Philips 26PW9100D - Hook Up Guide Connecting Manual

4
Video Camera/Games Console toTV
Composite Audio/Video
Connect the video Connect audio cables
A B
cable (yellow) from (red/white) from audio
the video output on outputs on device to
camera (or other audio inputs (red/white)
device) to the video on the side of TV.
input (yellow)
Note: for mono devices,
located on the side
connect only white audio
of TV.
cable from device's audio
output to white audio input
on the side of TV.
Turn on TV and the Press PLAY on the
C D
device. Press CH+ or device to verify
CH- on the remote connection.
control until FRONT/
SIDE appears on TV
screen.
Other Possible Connections
S-Video
Refer to panel 3.
Need more help?
User manual:
Check the user manual that came with yourTV.
Online help: www.p4c.philips.com or
www.usasupport.philips.com
2005 © Koninklijke Philips Electronics N.V.
All rights reserved.
3139 125 34972
TV Side Jack Panel
S-VIDEO
A
VIDEO
L
AUDIO
R
B
TV
VIDEO AUDIO
S-VIDEO
LEFT RIGHT
Video Camera
Video Camera Jack Panel
C
Remote
Control
CH+ and CH- Buttons
How to
make the best connection
Use this guide to achieve the optimal connection for each of your components.
Alternative connections are also provided.
Connection Basics
Best Better
Component Video S-Video
HDMI
High-Definition Multimedia Input Supplies a better picture
Interface provides an than RF and Composite
Provides superior picture
connections. Used with
uncompressed, all-digital
quality by separating the
red/white audio cables.
audio/video connection.
green, blue and red
HDMI provides the ultimate
luminance signals. Typically
connection. Please use a
used with red/white
certified HDMI cable
audio cables.
1
Set-Top Box toTV
HDMI
Connect RF cable Connect cable box
A B
from wall to input at to TV using HDMI
back of the cable cable.
box.
Cable Signal IN
Set output switch
C
from Cable Company
on set-top box to
CH 3 or 4 and
A A
tune TV to same
channel.
Note: In some cases,
cable box will automati -
CABLE
cally tune to channel 3
TO
IN
TV/VCR
or 4. Just change
channels until picture
appears.
B
Other Possible
Connections
Component
75 ? Input
Video
Refer to panel 2.
Good Basic
Composite Audio/Video RF
Separate video (yellow) and Provides a basic
audio (red/white) cables that connection
provide a basic connection from for antenna or cable.
the cable box and other devices. Provides both audio
Note : The color of audio inputs
and video.
may differ, e.g. red/white or
red/black.
RF Cable
OR
Connect RF cable Use second RF cable to
A B
from wall to input at connect the cable box
the back of the cable to the TV input (75 ?).
box.
Note: This connection gives
Set output switch mono sound. For stereo
C
on set-top box to sound use also composite
CH 3 or 4 and tune
audio/video connection
TV to same channel. (Refer to panel 3).
Back of Cable Box
VIDEO
AUDIO IN SPDIF IN OUT
R L
S-VIDEO
DVD-D OUT
IR
AUDIO OUT Y Pb Pr
OPTICAL
USB TV
SPDIF
PASSCARD
75 ?
TV
HDMI Input
Basic
B
