RSA Lighting C900 Specification Sheet

DESCRIPTION
Shallow insulated ceiling AirTite (I.C.) Microgem recessed low voltage
housing with integral magnetic transformer 50W max. 120V or 277V.
For use in insulated ceiling (I.C.) applications. Housing may be covered
on all sides with insulation material.
SPECIFICATION FEATURES
A ...Housing
Shallow low voltage recessed fixture
housing for insulated ceiling installations.
Includes integral low voltage magnetic
transformer. All aluminum construction.
14 ga. steel junction box.
B ...Electrical
Socket is pre-wired to the j-box 18AWG
SF-1 leads. Primary lead is 120V or 277V.
Transformer is rated 180˚ Class H. State of
Washington AirTite approved.
C ...Mounting
Provided with two (2) adjustable 16 ga.
steel hanger bars which can be extended
to 25.25".
D ...System Protection
Transformers have thermal protection
and operate at 11.5 volts nominal.
Ceiling Cut-Out: 3.75" dia.
ORDERING INFORMATION
C900
Housing Voltage
C900 =
120
Microgem shallow insulated
277
ceiling low voltage recessed
housing.
www.cooperlighting.com
14.13" 13.25"
B
120 volts primary
=
= 277 volts primary
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031
Catalog #
Project
Comments
Prepared by
14" min.
25.25" max.
15.188"
18.125"
20.125"
5.5"
3.75"
A
Type
Date
MICROGEM
SHALLOW
HOUSING
C
Insulated Ceiling
AirTite Shallow
Housing w/ Integral
Low Voltage
D
Transformer
FOR 12V LAMP 50W max.
C900
rev. 102406
