Summary of Contents for BBQ BBQ1100300
- Page 1 MODULAR OUTDOOR KITCHEN BBQ1100300 DOUBLE DRAWER SET incl. screw set ASSEMBLY INSTRUCTIONS REV 1.0 Video guide 03/2023 ...
-
Page 2: Table Of Contents
BBQ1100300 DOUBLE DRAWER SET incl. screw set TABLE OF CONTENTS KEY POINTS FOR ASSEMBLY FOR YOUR SAFETY CARE AND MAINTENANCE IMPORTANT FOR THE FOUNDATION DESCRIPTION OF SYMBOLS SCOPE OF DELIVERY ASSEMBLY... -
Page 3: Key Points For Assembly
BBQ1100300 DOUBLE DRAWER SET incl. screw set KEY POINTS FOR ASSEMBLY These assembly instructions show the assembly of the outdoor barbecue kitchen. Read these assembly instructions carefully before commissioning! Failure to observe the risks, warnings and safety precautions set out in these assem- bly instructions may result in injuries or property damage. -
Page 4: Scope Of Delivery
BBQ1100300 DOUBLE DRAWER SET incl. screw set SCOPE OF DELIVERY BBQ2000109 drawer front BBQ2000175 Tandembox left profile & BBQ2000176 Tandembox right profile BBQ2000185 Tandembox steel back panel BBQ2000108 drawer bottom BBQ2000181 Tandembox left lengthwise railing & BBQ2000182 Tandembox right lengthwise railing... -
Page 5: Assembly
BBQ1100300 DOUBLE DRAWER SET incl. screw set ASSEMBLY ACCESSORIES – BBQ1100300A: small parts drawer set – BBQ2000237: 2 pcs. stainless steel handle, 420 mm 42 pcs. truss head screws M4x10 DIN 7380-1 A2 Tx 20 2 pcs. Tandembox left profile 4 pcs. - Page 6 BBQ1100300 DOUBLE DRAWER SET incl. screw set Connect the front panel to the two pro- Connect the steel back panel to the front files. panel using the lengthwise railings (left + right). CLICK CLICK Attach the left + right cabinet profiles to the base module.
- Page 7 BBQ1100300 DOUBLE DRAWER SET incl. screw set Adjust the angle of the front panel on the Install the cover caps. lengthwise railing. Then slide the cover cap forward. DONE ATTENTION! Tipping over of the base module with drawers may result in property damage.
