- Page 1 BPF manual.qxd 7/28/03 10:53 AM Page 1 408MHz Single-Channel Bandpass Filter Installation and Operation Manual Operation www.picomacom.com Ph:800-421-6511 Manual Rev. 07/03...
-
Page 2: Product Inspection
To insure proper installation and operation, take a moment to read this guide before proceeding with the installation. If you have any questions or comments about the BPF bandpass filter, please contact your dealer or have him contact the PICO MACOM Service Center at these phone numbers: 800-421-6511, 818-493-4300. - Page 3 BPF manual.qxd 7/28/03 10:54 AM Page 3 11. Power Sources: This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult your appli- ance dealer or local power company.
- Page 4 Rev. 07/03 408MHz Single-Channel Bandpass Filter The Pico Macom BPF is an extremely cost and space effective professional grade single-channel bandpass filter. The BPF was designed to provide an additional level of bandpass filtering when used in conjunction with Pico Macom’s XBS series of single channel amplifiers, especially in applications...
-
Page 5: Specifications
BPF manual.qxd 7/28/03 10:55 AM Page 5 Specifications Channels: Frequency Range: Bandwidth: Insertion Loss: Low-band: Mid-band: High-band: Super-band: 7 dB maximum Hyper-band: 6.5 dB maximum Impedance: Finish: Adjacent Channel Rejection: Upper adj. picture: Upper adj. sound: Lower adj. sound: Lower adj. picture:... -
Page 6: Operation And Controls
BPF manual.qxd 7/28/03 10:55 AM Page 6 Operation and Controls Front and Rear Panels LOWER CHANNEL SOUND (HI-Q TRAP): These controls are preset at the factory to reduce the audio RF carrier level of the lower adjacent channel and should not be adjusted by the user. -
Page 7: Installation Procedure
It is recommended that assistance be available to safely install equipment in equipment racks. Chassis must be fastened securely in equipment rack before populating with modules. 1. Install BPF in equipment rack (equipment rack sold separately) by supporting the bottom and rear of the unit at the desired elevation in rack. -
Page 8: Warranty
We will issue an invoice for the List Price of the loaner unit plus shipping costs. When you receive the loaner unit, pack the failed unit in the loaner unit’s box and ship it freight prepaid to Pico Macom for repair. When you receive the repaired unit, a new RMA number will be provided in the box. Carefully pack the loaner unit and affix the new RMA number on the box and ship it back to us for full credit excluding shipping costs.
