4-5/8"
[118mm]
24" [610mm]
Construction
20-gauge steel housing with 24 ga. steel reflector.
Shielding
Acrylic linear prism lens backed by precise frost
acrylic overlay.
Electrical
120, 277, 347 or Universal Voltage electronic ballast.
Fixtures and electrical components certified to UL
and CUL standards
Finish
Durable, low gloss, white, powder coated acrylic
finish.
Mounting
Recessed.
Tannenbaum Reflector
S T A N D A R D L U M I N A I R E P L A N – V I E W – V I E W
24" x 48"
(610mm x 1219mm)
(2, 3, 4 or 6 Lamps)
264
M O U N T I N G I N F O R M AT I O N
ETG
EXPOSED TEE GRID
NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
ORDERING INFORMATION:
Sample number: 274R-1BX40W-ETG-1EB-SI-EM
Series
174=1'x4'
Options
2
A=Air Return
C=Chicago Plenum
Mounting
R=Recessed
Number of Lamps
(in cross section) (not included)
1=1 Lamp
Lamp Type
T5
T5HO
Ceiling Type
ETG=Exposed T-Grid
1
Voltage
1=120V
2=277V
Ballast
EB=Electronic Ballast (Standard)
Switching
SI=Single Switching
Emergency
EM=Emergency Pack (Consult Factory)
1 Due to various constraints, some options may not be combined with others.
2 Can be left blank or more than one option may be available, consult factory.
24" x 24"
(610mm x 610mm)
(2 or 3 Lamps)
262
STG
SLOT TEE GRID
272=2'x2'
274=2'x4'
T=Tannenbaum Reflector
2=2 Lamps
BX40W
BX50W
STG=Slot T-Grid
SR=Sheet Rock
3=347V
U=Universal
DB=Dimming Ballast
DU=Dual Switching
SR
SHEET ROCK
NEO-RAY
™
FENESTRA
264
262
D I R E C T- I N D I R E C T
• Opal white diffuser fully
encloses lamp compatment
for easy whipe down.
• Perfect for healthcare,
educational and other
institutional facilities that
require simple easy cleaning
and minimized contagion
accumulation.
• T5 or T8 Lamping
• Highly efficient linear
prismatic diffuser offers low
glare, broad distribution.
• Combine the three lamp
profile with dual switching for
three levels of lighting
through basic switches for
complete, trustworthy
control.
• Consult factory for dimming
and emergency options.
• Recessed Mounting for T-grid,
sheet rock ceiling and
• 9/16" slot T-grid.
• Can be mounted end-to-end
and side-to-side.
COOPER LIGHTING
751
