Congratulations on owning a Scag mower! This manual contains the operating
instructions and safety information for your Scag mower. Reading this manual
can provide you with assistance in maintenance and adjustment procedures to
keep your mower performing to maximum efficiency. The specific models that
this book covers are listed on the inside cover. Before operating your machine,
please read all the information enclosed.
© 2022
Scag Power Equipment
Division of Metalcraft of Mayville, Inc.
OPERATOR'S
MANUAL
Models:
SZL-36H-18FR
SZL-36H-20KT
SZL-42H-21FR
SZL-42H-22PX
SZL-42H-22KT
SZL-48H-21FR
SZL-48H-22PX
SZL-48H-22KT
SZL-48H-24SR
SZL-52H-23FR
SZL-52H-24PX
SZL-52H-24SR
SZL-52H-24KT
SZL-61H-24FR
SZL-61H-26KT
SZL-61H-27SR
PART NO. 03483 Rev.01
PRINTED 04/2022
PRINTED IN USA
