00_CV_3P232550-9C.fm Page 1 Thursday, September 16, 2010 11:21 AM
MODEL
RXL20J2V1B
RXL25J2V1B
RXL35J2V1B
RXLG25K2V1B
RXLG35K2V1B
OUTDOOR UNIT
INSTALLATION MANUAL
R410A Split Series
Installation manual
Installationsmanual
Installationshandbok
Installasjonshåndbok
Asennusohje
Installierungshandbuch
Manuel d'installation
Ðóêîâîäñòâî ïî ìîíòàæó
Instrukcja montazu
Installatiehandleiding
Paigaldusjuhend
Montavimo vadovas
Uzst d šanas pam c ba
Advertisement
Table of Contents
Related Manuals for Daikin RXL20J2V1B
Summary of Contents for Daikin RXL20J2V1B
- Page 1 00_CV_3P232550-9C.fm Page 1 Thursday, September 16, 2010 11:21 AM OUTDOOR UNIT R410A Split Series INSTALLATION MANUAL Installation manual Installationsmanual Installationshandbok Installasjonshåndbok Asennusohje Installierungshandbuch Manuel d’installation Ðóêîâîäñòâî ïî ìîíòàæó Instrukcja montazu Installatiehandleiding Paigaldusjuhend Montavimo vadovas Uzst d šanas pam c ba MODEL RXL20J2V1B RXL25J2V1B RXL35J2V1B RXLG25K2V1B RXLG35K2V1B...
- Page 2 DAIKIN INDUSTRIES CZECH REPUBLIC s.r.o. RXL20J2V1B, RXL25J2V1B, RXL35J2V1B, RXLG25K2V1B, RXLG35K2V1B Low Voltage 2006/95/EC Electromagnetic Compatibility 2004/108/EC * DAIKIN,TCF,015N15/04-2011 DEKRA (NB0344) 74736-KRQ/EMC97-4957 Takayuki Fujii Managing Director U Nove hospody 1/1155, 301 00 Plzen Skvrnany, 1st of Jul. 2011 Czech Republic...
-
Page 3: Safety Precautions
01_EN_3P232550-9C.fm Page 1 Thursday, September 16, 2010 11:23 AM Safety Precautions • The precautions described herein are classified as WARNING and CAUTION. They both contain important information regarding safety. Be sure to observe all precautions without fail. • Meaning of WARNING and CAUTION notices WARNING .. -
Page 4: Precautions For Selecting The Location
01_EN_3P232550-9C.fm Page 2 Thursday, September 16, 2010 11:23 AM Accessories Accessories supplied with the outdoor unit: (B) Refrigerant charge label (A) Installation Manual Precautions for Selecting the Location 1) Choose a place solid enough to bear the weight and vibration of the unit, where the operation noise will not be amplified. 2) Choose a location where the hot air discharged from the unit or the operation noise will not cause a nuisance to the neighbors of the user. -
Page 5: Outdoor Unit Installation Drawings
01_EN_3P232550-9C.fm Page 3 Thursday, September 16, 2010 11:23 AM Outdoor Unit Installation Drawings Max. allowable length Min. allowable length 1.5m Max. allowable height Additional refrigerant Wrap the insulation pipe with required for refrigerant the finishing tape from bottom 20g/m to top. pipe exceeding 10m in length. -
Page 6: Precautions On Installation
01_EN_3P232550-9C.fm Page 4 Thursday, September 16, 2010 11:23 AM Installation Guidelines • Where a wall or other obstacle is in the path of outdoor unit’s intake or exhaust airflow, follow the installation guidelines below. • For any of the below installation patterns, the wall height on the exhaust side should be 1200mm or less. Wall facing one side Walls facing two sides More than 50... -
Page 7: Flaring The Pipe End
01_EN_3P232550-9C.fm Page 5 Thursday, September 16, 2010 11:23 AM Outdoor Unit Installation Flaring the pipe end. (Cut exactly at 1) Cut the pipe end with a pipe cutter. right angles.) Remove burrs 2) Remove burrs with the cut surface facing Flaring downward so that the chips do not enter the pipe. - Page 8 01_EN_3P232550-9C.fm Page 6 Thursday, September 16, 2010 11:23 AM Purging air and checking gas leakage. • When piping work is completed, it is necessary to purge the air and check for gas leakage. WARNING 1) Do not mix any substance other than the specified refrigerant (R410A) into the refrigeration cycle. 2) When refrigerant gas leaks occur, ventilate the room as soon and as much as possible.
- Page 9 01_EN_3P232550-9C.fm Page 7 Thursday, September 16, 2010 11:23 AM Outdoor Unit Installation Refilling the refrigerant. Check the type of refrigerant to be used on the machine nameplate. Precautions when adding R410A Fill from the liquid pipe in liquid form. It is a mixed refrigerant, so adding it in gas form may cause the refrigerant composition to change, preventing normal operation. 1) Before filling, check whether the cylinder has a siphon attached or not.
-
Page 10: Standby Electricity Saving
01_EN_3P232550-9C.fm Page 8 Thursday, September 16, 2010 11:23 AM Standby Electricity Saving The standby electricity saving function turns OFF power supply to the outdoor unit and sets the indoor unit into standby electricity saving mode, thus educing the power consumption of the air conditioner. CAUTION The standby electricity saving function cannot be used for models other than the specified ones. -
Page 11: Pump Down Operation
01_EN_3P232550-9C.fm Page 9 Thursday, September 16, 2010 11:23 AM Pump Down Operation In order to protect the environment, be sure to pump down when relocating or disposing of the unit. 1) Remove the valve cap from liquid stop valve and gas stop valve. Hexagonal 2) Carry out forced cooling operation. - Page 12 01_EN_3P232550-9C.fm Page 10 Thursday, September 16, 2010 11:23 AM Wiring WARNING 1) Do not use tapped wires, stranded wires, extension cords, or starburst connections, as they may cause overheating, electrical shock, or fire. 2) Do not use locally purchased electrical parts inside the product. (Do not branch the power for the drain pump, etc., from the terminal block.) Doing so may cause electric shock or fire.
-
Page 13: Test Run And Final Check
01_EN_3P232550-9C.fm Page 11 Thursday, September 16, 2010 11:23 AM Test Run and Final Check Trial operation and testing. 1-1 Measure the supply voltage and make sure that it falls in the specified range. 1-2 Trial operation should be carried out in either cooling or heating mode. •...
