D I M E N S I O N S
BSX-T
BSX-BA
BSX-AR
BSX-PP, BSX-FP
BSX-PM, BSX-FM
BSX-AP
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : B S X - P A - 2 3 2 - 1 2 0 V - E B 8 1 - U
Tandem
(8)
Optic
8T=8'
SB=Spread Baffle
(3)
Length
BA=Baffle Arch
(available
HR=Half Round
for FR,
HRF=Half Round Frost
(3) (6)
FA, AR,
P=Para
(3) (6)
FP, FM,
PS=Para Stack
TD, HRF,
T=Taper
(4)
AP only)
PU=Perf Uplight
PP=Perf Point
Series
PM=Perf Mono
BSX= BASIX
PA=Perf Arch
Architectural
PR=Perf Round
Striplights
FP=Frost Point
FM=Frost Mono
Mounting
FA=Frost Arch
Blank=Stand Alone
FR=Frost Round
(Standard)
AP=Acrylic Point
R=Continuous Row
AR=Acrylic Round
(2" Row Coupler
TD=Teardrop
Included)
(1)
NOTES:
Products also available in non-US voltages and frequencies for international markets.
(2)
Not available when specifying emergencies, voltage must be specific.
(4)
(5)
Available in 2-lamp only.
Not available in 347V.
(8)
2' units.
BASIX is not recommended for wall mounting.
For complete product data, reference the Fluorescent Specification binder. Specifications &
dimensions subject to change without notice. Consult your Cooper Lighting Representative for
availability and ordering information.vailability and ordering information.
COOPER LIGHTING - METALUX
BSX-PR, BSX-FR
BSX-PA, BSX-FA
BSX-PU
BSX-SB
BSX-TD
BSX-P
No. of
(1)
Voltage
Lamps
120V=120 Volt
1=1 Lamp
277V=277 Volt
2=2 Lamp
347V=347 Volt
UNV=Universal
(2)
Wattage (Length)
Voltage 120-277V
17=17W T8 (24")
(5)
Options
14T5=14W T5 (24")
24T5=24W T5HO
GL=Single
(5)
(24")
Element Fuse
32=32W T8 (48")
GM=Double
(5)
28T5=28W T5 (48")
Element Fuse
54T5=54W T5HO (48")
Emergency - for
EM installed, see
EM options table
(3)
Not availble in T5.
(6)
(7)
Metallic finish standard.
Not available for
D E S C R I P T I O N
The BASIX series is a
celebration of the striplight.
The result is a wide range of
exciting new lighting
opportunities for virtually any
commercial application. BASIX
is designed to feature
contemporary styling with a
slight industrial edge. All
components are produced by
precision methods using
premium materials. Each of
the many unique BASIX optics
is easily field assembled to a
standard SN striplight channel.
Surface, cable, and stem
mounting in stand-alone or
continuous row configurations
provides further versatility.
With creative application of
architectural shielding
elements to the basic form of
the T8 and T5 striplight, BASIX
transforms the fundamental
into the unique.
BSX-HR, BSX-HRF
BSX-PS
Packaging
Options
(See Options
U=Unit Pack
Section)
(1)
Ballast Type
LE3=T12 Magnetic Energy Saving
EB8 = T8 Electronic Instant Start.
Total Harmonic Distortion < 10%
No. of Ballast
1, 2 or 3
EB8 /PLUS= T8 Electronic Instant Start.
High Ballast Factor >1.13. Total
No. of
Harmonic Distortion < 20%
Ballast
1, 2 or 3
ER8 = T8 Electronic Program Rapid Start.
(7)
Total Harmonic Distortion < 10%
No. of Ballast
1, 2 or 3
EB5 = T5 Biax Electronic Instant Start.
Total Harmonic Distortion < 20%
No. of Ballast
1, 2 or 3
EB2 =T12 Electronic Rapid Start.
No. of Ballast
1 or 2
(For complete details on generic or to specify
manufacturer's ballast see pg. 469)
®
BASIX SERIES
A r c h i t e c t u r a l S t r i p l i g h t
1 o r 2 L a m p
T 5 O R T 8
• Stylish optics added to
traditional striplight allows
for low cost alternative to
expensive linear lighting.
• Nineteen different optics
available, offering
versatility for all
commercial applications.
• Offered in one or two lamp,
with both T8 and T5
models available.
• Units offered in 2 ft. and 4
ft. lengths. Can be ordered
as stand alone or row
mounted versions.
• Row mount options
standard with 2" Row
Coupler. Row Coupler
allows for only one
mountiong point per
fixture joint.
• Strip channel allows for
surface, cable, or stem
mounting.
• Optional metallic finish for
many models.
• UL/CUL listed. Suitable for
damp locations.
COOPER LIGHTING
443
