Exos® E 4U106 Hardware
Installation and Maintenance Guide
Abstract
This guide describes initial hardware setup for Seagate Exos 4U106 controller enclosures and disk enclosures. It also
describes removal and installation of customer-replaceable components. The guide is intended for use by storage
system administrators familiar with servers and computer networks, network administration, storage system
administration and configurations, storage area network management, and relevant protocols.
Part Number: 83-00007495-02-01
Revision: B
Published: December 2021

Advertisement

Table of Contents
loading

Related Manuals for Seagate Exos E 4U106

Summary of Contents for Seagate Exos E 4U106

  • Page 1 Installation and Maintenance Guide Abstract This guide describes initial hardware setup for Seagate Exos 4U106 controller enclosures and disk enclosures. It also describes removal and installation of customer-replaceable components. The guide is intended for use by storage system administrators familiar with servers and computer networks, network administration, storage system administration and configurations, storage area network management, and relevant protocols.
  • Page 2 Seagate Technology LLC, for any reason, in any manner, medium, or form, in whole or in part, if not expressly authorized, is strictly prohibited. Seagate reserves the right to change, without notice, product offerings or specifications.

  • Page 3: Table Of Contents

    Contents 1 Introduction Intended audience Knowledge prerequisites Product documentation and support Safety guidelines 2 System overview Storage enclosure components Storage enclosure chassis Storage enclosure modules Storage enclosure PCBAs Optional components 3 Initial installation Installation checklist Complete installation prerequisites Unpack and prepare the storage enclosure Install the rackmount rail kit Separate the inner rails from the outer and mid rails Adjust the outer rails to the rack cabinet...
  • Page 4 6 In-service field maintenance Replace a drive carrier Replace a SAS expander module Replace a controller fan module Replace a system fan module Replace a power supply unit Replace an input/output module Replace a main bay cover Replace an auxiliary bay cover A Technical specifications B Standards and regulations International standards...
  • Page 5 Figures Figure 1 Storage enclosure with rails Figure 2 Customer-replaceable FRUs, top view Figure 3 Storage enclosure PCBAs Figure 4 Default belt straps already around the storage enclosure Figure 5 Optional lift handles attached to the storage enclosure Figure 6 Left and right lift handles Figure 7 Separated left rail assembly, inner sides facing Figure 8 Extension of left inner rail beyond mid rail Figure 9 Location of inner rail safety lock...
  • Page 6 Figure 55 Power supply unit fault LED Figure 56 Input/output module LEDs to examine for fault conditions Figure 57 Removal of drive carrier from the main bay (other drive carriers removed for clarity) Figure 58 Removal of a SAS expander module Figure 59 Removal of a controller fan Figure 60 Removal of a system fan Figure 61 Removal of the PSU without power...
  • Page 7 Tables Table 1 Installation checklist tasks Table 2 Fault LED prioritization Table 3 Host port link LED status types Table 4 Interface options Table 5 Supported terminal emulator applications Table 6 Terminal emulator serial port hex codes Table 7 Sample Linux Minicom serial port parameter settings Table 8 Terminal emulator port connection settings Table 9 Factory default network port IP addresses Table 10 Supported browsers...

  • Page 8: Introduction

    1 Introduction The Exos E 4U106 storage enclosure product is a high-capacity expansion enclosure designed for cloud and enterprise environments, using ADAPT software features. It supports high-demand storage applications that require high data availability, capacity, and performance. Each storage enclosure can be used either as a server-attached Just a Bunch of Disks (JBOD), or cabled to a RAID bunch of disks (RBOD) as an Expanded Bunch of Disks (EBOD) for added storage.

  • Page 9: System Overview

    2 System overview The Exos 4U106 storage enclosure mounts to a rack cabinet, occupying four EIA rack space units (4U) and contains up to 106 hot-swappable drive modules. CAUTION Make sure you are not connected to power at any time during installation procedures. CAUTION Only operate the storage enclosure in a dust-free environment to meet temperature control and airflow requirements.

  • Page 10: Storage Enclosure Modules

    Figure 1 Storage enclosure with rails Storage enclosure modules The storage enclosure contains a number of field-replaceable units (FRUs). Modules or components that require Seagate- authorized warranty and repair personnel to replace them are not identified. CAUTION If you partially populate the storage enclosure with disk drives, you must populate from front to back, filling an entire lateral bay before populating the next bay.

  • Page 11: Storage Enclosure Pcbas

    The storage enclosure provides separate access to two bays:  the main bay and the auxiliary bay. The PCBAs identified in this section are all assemblies that require replacement by Seagate-authorized warranty and repair personnel, other than the SAS expander modules.

  • Page 12: Optional Components

    Item Description Function Power midplane (1) Distributes power from the power supply units to each fan module and the main baseplane, sends signals to the controller module, and provides busbar connection for both drive module and controller channels SAS riser sideplane (4) Passively balances drive module paths between both SAS expander modules, one per main baseplane SAS expander module (8),...

  • Page 13: Initial Installation

    3 Initial installation Each storage enclosure installation requires the same amount of preparation to successfully mount it into your 1.2m industry- standard rack cabinet. WARNING! Heed all warnings and cautions on labeling and throughout this guide to reduce risk of personal injury or damage to equipment.

  • Page 14: Complete Installation Prerequisites

    To adhere to installation safety precautions: Site preparation 1. Use the installation checklist. 2. Clear the site for installation and secure a static-protected area. Before storage enclosure installation 1. Unpack the storage enclosure in a clear area, using appropriate safety precautions. 2.

  • Page 15: Unpack And Prepare The Storage Enclosure

    CAUTION The storage enclosure ships in a partially-populated state. All PCBAs and FRUs ship in the storage enclosure, but the disk drives do not. It is very heavy, so handle with care and adhere to Seagate recommendations. There are two primary packing configurations: a three-piece or a regular slotted container. Neither configuration includes the drive modules, which ship separately, based on system configuration: Single drive modules, 10-packs, or 24-packs.

  • Page 16: Figure 4 Default Belt Straps Already Around The Storage Enclosure

    To unpack the enclosure: 1. Prepare the site for the storage enclosure installation. This includes meeting all product specifications and providing a clean, clear, static-protected environment prior to unpacking the storage enclosure. 2. Examine packaging for damage. This includes cuts, water damage, or evidence of mishandling during shipment. 3.

  • Page 17: Install The Rackmount Rail Kit

    7. To use the default belt straps, perform the following actions: a. Position one person at the front to grip the front belt strap securely by both loops. b. Position one person at each rear corner to grip both rear belt straps by the loops on that side. c.

  • Page 18: Separate The Inner Rails From The Outer And Mid Rails

    NOTE Allocate and maintain a 1.7m or 5.58 ft safe distance to mount or remove a storage enclosure into a rack. You must take all appropriate rack cabinet safety precautions before mounting a storage enclosure into a rack. CAUTION Observe all of the following directives: Always place the rack cabinet on a flat, leveled surface.

  • Page 19: Figure 7 Separated Left Rail Assembly, Inner Sides Facing

    Item Description Item Description Front mount bracket End cap Outer rail Slotted screw holes Ball bearing retainer T-pin keyholes Rear mount bracket Safety lock Mid rail, slides within outer rail Inner rail Figure 7 Separated left rail assembly, inner sides facing To separate the inner rails from the outer and mid rail sub-assemblies: 1.

  • Page 20: Figure 8 Extension Of Left Inner Rail Beyond Mid Rail

    Figure 8 Extension of left inner rail beyond mid rail 5. Turn the left rail assembly over, then press the safety lock to disengage the inner rail. Figure 9 Location of inner rail safety lock 6. Slide out the left inner rail until it separates from the outer rail subassembly, setting it aside. 7.

  • Page 21: Adjust The Outer Rails To The Rack Cabinet

    Figure 10 Location of mid rail release switch lever 8. Rotate the mid rail release switch lever to release it, then slide the left mid rail back until fully retracted onto the outer rail. 9. Set aside the left outer rail subassembly near the left inner rail. 10.

  • Page 22: Figure 11 Distance Measurement Of Rack Inside Post-To-Post Depth

    To adjust the outer rails to the rack cabinet: 1. Facing the left side of the rack cabinet, measure the distance of the post-to-post depth between the inner side of the rear and front rack posts. Figure 11 Distance measurement of rack inside post-to-post depth 2.

  • Page 23: Figure 13 Measurement Of Rail From Rear To Front Mount Bracket

    5. Measure the rail distance from the inside of the front mount bracket to inside of the back mount bracket to determine if it matches the distance between rack posts. Figure 13 Measurement of rail from rear to front mount bracket 6.

  • Page 24: Install The Outer Rails In The Rack Cabinet

    11. Attach the CMA B bracket with the proper orientation to the right outer rail using four (4) M4 Panhead screws, tightening with a #2 Phillips-head screwdriver to a torque of 18 lbf-in (2.0 N-m). Figure 15 Alignment of CMA B bracket to rear outer rail bracket holes alignment and attachment Install the outer rails in the rack cabinet WARNING! If you do not properly install and securely fasten the rack rails according to this procedure, you risk serious personal injury and could damage the storage enclosure.

  • Page 25: Figure 16 Attach The Rear Of The Outer Right Rail Assembly

    To install the outer rails in the rack cabinet: 1. Verify that you assembled the rack rails according to prior tasks, orienting it with embossed arrows pointing upward. 2. Complete the following actions to insert the right outer rail assembly as shown to attach it to the rear post on the right side of the rack cabinet: a.

  • Page 26: Figure 17 Right Front Post Detail Of The Inserted Outer Right Rail Assembly

    b. Clip the front mount bracket spring onto the front rack post so that the outer sleeve, which mates to either a round or square mounting hole, snaps fully into place. c. Confirm that the mounting bracket fully seats in the mounting holes by verifying that the outer sleeve fully extends and is flush with the fixed inner pin.

  • Page 27: Attach The Inner Rails To The Storage Enclosure

    b. (Optional) Insert a cage nut in the front rack post just below it in the allocated 4U space, then make sure the nut spring is fully engaged in the post hole. Reserve this cage nut for use during non-operating transport of the storage enclosure. Figure 18 Location for cage nut near top of allocated 4U space 5.

  • Page 28: Figure 19 Left And Right Inner Rail Edge Details

    To attach the inner rails to the storage enclosure: 1. Examine the inner rails, locating the smooth inner edge of the rail, the flanged outer edge, and the rear top notch. Figure 19 Left and right inner rail edge details 2.

  • Page 29: Install The Storage Enclosure

    6. Repeat the process for the right inner rail, using the proper orientation. 7. Locate the CMA A bracket in the CMA shipping box, then orient it so you can see the part number etched on it. 8. Facing the rear of the storage enclosure, locate the two holes on the right side of the chassis, above the CMA shelf. 9.

  • Page 30: Figure 23 Align Inner Rails With Mid And Outer Rails, Detail

    Make your approach with the mechanical lift level, straight, and parallel to the rack cabinet. Any skew, warp, or tilt prevents the inner rails attached to the storage enclosure from properly engaging the outer rails in the rack cabinet. Required equipment Retractable tape measure Mechanical lift Storage enclosure with attached inner rails...

  • Page 31: Figure 24 Leaf Spring Latch Engaged, Extension Of Mid Rail To Fully Forward And Locked Position

    IMPORTANT Retention against the inner leaf spring is essential for proper rail sequencing and full engagement of the mid rail on the inner rail. Figure 24 Leaf spring latch engaged, extension of mid rail to fully forward and locked position c.

  • Page 32: Install The Cma And Crossbar

    6. Complete the following actions to begin insertion of the storage enclosure into the rack cabinet: a. Facing the front of the enclosure, carefully exert even pressure on both sides of the storage enclosure front, inserting the storage enclosure until it locks into the service position with an audible click. b.

  • Page 33: Figure 26 Attachment Of The Cma Bracket Assembly To The Cma A Bracket On The Chassis

    Required equipment Identification CMA bracket assembly Crossbar #2 Phillips-head screwdriver, 12-in length (Optional) Panhead screw, M5 0.8x4mm length (Optional) Truss head screws, 10-32x3/4 in length To install the CMA and crossbar: 1. Facing the rear of the rack cabinet, grasp the CMA bracket assembly so that arrows by embossed letters point upward and are visible to you, then fully extend the CMA bracket with the front end in your right hand.

  • Page 34: Figure 27 Insertion Of Cma Bracket Assembly Into Cma B Bracket On The Outer Rail

    4. Route the portion of the CMA bracket assembly in your left hand inward until it clips to the CMA B bracket that you previously installed on the outer rail. Figure 27 Insertion of CMA bracket assembly into CMA B bracket on the outer rail 5.

  • Page 35: Figure 29 Direction To Tighten Crossbar Thumbscrews

    Figure 29 Direction to tighten crossbar thumbscrews 8. (Optional) For non-operating transport of the rack cabinet, complete the following steps: a. Return to the front of the rack cabinet. b. Lower the pull handle, and then insert and tighten two (2) Truss-head screws per side in the available screwholes on the rack ear to a torque of 35 lbf-in (3.95 N-m).

  • Page 36: Install Drive Carriers In The Storage Enclosure

    TIP Use the QR code on the included Getting Started sheet to access related storage enclosure documentation online. Install drive carriers in the storage enclosure Seagate provides drive carriers to protect each drive module and connect each drive module to the baseplane after vertical insertion into a slot.

  • Page 37: Figure 32 Front Half Of Unpopulated Main Bay

    Figure 32 Front half of unpopulated main bay 4. Select the first drive carrier from the static-protected area you used when unpacking the storage enclosure. 5. Go to the right side of the open storage enclosure, so that the auxiliary bay is to the top of your workspace. 6.

  • Page 38: Figure 34 Required Installation Of First Complete Row Of Drive Carriers

    Figure 34 Required installation of first complete row of drive carriers 9. Firmly press the drive carrier into the mating connector on the baseplane. 10. Close and press down on the drive carrier handle until you engage the locking mechanism. 11.

  • Page 39: Test Enclosure Connections

    Figure 36 Auxiliary bay latch g. Continue insertion of the final 10 drives to complete population of the auxiliary bay using the same progression from top to bottom and from front to back. h. Replace the auxiliary bay cover, latching it firmly in place. 13.

  • Page 40: Route Power Cords From The Power Supply Units

    IMPORTANT Use only Seagate or OEM-qualified fibre channel or HD mini-SAS (SFF-8644) x4 data cables that are at least 3m (9.83 ft) in length and do not exceed 5m (16.4 ft) in length to connect to the SAS ports on each controller module.

  • Page 41: Figure 37 Location Of Cable Capture Clip Release Screw

    Figure 37 Location of cable capture clip release screw 4. Route the outer power cord just inside the outer fan and up to the clip, allowing a minimum of slack. 5. Route the inner power cord just inside the third fan and up to the clip, allowing a minimum of slack. Figure 38 Power cord routing up to cable capture clip 6.

  • Page 42: Route Data Cables From The Controller Module

    Figure 39 Final power cord routing 8. Proceed with routing data cables in the next tasks, leaving the power cord plugs for future connection when you complete all other cabling tasks and are fully ready to test your connections. Route data cables from the controller module The storage enclosure chassis retains cable capture mechanisms for securing data cables to the chassis.

  • Page 43: Figure 40 Open Cable Capture Arms On Chassis

    Figure 40 Open cable capture arms on chassis 4. Complete the following actions to route four mini-SAS data cable pairs to each of the controller modules: a. Route the first four data cable pairs, numbered 1 through 4, to the 12Gb SAS ports on the outer controller module, labeled data ports DP0, DP1, DP2, and DP3, respectively.

  • Page 44: Figure 42 Route For Sample Data Cables On Either Side Of The Cma Cable Capture Arm

    5. (Optional, when enabled) Complete the following actions to route an Ethernet cable to each of the controller modules: a. Route the first Ethernet cable, numbered 9, to the Ethernet port on the outer controller module. b. Route the second Ethernet cable, numbered 10, to the Ethernet port on the inner controller module. Figure 42 Route for sample data cables on either side of the CMA cable capture arm 6.

  • Page 45: Route Enclosure And Expansion Data Cables

    Figure 43 Sample HBA data and management connections 9. (Optional, when enabled) Connect the Ethernet cables numbered 9 and 10 to the host system or management network. Route enclosure and expansion data cables The storage enclosure supports up to three (3) expansion enclosures and several methods for connectivity to a switch or the host system.

  • Page 46: Figure 44 Sample Reverse Cabling Method Among Host Switches And Expansion Modules

    c. Connect an approved mini-SAS data cable from SAS port C in the first expansion enclosure, 1A, as the second output and using each additional SAS port C as the output side. d. Connect the cable's other end to SAS port A in the second expansion enclosure, 2A. e.

  • Page 47: Route And Connect Power Cords And Data Cables

    Figure 45 Sample invalid loop (in red) among host switches and expansion modules Route and connect power cords and data cables This task will maximize space, provide for minimal cable crossover, and enable in-service maintenance. NOTE The following cable configuration is only a sample configuration and changes, based on individual system requirements.

  • Page 48: Figure 46 Close All Cma Bracket Clips

    Figure 46 Close all CMA bracket clips 9. Connect the Ethernet cables numbered 9 and 10 to the host system or management network. 10. Facing the front panel, press both safety lock switches to release the rails. 11. Carefully exert even pressure on both sides of the storage enclosure front and continue insertion all the way into the rack until it locks in the storage position.

  • Page 49: Operation

    4 Operation The storage enclosure management interface allows for provisioning, monitoring, and managing the storage enclosure. It uses the storage enclosure processor (SEP) and associated monitoring and control logic, such as the SCSI Enclosure Services (SES) service, to identify, assess, and diagnose storage enclosure hardware systems. CAUTION Never attempt to power on or operate the storage enclosure until it reaches the proper operating temperature and humidity requirements identified in the Environmental Requirements...

  • Page 50: Interpret System Leds

    with redundant power. IMPORTANT The storage enclosure design requires two redundant power supply units (PSUs). You must plug each power cord into an independent power distribution unit (PDU) that connects to an uninterruptible power system. Figure 47 Route power cables to redundant PDUs 2.

  • Page 51: Interpret Input/Output Module Leds

    In the case of a system fault condition, identified in the state column with an asterisk (*), troubleshoot the fault. LED number: Name Color State Status System powered on 1: System power Green System powered off Flashing System unit identification (UID) active 2: System ID Blue Normal state, no query for UID active...

  • Page 52: Storage Enclosure Management

    IOM LEDs Type Color State Status IOM hardware fault Hardware fault Amber IOM hardware is functioning properly IOM is functioning properly Hardware normal Green Flashing Part of sequence as IOM comes online IOM power is off Figure 49 Input/output module LEDs Additional LEDs on the IOM relate to host connectivity.

  • Page 53: Command-Line Interface Usage

    OS recognizes the USB device and can connect to a controller module. To install a device driver: 1. Navigate to https://www.seagate.com/support/systems/general-support/ and locate the device driver for download. 2. Download the zip file to the management computer.

  • Page 54: Table 5 Supported Terminal Emulator Applications

    Once you successfully install and run a supported terminal emulator, the controller presents a single serial port that uses the related USB vendor identification (ID) and product ID hex codes. Table 5 Supported terminal emulator applications Operating system Supported application Microsoft Windows (all versions) HyperTerminal, TeraTerm, PuTTY Linux (all versions)

  • Page 55: Table 8 Terminal Emulator Port Connection Settings

    An installed and tested Windows USB device driver to connect to the controller module USB port, by using the native USB  serial driver for Windows 10/Server 2016 or higher, or by downloading and installing the Seagate device driver. To configure Windows for serial communication: 1.

  • Page 56: Table 9 Factory Default Network Port Ip Addresses

    Table 9 Factory default network port IP addresses IP version Controller 0A addresses Controller 0B addresses IP address: 10.0.0.2 IP address: 10.0.0.3 IPv4 IP subnet mask: 255.255.255.0 IP subnet mask: 255.255.255.0 Gateway IP address: 10.0.0.1 Gateway IP address: 10.0.0.1 Autoconfig: Enabled Autoconfig: Enabled...

  • Page 57: Storage Management Console Usage

    Storage Management Console usage Seagate provides a user-friendly interface that provides the means to configure, monitor, and manage the storage system: the Storage Management Console (SMC). Access it through a supported browser, then use it to complete initial configuration of the management host, then monitor and manage the storage enclosure.
  • Page 58 NOTE By default, your system is loaded with self-signed certificates. You should generate new self-signed certificates on each controller, using the create certificate CLI command. Expect browser warnings about security or privacy concerns related to self-signed or untrusted certificates or invalid certificate authorities. Bypass such warnings, if you are confident of a secure connection.

  • Page 59: Update Firmware

    TIP Use the QR code on the included Getting Started sheet to access related storage enclosure documentation online. Update firmware All modules within the storage and expansion enclosure system, such as drives, controllers, power supply units, and fans, must be compatible and must run on firmware revisions from the same Universal Storage Module™ (USM) firmware release. After installing the storage enclosure and applying power for the first time, verify that all modules and drives within the storage and expansion enclosures have the most current USM firmware.

  • Page 60: Hardware Installation And Configuration Issues

    IMPORTANT Do not use this section for configured systems already interacting with production data. For the kind of assistance you need in such cases, contact Seagate for technical support. Address initial start-up issues You must successfully complete the installation tasks in the identified sequence. You must use the power cords provided with the system and install interface cables that meet system requirements.

  • Page 61: Interpret Fru Fault Condition Leds

    Interpret FRU fault condition LEDs Throughout the storage enclosure, amber LEDs indicate a fault condition. Some FRUs are more complex than others, so have more than one fault condition. Those items in the state column with an asterisk (*) indicate a fault condition. Drive module fault LED The drive module uses an amber fault LED to identify various states.

  • Page 62: System Fan Module Fault Led

    Color State Status None No AC power is present or the controller fan module is functioning normally. The controller fan module has a hardware fault. Amber Flashing AC power is present and the controller fan module is undergoing system identification. Figure 53 Controller fan module fault LED, rotated orientation System fan module fault LED Each system fan module has an amber fault LED.

  • Page 63: Power Supply Unit Status Led

    Color State Status None No AC power is present or the system fan module is functioning normally. Fan activity indicates AC power is present. The system fan module has a hardware fault. Amber Flashing AC power is present and the system fan module is undergoing system identification. Figure 54 System fan module fault LED Power supply unit status LED Each power supply unit (PSU) has a bitonal status LED.

  • Page 64: Input/Output Module Fault Leds

    Color State Status None No AC power is present. Green AC power is present and the PSU is functioning normally. The PSU has a hardware fault: over temperature, over voltage, or over current. Amber Flashing A PSU firmware download is in progress. Figure 55 Power supply unit fault LED Input/output module fault LEDs The input/output module (IOM) has a number of ports, each with independent status LEDs.

  • Page 65: Identify Fault Conditions

    Consult your solution service documentation for details on how to minimize system disruption during service replacement of a controller module. Fault conditions include the following: Logs or events indicate a fault condition for the IOM. The OK to remove LED on the IOM is off. The Hardware fault LED for one of the four 12Gb SAS ports on the IOM is steady or flashing amber.

  • Page 66: Isolate Hardware And Connectivity Faults

    Table 11 Non-fault conditions (continued) Symptom Cause Recommended action Amber flashing LED: 1 second on, 1 second off Amber flashing LED: 3 seconds on, 1 off Drive module reconstruction No action required Green LED flickers PSU LEDs, no fault conditions Green LED on AC power is present, PSU No action required...

  • Page 67: Isolate System Application Faults

    Isolate system application faults System application faults generally fall into two categories: drive module and array faults or input/output module (IOM)cache faults. In the case of a faulty IOM or a power loss, the cache memory flushes to nonvolatile memory. During the process of writing the cache to nonvolatile memory, only those components used in the flush process receive super-capacitor power while the Cache LED momentarily flashes.

  • Page 68: Take Corrective Action

    4. For still unaddressed issues, proceed to the next section and take the recommended corrective action, based on the symptom. This may mean obtaining a replacement FRU of the same type before replacing the faulty module. Take corrective action After you follow the process above and isolate the fault to an area of the storage enclosure or to a particular module, use the following chart to determine the type of corrective action you should take.
  • Page 69 4. If the PSU is still failing, remove it, wait one (1) minute, then reseat it. 5. If the PSU is still failing, replace it within the specified six (6) minutes. 6. If the power fault condition persists, contact Seagate for support. Fault-Rear panel LED is A fault condition related 1.
  • Page 70 Table 14 Corrective action for fault conditions (continued) Symptom Cause Recommended action Thermal monitoring and control, continued Increased fan speed is Increases in fan speed are 1. Look for airflow restrictions at the front and rear of the storage enclosure. Recommendation: If a rack door blocks airflow by more than 60%, make sure greater than 12K RPM associated with reaching a...

  • Page 71: In-Service Field Maintenance

    6 In-service field maintenance You may service the identified storage enclosure FRUs and still maintain continuous operation during the replacement, but with two very important qualifiers: You must determine whether your system allows for continuous operation during service replacement of the storage enclosure drive modules without interrupting access to enclosure file systems.

  • Page 72: Replace A Drive Carrier

    a. Keep a static-protected work surface clear of clutter, including plastic, vinyl, and foam. b. Transport and store FRUs in static-safe containers. c. Keep FRUs in their containers until reaching a clear, static-protected work surface. d. Always wear a grounded ESD wrist strap that meets a minimum 1 megohm (± 10 percent) resistance standard and that is snug against your skin.

  • Page 73: Figure 57 Removal Of Drive Carrier From The Main Bay (Other Drive Carriers Removed For Clarity)

    b. For drive carriers in the auxiliary bay: After locating the auxiliary bay cover's front latch, release it by pressing the latch in to release the cover, then lift the cover away and set it aside. 7. Locate the drive carrier you need to replace. The fault LED for each drive carrier is a steady or blinking amber for a fault condition.

  • Page 74: Replace A Sas Expander Module

    18. Facing the front panel, press both safety lock switches to release the rails. 19. Carefully exert even pressure on both sides of the storage enclosure front and continue insertion all the way into the rack until it locks in the storage position. Do not force insertion, which could damage the rails. 20.

  • Page 75: Replace A Controller Fan Module

    Figure 58 Removal of a SAS expander module 10. While maintaining proper static protection, remove the new SAS expander module from its static-protected container. 11. Inspect the SAS expander module carefully to make sure it is not damaged in any way, paying particular attention to the connectors.

  • Page 76: Figure 59 Removal Of A Controller Fan

    CAUTION Do not remove covers from any FRU. There is a danger of electric shock inside. Return the FRU to your supplier for repair. To remove and replace a controller fan module: 1. If you plan on removing all controller fan modules, properly shut down the storage enclosure. 2.

  • Page 77: Replace A System Fan Module

    11. Inspect the controller fan module carefully to make sure it is not damaged or bent in any way, paying particular attention to connector pins. 12. Properly orient the controller fan module so you can grasp the handle, then orient it to its empty slot. 13.

  • Page 78: Replace A Power Supply Unit

    Figure 60 Removal of a system fan 5. While maintaining proper static protection, remove the new system fan module from its static-protected container. 6. Inspect the system fan module carefully to make sure it is not damaged or bent in any way, paying particular attention to connector pins.

  • Page 79: Figure 61 Removal Of The Psu Without Power

    To remove and replace a power supply unit: 1. Use your management interface to halt all data input and output operations to the storage enclosure. 2. If you plan on removing both PSUs, properly shut down the storage enclosure. 3. Retrieve the new PSU in its static-protected container, ready to access and use it upon removal of the faulty one. 4.

  • Page 80: Replace An Input/Output Module

    Figure 62 Removed PSU 7. While maintaining proper static protection, remove the new PSU from its static-protected container. 8. Inspect the PSU carefully to make sure it is not damaged or bent in any way, paying particular attention to connector pins. 9.

  • Page 81: Figure 63 Input/Output Module Leds To Examine For Fault Conditions

    Item Color State Status SAS connected; one or more SAS lanes inactive; partial link up results in lower and inconsistent speed SAS host port fault Amber SAS connected; one or more SAS lanes inactive; active lanes register input or output Flashing* activity No host link connection, not a fault...

  • Page 82: Figure 64 Release Of The Input/Output Module Latch Handle

    5. If each cable does not have a numbered label, label each as you disconnect it from its port. 6. Twist the thumbscrew counter-clockwise only far enough to loosen the latch handle. 7. Pull outward, then downward on the latch handle to leverage the IOM away from the midplane. Figure 64 Release of the input/output module latch handle 8.

  • Page 83: Replace A Main Bay Cover

    Replace a main bay cover The main bay cover protects the main bay components and assists with containing airflow to cool the main bay. You can still maintain continuous operation during the replacement of the main bay cover, as long as it is within the time limit of eight (8) minutes, since the removal of the main bay cover impacts airflow in the main bay.

  • Page 84: Figure 66 Rear Half Of An Unpopulated Main Bay

    Figure 66 Rear half of an unpopulated main bay 5. After locating the main bay cover's front latch, closest to the front panel, push in on the latch to release it, then, grasping both halves, simultaneously lift them away from the hinge pin slot in an upward and outward angle toward the front panel. Figure 67 Main bay cover's front hinge pin 6.

  • Page 85: Replace An Auxiliary Bay Cover

    IMPORTANT Do not proceed until you perform a visual inspection to verify all main bay cover edges connect completely with supporting surfaces, both hinge mechanisms are at the bottom of the pin slots, and latches for both halves fully engage. 13.
  • Page 86 5. (Optional) If you need to replace the auxiliary bay cover with a new one, retrieve it from its container, inspect it for damage, and orient it so to match the final removal position of the damaged one. 6. Gently slide the auxiliary bay cover along the chassis until the rear of the cover slides under the rear retainer. 7.

  • Page 87: A Technical Specifications

    A Technical specifications Table 16 Storage enclosure dimensions Dimension type Metric units Imperial units Height, including top covers 176.40mm 6.94 in Width, excluding rails and rack ears 441.00mm 17.36 in Depth, including handles, excluding cables 1139.00mm 44.84 in Table 17 Storage enclosure FRU weights¹ FRU or component Metric units Imperial units...

  • Page 88: Table 20 Power Specifications

    Table 20 Power specifications Qualifier Type Description Power supply dimensions 38.1mm (1.50 in) high x 169.9mm (6.69 in) wide x 211.1mm (8.30 in) long Maximum output power 2000W Max output 2000W Range 200-240VAC, rated Voltage Range selection 90-264VAC, 47-63Hz, auto-ranging Frequency 50-60Hz Maximum inrush current...

  • Page 89: B Standards And Regulations

    B Standards and regulations International standards The storage enclosure complies with the requirements of the following agencies and latest editions of these standards: Table 21 Safety compliance Type Specification System product type approval UL/cUL/CE UL 60950-1; UL & cUL to UL 60950-1 CAN/CSA-C22.2 No.

  • Page 90: Index

    Index cabling LEDs cable management arm (CMA) 9-10, controller fan module fault LED method, reverse 45-46 controller module LEDs 51, method, straight-through drive fault LED power cords meeting product specifications 13, front panel LEDs route power cords power supply unit fault LED SAS expander module fault LED command-line interface (CLI) system fan module fault LED...
  • Page 91 shipping container suitable rack cabinet system airflow 9, 15, 49, 69-70, 75, 77, temperature control 9, 49, 69, 75, 77, total staff to install Index...

Table of Contents
