Maintenance

TO ADD ENGINE OIL TO THE CRANKCASE

1. Place the unit on a firm, level surface.
2. Remove the Left Side Service Cover.
3. Remove the oil fill cap located on the bottom of the engine
crankcase.
4. Add the recommended engine oil slowly, stopping frequently to
check the level. The full level is the base of the threads in the filler
neck. DO NOT OVERFILL!
5. Replace the oil fill cap and tighten.
6. Always check the oil level before starting the generator engine.
n
DO NOT overfill the engine crankcase with
oil. High oil pressure may result, causing
premature engine wear and damage.
Figure 9 - Oil Fill
FULL OIL LEVEL
IS THE BOTTOM
OF THESE
THREADS
OIL FILL
CAP
10

GENERATOR MAINTENANCE

Proper care will ensure maximum performance of your generator.
Generator maintenance consists of keeping the unit clean and dry.
Operate and store the unit in a clean dry environment where it will not
be exposed to excessive dust, dirt, moisture or any corrosive vapors.
Cooling air slots in the generator must not become clogged with snow,
leaves, or any other foreign material.
Check the cleanliness of the generator frequently and clean when
dust, dirt, oil, moisture or other foreign substances are visible on its
exterior surface.
Never insert any object or tool through the air cooling slots, even
if the engine is not running.
DO NOT use a garden hose to clean the generator. Water
can enter the engine fuel system and cause problems. In
addition, if water enters the generator through cooling air
slots, some water will be retained in voids and crevices of the
rotor and stator winding insulation. Water and dirt buildup on
the generator internal windings will eventually decrease the
insulation resistance of these windings.

GENERATOR MAINTENANCE SCHEDULE

Follow the recommended service schedule; to order replacement
parts call 1-888-436-3722.
Each
Use
Fuel Level X
Oil Level X
Check Air Filter X
*Change Engine Oil
**Clean Air Filter
Check Spark Plug
Check Muffler
Inspect and Clean
Spark Arrestor
Replace Spark Plug
Replace Fuel Filter
* Perform initial oil change after the first five (5) hours of operation
** Clean the air filter more often if operating in dusty or sandy conditions.
Replace as necessary.
NOTE:
NOTE:
Every 100 Every 6
Hours Months
X
X
X
X
Each
Year
X
X
X
