Pico Macom MUL-280 Specifications

Installation Tools &
Instrumentation
Auto-ranging measurement
provides simple operation for
all measurement types
Large / ˝ high 3 / ˝ digital dis-
5 3
8 4
play with 33 segment fast ana-
log bar graph provides easy to
read "at a glance" operation
Full feature multimeter allows
testing of diodes, transistors,
capacitance, DC & AC voltage
and current, frequency, resist-
ance, and continuity with
tone alert
Data hold switch saves time by
ensuring display of maximum
level without constant monitoring
Manual range override switch
disables auto-range feature for
in-range testing
Overload protected for maxi-
mum safety and guaranteed
performance
3ft. 1500V double insulated test
leads provide a low loss path
while providing shock protec-
tion for increased safety
High impact plastic case and
high visibility yellow holster
ensure durability and quick
identification
Includes 9V battery
www.picomacom.com
MUL-280
Auto-Ranging Digital Multimeter
MUL-280
Auto-Ranging Digital Multimeter
The Pico Macom MUL-280 full featured hand held auto-ranging multimeter pro-
vides a complete voltage and circuit test system in a convenient hand held case.
The MUL-280 enables an extensive array of measurement options all within one
easy to operate auto-ranging meter. The level readings display on the large LCD
screen in the form of a digital numeric readout and a bar graph for quick easy view-
ing. Standard measurements include, voltage up to 1000VDC & 750VAC, current
up to 10A, resistance up to 3.26 M-Ohm, and continuity with tone alert. Featured
measurements include diodes, transistors, capacitance, and frequency up to
200KHz providing the most complete array of testing functionality available in an
cost-effective meter. Functionality features include data-hold, overload protection,
double insulated leads and a holster that doubles as a table stand for use in test
bench applications. Pico Macom's MUL-280 full-featured hand held auto-ranging
multimeter is ideally suited for use in field and test bench environments where high
performance and reliable measurements are essential.
355 Parkside Drive San Fernando, CA 91340
Ph: 818-493-4300 Toll Free: 800-421-6511 Fax: 818-493-4433
MUL-280
E-7
Rev. 12/02
