Technical Specifications; Product Highlights; Supported Display Resolution - Philips 42PF9966 Specifications

42" plasma widescreen flat TV Pixel Plus

Technical specifications

Picture/Display
• Aspect ratio: 16:9
• Brightness: 1000 cd/m²
• Contrast ratio (typical): 3000:1
• Diagonal screen size: 42 inch / 107 cm
• Display screen type: HD Plasma panel
• Picture enhancement: Pixel Plus, Digital Crystal
Clear, Progressive Scan, 3D Combfilter, Active
Control + Light sensor, Digital Natural Motion,
Jagged Line Suppression, Movie Plus,
Widescreen Plus
• Screen enhancement: Anti ageing circuit, Anti-
Reflection coated screen
• Viewing angle (H / V): 160 / 160 degree
• Panel resolution: 1024 x 768p
Ambilight
• Ambilight Features: Auto adaptive to video
content, Full operation in Stand-by
• Color Settings: Full Multi Colour
• Dimming Function: Manual and via Light Sensor
• Preset modes: 2 Active Adaptive preset modes,
6 Preset modes and user preset

Supported Display Resolution

Resolution Refresh rate
• Computer formats
640 x 480 60Hz
800 x 600 60Hz
1024 x 768 60Hz
• Video Formats
640 x 480i 1Fh
640 x 480p 2Fh
720 x 576i 1Fh
720 x 576p 2Fh
1280 x 720p 3Fh
1920 x 1080i 2Fh
Sound
• Sound Enhancement: Auto Volume Leveller,
Digital Signal Processing, Dynamic Bass
Enhancement, Graphic Equaliser, Smart Sound
• Sound System: Virtual Dolby Surround
• Output power (RMS): 2x15W
Loudspeakers
• Built-in speakers: 4
• Loudspeaker types: Dome tweeter, Integrated
woofers with wOOx
Date of issue 2005-08-25
Version: 2.0
12 NC: 8670 000 20647
UPC: 3 78499 45926
Convenience
• Ease of Installation: Automatic Tuning System
(ATS), PLL Digital Tuning, Plug & Play
• Ease of Use: 9-channel smart surf list,
Backlighted side controls, Channel list, Delta
Volume per preset, Smart Picture Control,
Smart Sound Control
• Remote control type: RC4307
• Teletext: Closed Captioning Full Text
• Remote Control: Universal
• Remote control: TV, VCR, DVD/R, SAT, CBL,
AMP
• Screen Format Adjustments: 6 Widescreen
Modes, Auto Format, Subtitle and Heading Shift
• Clock: Smart Clock
• Child Protection: Child Lock+Parental Control
• Picture in Picture: 2 tuner PIP, Mozaic
Tuner/Reception/Transmission
• TV system: NTSC
• Video Playback: NTSC
• Aerial Input: 75 Ohm F-type
Connectivity
• Other connections: Analog audio Left/Right out,
Centre Speaker connection in, Monitor out,
CVBS, L/R (cinch), Subwoofer out
• AV 1: (1, 2, 3Fh autoranging), Audio L/R in,
Component Video in, Y/C, YPbPr
• AV 2: (1, 2, 3Fh autoranging), Audio L/R in,
Component Video in, CVBS, RGB+H/V, Y/C,
YPbPr
• AV 3: Audio L/R In, HDCP, HDMI (Digital
Stream & SP-DIF)
Power
• Power consumption: 426 W
• Standby power consumption:
• Mains power: AC 110-120V (+/-10%)
• Ambient temperature: +5 -/+ 40 C
Dimensions
• Product weight: 42 kg
• Weight incl. Packaging: 54 kg
• Color cabinet: Pearl White Sliver 11092
Accessories
• Included Accessories: HDMI-DVI adapter cable,
Table top stand, Wall mounting bracket
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2005 Koninklijke Philips Electronics N.V.
All Rights reserved.
www.philips.com
42PF9966/37

Product highlights

Pixel Plus
This set uses the power of the Pixel Plus processor to
increase the number of lines and the number of pixels.
The result is razor sharp pictures with incredible detail
and dept, every time from any source.
Ambilight
The full-color ambient lights offers you relaxed viewing
and a unique ambiance via a soft light glow on the walls
surrounding the TV. Research has shown that watching
television with adapted ambient lighting promotes more
relaxed TV viewing. the Ambilight colors automatically
adapt to the images on the screen to add a new
sensation to the viewing experience. The light can also
be switched to fixed colors or various shades of white.
In standby mode, the lights can be operated to any color
and create a unique ambiance in the room.
Digital Natural Motion
Philips invented Digital Natural Motion to eliminate
juddering effects that are visible with moving picture
content. Digital Natural Motion estimates motion in the
picture and corrects juddering movements in both
broadcast and recorded movie material (such as DVD).
The resulting smooth motion reproduction and excellent
sharpness take the viewing experience to a higher level.
3D Combfilter
The 3D comb filter separates brightness and color
signals better in 3D domain to eliminate cross-color,
cross-luminance and dot-crawl distortion - all of which
detract from your viewing pleasure. The 3D digital
comb filter performs field-by-field comparisons of the
television image to accurately separate the color from
the black-and-white information and remove both
horizontally and vertically hanging dots, as well as dot
crawl. The result is a razor sharp image.
2.6
Active Control + Light Sensor
Active Control is a unique and intelligent way of
optimizing picture quality by measuring and analyzing
the incoming signal to automatically adjust picture
quality settings. Active Control with Light Sensor uses a
sensor to adjust the picture brightness depending on the
room light conditions.
Virtual Dolby Surround
Incredible Surround is an audio technology from Philips
that dramatically magnifies the sound field to immerse
you in the audio. Using state-of-the-art electronic phase
shifting, Incredible Surround mixes sounds from left and
right in such a way that it expands the virtual distance
between the two speakers. This wider spread greatly
enhances the stereo effect and creates a more natural
sound dimension. Incredible Surround means you
experience total surround with greater depth and width
of sound without the use of additional speakers.
HDMI input
HDMI makes an uncompressed digital RGB connection
from the source to the screen. By eliminating conversion
to an analog signal, it delivers an unblemished image.
The non-degraded signal reduces flicker and leads to a
clearer picture. HDMI intelligently communicates the
highest output resolution with the source device. The
HDMI input is fully backward compatible with DVI
sources but includes digital audio. HDMI uses HDCP
copy protection.
