● Crosswinds and rough roads will adversely affect handling of your vehicle and trailer, causing sway.
Page 248 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential and wheel bearing), Toyota recommends that you do not tow a trailer until it has been driven for over 500 miles (800 km).
Page 249 2-5. Driving information ■ Maintenance ● If you tow a trailer, your vehicle will require more frequent maintenance due to the additional load. (See “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”.) ● Retighten the fixing bolts of the towing ball and bracket after approxi- mately 600 miles (1000 km) of trailer towing.
Page 250 CAUTION ■ Hitches ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight requirement. ● The towing capacity of 3500 lb. (1500 kg) can only be guaranteed when using a genuine Toyota hitch assembly or equivalent.
Page 251 ■ When installing a trailer hitch ● Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper as this may cause body damage. ● Do not use axle-mounted hitches, as they can cause damage to the axle housing, wheel bearings, wheels or tires.
Page 252: Dinghy Towing
2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with 4 wheels on the ground.
Page 253 2-5. Driving information...
Page 254: Interior Features
Interior features 3-1. Using the air Using the CD player..290 conditioning system Playing back MP3 and and defogger WMA discs ..... 297 Optimal use of the audio Front manual air system ......304 conditioning system ..256 Using the AUX Front automatic air adapter......
Page 255 Interior features 3-4. Using the hands-free 3-6. Using the storage features phone system List of storage features ..374 (for cellular phone) • Glove box....... 375 • Console box ....376 Hands-free phone system • Overhead console..377 (for cellular phone) •...
Page 256: Front Manual Air Conditioning System
3-1. Using the air conditioning system and defogger  Front manual air conditioning system Temperature control dial Fan speed control dial Outside air or recirculated air mode Air outlet selection dial Rear air conditioning Air conditioning on/off switch on/off switch (if equipped) Adjusting the settings ■...
Page 257 3-1. Using the air conditioning system and defogger ■ Adjusting the fan speed Turn the fan speed control dial clockwise (increase) or counter- clockwise (decrease). Turn the dial to “OFF” to turn the fan off. ■ Changing the air outlets Set the air outlet selection dial to an appropriate position.
Page 258 3-1. Using the air conditioning system and defogger Feet : Vehicles without rear air conditioning system Without rear air conditioning system Feet and windshield With rear air conditioning system Feet and windshield...
Page 259 3-1. Using the air conditioning system and defogger ■ Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recircu- lated air mode (indicator on) modes each time is pressed. Defogging the windshield Set the air outlet selection dial to position.
Page 260 3-1. Using the air conditioning system and defogger Front side outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Rear center outlets (vehicles without rear air conditioning system) Direct air flow to the left or right, up or down.
Page 261 3-1. Using the air conditioning system and defogger ■ When is selected for the air outlets used For your driving comfort, air flowing to the feet may be warmer than air flow- ing to the upper body depending on the position of the temperature adjust- ment dial.
Page 262: Front Automatic Air Conditioning System
3-1. Using the air conditioning system and defogger  Front automatic air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Control panel Rear air conditioning Temperature control on/off switch for rear passengers Fan speed Windshield defogger Outside air or recirculated...
Page 263 3-1. Using the air conditioning system and defogger Multi-information display Airflow display Fan speed display Driver’s side Front passenger’s side tem- temperature Temperature setting dis- perature setting display setting dis- play for rear passengers play...
Page 264 3-1. Using the air conditioning system and defogger Using the automatic mode STEP Press The air conditioning system begins to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting. “AUTO” will be displayed on the multi-information display. STEP Turn the temperature control dial clockwise (warm) or coun- terclockwise (cool).
Page 265 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool). The air conditioning system switches between individual and simultaneous modes each time (without rear air conditioning system) or (with rear air conditioning system) is pressed.
Page 266 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Press The air outlets switch each time either side of is pressed. The air flow shown on the display indicates the following. Upper body : Vehicles without rear air conditioning system Upper body and feet : Vehicles without rear air conditioning system Feet...
Page 267 3-1. Using the air conditioning system and defogger Without rear air conditioning system Feet and windshield With rear air conditioning system Feet and windshield ■ Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recircu- lated air mode (indicator on) modes each time is pressed.
Page 268 3-1. Using the air conditioning system and defogger Defogging the windshield Press The air conditioning system oper- ates automatically. Adjusting the position of and opening and closing the air outlets Front center outlets Direct air flow to the left or right, up or down.
Page 269 3-1. Using the air conditioning system and defogger Rear center outlets (vehicles without rear air conditioning system) Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Air outlets of the rear seat. (P. 276) ■...
Page 270 3-1. Using the air conditioning system and defogger ■ Air conditioning odors ● During use, various odors from inside and outside the vehicle may enter into and accumulate in the air conditioning system. This may then cause odor to be emitted from the vents. ●...
Page 271: Rear Manual Air Conditioning System
3-1. Using the air conditioning system and defogger  Rear manual air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Changes the air outlets used Fan speed control dial Temperature control dial  : If equipped...
Page 272 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool). ■ Changing the air outlets Press the desired Air flows as shown below according to the mode selected. Upper body Upper body and feet...
Page 273 3-1. Using the air conditioning system and defogger Feet ■ Adjusting the fan speed Turn the fan speed control dial clockwise (increase) or counter- clockwise (decrease). Adjusting the position of and opening and closing the air outlets Direct air flow to the left or right, up or down.
Page 274: Rear Automatic Air Conditioning System
3-1. Using the air conditioning system and defogger  Rear automatic air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Fan speed display Airflow display Temperature setting display Temperature Fan speed control dial control dial Changes the air Automatic mode outlets used...
Page 275 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool). ■ Changing the air outlets Press The air outlets change as follows each time is pressed.
Page 276 3-1. Using the air conditioning system and defogger Feet ■ Adjusting the fan speed Turn the fan speed control dial clockwise (increase) or counter- clockwise (decrease). Press to turn the fan off. Adjusting the position of and opening and closing the roof side air outlets Direct air flow to the left or right, up or down.
Page 277: Rear Window And Outside Rear View Mirror Defoggers
3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers Clear the rear window using the defogger. Vehicles with manual air conditioning system On/off Press the button to turn on the rear window defogger. The indicator light will come on.
Page 278 3-1. Using the air conditioning system and defogger ■ The defogger can be operated when The “POWER” switch is in ON mode. ■ Outside rear view mirror defoggers (vehicles with outside rear view mirror defoggers) Turning the rear window defogger on will turn the outside rear view mirror defoggers on.
Page 279: Windshield Wiper De-Icer
3-1. Using the air conditioning system and defogger  Windshield wiper de-icer This feature is used to prevent ice from building up on the wind- shield and wiper blades. On/off Press the button to turn on the windshield wiper de-icer. The indicator light will come on.
Page 280: Using The Steering Wheel Climate Remote Control Switches
3-1. Using the air conditioning system and defogger  Using the steering wheel climate remote control switches Some air conditioning features can be controlled using the switches on the steering wheel. Temperature control Automatic mode Using the automatic mode STEP Press The air conditioning system will operate, and air outlets and fan speed will be set automatically.
Page 281: Using The Audio System
3-2. Using the audio system Audio system (without navigation system) With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”. Without navigation system Type A: CD player and AM/FM radio (with CD changer controller) Type B: CD player with changer and AM/FM radio...
Page 282 3-2. Using the audio system Type C: CD player with changer and AM/FM radio Title Page Using the radio P. 284 Using the CD player P. 290 Playing back MP3 and WMA discs P. 297 Optimal use of the audio system P.
Page 283 3-2. Using the audio system CAUTION ■ For vehicles sold in U.S.A. and Canada ● Part 15 of the FCC Rules FCC Warning: Any unauthorized changes or modifications to this equipment will void the user’s authority to operate this device. ●...
Page 284: Using The Radio
3-2. Using the audio system Using the radio Power Volume Scanning for receivable stations Station selector Adjusting the frequency (AM, FM mode) or Seeking the · AM/AM SAT*/FM channel frequency mode buttons (SAT mode) *: Type B and C Changing the program type ®...
Page 285 3-2. Using the audio system ■ Scanning all radio stations within range STEP Press All stations with reception will be played for 5 seconds each. STEP When the desired station is reached, press once again. ® Satellite Radio (type B and C) ®...
Page 286 3-2. Using the audio system ● Scanning preset channels STEP Press and hold until you hear a beep. STEP When the desired channel is reached, press again. ■ Displaying text information Press The display will show up to 10 characters. The display changes as follows each time is pressed.
Page 287 3-2. Using the audio system ■ When the 12-volt battery is disconnected Stations presets are erased. ■ Reception sensitivity ● Cargo loaded on the roof luggage carrier, especially metal objects, may ® adversely affect the reception of XM Satellite Radio (type B and C). ●...
Page 288 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to the XM Satellite Radio. The radio is being updated with the latest ®...
Page 289 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel. ® Contact the XM Listener Care Center at 1-800-967-2346 (U.S.A.) or 1-877- 438-9677 (Canada).
Page 290: Using The Cd Player
3-2. Using the audio system Using the CD player Power Volume CD eject Reverse Displaying text message Search playback Fast-forward CD insert CD slot (type B and C) Playback CD selection (with a CD changer) Repeat play Random playback Track selection Loading CDs ■...
Page 291 3-2. Using the audio system ■ Loading multiple CDs (type B and C) STEP Press and hold until you hear a beep. “WAIT” is shown on the display. STEP Insert a CD when the indicator on the slot turns from amber to green.
Page 292 3-2. Using the audio system Fast-forwarding and reversing tracks  To fast-forward or reverse, press and hold “ ” or “” on Scanning tracks STEP Press The first ten seconds of each track will be played. STEP Press again when the desired track is reached. Selecting a CD (with a CD changer) ■...
Page 293 3-2. Using the audio system Random playback ■ Current CD Press (RAND). Tracks are played in a random order until is pressed once more. ■ All CDs (with a CD changer) Press and hold until you hear a beep. Tracks on all loaded CDs are played in a random order until pressed once more.
Page 294 3-2. Using the audio system ■ Display Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding for 1 second or more will display the remaining characters. A maximum of 24 characters can be displayed. is pressed for 1 second or more again or has not been pressed for 6 seconds or more, the display will return to the first 12 characters.
Page 295 3-2. Using the audio system NOTICE ■ CDs and adapters that cannot be used Do not use the following types of CDs, 3 in. (8 cm) CD adapters or Dual Disc. Doing so may damage the CD player and/or the CD insert/eject function. ●...
Page 296 3-2. Using the audio system NOTICE ■ CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself. ● Do not insert anything other than CDs into the CD slot. ●...
Page 297: Playing Back Mp3 And Wma Discs
3-2. Using the audio system Playing back MP3 and WMA discs Power Volume Fast-forward CD eject Reverse Displaying text message Search playback CD insert CD slot (type B and C) File selection Playback CD selection (with a CD changer) Folder selection Repeat play File selection Random playback...
Page 298 3-2. Using the audio system Selecting and scanning a folder ■ Selecting folders one at a time Press “” or “” on to select the desired folder. ■ Selecting the desired folder by cueing the first file of each folder Press and hold until you hear a beep.
Page 299 3-2. Using the audio system Repeat play ■ To repeat a file Press (RPT). ■ To repeat all of the files on a folder Press and hold (RPT) until you hear a beep. Random playback ■ To play files from a particular folder in random order Press (RAND).
Page 300 3-2. Using the audio system ■ Display P. 294 ■ Canceling random and repeat playback P. 294 ■ Error messages “ERROR”: This indicates a trouble either in the CD or inside the player. The CD may be dirty, damaged or inserted up-side down. “NO MUSIC”: This indicates that the MP3/WMA file is not included in the ■...
Page 301 3-2. Using the audio system ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 302 3-2. Using the audio system ● Compatible disc formats The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
Page 303 3-2. Using the audio system ● Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
Page 304: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Displays the current mode Changes the following set- ting ● Sound quality and vol- ume balance (P. 305) The sound quality and bal- ance setting changed to produce the best sound.
Page 305 3-2. Using the audio system Using the audio control function ■ Changing sound quality modes Pressing selects the mode to be changed in the following order. “TRE”“FAD”“BAL”“ASL”“RSE”* “BAS”“MID”* : Type C only : Vehicles with rear seat entertainment system ■ Adjusting sound quality Turning adjusts the level.
Page 306 3-2. Using the audio system ■ Adjusting the Automatic Sound Levelizer (ASL) Type A and B When “ASL” is selected, turning to the right changes the amount of “ASL” in the order of “LOW”, “MID” and “HIGH”. Turning to the left turns “ASL” off. ASL automatically adjusts the volume and tone quality according to vehi- cle speed.
Page 307: Using The Aux Adapter
3-2. Using the audio system Using the AUX adapter This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. STEP Open the cover and connect the portable audio device. Vehicles without seat heater Vehicles with seat heater Press STEP...
Page 308 3-2. Using the audio system ■ Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle's audio controls. All other adjustments must be made on the portable audio device itself. ■ When using a portable audio device connected to the power outlet Noise may occur during playback.
Page 309: Using The Steering Wheel Audio Switches
3-2. Using the audio system Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Volume Radio: Selects radio sta- tions CD: Selects tracks, files (MP3 and WMA) and discs Turns the power on, selects audio source Turning on the power Press...
Page 310 3-2. Using the audio system Adjusting the volume Press “+” on to increase the volume and “-” to decrease the volume. Press and hold the switch to continue increasing or decreasing the vol- ume. Selecting a radio station STEP Press to select radio mode.
Page 311: Using The Rear Audio System
3-3. Using the rear audio system  Rear seat entertainment system features The rear seat entertainment system is designed for the rear passen- gers to enjoy audio and DVD video separately from the front audio system. Front audio system Power outlet main switch Display Headphone volume control dials and headphone jacks DVD player...
Page 312 3-3. Using the rear audio system Opening and closing the display Press the lock release button to open the display. Pull the display down to an easily viewable angle (between 90 and 125). To close the display, push the display up until a click is heard. The illumination of the screen is automatically turned off when the display is closed.
Page 313 3-3. Using the rear audio system Ejecting a disc Press and remove the disc. Headphone jacks To use the headphones, con- nect them to the jack. To adjust the volume Right side dial: Turn it toward the front of the vehicle to increase the volume.
Page 314 REGION ERROR: Indicates that the DVD region code is not set properly. DVD ERROR: Indicates that there is a problem inside the player. Eject the disc. Set the disc again. If the malfunction still exists, take the vehicle to your Toyota dealer.
Page 315 When using 3 AA batteries Batteries can be purchased at your Toyota dealer, electric appliance shop, or camera stores. Replace only with the same or equivalent type recommended by a Toyota dealer. Dispose of used batteries according to the local laws.
Page 316 3-3. Using the rear audio system ■ Headphones With some headphones generally available in the market, it may be difficult to catch signals properly. Toyota recommends the use of Toyota genuine wireless headphones. Please contact your Toyota dealer for further details. ■...
Page 317 3-3. Using the rear audio system NOTICE ■ For normal operation after replacing the battery Observe the following precautions to prevent accidents. ● Always work with dry hands. Moisture may cause the battery to rust. ● Do not touch or move any other components inside the remote control. ●...
Page 318: Using The Dvd Player (Dvd Video)
3-3. Using the rear audio system Using the DVD player (DVD video) ■ Remote controller Turning on the DVD mode Selecting a chapter Reversing a disc Turning on the menu screen Turning on the title selection screen Searching the title Changing the screen angle Inputting selected...
Page 319 3-3. Using the rear audio system ■ Display (page 1) Turning off the operation switches (icon) on the dis- play Displaying page 2 Turning on or off the title selection screen for the disc Turning on or off the menu screen for the disc Reversing a disc Stopping a disc...
Page 320 3-3. Using the rear audio system Turning on or off the operation switches Press to turn on the operation switches. Press once again or select to turn off the opera- tion switches. Turning on the title selection screen Press or select to turn on the title selection screen.
Page 321 3-3. Using the rear audio system Changing the subtitle language Press or select display the subtitle language screen. Each time is pressed or is selected, another lan- guage stored on the disc is selected. Select to return to the pre- vious screen.
Page 322 3-3. Using the rear audio system Changing the angle Press or select display the screen to change the angle. Each time is pressed or is selected, the angle changes. Select to return to the pre- vious screen. ■ DVD player and DVD video discs This DVD player is compatible NTSC color TV formats.
Page 323 3-3. Using the rear audio system ■ Marks shown on DVD video discs Indicates NTSC format of color TV. Indicates the number of audio tracks. Indicates the number of language subtitles. Indicates the number of angles. Indicates the screen to be selected. Wide screen: 16:9 Standard: 4:3 Indicates regions in which this video disc can...
Page 324 3-3. Using the rear audio system ■ DVD video disc glossary ● DVD video discs: Digital Versatile Discs that holds world’s standard video. DVD video discs have adopted “MPEG2”, one of the world stan- dards of digital compression technologies. The picture data is com- pressed by 1/40 on average and stored.
Page 325 3-3. Using the rear audio system ■ Audio  Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”,  are trademarks of Dolby Laboratories. Confidential unpublished works.  1992-1997 Dolby Laboratories. All rights reserved. “dts” is a trademark of Digital Theater Systems, Inc. NOTICE ■...
Page 326: Using The Dvd Player (Video Cd)
3-3. Using the rear audio system Using the DVD player (video CD) ■ Remote controller Selecting a switch (icon) Selecting a chapter Playing/pausing a disc Reversing a disc Displaying operation switches (icon) Inputting selected switch (icon) Fast forwarding a disc Stopping a disc Changing the initial setting ■...
Page 327 3-3. Using the rear audio system ■ Display (page 1) Selecting a disc menu num- Turning off the menu screen Displaying page 2 Turning on the disc menu Returning to the previous page screen (with the disc menu displayed) Proceeding to the next page screen (with the disc menu displayed) Changing to a multiplex...
Page 328: Using The Dvd Player (Audio Cd/Cd Text)
3-3. Using the rear audio system Using the DVD player (audio CD/CD text) Using control screen, press to display the control screen. Repeat play Random playback Search playback ■ Canceling random, repeat and scan play Select again.
Page 329: Using The Dvd Player (Mp3 Discs)
3-3. Using the rear audio system Using the DVD player (MP3 discs) ■ Using the control screen Press to dis- play the control screen. Repeat play Random playback Search playback Displaying file information Selecting a folder Repeat play ■ Repeat a file Select ■...
Page 330 3-3. Using the rear audio system ■ Selecting the desired file by cueing the folders on the disc Select , and press and hold the remote controller. The player will scan all the folders on the disc. The first file in each folder will be played for 10 seconds.
Page 331: Using The Video Mode
3-3. Using the rear audio system Using the video mode Press to select the video mode. Before switching to the video mode, connect audio source input adapter. Using the adapter Open the cover. The A/V input adapter is com- posed of 3 input adapters. Yellow: Image input adapter White: Left channel audio input adapter...
Page 332 3-3. Using the rear audio system NOTICE ■ When the A/V input adapter is not in use Keep the A/V input adapter cover closed. Inserting anything other than an appropriate plug may cause electrical fail- ure or short circuit.
Page 333: Changing The Initial Setting
3-3. Using the rear audio system Changing the initial setting Press or select display initial setting screen. The following initialization can be changed here. ● Audio language ● Subtitle language ● DVD language ● Angle mark ● Parental lock Changing the audio language Select “Audio Language”.
Page 334 3-3. Using the rear audio system Changing the subtitle language Select “Subtitle Language”. Select the language you want to read, and press to input it. Select “Others” if you cannot find the language you want to read. Enter the appropriate 4-digit lan- guage code.
Page 335 3-3. Using the rear audio system Changing the DVD language Select “DVD Language”. Select the language you want to read and press to input it. Select “Others” if you cannot find the language you want to read. Enter the appropriate 4-digit lan- guage code.
Page 336 3-3. Using the rear audio system Setting viewer restriction levels Setting a password allows the viewer restriction to be effective. Select “Parental Lock”. Enter the password and press The setting cannot be changed unless the password is entered. When you forget the password, initialize the password.
Page 337 3-3. Using the rear audio system ■ Returning to the previous screen Select , and press ■ To initialize the password Press on the remote controller or unit ten times when the screen to enter the personal code is displayed. ■...
Page 338 3-3. Using the rear audio system Code Language Code Language 0721 Gujarati 1311 Macedonian 0801 Hausa 1312 Malayalam 0809 Hindi 1314 Mongolian 0818 Croatian 1315 Moldavian 1821 Hungarian 1318 Marathi 1825 Armenian 1319 Malay 0901 Interlingua 1320 Maltese 0905 Interlingue 1325 Burmese 0911...
Page 339 3-3. Using the rear audio system Code Language Code Language 1914 Shona 2014 Setswana 1915 Somali 2015 Tonga 1917 Albanian 2018 Turkish 1918 Serbian 2019 Tsonga 1919 Siswati 2020 Tatar 1920 Sesotho 2023 1921 Sundanese 2111 Ukrainian 1923 Swahili 2118 Urdu 2001 Tamil...
Page 340: Using The Hands-Free Phone System (For Cellular Phone)
3-4. Using the hands-free phone system (for cellular phone)  Hands-free phone system (for cellular phone) features Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”. ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone.
Page 341 3-4. Using the hands-free phone system (for cellular phone) ■ Conditions under which the system will not operate ● ® If using a mobile phone that does not support Bluetooth ● If the mobile phone is switched off ● If you are outside service range ●...
Page 342 3-4. Using the hands-free phone system (for cellular phone) ■ Certification for the hands-free phone system FCC ID: HYQBTAU01A IC ID: 1551A-BTAU01A MADE IN JAPAN This device complies with Part 15 of the FCC Rules and RSS-210. Opera- tion is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 343 3-4. Using the hands-free phone system (for cellular phone) FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth, for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.
Page 344: Using The Hands-Free Phone System
3-4. Using the hands-free phone system (for cellular phone)  Using the hands-free phone system ■ Audio unit Displays such items as messages, names, phone numbers Lower-case characters and special characters, such as an umlaut, cannot be dis- played. Push and hold: Displays information that is too long to be displayed at one time on the screen...
Page 345 3-4. Using the hands-free phone system (for cellular phone) ■ Steering wheel telephone switches Volume The voice guidance volume cannot be adjusted by using this switch. Hands-free phone system off/ends a call/refuses a call Hands-free phone system on/starts a call Press: Voice command sys- tem on Press and hold: Voice com-...
Page 346 3-4. Using the hands-free phone system (for cellular phone) Operating the system by using a voice command By following voice guidance instructions output from the speaker, voice commands can be given to allow for operation of the hands- free phone system without checking the display or operating ■...
Page 347 3-4. Using the hands-free phone system (for cellular phone) Using the hands-free phone system for the first time Before using the hands-free phone system, it is necessary to register a cellular phone in the system. The phone registration mode will be entered automatically when starting the system with no cellular phone registered.
Page 348 3-4. Using the hands-free phone system (for cellular phone) Menu list of the hands-free phone system ■ Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in Callback the incoming history memory Dialing a number stored in Redial the outgoing history memory Dial by...
Page 349 3-4. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN code Phonebook Locking the phone book Security Lock Phonebook Unlocking the phone book Unlock Registering a cellular phone Pair Phone to be used Changing a registered name...
Page 350 3-4. Using the hands-free phone system (for cellular phone) ■ Using a short cut key First menu Second menu Operation detail Dialing a number registered Dial “XXX (name)” in the phone book Phone book add Adding a new number entry Phone book change Changing a name of a phone name...
Page 351 3-4. Using the hands-free phone system (for cellular phone) ■ Automatic adjustment of volume When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. ■...
Page 352: Making A Phone Call
3-4. Using the hands-free phone system (for cellular phone) Making a phone call ■ Making a phone call ● Dialing by inputting a number “Dial by number” ● Dialing by inputting a name “Dial by name” ● Speed dialing ● Dialing a number stored in the outgoing history memory “Redial”...
Page 353 3-4. Using the hands-free phone system (for cellular phone) STEP Dial by one of the following methods: a. Press b. Press and say “Dial”. c. Select “Dial” by using Dialing by inputting a name STEP Press and say “Dial by name”. STEP Select a registered name to be input by either of the following methods:...
Page 354 3-4. Using the hands-free phone system (for cellular phone) When receiving a phone call ■ Answering the phone Press ■ Refusing the call Press Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the follow- ing methods: a.
Page 355 3-4. Using the hands-free phone system (for cellular phone) STEP Select the number by either of the following methods: a. Say “Previous” or “Go back” until the desired number is dis- played. b. Select the desired number by using The following operations can be performed: Dialing: Press or select “Dial”...
Page 356: Setting A Cellular Phone
3-4. Using the hands-free phone system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free phone system allows the system to function. The following function can be used for regis- tered cellular phones: ■ Functions and operation procedures To enter menu for each function, follow the steps below by using a voice command or ●...
Page 357 3-4. Using the hands-free phone system (for cellular phone) Selecting a cellular phone to be used STEP Select “Select Phone” by using a voice command or Pattern A STEP Select a cellular phone to be used by either of the following methods, and select “Confirm”...
Page 358 3-4. Using the hands-free phone system (for cellular phone) STEP Press or select “Record Name” by using , and say a new name. STEP Select “Confirm” by using a voice command or Listing the registered cellular phones Selecting “List Phones” by using a voice command or begins reading aloud the list of the registered cellular phones.
Page 359 3-4. Using the hands-free phone system (for cellular phone) Deleting a cellular phone STEP Select “Delete” by using a voice command or Pattern A STEP Select a cellular phone to be deleted by either of the following methods and select “Confirm” by using a voice command or a.
Page 360 3-4. Using the hands-free phone system (for cellular phone) Pattern B STEP Select a 4 to 8-digit number by using The number should be input 1 digit at a time. STEP When the entire number to be registered as a passkey has been input, press once again.
Page 361: Security And System Setup
3-4. Using the hands-free phone system (for cellular phone) Security and system setup To enter the menu of each setting, follow the steps below: ■ Security setting items and operation procedure ● Setting or changing the PIN (Personal Identification Number) 1.
Page 362 3-4. Using the hands-free phone system (for cellular phone) STEP Enter the registered PIN by using a voice command or STEP Enter a new PIN by using a voice command or When using , input the code 1 digit at a time. Locking or unlocking the phone book STEP Select “Phonebook lock (Phbk Lock)”...
Page 363 3-4. Using the hands-free phone system (for cellular phone) Initialization STEP Select “Initialize” and then “Confirm” by using STEP Select “Confirm” by using again. ■ Initialization ● The following data in the system can be initialized: • Phone book • Outgoing and incoming history •...
Page 364: Using The Phone Book
3-4. Using the hands-free phone system (for cellular phone) Using the phone book To enter the menu of each setting, follow the steps below: ● Adding a new phone number 1. “Phonebook”  2. “Add Entry” ● Setting speed dial 1.
Page 365 3-4. Using the hands-free phone system (for cellular phone) STEP Use one of the following methods to input a telephone num- ber: Inputting a telephone number by using a voice command STEP2-1 Select “By Voice” by using a voice command or STEP2-2 Press , say the desired number, and select “Confirm”...
Page 366 3-4. Using the hands-free phone system (for cellular phone) Inputting a phone number by using STEP2-1 Select “Manual Input” by using STEP2-2 Input a phone number by using , and press once again. Input the phone number 1 digit at a time. Selecting a phone number from outgoing or incoming history STEP2-1 Select “Call History”...
Page 367 3-4. Using the hands-free phone system (for cellular phone) STEP Select the name to be registered by either of the following methods, and select “Confirm” by using a voice command or a. Press and say the desired name. b. Select “Record Name” by using , and say the desired name.
Page 368 3-4. Using the hands-free phone system (for cellular phone) STEP Select the desired preset button, and register the data into speed dial by either of the following methods: a. Press the desired preset button, and select “Confirm” by using a voice command or b.
Page 369 3-4. Using the hands-free phone system (for cellular phone) Deleting registered data STEP Select “Delete Entry” by using a voice command or Pattern A STEP Select data to be deleted by either of the following methods, and select “Confirm” by using a voice command or a.
Page 370 3-4. Using the hands-free phone system (for cellular phone) Listing the registered data Selecting “List names” by using a voice command begins reading the list of the registered data. When listing is complete, the system returns to “Phonebook”. Pressing while a data is being read aloud selects the data, and the following function will be available.
Page 371: Using The Interior Lights
3-5. Using the interior lights Interior lights list Your Toyota is equipped with the illuminated entry system to assist in entering the vehicle. Owing to the function of the system, the lights shown in the following illustration automatically turn on/off...
Page 372: Personal/Interior Light Main Switch
3-5. Using the interior lights Personal/interior light main switch and personal/interior lights Personal/interior light main switch “OFF” The personal/interior lights and interior light can be individually turned on or off. Door position The personal/interior lights and interior light come on when a door or the glass hatch (if equipped) is opened.
Page 373: Interior Light
20 minutes. ■ Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed. (Customizable features P. 569)
Page 374: Using The Storage Features
3-6. Using the storage features List of storage features Auxiliary boxes Overhead console Glove box Bottle holders Cup holders Side table Console box...
Page 375: Glove Box
3-6. Using the storage features Glove box Glove box Unlock with the key Lock with the key Open (pull lever) ■ Power back door main switch (vehicles with power back door) The power back door main switch is located in the glove box. (P. 80) CAUTION ■...
Page 376: Console Box
3-6. Using the storage features Console box Console box Upper Pull up the knob to release the lock. Lift the lid. Lower Push down the lever. CAUTION ■ Caution while driving Keep the console box closed. Injuries may result in the event of an accident or sudden braking.
Page 377: Overhead Console
3-6. Using the storage features Overhead console Overhead console The overhead console is useful for temporarily storing sunglasses and similar small items. Press in the lid. CAUTION ■ Items that should not be left in the overhead console Do not leave glasses or lighters in the console. If the interior of the vehicle becomes hot, lighters may explode and glasses may warp or becomes cracked.
Page 378: Cup Holders
3-6. Using the storage features Cup holders Cup holders Front (type A) Front (type B) Lift the lid. Console box Pull out the cup holder.
Page 379 3-6. Using the storage features Cup holders Side table Install the side table before using the cup holder. (P. 385) Removing the adapters changes the size. (P. 380) Rear (vehicles without third seat) Rear (vehicles with third seat) Removing the adapters changes the size.
Page 380 3-6. Using the storage features Cup holders ■ Adjusting size of the cup holders (front [type B], side table and rear [vehicles with third seat]) Front (type B) Remove the separator. The cup holder insert may be removed for cleaning. Side table Remove the adapter.
Page 381 3-6. Using the storage features Cup holders CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or beverage cans in the cup holders. Even when the lid is closed, items must not be stored in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 382: Bottle Holders
3-6. Using the storage features Bottle holders Bottle holders Front Rear CAUTION ■ Items unsuitable for the bottle holder Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 383: Auxiliary Boxes
3-6. Using the storage features Auxiliary boxes Auxiliary boxes Type A Pull up the lever. Type B (if equipped) Lift the lid.
Page 384 3-6. Using the storage features Auxiliary boxes Type C Lift the lid. ■ Auxiliary box (type C) The side table can be installed. (P. 385) CAUTION ■ Caution while driving Keep the auxiliary boxes closed. Injuries may result in the event of an accident or sudden braking.
Page 385: Side Table
3-6. Using the storage features Side table Side table ■ Installing the side table Take out the side table from the STEP console box. STEP Remove the second center seat. (P. 97) Engage the front pins of the STEP side table with the hooks. Push down on the side table to engage the rear pin locks.
Page 386 3-6. Using the storage features Side table Pull the lock release lever to STEP remove the side table. Stow the side table in the con- STEP sole box. Push down on the end to engage STEP the pins in the holes and close the console box door.
Page 387: Other Interior Features
3-7. Other interior features Sun visors Forward position Flip down. Side position Flip down, unhook, and swing to the side. Side extender Place in side position then slide backwards.
Page 388: Vanity Mirrors
3-7. Other interior features Vanity mirrors Slide the cover. The light turns on when the cover is opened. (vehicles with vanity mirror light) NOTICE ■ To prevent the 12-volt battery from being discharged Do not leave the vanity lights on for extended periods while the hybrid sys- tem is off.
Page 389: Conversation Mirror
3-7. Other interior features Conversation mirror Press in the lid. STEP Push the lid back up half way. STEP ■ To use the overhead console from the conversation mirror state Fully close the lid, then open it again. (P. 377)
Page 390: Power Outlet
3-7. Other interior features Power outlet The power outlet can be used for a following component. 12 V: Accessories that run on less than 10 A. 115 VAC: Accessories that use less than 100 W. Type A (12 V)* Type B (12 V)*...
Page 391 3-7. Other interior features Type C (12 V) Type D (115 VAC)* Main switch To use the power outlet, turn on the main switch. Power outlet socket Type E (12 V) : Vehicles with seat heater : Vehicles without seat heater : Vehicles with rear entertainment system...
Page 392 3-7. Other interior features ■ The power outlet can be used when 12 V The “POWER” switch is in ACCESSORY or ON mode. 115 VAC The “POWER” switch is in ON mode. NOTICE ■ To avoid damaging the power outlet Close the power outlet lid when the power outlet is not in use.
Page 393: Seat Heaters
3-7. Other interior features  Seat heaters Pops the knob out Driver's seat The indicator light comes on. Adjusts the seat tempera- ture The further you turn the knob Front passenger's seat clockwise, the warmer the seat becomes. ■ The seat heaters can be used when The “POWER”...
Page 394 3-7. Other interior features CAUTION ■ Burns ● Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the disabled •...
Page 395: Armrests
3-7. Other interior features Armrests Pull the armrest down for use. NOTICE ■ To prevent damage to the armrest Do not place too much strain on the armrest.
Page 396: Floor Mat
3-7. Other interior features Floor mat Securely place a mat that matches the size of the space on the car- pet. Secure the driver's floor mat using the hooks provided. CAUTION ■ When inserting the floor mat Observe the following precautions. Failure to do so may result in the floor mat slipping and interfering with the movement of the pedals during driving, resulting in an accident.
Page 397: Luggage Compartment Features
3-7. Other interior features Luggage compartment features ■ Cargo hooks Cargo hooks are provided for securing loose items. ■ Grocery bag hooks ■ Auxiliary box Lift the center deck board.
Page 398 3-7. Other interior features ■ Separating luggage compartment The center deck board can be used to separate the luggage compartment. Remove center deck board and insert it upright into the groove. The board cannot be inserted when the luggage cover is stowed.
Page 399 3-7. Other interior features ■ Luggage cover (vehicles with luggage cover) Hang the hooks on the hook STEP brackets on the second seat seatback. Vehicles with the third seat: When using the luggage cover, the third seat must be fold down.
Page 400 3-7. Other interior features ■ Removing the luggage cover (vehicles with luggage cover) The luggage cover can be removed by following the procedure below. Detach the hooks. Push in the left side of the luggage cover while keeping hold of the right side.
Page 401 3-7. Other interior features ■ Stowing the luggage cover (vehicles with luggage cover) Remove the side deck boards and open STEP the center deck board. Fold the flaps on top of the luggage cover STEP with the hooks rolled inside. Place the left end of the luggage cover in STEP the recess on the left-hand side and then...
Page 402 3-7. Other interior features NOTICE ■ Shopping bag hook weight capacity Do not hang any object heavier than 4 lb. (2 kg) on shopping bag hooks. ■ While driving Do not drive with the luggage cover standing upright in the grooves as the luggage cover may fall down.
Page 403: Garage Door Opener
3-7. Other interior features  Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, and security systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufac- ®...
Page 404 3-7. Other interior features Press and hold down one of the STEP ® buttons on the HomeLink the button on the transmitter. When the indicator light on the ® HomeLink changes from a slow to a rapid flash after 20 seconds, you can release both buttons.
Page 405 3-7. Other interior features ■ Programming a Rolling Code system (for U.S.A. owners) If your device is Rolling Code equipped, follow the steps under the ® heading “Programming the HomeLink ” before proceeding with the steps listed below. STEP Locate the learn button on the ceiling mounted garage door opener motor.
Page 406 ® the remaining HomeLink buttons. ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. ■ Reprogramming a button ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 407 3-7. Other interior features ■ Before programming ● Install a new battery in the transmitter. ● The battery side of the transmitter must be pointed away from the ® HomeLink ■ Certification for the garage door opener For vehicles sold in the U.S.A. FCC ID: CB2300NHL3 NOTE: This device complies with Part 15 of the FCC Rules.
Page 408 3-7. Other interior features CAUTION ■ When programming a garage door or other remote control device The garage door may operate, so ensure people and objects are out of dan- ger to prevent potential harm. ■ Conforming to federal safety standards ®...
Page 409: Compass
3-7. Other interior features  Compass The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. ■ Operation To turn the compass on or off, press the switch. ■ Displays and directions Display Direction North Northeast...
Page 410 3-7. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 411 3-7. Other interior features ■ Circling calibration When C appears on the display, drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed. If there is not enough space to drive in a circle, drive around the block until the direction is dis- played.
Page 412 3-7. Other interior features NOTICE ■ To avoid the compass malfunctions Do not place magnets or any metal objects near the inside rear view mirror. Doing this may cause a malfunction of the compass sensor. ■ To ensure normal operation of the compass ●...
Page 413 Maintenance and care 4-1. Maintenance and care 4-3. Do-it-yourself maintenance Cleaning and protecting the vehicle exterior..414 Do-it-yourself service precautions ....426 Cleaning and protecting the vehicle interior..417 Hood ........ 430 Positioning a floor jack ..432 4-2. Maintenance Engine compartment..
Page 414: Cleaning And Protecting The Vehicle Exterior
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 415 4-1. Maintenance and care ■ Aluminum wheels Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the paint. ■...
Page 416 Do not use organic cleaners such as benzene or gasoline. ■ If the windshield washer nozzle become blocked Contact your Toyota dealer. Do not try to clear it with a pin or other object. This may damage the nozzle. ■...
Page 417: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 418 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 419 4-1. Maintenance and care NOTICE ■ Cleaning detergents Do not use organic substances such as benzene or gasoline, acidic or alka- line solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. ■...
Page 420: Maintenance
It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 421 4-2. Maintenance ■ Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 422: General Maintenance
“Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
Page 423 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be hold securely Transmission “Park” mechanism on an incline with the shift lever in • Moves smoothly? • Does it have appropriate clear- Brake pedal ance and correct amount of free play?
Page 424 4-2. Maintenance Vehicle exterior Items Check points Door • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tire •...
Page 425: Emission Inspection And Maintenance (I/M) Programs
If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...
Page 426: Do-It-Yourself Maintenance
(P. 444) • Conventional wrench (for terminal clamp bolts)  Brake fluid level (P. 443) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 427 4-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (P. 468) as original Radiator and condenser  (P. 443) • Tire pressure gauge Tire inflation pressure (P. 457) • Compressed air source • Water washer fluid containing Washer fluid (P.
Page 428 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. ■ When working on the engine compartment ● Make sure that the indicator on the “POWER”...
Page 429 4-3. Do-it-yourself maintenance CAUTION ■ Safety glasses Wear safety glasses to prevent flying or falling material, fluid spray, etc. from getting in the eyes. NOTICE ■ If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air.
Page 430: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the auxiliary catch lever STEP and lift the hood. Hold the hood open by insert- STEP ing the supporting rod into either of the slots.
Page 431 4-3. Do-it-yourself maintenance CAUTION ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
Page 432: Positioning A Floor Jack
4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. ■ Front ■ Rear...
Page 433 4-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 434: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment Washer fluid tank (P. 448) Power control unit coolant reservoir (P. 441) 12-volt battery (P. 444) Fuse boxes (P. 468) Brake fluid reservoir (P. 443) Power control unit coolant radiator (P. 443) Engine oil level dipstick (P.
Page 435 4-3. Do-it-yourself maintenance Engine compartment cover (front) ■ Removing the engine compartment cover ■ Installing the clips...
Page 436 4-3. Do-it-yourself maintenance Engine compartment cover (left side) ■ Removing the engine compartment cover ■ Installing the engine compartment cover...
Page 437 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil STEP Park the vehicle on level ground. After turning off the hybrid system, wait more than five minutes for the oil to drain back into the bottom of the engine.
Page 438 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 439 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 440 4-3. Do-it-yourself maintenance Coolant The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir when the hybrid system is cold. Engine coolant reservoir Reservoir cap “FULL” “LOW” If the level is on or below the “LOW”...
Page 441 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, coolant reservoir cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. ■...
Page 442 4-3. Do-it-yourself maintenance CAUTION ■ When the hybrid system is hot Do not remove the coolant reservoir cap. The cooling system may be under pressure and may spray hot coolant if the cap is removed, causing burns or other injuries. NOTICE ■...
Page 443 Radiator and condenser Check the radiators and condenser, and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
Page 444 4-3. Do-it-yourself maintenance CAUTION ■ When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces. If fluid gets in your eyes, flush your eyes with clean water immediately. If you still experience discomfort, see a doctor. NOTICE ■...
Page 445 4-3. Do-it-yourself maintenance ■ Checking 12-volt battery fluid Check that the level is between “UPPER LEVEL” and “LOWER LEVEL”. “UPPER LEVEL” “LOWER LEVEL” If the fluid level is at or below “LOWER LEVEL”, add distilled water. ■ Adding distilled water O.
Page 446 With the shift lever in P and the “POWER” switch OFF, open and close the driver’s door, then attempt to start the hybrid system. If the system will not start even after multiple attempts at both methods, con- tact your Toyota dealer. CAUTION ■...
Page 447 4-3. Do-it-yourself maintenance CAUTION ■ Emergency measures regarding electrolyte ● If electrolyte gets in your eyes Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. If possible, continue to apply water with a sponge or cloth while traveling to the nearest medical facility.
Page 448 4-3. Do-it-yourself maintenance Washer fluid Add washer fluid in the following situations. ● Any washer does not work. ● The warning message appears on the multi-informa- tion display. (P. 511) CAUTION ■ When adding the washer fluid Do not add the washer fluid when the engine is hot or running, as the washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 449: Tires
Tire rotation Vehicles without compact spare tire Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota rec- ommends that tire rotation is Front carried out at the same inter- val as tire inspection.
Page 450 ■ The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (P. 505, 511) Vehicles with compact spare tire: The compact spare tire is not equipped with the tire pressure warning valve and transmitters.
Page 451 ID codes must be registered in the tire pressure warning computer and tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 451) Registering ID codes The tire pressure warning valve and transmitter is equipped with a unique ID code.
Page 452 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 453 4-3. Do-it-yourself maintenance ■ Tire types 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 454 4-3. Do-it-yourself maintenance ■ Tire pressure warning system certification For vehicles sold in the U.S.A. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 455 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 456 Repairing or replacing tires, wheels and tire pressure warning valves and transmitters When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. ■...
Page 457: Tire Inflation Pressure
4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (P. 557) ■ Inspection and adjustment procedure Tire valve Tire pressure gauge STEP Remove the tire valve cap.
Page 458 Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 459 4-3. Do-it-yourself maintenance ● Always use a tire pressure gauge. The appearance of the tire can be misleading. In addition, tire infla- tion pressures that are even just a few pounds off can degrade ride and handling. ● Do not bleed or reduce tire inflation pressure after driving. It is normal for the tire inflation pressure to be higher after driving.
Page 460: Wheels
● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 461 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 462: Air Conditioning Filter
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. ■ Removal method STEP Turn the “POWER” switch OFF. Open the glove box. Slide off STEP the damper. Push each side of the glove STEP box to release the pins.
Page 463 4-3. Do-it-yourself maintenance Remove the filter cover. STEP ■ Replacement method Remove the air conditioning filter and replace it with a new one. The“UP” marks shown on the filter should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 464 4-3. Do-it-yourself maintenance NOTICE ■ When using the air conditioning system Make sure that a filter is always installed. Using the air conditioning system without a filter may cause damage to the system.
Page 465: Electronic Key Battery
4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with a rag.) ●...
Page 466 ● The operational range is reduced. ■ Use a CR1632 lithium battery ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by your Toyota dealer. ●...
Page 467 4-3. Do-it-yourself maintenance NOTICE ■ For normal operation after replacing the battery Observe the following precautions to prevent accidents. ● Always work with dry hands. Moisture may cause the battery to rust. ● Do not touch or move any other components inside the remote control. ●...
Page 468: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Turn the “POWER” switch OFF. STEP Remove the left side engine compartment cover. (P. 436) STEP Open the fuse box cover.
Page 469 4-3. Do-it-yourself maintenance Under the instrument panel Remove the lid. STEP After a system failure, see “Fuse layout and amperage rat- ings” (P. 471) for details about which fuse to check. Remove the fuse with the pull- STEP out tool. STEP Check if the fuse has blown.
Page 470 Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Contact your Toyota dealer. Type D Normal fuse Blown fuse Contact your Toyota dealer.
Page 471 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Type A (fuse block on the back of the cover) Type A (fuse block) Fuse Ampere Circuit SPARE 7.5 A Spare fuse SPARE 15 A Spare fuse SPARE 25 A Spare fuse...
Page 472 4-3. Do-it-yourself maintenance Fuse Ampere Circuit DEF RLY 10 A Rear window defogger MIR HTR 20 A MIR HTR (15 A) P/OUT 20 A Power outlet DOOR 1 25 A Multiplex communication system Multiport fuel injection system/ IGCT NO.3 10 A sequential multiport fuel injection system Multiport fuel injection system/...
Page 473 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Steering sensor, gauges and meters, air conditioning system, main body ECU, wireless remote ECU-B 10 A control, smart key system, power back door, on-board diagnosis sys- Vanity lights, personal lights, inte- DOME 10 A rior light, gauges and meters, door courtesy lights, power back door 15 A...
Page 474 4-3. Do-it-yourself maintenance Fuse Ampere Circuit H-LP RL 15 A Right-hand headlight (low beam) HORN 10 A Horn Multiport fuel injection system/ EFI NO.1 10 A sequential multiport fuel injection system, smart key system Multiport fuel injection system/ sequential multiport fuel injection ETCS 10 A system, electronic throttle control...
Page 475 4-3. Do-it-yourself maintenance ■ Under the instrument panel Front side of the fuse block Fuse block Fuse Ampere Circuit P/SEAT 30 A Power seat POWER 30 A Power windows RR DOOR RH 25 A Power windows RR DOOR LH 25 A Power windows FR FOG 15 A...
Page 476 4-3. Do-it-yourself maintenance Fuse Ampere Circuit A/C NO.1 10 A Air conditioning system FUEL OPN 7.5 A Fuel filler door opener S/ROOF 30 A Electric moon roof Parking lights, tail lights, license TAIL 15 A plate lights, front fog lights, trailer lights Glove box light, emergency flash- ers, audio system, outside rear...
Page 477 4-3. Do-it-yourself maintenance Fuse Ampere Circuit RR WIP 15 A Rear window wiper and washer Multiport fuel injection system/ sequential multiport fuel injection 10 A system, steering lock system, smart key system, SRS airbag sys- Gauges and meters, rear view GAUGE NO.2 7.5 A monitor...
Page 478 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.
Page 479: Light Bulbs
You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 480 4-3. Do-it-yourself maintenance ■ Rear bulb locations Back-up lights Stop/tail and rear side marker lights License plate lights Rear turn signal lights Replacing light bulbs ■ Headlights Right side only: Lift up the filler STEP tube for the washer fluid tank and move it to the side.
Page 481 4-3. Do-it-yourself maintenance Remove the rubber cover. STEP Release bulb retaining STEP spring. Remove the bulb. STEP...
Page 482 4-3. Do-it-yourself maintenance ■ Front fog lights (if equipped) STEP Remove the fender liner bolts and clips as follows. Left side...
Page 483 4-3. Do-it-yourself maintenance Right side Remove the fender liner. STEP Turn the bulb base counterclock- STEP wise.
Page 484 4-3. Do-it-yourself maintenance Unplug connector while STEP depressing the lock release. ■ Parking and front side marker lights Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP...
Page 485 4-3. Do-it-yourself maintenance ■ Front turn signal lights Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP...
Page 486 4-3. Do-it-yourself maintenance ■ Back-up lights, stop/tail and rear side marker lights Left side Open the back door and remove STEP the cover. To protect the cover, place a rag between the flathead screwdriver and cover as shown in the illus- trations.
Page 487 4-3. Do-it-yourself maintenance Remove the light bulb. STEP Back-up light Rear turn signal light Stop/tail and rear side marker light ■ License plate lights Remove the screw and remove STEP the unit. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP...
Page 488 ■ LED high mounted stoplight The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. ■ Installing the fender liner clips Insert the clips.
Page 489 4-3. Do-it-yourself maintenance CAUTION ■ Replacing light bulbs ● Turn off the headlights. Do not attempt to replace the bulb immediately after turning off the headlights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by the plastic or metal portion.
Page 490 4-3. Do-it-yourself maintenance...
Page 491: When Trouble Arises
When trouble arises 5-1. Essential information 5-2. Steps to take in an emergency Emergency flashers ..492 If a warning light turns If your vehicle needs to on or a warning buzzer be towed ......493 sounds......502 If you think something If a warning message is is wrong ......
Page 492: Essential Information
5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Vehicles without navigation system Press the switch to flash all the turn signal lights. To turn them off, press the switch once again.
Page 493: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 494 5-1. Essential information Emergency towing If a tow truck is not available, in an emergency your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet(s). This should only be attempted on hard surfaced roads for short distances below 18 mph (30 km/h).
Page 495 5-1. Essential information NOTICE ■ To prevent causing serious damage to the transmission Never tow this vehicle from the rear with the front wheels on the ground. This may cause serious damage to the transmission. Installing towing eyelet Remove the eyelet cover while STEP pushing it.
Page 496 5-1. Essential information ■ Location of the emergency towing eyelet P. 512 CAUTION ■ Installing towing eyelet to the vehicle Make sure that towing eyelet is installed securely. If not securely installed, towing eyelet may come loose during towing. This may lead to accidents that cause serious injury or even death.
Page 497 5-1. Essential information Towing with a sling-type truck NOTICE ■ To prevent body damage Do not tow with a sling-type truck, either from the front or rear. Towing with a wheel lift-type truck From front Use a towing dolly under the rear wheels.
Page 498 5-1. Essential information From rear Use a towing dolly under the front wheels. NOTICE ■ To prevent causing serious damage to the transmission Never tow this vehicle from the rear with the front wheels on the ground. ■ To prevent damaging the vehicle ●...
Page 499: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 500: Event Data Recorder
5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is an event data recorder (EDR) that records data in a crash or a near car crash event.
Page 501 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: ● An agreement from the vehicle's owner (or the leasing company for a leased vehicle) is obtained ●...
Page 502: Steps To Take In An Emergency
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light in red (warning buzzer)* •...
Page 503 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: (U.S.A.)
Page 504 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
Page 505 When the light comes on: Adjust the tire inflation Low tire inflation pressure pressure. When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer. pressure warning system...
Page 506 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Master warning light A buzzer sounds and the warning light comes on P. 511 and flashes to indicate that the master warning system has detected a malfunc- tion.
Page 507 5-2. Steps to take in an emergency ■ The tire pressure warning light may turn on due to natural causes The tire pressure warning light may turn on due to natural causes such as natural air leaks or tire inflation pressure changes caused by temper- ature.
Page 508 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 509 5-2. Steps to take in an emergency CAUTION ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 510 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).
Page 511: If A Warning Message Is Displayed
■ Warning buzzer A buzzer may sound when a warning message is shown on the multi-information display. ■ If the warning message is shown again after its correction procedure has been performed Contact your Toyota dealer as soon as possible.
Page 512: If You Have A Flat Tire
5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
Page 513 5-2. Steps to take in an emergency Taking out the jack Remove the right side deck STEP board. Unhook the tightening strap and STEP remove the pad. After storing the jack, make sure it is securely held by the tightening strap. Loosen STEP Tighten...
Page 514 5-2. Steps to take in an emergency Taking out the spare tire Open the center deck board and STEP remove the cover. Remove the cover. STEP If it is difficult to remove the cover, you can use the key. Attach the adapter socket (for STEP removing a spare tire) on the spare tire clamp bolt.
Page 515 5-2. Steps to take in an emergency Assemble the jack handle and STEP tighten the screw. Connect the jack handle and the STEP adapter socket. Turn the jack handle. The tire will be lowered com- pletely to the ground. Pull out the spare tire and stand STEP it against the bumper.
Page 516 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP STEP Wheel Flat tire chock posi- tions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of...
Page 517 5-2. Steps to take in an emergency Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and STEP the tire.
Page 518 5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 519 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) Stowing the flat tire, jack and all tools STEP Remove the center wheel ornament by pushing from the reverse side.
Page 520 5-2. Steps to take in an emergency ■ The compact spare tire ● The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily only in an emergency. ● Make sure to check the tire inflation pressure of the compact spare tire.
Page 521 5-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 522 5-2. Steps to take in an emergency CAUTION ● Have the wheel nuts tightened with a torque wrench to 76 ft•lbf (103 N•m, 10.5 kgf•m) as soon as possible after changing wheels. Failure to follow these precautions could cause the nuts to loosen and the wheel may fall off, which could lead to an accident causing death or serious injury.
Page 523 ■ When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. ■...
Page 524: If The Hybrid System Will Not Start
5-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate proce- dure: ■ The hybrid system will not start, even though the correct starting procedure is being followed.
Page 525 ● One or both of the 12-volt battery terminals may be discon- nected. ● The 12-volt battery may be discharged. (P. 530) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 526: If The Shift Lever Cannot Be Shifted From P
(a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 527: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer. Bring the key and the key number stamped on the key number plate.
Page 528: If The Electronic Key Does Not Operate Properly
Changing “POWER” switch modes and starting the hybrid system STEP Shift the shift lever to P and apply the brakes. Touch the Toyota emblem side of STEP electronic “POWER” switch. If any of the doors is opened and...
Page 529 5 seconds after the buzzer sounds, keeping the brake pedal depressed. In the event that the hybrid system still cannot be operated, contact your Toyota dealer. ■ Stopping the hybrid system Shift the shift lever to P and press the “POWER” switch as you normally do when stopping the hybrid system.
Page 530: If The 12-Volt Battery Is Discharged
You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. STEP...
Page 531 STEP Make sure the “READY” indicator comes on. If the indicator does not comes on, contact your Toyota dealer. STEP Once the hybrid system has started, remove the jumper cables in the exact reverse order in which they were con- nected.
Page 532 5-2. Steps to take in an emergency CAUTION ■ Avoiding 12-volt battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the 12-volt battery. ● Make sure each jumper cable is connected to the correct terminal. ●...
Page 533 5-2. Steps to take in an emergency NOTICE ■ When handling jumper cables Be careful that the jumper cables do not become tangled in the cooling fans or belt when connecting or disconnecting the cables.
Page 534: If Your Vehicle Overheats
Check if the cooling fans are operating. If the fans are operating: Wait until the engine coolant temperature gauge begins to fall and then stop the hybrid system. If the fans are not operating: Stop the hybrid system immediately and call your Toyota dealer.
Page 535 5-2. Steps to take in an emergency After the hybrid system has STEP cooled down, check the engine coolant level and inspect the cooling system for leaks. Engine coolant reservoir Radiator If necessary, add engine coolant STEP up to the “FULL” line. Water can be used in an emer- gency if engine coolant is unavail- able.
Page 536 If necessary, add power control STEP unit coolant up to the “FULL” line. Water can be used in an emer- gency if power control unit cool- ant is unavailable. (P. 545) Have the vehicle inspected at your nearest Toyota dealer as soon as possible.
Page 537 5-2. Steps to take in an emergency ■ Overheating The following symptoms may occur when your vehicle is overheating: ● Hybrid system output decreases. ● Steam is coming from the engine area. CAUTION ■ To prevent an accident or injury when inspecting under the hood of your vehicle ●...
Page 538: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. STEP Stop the hybrid system. Set the parking brake and put the shift lever in P.
Page 539: Vehicle Specifications
Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.) ..540 Fuel information ....554 Tire information ....557 6-2. Customization Customizable features ..569 6-3. Initialization Items to initialize ....572...
Page 540: Specifications Maintenance Data (Fuel, Oil Level, Etc.)
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 188.4 in. (4785 mm) Overall width 75.2 in. (1910 mm) Without roof rails 68.1 in. (1730 mm) Overall height With roof rails 69.3 in. (1760 mm) Wheelbase 109.8 in.
Page 541 ■ Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped under the right-hand front seat.
Page 542 6-1. Specifications ■ Gasoline engine number and electric motor (traction motor) number The gasoline engine number and electric motor (traction motor) num- ber are stamped as shown. Gasoline engine number Electric motor (traction motor) number Engine Model 3MZ-FE Type 6-cylinder V type, 4-cycle, gasoline 3.62 ...
Page 543 6-1. Specifications Front electric motor (traction motor) Type Permanent magnet synchronous motor Maximum output 123 kW Maximum torque 245 ft•lbf (333 N•m, 33.9 kgf•m) Rear electric motor (traction motor) Type Permanent magnet synchronous motor Maximum output 50 kW Maximum torque 95 ft•lbf (130 N•m, 13.2 kgf•m) Hybrid battery (traction battery) Type...
Page 544 5.0 qt. (4.7 L, 4.1 Imp. qt.) ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toy- ota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil...
Page 545 13.5 qt. (12.8 L, 11.3 Imp. qt.) Power control unit 3.6 qt. (3.4 L, 3.0 Imp. qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 546 6-1. Specifications Ignition system Spark plug Make DENSO SK20R11 NGK IFR6A11 0.043 in. (1.1 mm) NOTICE ■ Iridium-tipped spark plugs Use only iridium-tipped spark plugs. Do not adjust spark plug gap. Electrical system 12-volt battery 12.6  12.8 V Fully charged 12.2 ...
Page 547 The fluid capacity is a reference quantity. If replacement is necessary, contact your Toyota dealer. Fluid type Toyota Genuine ATF WS NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may ulti- mately damage the transmission of your vehicle.
Page 548 6-1. Specifications Brakes Pedal clearance* 3.74 in. (95 mm) Min. 0.04  0.08 in. (1  2 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) 8 10 clicks Parking brake pedal travel* Fluid type SAE J1703 or FMVSS No.
Page 549 6-1. Specifications Tires and wheels Type A Tire size P245/65R17 105S Driving under normal conditions Front: 33 psi (230 kPa, 2.3 kgf/cm or bar) Rear: 33 psi (230 kPa, 2.3 kgf/cm or bar) Spare: Tire inflation pressure 33 psi (230 kPa, 2.3 kgf/cm or bar) (Recommended cold tire Driving at high speeds above 100 mph...
Page 550 6-1. Specifications Type B Tire size P245/55R19 103S Driving under normal conditions Front: 33 psi (230 kPa, 2.3 kgf/cm or bar) Rear: 33 psi (230 kPa, 2.3 kgf/cm or bar) Spare: Tire inflation pressure 33 psi (230 kPa, 2.3 kgf/cm or bar) (Recommended cold tire Driving at high speeds above 100 mph...
Page 551 6-1. Specifications Type C P245/65R17 105S, T165/90D18 107M Tire size (spare) Driving under normal conditions Front: 33 psi (230 kPa, 2.3 kgf/cm or bar) Rear: 33 psi (230 kPa, 2.3 kgf/cm or bar) Driving at high speeds above 100 mph Tire inflation pressure (160 km/h) (in countries where such (Recommended cold tire...
Page 552 6-1. Specifications Type D P245/55R19 103S, T165/90D18 107M Tire size (spare) Driving under normal conditions Front: 33 psi (230 kPa, 2.3 kgf/cm or bar) Rear: 33 psi (230 kPa, 2.3 kgf/cm or bar) Driving at high speeds above 100 mph Tire inflation pressure (160 km/h) (in countries where such (Recommended cold tire...
Page 553 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type  Headlights 60/55  Front turn signal lights  Parking/front side marker lights  Front fog lights*  Rear turn signal lights Exterior  Back-up lights Stop/tail and rear side marker ...
Page 554: Fuel Information
ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■...
Page 555 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10% ethanol or 15% MTBE. ● If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87. ●...
Page 556 6-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline will cause the three-way catalytic converter to lose its effectiveness and the emission control system to function improperly.
Page 557: Tire Information
6-1. Specifications Tire information Typical tire symbols Standard tire Compact spare tire Tire size (P. 560) DOT and Tire Identification Number (TIN) (P. 559) Uniform tire quality grading For details, see “Uniform tire quality grading” that follows. Location of treadwear indicators (P.
Page 558 6-1. Specifications Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Radial tires or bias-ply tires A radial tire has “RADIAL” on the sidewall. A tire not marked with “RADIAL”...
Page 559 6-1. Specifications Typical DOT and tire identification number (TIN) DOT symbol* Tire Identification Number (TIN) Tire manufacturer's identifica- tion mark Tire size code Manufacturer's optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year *: The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 560 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
Page 561 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
Page 562 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
Page 563 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
Page 564 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
Page 565 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
Page 566 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall...
Page 567 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between adja- Ply separation cent plies A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load...
Page 568 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the...
Page 569: Customization
Your vehicle includes a variety of electronic features that can be personalized to your preferences. Programming these preferences requires specialized equipment and may be performed by your Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer. Customized Item Function Default setting...
Page 570 6-2. Customization Customized Item Function Default setting setting Wireless remote control Driver's door unlocked in one All doors Unlocking operation step, all doors unlocked in one unlocked in two step steps Automatic door lock function to be activated if door is not opened after being unlocked Wireless remote con-...
Page 571 6-2. Customization Customized Item Function Default setting setting Multi-infor- mation dis- Language selection English French play (P. 197) 7.5 seconds Time elapsed before 15 seconds lights turn off 30 seconds Operation when the Illumination doors are unlocked  P. 371) Operation after the “POWER”...
Page 572: Initialization Items To Initialize
6-3. Initialization Items to initialize The following items must be initialized for normal system operation in cases such as after the 12-volt battery is reconnected, or mainte- nance is performed on the vehicle. Item When to initialize Reference • After reconnecting or changing the Power back door battery P.
Page 573: For Owners
For owners Reporting safety defects for U.S. owners ....574 Seat belt instructions for Canadian owners (in French) ..... 575...
Page 574: Reporting Safety Defects For U.s. Owners
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 575: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 576 Entretien et soin ■ Ceintures de sécurité Nettoyez avec un chiffon ou une éponge humectée d'eau savonneuse tiède. Profitez de l'occasion pour vérifier régulièrement que les ceintures ne sont pas effilochées, entaillées, ou ne paraissent pas exagérément usées. ATTENTION ■ Détérioration et usure des ceintures de sécurité...
Page 577: Index
Index Abbreviation list ..... 578 Alphabetical index....579 What to do if......589 For details of equipment related to the navigation sys- tem and touch screen, such as the audio system, refer to the “Navigation System Owner's Manual”.
Page 578: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Automatic Locking Retractor Calibration Child Restraint System DISP Display ECON Economy Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering GAWR Gross Axle Weight Rating Gross Vehicle Mass Emission Inspection and Maintenance INFO Information...
Page 579: Alphabetical Index
Alphabetical index Alphabetical index A/C ....256, 262, 271, 274 Audio system ABS........... 222 Antenna.........287 Air conditioning filter....462 Audio input ......307 Air conditioning system Audio visual input ....331 Air conditioning filter ..... 462 AUX adapter......307 Front automatic air A/V input adapter ....331 conditioning system ...
Page 580 Alphabetical index Brakes Removed key battery Fluid ........443 precautions ......466 Parking brake ......189 Seat belt extender Brake assist......222 precautions ......110 Break-in tips ......171 Seat belt precautions .... 109 Seat heater precautions..394 12-volt battery Care precautions ....446, 532 Exterior........414 Child-protectors......75 Interior ........417...
Page 581 Alphabetical index Doors If your vehicle becomes Door glasses ......116 stuck ........538 Door lock ....44, 65, 74 If your vehicle needs to be Side mirrors ......114 towed ........493 Driver's seat belt reminder If your vehicle overheats ..534 light ........
Page 582 Alphabetical index Floor mat........396 Garage door opener ....403 Fluid Gas station information ..592 Brake........443 Gauges........191 Washer........448 Glove box ......... 375 Fog lights Replacing light bulbs .....479 Hands-free system Switch........211 (for cellular phone)....340 Wattage.........553 Hazard lights Front automatic air Switch ........
Page 583 Alphabetical index Inside rear view mirror.... 112 Replacing light bulbs .....479 Interior lights Turn signal lever....188 Interior lights......371 Vanity lights......388 Switch......372, 373 Wattage.........553 Wattage ........ 553 Load capacity ......237 Lock steering column....182 Luggage cover ......399 Jack Positioning a floor jack ..432 Vehicle-equipped jack ..
Page 584 Alphabetical index Off-road precautions ....228 Radiator ........443 Odometer ........191 Radio......... 284 Rear automatic air Engine oil ......437 conditioning system ..... 274 Opener Rear manual air Back door ........78 conditioning system ..... 271 Fuel filler door .......121 Rear seat Glass hatch ......87 Adjustment ......92 Hood........430 Folding down second...
Page 585 Alphabetical index Seat belts Shift lever Adjusting the seat belt ..104 If the shift lever cannot Automatic Locking be shifted from P....526 Retractor ......106 Transmission......186 Child restraint system Shift lock system .....526 installation ......154 Shopping bag hooks ....397 Cleaning and maintaining Side airbags......136 the seat belts......
Page 586 Alphabetical index Stop lights Tail lights Replacing light bulbs .....479 Replacing light bulbs..... 479 Wattage.........553 Switch ........207 Storage feature......374 Wattage......... 553 Storage precautions ....235 Talk switch ....... 345 Stuck Telephone switch..... 345 If your vehicle becomes Theft deterrent system stuck ........538 Alarm........
Page 587 Alphabetical index Tools......... 512 Vanity lights Total load capacity....237 Vanity lights......388 Towing Wattage.........553 Dinghy towing....... 252 Vanity mirrors......388 Emergency towing....494 VDIM ..........222 Trailer towing......242 Vehicle dynamics integrated Traction control....... 222 management ......222 TRAC ........222 Vehicle identification Transmission......
Page 588 Alphabetical index Warning buzzers Weight Brake system ......502 Cargo capacity ...... 233 Moon roof ......506 Load limits......237 Open door ......505 Weight........540 Seat belt reminder....505 Wheels ........460 Warning lights Window glasses ...... 116 Anti-lock brake system ..503 Window lock switch....116 Brake assist system ....503 Windows Brake system ......502...
Page 589: What To Do If
What to do if... What to do if... If you have a flat tire A tire punctures P. 512 P. 524 If the hybrid system will not start The hybrid system does not P. 126 Immobilizer system start P. 530 If the 12-volt battery is discharged If the shift lever cannot be shifted The shift lever cannot be...
Page 590 What to do if... If a warning light turns on or a A warning light or indicator light P. 502 warning buzzer sounds... comes on ■Warning lights Brake system warning Low fuel level warning light in red light P. 505 Driver’s seat belt reminder light P.
Page 591 What to do if... ABS warning light Tire pressure warning light P. 505 P. 503 Electric power steering warning light P. 503 A warning message is If a warning message is displayed P. 511 displayed...
Page 592 (L, Imp. qt.) Drain and refill Without filter 4.8 (4.5, 4.0) (Reference) With filter 5.0 (4.7, 4.1) Toyota Genuine Motor Oil or equivalent Oil grade: P. 544 Engine oil type ILSAC multigrade engine oil Recommended oil viscosity: SAE-5W-20 or SAE-0W-20...
