- Page 1 Operating instructions For the operator Operating instructions ecoTEC plus VU 246/6-5 OVZ (P-GB) GB, IE Publisher/manufacturer Vaillant GmbH Berghauser Str. 40 D-42859 Remscheid Tel. +49 21 91 18‑0 Fax +49 21 91 18‑2810 info@vaillant.de www.vaillant.de...
-
Page 2: Table Of Contents
Contents Contents Care and maintenance ....13 Maintenance ........ 13 Safety ..........3 Caring for the product ....13 Action-related warnings ....3 Checking the condensate drain Intended use ........3 pipework and tundish....13 General safety information..... 4 Reading maintenance messages ........ -
Page 3: Safety
Safety 1 1 Safety ral heating installations and for hot water generation. 1.1 Action-related warnings Intended use includes the fol- Classification of action-re- lowing: lated warnings – observance of the operating The action-related warnings instructions included for the are classified in accordance product and any other system with the severity of the pos- components... -
Page 4: General Safety Information
1 Safety ▶ Do not use any electrical 1.3 General safety information switches, mains plugs, door- bells, telephones or other 1.3.1 Installation by skilled communication systems in tradesmen only the building. The installation, inspection, ▶ If it is safe to do so, close the maintenance and repair of the emergency control valve or product, as well as the gas ratio... - Page 5 Safety 1 – to the entire condensate 1.3.5 Risk of death due to explosive and flammable drain system – to the expansion relief valve materials – to the drain pipework ▶ Do not use or store explosive – to constructional condi- or flammable materials (e.g.
- Page 6 1 Safety an approved heating special- ist company. 1.3.10 Risk of material damage caused by frost ▶ Ensure that the heating in- stallation always remains in operation during freezing con- ditions and that all rooms are sufficiently heated. ▶ If you cannot ensure the op- eration, have a competent person drain the heating in- stallation.
-
Page 7: Notes On The Documentation
Notes on the documentation 2 2 Notes on the Information Meaning on the identi- documentation fication plate Serial number For quality control purposes; 2.1 Observing other applicable 3rd and 4th digits = year of documents production ▶ You must observe all operating instruc- For quality control purposes;... -
Page 8: Ce Label
3.4 Benchmark 3.5 Design of the product Vaillant is a licensed member of the Benchmark Scheme which aims to im- prove the standards of installation and commissioning of domestic heating and... -
Page 9: Operator Control Panel
Product description 3 3.6 Operator control panel Sym- Meaning Explanation – Permanently Heating mode active on: Heating mode heat requirement – Flashing: Burner on in heating mode Maintenance re- Information on quired the maintenance message in the "Live Monitor" Summer mode active Heating mode is switched off... -
Page 10: Basic Display
4 Operation If there is an error message present, the Meaning basic displays switches to the error mes- erator control sage. element 3.9 Operating levels Displaying the current product status at the The product has two operating levels. same – The end user level contains information time and setting options that you require as –... -
Page 11: Opening And Closing The Front Flap
Operation 4 4.2 Opening and closing the front Conditions: No controller connected flap ▶ Change the hot water temperature by 1. Take hold of the recessed handle in pressing ▶ the front flap. Confirm by pressing 2. Fold down the front flap. Conditions: Controller connected 3. -
Page 12: Switching Off Heating Mode (Summer Mode)
5 Detecting and rectifying faults 4.7 Switching off heating mode Note (Summer mode) To keep the frost protection devices active, you should switch Target flow temp. your product on and off using the controller, if one is provided. Heating off If the heating flow temperature falls be- Cancel low 5 °C when the on/off button is on, the... -
Page 13: Care And Maintenance
Care and maintenance 7 7 Care and maintenance 8 Decommissioning 7.1 Maintenance 8.1 Temporarily decommissioning the product An annual inspection of the product carried out by a competent person is a prerequis- Caution. ite for ensuring that the product is perman- Risk of material damage due ently ready and safe for operation, reliable, to frost. -
Page 14: Guarantee And Customer Service
Vaillant scheme. – Immediate help If your Vaillant boiler develops a fault your first action should be to contact your in- staller, as his professional assessment is needed under the terms of our Guarantee. -
Page 15: Appendix
Appendix Appendix A Operator level – overview Setting level Values Unit Increment, select Default setting Min. Max. Live Monitor → Status Current value Information → Contact data Phone num- Serial number Permanent value Display contrast Current value Reset anti-cycl. time → Current burner anti- Current value min cycling time... - Page 16 Appendix Fault Cause Measure Heating does not The external controller is not set cor- Set the external controller cor- start. rectly. rectly (→ Controller operating in- structions). Operating instructions ecoTEC plus 0020239016_01...
- Page 20 0020239016_01 10.10.2016 supplier Vaillant Ltd. Nottingham Road Belper Derbyshire DE56 1JT Telephone 0330 100 3461 info@vaillant.co.uk www.vaillant.co.uk © These instructions, or parts thereof, are protected by copyright and may be reproduced or distributed only with the manufacturer's written consent. We reserve the right to make technical changes.
