Panasonic ER220-E2 Service Manual

Ac/rechargeable beard/hair trimmer
Hide thumbs

Advertisement

Quick Links

Download this manual
SPECIFICATIONS
CONTENTS
AC/Rechargeable Beard/Hair Trimmer
ER220-E2
ER221-E2
Page
2
2
3
5
© 2004 Matsushita Electric Works, Ltd. All rights
reserved. Unauthorized copying and distribution is a
violation of law.
ORDER NO. SD0410E52C2
Page
8
9
10

Advertisement

loading

Related Manuals for Panasonic ER220-E2

Summary of Contents for Panasonic ER220-E2

  • Page 1: Table Of Contents

    ORDER NO. SD0410E52C2 AC/Rechargeable Beard/Hair Trimmer ER220-E2 ER221-E2 SPECIFICATIONS CONTENTS Page Page 1 SCHEMATIC DIAGRAM 5 TROUBLESHOOTING GUIDE 2 WIRING CONNECTION DIAGRAM 6 EXPLODED VIEW 3 DISASSEMBLY INSTRUCTIONS 7 REPLACEMENT PARTS LIST 4 ASSEMBLY INSTRUCTIONS © 2004 Matsushita Electric Works, Ltd. All rights reserved.

  • Page 2: Schematic Diagram

    ER220-E2 / ER221-E2 1 SCHEMATIC DIAGRAM 2 WIRING CONNECTION DIAGRAM...

  • Page 3: Disassembly Instructions

    ER220-E2 / ER221-E2 3 DISASSEMBLY INSTRUCTIONS Follow the procedure below to disassemble the main body. 1. Remove the attachment and blade. 2. Peel off the dial cover. NOTE: Dial cover is fixed with an adhesive tape. Make sure not to scratch dial cover or dial by something sharp-edged tool when taking out the dial cover.
  • Page 4 ER220-E2 / ER221-E2 9. Loosen four screws with O-rings. 10. Slightly sliding the trimmer ups and loosens two screws and removes the retaining plate. 11. Remove the waterproof rubber and two O-rings. 12. Take out housing B. 13. To take out the motor assembly, lift up the lead wire side of motor and pull it towards the battery side in the direction of arrow.

  • Page 5: Assembly Instructions

    ER220-E2 / ER221-E2 4 ASSEMBLY INSTRUCTIONS NOTE: When reassembling, replace the new waterproof rubber and O-rings. Make sure whether there is NO foreign substance sticking around a part covered with water seal. 1. Install the driving head in motor. NOTE: Make sure of the direction.
  • Page 6 ER220-E2 / ER221-E2 5. Set the trimmer. And tighten four housing screws. NOTE: Make sure to attach the O-ring with screw. 6. Set waterproof rubber, O-rings, retaining plate with tightening two screws. The waterproof rubber must be fitted the right way around.
  • Page 7 ER220-E2 / ER221-E2 8. Set the trimmer driving bar and click spring. 9. Set the bottom cover and tighten it with a screw. 10. Attach the connecting bar to housing C. 11. Set housing C and attach the dial and the dial-fixing button with tightening a screw.

  • Page 8: Troubleshooting Guide

    ER220-E2 / ER221-E2 5 TROUBLESHOOTING GUIDE <TROUBLE> <CHECK> <REMEDY> → Does not operate. <CHECK ADAPTOR.> Replace adaptor. → Does not charge. Supply rated voltage to the adaptor. OK if it is approx. DC 2.8V between Functions for a mo- the terminals of the plug with no-load operation.

  • Page 9: Exploded View

    ER220-E2 / ER221-E2 6 EXPLODED VIEW...

  • Page 10: Replacement Parts List

    ER220-E2 / ER221-E2 7 REPLACEMENT PARTS LIST NOTE : *A=available as an optional accessory *B=only available as set *C=available individually Ref.No. Part No. Part Name & Descriptions Remarks Per Unit WER221S7408 COMB ATTACHMENT FOR HAIR ER220/ER221 WER221S7418 COMB ATTACHMENT FOR BEARD...
