The workpiece must lay flat and be secured against
slipping, e.g. using clamps. Large workpieces must
be supported adequately.
If accessories with threaded inserts are used, the
end of the spindle may not touch the base of the
hole on the grinding tool. Make sure that the thread
in the accessory is long enough to accommodate
the full length of the spindle. The thread in the
accessory must match the thread on the spindle.
See page 3 and chapter 15. Technical
Specifications for more information on the spindle
length and thread.
Impurities that manage to enter the
machine may block the switching
mechanism. This is why, when the machine is
running, it is necessary to blow compressed air
through the rear ventilation slots of the machine
regularly, frequently and thoroughly. The machine
must be held firmly in this case.
Reducing dust exposure:
WARNING - Some dust created by power
sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to
cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
- Lead from lead-based paints,
- Crystalline silica from bricks and cement and
other masonry products, and
- Arsenic and chromium from chemically treated
lumber.
Your risk from these exposures varies, depending
on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well
ventilated area, and work with approved safety
equipment, such as those dust masks that are
specially designed to filter out microscopic
particles.
This also applies to dust from other materials such
as some timber types (like oak or beech dust),
metals, asbestos. Other known diseases are e.g.
allergic reactions, respiratory diseases. Do not let
dust enter the body.
Observe the relevant guidelines and national
regulations for your material, staff, application and
place of application (e.g. occupational health and
safety regulations, disposal).
Collect the particles generated at the source, avoid
deposits in the surrounding area.
Use suitable accessories for special work. In this
way, fewer particles enter the environment in an
uncontrolled manner.
Use a suitable extraction unit.
Reduce dust exposure with the following measures:
- do not direct the escaping particles and the
exhaust air stream at yourself or nearby persons
or on dust deposits,
- use an extraction unit and/or air purifiers,
- ensure good ventilation of the workplace and keep
clean using a vacuum cleaner. Sweeping or
blowing stirs up dust.
- Vacuum or wash the protective clothing. Do not
blow, beat or brush.
12
5. Overview
See page 2.
1 Bar auxiliary handle *
2 Thumb screws of the bar auxiliary handle *
3 Locking discs of the bar auxiliary handle *
4 Threaded holes on gear housing
5 2-hole spanner
6 Routing tool*
7 Spindle
8 Extractor connection piece
9 Spindle locking button
10 Clamping nut *
11 Diamond cup wheel*
12 Support flange *
13 Screw *
14 Safety disc*
15 Sliding on/off switch
16 Handle
17 Electronic signal indicator
18 Speed adjustment wheel
19 Safety guard
20 Flat area for working close to edges
21 Wing nut
22 Depth stop
* depending on equipment/not in scope of delivery

6. Initial Operation

Before plugging in the device, check that the
rated mains voltage and mains frequency, as
specified on the rating label, match your power
supply.
Australia: Always use a residual current device
(RCD) protected supply with a rated residual
current of 30 mA or less.
6.1 Fitting of bar auxiliary handle
Always work with the bar auxiliary handle (1)
attached! Fit the bar auxiliary handle as shown
(see illustration A, page 2).
- Fit locking discs (3) to the left and right of the gear
housing.
- Fit the bar auxiliary handle (1) at the gear housing.
- Insert the thumb screws (2) left and right into the
bar auxiliary handle (1) and turn gently.
- Adjust the bar auxiliary handle (1) to the required
angle.
- Firmly tighten the thumb screws (2) to the left and
right manually.
6.2 Adjusting the depth stop
For safety reasons, only use the safety guard
(19) provided.
See figure, page 2.
- Release wing screw (21).
- Twist the depth stop (22) to adjust the height in
relation to the accessory and the work task.
- Hand-tighten the wing screw (21) securely.
