Pico Macom PFT-10 Specifications

Fiber Optic
PFT
T
he Pico Macom PFT Series of optical transmitters is available in nine output power levels, from 6 to 14dBm, allowing flexibil-
ity in numerous CATV applications. Each unit takes various combinations of input modulated RF signals and converts them
to light for distribution to nodes. With an optical wavelength of 1310nm and a bandwidth of 54~860MHz, the transmitter
supports transmission of NTSC and QAM RF signals over a single-mode optical fiber. The PFT Series optical fiber transmitters are
19˝ wide and rack mounted with a height of 1RU.
Features
• Wide bandwidth, 54~860MHz, high-performance
single-mode 1310nm optical fiber transmitter.
• Supports analog and QAM digital applications.
• Wide range laser options, from 6dBm to 14dBm
(4mW to 26mW), for multiple broadband
applications.
• Optical power monitoring of input RF and laser status.
• RS232 port.

www.picomacom.com
Series
Series
1310nm Optical Transmitters
6260 Sequence Drive San Diego, CA 92121
Ph: 858-546-5050 Toll Free: 800-421-6511 Fax: 858-546-5051
• Manual or automatic gain controls RF input level.
• Automatic gain controlled input allows unit to maintain
the same optical output with varying inputs without
distortion.
• Input voltage between 90-260Vac.
• Unit can be used for NTSC and PAL systems.
• Front panel RF test port -20dB.
• Low power consumption.
PICO MACOM
Rev. 9/07
