R-410A
ZW SERIES W/SMART EQUIPMENT™
3 - 5 Ton
60 Hertz
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preceding Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Side Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Compressors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Power And Control Wiring. . . . . . . . . . . . . . . . . . . . . . . . . 17
Optional Electric Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Optional Gas Heat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Options/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Economizer Sequences . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Dry Bulb Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Single Enthalpy Changeover. . . . . . . . . . . . . . . . . . . . . . . 29
Dual Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . 29
Auto. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
1 ZW-A3 thru -A5 Unit Limitations . . . . . . . . . . . . . . . . . . . . 7
2 Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 ZW-A3 thru -A5 Unit Accessory Weights . . . . . . . . . . . . . 8
5 ZW-A3 thru -A5 Unit Clearances . . . . . . . . . . . . . . . . . . 11
6 Side Duct Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7 Left/End Duct Dimensions . . . . . . . . . . . . . . . . . . . . . . . . 14
8 Control Wire Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
9 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
10 Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
11 Electric Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . 25
12 Gas Pipe Sizing - Capacity of Pipe . . . . . . . . . . . . . . . . . 26
13 Gas Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . . . 27
15 Supply Air Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
1 Unit Shipping Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Condenser Covering . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Compressor Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 Component Location (ZW-A3 Shown) . . . . . . . . . . . . . . . 6
5 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
6 Unit 6 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 Center of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
8 ZW-A3 thru -A4 Physical Dimensions . . . . . . . . . . . . . . . 9
9 ZW-A5 Physical Dimensions . . . . . . . . . . . . . . . . . . . . . 10
11 ZW-A3 thru -A5 Unit Electrical Entry . . . . . . . . . . . . . . . 13
14 ZW-A3 thru -A5 Roof Curb . . . . . . . . . . . . . . . . . . . . . . . 14
15 ZW-A3 thru -A5 Transition Roof Curb . . . . . . . . . . . . . . 15
16 Side Panels With Hole Plugs . . . . . . . . . . . . . . . . . . . . . 15

TABLE OF CONTENTS

Free Cooling Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Power Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Airflow Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Air Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Checking Air Quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Cooling Sequence Of Operation . . . . . . . . . . . . . . . . . . . . 44
No Outdoor Air Options . . . . . . . . . . . . . . . . . . . . . . . . . 44
Cooling Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . 44
Electric Heating Sequence Of Operations . . . . . . . . . . . . 45
Electric Heat Operation Errors . . . . . . . . . . . . . . . . . . . . 46
Gas Heating Sequence Of Operations . . . . . . . . . . . . . . . 47
Ignition Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Gas Heating Operation Errors . . . . . . . . . . . . . . . . . . . . 47
Start-Up (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Start-Up (Gas Heat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Checking Gas Heat Input . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Charging The Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Control Board Navigation Components . . . . . . . . . . . . . . . . . 51
Start-Up Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
LIST OF TABLES
19 RPM Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
20 Indoor Blower Specifications . . . . . . . . . . . . . . . . . . . . . 40
21 Power Exhaust Specifications . . . . . . . . . . . . . . . . . . . . 40
22 Motor Sheave Datum Diameters . . . . . . . . . . . . . . . . . . 42
23 Additional Static Resistance . . . . . . . . . . . . . . . . . . . . . . 43
24 Electric Heat Limit Setting . . . . . . . . . . . . . . . . . . . . . . . . 46
25 Electric Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . 46
26 Gas Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . 48
27 Gas Rate Cubic Feet Per Hour . . . . . . . . . . . . . . . . . . . . 50
28 Gas Heat Stages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
29 Smart Equipment™ UCB Details . . . . . . . . . . . . . . . . . . 52
31 Ignition Control Flash Codes . . . . . . . . . . . . . . . . . . . . . 58
LIST OF FIGURES
17 Return Downflow Plenum With Panel . . . . . . . . . . . . . . 16
18 Discharge Panel In Place . . . . . . . . . . . . . . . . . . . . . . . . 16
20 Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
21 Field Wiring Disconnect . . . . . . . . . . . . . . . . . . . . . . . . . 18
22 Typical Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . 19
23 Side Entry Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . 26
24 Bottom Entry Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . 26
25 SE-ECO1001-0 Economizer Controller . . . . . . . . . . . . . 31
26 Belt Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
28 Dry Coil Delta P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
29 Typical Flame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
30 Typical Two Stage Gas Valve . . . . . . . . . . . . . . . . . . . . 51
31 Unit Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
