- Page 1 INSTALLATION VX5.2E VX6.2E...
- Page 2 DEUTSCH EINBAUHINWEISE Der erste Schritt bei der Installation der Lautsprecher sollte die sorgfältige Planung sein. Folgen Sie einfach diesen Vorschlägen um das bestmögliche Resultat zu erreichen. 1. Wählen Sie eine Position für die einzelnen Komponenten, bei der das Signal am besten ohne Hindernisse im Fahrgastraum verteilt wird.
- Page 3 DEUTSCH VX6.2E, VX5.2E ANSCHLUSSDIAGRAMM (muss jeweils für die linke und rechte Fahrzeugseite vorgenommen werden) Tiefmitteltöner Zum Verstärker + rot markiert Frequenzweiche Hochtöner + rot markiert WICHTIG: Bitte achten Sie unbedingt auf die korrekte Polarität (+ oder –) aller Anschlüsse und Verbindungen.
- Page 4 DEUTSCH HOCHTÖNEREINBAU...
-
Page 5: Installation Notes
INSTALLATION NOTES The first step of installing a speaker system is thorough planning. Choose a suitable lo- cation for your speaker components carefully. Follow these suggestions to ensure proper imaging and maximum performance: 1. Choose a location that offers the least amount of obstruction between the components and your ears. Pay also attention to the position of the seats, headrests and other constructional systems in the interior space of the car. 2. Try to mount the speakers on the same arrangement. They should be installed at the same height and directly across from each other. Do not mount one speaker higher, lower, further forward or further backward from the opposite speaker. 3. The tweeter should always be installed as close as possible to the midbass speaker. 4. Always take a look behind the chosen mounting locations to ensure that there is proper clearance for the rear side of the speakers and avoid obstructions such as window tracks, wire harnesses, gas tank etc. -
Page 6: Wiring Diagram
ENGLISH VX6.2E, VX5.2E WIRING DIAGRAM (must be made for right and left side of the vehicle) Midbass Woofer To Amplifier + red marked Crossover Tweeter + red marked NOTE: Please pay attention to the correct polarity (+ or -) for all terminals and connections. -
Page 7: Tweeter Mounting
ENGLISH ENGLISH TWEETER MOUNTING... - Page 8 Audio Design GmbH Am Breilingsweg 3 · D-76709 Kronau/Germany Tel. +49 7253 - 9465-0 · Fax +49 7253 - 946510 www.audiodesign.de © Audio Design GmbH, All Rights Reserved...
