Cooper Lighting Halo LV20216 Specification

DESCRIPTION
A series of Open and Closed Back styled lampholders available for use with
a variety of lamp types. The clean, minimal stem and tine design of the
open back version allows the lamp to be part of the design, while the ample
closed back version removes the lamp from the design, thus creating an
all-together different aesthetic.
APPLICATION
Ideal for accent and display applications. The Open and Closed Back 50W
MR16 versions offer their own unique styling to complement any space.
SPECIFICATION FEATURES
A ... Electrical Quick Lock
Adapter
Polycarbonate housing. Attaches
electrically and mechanically
anywhere along Linea track.
B ... Arm
Round aluminum arm allows
lampholder to rotate 330° and
provides 0° to 90° vertical pivot for
maximum aiming adjustability.
C ... Lockable Tilt
Lampholder tilt can be locked in
place easily with the use of a
1.5mm allen wrench.
D ... Lampholder Body
Die Cast Aluminum housing
provides durability and good
thermal performance.
LV 2
Track Lamp Type
LV=Linea 2=Low Voltage
Track
IMPORTANT!
Lampholder is ready to install on Linea track. To install lampholder on other Cooper Lighting Track Systems, converters
and/or transformers are required.
E ... Cover Glass
Fixture provided with cover glass
(required for use with non-open
fixture rated lamps).
Labels
UL/c-UL Listed for use with Linea
Track.
A
B
02 16
Series Style Lamp
02=Span Blank= Open 16=MR16
Back
CB= Closed
Back
Specifications and Dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
Max Extension
L
W
H=2.56" [65mm]
W=2.56" [65mm]
Max Extension=
7.6" [193mm]
AH
Finish Accessories
AH=Aluminum LM20216AH=Media Holder
Haze L100 Series Lenses
L100MB Hex Cell Louver
HALO
®
Type
Date
LV202CB16
LV20216
Span
50W MR16 Accent
Flexible Track
ADV050025
01/25/2007 7:09:53 AM
