Summary of Contents for Beko QLS3682
- Page 1 Integrated Larder Fridge User manual QLS3682 EN / 58 4735 0000/AA...
- Page 2 Please read these instructions first before using your appliance Thank you for choosing a Beko appliance. Please take some time to read this user manual before using your appliance, to ensure you know how to safely operate the controls and functions.
-
Page 3: Table Of Contents
1 Your Refrigerator 4 Preparation 2 Warnings 5 Using your refrigerator Electrical requirements ......5 Temperature setting button ....12 Warning! This appliance must be Defrost ............12 earthed ............5 Changing the illumination lamp ..13 Energy saving tips ........6 Reversing the doors ......20 Compliance with WEEE Directive and 6 Maintenance and Disposing of the Waste Product: .. -
Page 4: Your Refrigerator
Your Refrigerator 1. Body shelves 2. Bulb thermostat box 3. Sliding crisper cover 4. Food storage cabin 5. Adjustable front legs 6. Egg compartment 7. Door shelf 8. Bottle shelf 9. Storage container 10. Bottle holder The figures in this manual are schematic, and they may not be in exact accordance with your product. -
Page 5: Warnings
• Do not dispose of the condition. appliance on a fire. At Beko • Ensure that the plug remains , the care and protection readily accessible. Do not use of our environment is an multiple adapter or extension ongoing commitment. -
Page 6: Electrical Requirements
• We suggest you keep these made mains lead which can instructions in a safe place for only be obtained from a Beko easy reference. authorised service agent. • This appliance can be used... -
Page 7: Energy Saving Tips
Important! Fitting A Energy saving tips Different Plug Ensure your appliance is As the colours of the wires in installed in a well ventilated the mains lead of this appliance area. may not correspond with the Ensure the time between coloured markings identifying buying chilled/frozen food the terminals in your plug... -
Page 8: Compliance With Weee Directive And Disposing Of The Waste Product
Compliance with WEEE Package information Directive and Disposing of Packaging materials of the the Waste Product: product manufactured This product complies from recyclable materials in with WEEE accordance with our National Directive (2012/19/ Environment Regulations. Do EU). This product not dispose of the packaging bears a classification materials together with the symbol... -
Page 9: Installation
Installation 3. Plug the refrigerator into the Please remember that the wall outlet. When the fridge door is manufacturer shall not be held open the fridge compartment interior liable if the information given in the light will come on. instruction manual is not observed. 4. -
Page 10: Disposing Of The Packaging
Disposing of the packaging Placing and Installation The packing materials may be 1. Install your refrigerator to a dangerous for children. Keep the place that allows ease of use. packing materials out of the reach 2. Keep your refrigerator away of children or dispose them of by from heat sources, humid places and classifying them in accordance with... -
Page 11: Placing The Refrigerator Under The Counter And Adjusting The Legs
Placing the refrigerator under the counter and adjusting the legs When you place your refrigerator, the distance between the product and the wall must be at least 30 mm, as seen in the figure. The air ventilation channels must not be blocked so that the performance of your refrigerator does not decrease. -
Page 12: Preparation
Preparation • Your refrigerator should be installed • The baskets/drawers that are at least 30 cm away from heat provided with the chill compartment must always be in use for low energy sources such as hobs, ovens, central heater and stoves and at least 5 consumption and for better storage cm away from electrical ovens and conditions. -
Page 13: Using Your Refrigerator
Using your refrigerator Temperature setting Defrost button It is normal when ice particles form The interior temperature of your on the back wall during the operation. refrigerator changes for the following These do not need to be scratched reasons; wiped out. -
Page 14: Changing The Illumination Lamp
Changing the illumination lamp To change the Bulb/LED used for illumination of your refrigerator, call your AuthorisedService. The lamp(s) used in this appliance is not suitable for household room illumination. The intended purpose of this lamp is to assist the user to place foodstuffs in the refrigerator/ freezer in a safe and comfortable way.The lamps used in this appliance... - Page 17 Note: Installation step for 2, screws for connecting the top plastic part should not be fully tightened until final left-right adjustment.
-
Page 21: Reversing The Doors
Reversing the doors... - Page 22 Maintenance and cleaning • We recommend that you switch off • To remove a freezer drawer, pull the appliance at the socket outlet it as far as possible, and then tilt and pull out the mains plug before it upwards, and then pull it out completely.
- Page 23 Troubleshooting Check this list before contacting the not balanced, which triggers the service. Doing so will save you time compressor thermic safeguard. and money. This list includes frequent The product will restart after complaints that are not related to approximately 6 minutes. If the faulty workmanship or materials.
- Page 24 • Large quantities of hot food may The food items kept in cooler compartment drawers are have been recently placed into the product. >>> Do not place hot food frozen. into the product. • The cooler compartment temperature is set to a very low • The doors were opened frequently degree.
- Page 25 the ground is sufficiently durable to Use holders and packaging materials bear the product. without free of odour. • Any items placed on the product • The foods were placed in unsealed may cause noise. >>> Remove any holders. >>> Keep the foods in items placed on the product.
- Page 26 The standard guarantee starts from the date of original purchase of the product, and lasts for a period of twelve (12) months unless Beko plc (the “Manufacturer”) agrees to extend the guarantee for the product in writing.
- Page 27 • Repairs to a product operated at any time on commercial or non-residential household premises (unless we have previously agreed to the installation environment). This guarantee is limited to the cost of repairing the product. To the extent permitted by law, the Manufacturer does not accept and will not be held liable for any financial loss incurred in connection with the failure of any product to operate in accordance with the expected standards.
- Page 28 Does Beko offer replacements? This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion, replace your product with a new product instead of carrying out a repair. Where a replacement is offered, this would normally be an identical model but when this is not possible, a model of similar specification will be provided.
- Page 29 Beko Free standing appliances come with a 12 month parts and labour guarantee as standard, Beko Built-in appliances come with a 12 month parts and labour guarantee as standard. This is extended to 24 months, free of charge, upon registration of the appliance.
- Page 30 5. Any repair/replacement of the ProSmart Inverter motor must only be carried out by an authorised Beko Service Agent (the “Service Agent”). 6. Labour for the repair/replacement of the ProSmart Inverter motor is not included in this guarantee and is chargeable directly by the Service Agent.
- Page 31 When you call us you may be required to input your serial number into your telephone keypad. For help please visit beko.co.uk/support/model-finder • The product model number is printed on the Operating Instruction Booklet / User guide • The product model and serial number is printed on the Rating Label affixed to...
- Page 32 Send us a secure message through our online contact us form. Please visit our website, click Contact Us and choose a product support topic from the list of options. Complete the required details and click send message. Product registrations For UK registrations please visit beko.co.uk/register and for the Republic of Ireland visit beko.ie/register.
