  • Page 1 TECHNICAL MANUAL SIMPLEBUS2 Simplebus2 audio/video system with power supply unit 4888C...

  • Page 2: Warning

    • any purpose other than the intended use, • failure to observe the indications and warnings contained in this Manual / Instruction sheet. Comelit Group S.p.A. reserves the right to change the information provided in this Manual / Instruction Sheet at any time and without prior notice.

  • Page 3: Table Of Contents

    Table of contents Warning .................... 2 System functions ................4 Operating distances .................5 Distances with video concentrator-amplifier Art. 4933 ......6 Maximum system expansion ..............7 Maximum expansion per apartment............7 Example of maximum expansion per apartment ........8 Wiring diagrams................9 System with a single riser ...............9 Digital Entrance Panel Variant with Touch-screen module Art.

  • Page 4: System Functions

    System functions 6601W 6601W/BM (MAX 3) 1216 6801W 6701W 6721W 6801W/BM 6701W/8 1214/2C 6701W/BM 6721W/BM +6710 +6710 4888C UT1020 1216 6801W 6701W 6601W 6721W 6801W/BM 6701W/8 6601W/BM 1214/2C 6721W/BM 6701W/BM +6710 +6710 4888C 4888C 4834/9 4833C 1200 UT1020 UT1020...

  • Page 5: Operating Distances

    (see A MAX B MAX C MAX D MAX E MAX F MAX H MAX Art.1216 page Comelit Art. 4577/4579 1 mm² 200 m 200 m 200 m 200 m 150 m 50 m 50 m 100 m (Ø 1.2 mm AWG 17)

  • Page 6: Distances With Video Concentrator-Amplifier Art. 4933

    200 m 300 m (Ø 1.4 mm AWG 15) (2295 feet) (325 feet) (655 feet) (985 feet) For greater distances, please contact Comelit Group S.p.A. for information on using the data amplifier Art. 1236, to be installed before Art. 4933.

  • Page 7: Maximum System Expansion

    Maximum system expansion Devices 6801W(/BM) 6701W(/BM) 6601W(/BM) 6721W(/BM) 6741W(/BM) 6701W/8 (4888C with IR Maximum number of door ≥053) entry monitors that can be powered from art. 4888C (4888C with IR ≥021 ≤052 ) Call repetition devices that can 1229A 1229A 1229A 1229A 1229A...

  • Page 8: Example Of Maximum Expansion Per Apartment

    Example of maximum expansion per apartment APARTMENT 7: max 4 internal units including 1 main internal unit Art. 6741W 1214/2C 6741W 6721W 6721W 6721W A single 6741W (/BM) door entry monitor can be installed for each user code; this will also be the only main door entry monitor. APARTMENT 6: max 4 internal units including 2 main internal units Art.

  • Page 9: Wiring Diagrams

    Wiring diagrams System with a single riser 1216 6601W 1214/2C Apartment n 2738W 2738W/A 1214/2C Apartment 4 6801W 1214/2C Apartment 3 6701W 6721W 6701W/8 1214/2C Apartment 2 6741W 1214/2C Apartment 1 4888C UT1020 1595 1595 UT9279M UT9270...
  • Page 10 VIDEO ENTRY SYSTEM RISER 1216 6601W/ 6601W/BM 22-28 Vdc 1214/2C 2738W 2738W/A 22-28 Vdc 1214/2C 6601W/ 6601W/BM 22-28 Vdc 1214/2C 22-28 Vdc 1 2 3 4 5 6 1214/2C 6721W 6701W 6701W/8 6721W/BM +6710 6701W/BM +6710 6741W 6741W/BM +6710 22-28 Vdc 1214/2C 22-28 Vdc 4888C...

  • Page 11: Digital Entrance Panel Variant With Touch-Screen Module Art. Ut9270

    Digital Entrance Panel Variant with Touch-screen module Art. UT9270 4888C 1595 120-230 V SE NO NC UT1020 UT9270 20 m MAX. Local door-opener button. Digital Entrance Panel Variant with number keypad module Art. UT9279M 4888C 1595 120-230 V SE NO NC UT1020 UT9279M 20 m MAX.

  • Page 12: Apartment Block Video Entry Phone System With 1 To 4 Risers With 2 Entrance Panels

    Apartment block video entry phone system with 1 to 4 risers with 2 entrance panels 6601W 2738W 2738W/A 6801W 6701W 6721W 6701W/8 6741W 4888C 1224A UT1020 UT1020 1595 1595 1224A 4888C ~ 230V 1 2 3 4 1 2 3 4 1595 1595 120-230 V...

  • Page 13: Apartment Block Video Entry Phone System With More Than 4 Risers

    Apartment block video entry phone system with more than 4 risers 6601W 6601W 2738W 2738W 2738W/A 2738W/A 6801W 6801W 6741W 6721W 6701W 6701W 6701W/8 6701W/8 4888C 4888C 4834/9 UT1020 1595 4888C 4888C 230V ~ 230V 4834/9 1595 120-230 V SE NO NC UT1020 UT9200 Video entry system riser (see:...

  • Page 14: System With 1 Main Video Entrance Panel (Max 9 Secondary Video Units)

    System with 1 main video entrance panel (max 9 secondary video units) 6601W 6601W 2738W 2738W 2738W/A 2738W/A 6801W 6801W 6721W 6741W 6701W 6701W 6701W/8 6701W/8 4888C 4888C 1224A 1224A UT1020 UT1020 1595 1595 4834/9 UT1020 1595...
  • Page 15 1224A 1224A 4888C 4888C ~ 230V 230V 1595 1595 120-230 V 120-230 V SE NO NC SE NO NC UT1020 UT9200 UT1020 UT9200 4834/9 1595 120-230 V SE NO NC UT1020 UT9200 Video entry system riser (see: “VIDEO ENTRY SYSTEM RISER”) 20 m MAX.

  • Page 16: Cascade Connection For Art. 4834/9

    Cascade connection for Art. 4834/9 6601W 6601W 2738W 2738W 2738W/A 2738W/A 6801W 6801W 6721W 6741W 6701W 6701W 6701W/8 6701W/8 4888C 4888C 4833C 4834/9 1200 6601W 2738W 4834/9 2738W/A 6801W 6721W 6701W 6701W/8 UT1020 4888C 1595 4833C 4834/9 1200...

  • Page 17: Connection Of Amplifier Art. 4833C

    1200 4833C 4834/9 230V~ 12V~ 14 15 16 17 1200 4833C 4834/9 230V~ 12V~ 1 2 3 4 5 6 25 26 27 1200 4834/9 4833C 4834/9 12V~ 230V~ Video entry system riser (see: “VIDEO ENTRY SYSTEM RISER”) Only cut off the resistor for the output used. Connection of amplifier Art.

  • Page 18: Cascade Connection With Several Door Entry Monitors Or Door-Entry Phones (Up To 25 Per Branch From Art. 4888C)

    Cascade connection with several door entry monitors or door-entry phones (up to 25 per branch from Art. 4888C) In the case of connection in cascade, the MAX number of door entry monitors/door-entry phones that can be connected for each riser branch of the Mixer-power supply Art. 4888C is 25. Each door-entry phone Art. 2738W, 2738/A and Art. 6750W must be preceded by an Art.

  • Page 19: Video Entry System With 1 Main Entrance And Porter Switchboard

    Video entry system with 1 main entrance and porter switchboard 6601W 6801W 6701W 6721W 6701W/8 6741W 4888C 1998VC 1195 UT1020 1595 4888C 230V 1998VC 1195 NO C 1595 120-230 V SE NO NC UT1020 UT9200 Video entry system riser (see: “VIDEO ENTRY SYSTEM RISER”) 20 m MAX.

  • Page 20: Video Entry System With 2 Main Entrances And Porter Switchboard

    Video entry system with 2 main entrances and porter switchboard 6601W 6801W 6701W 6721W 6701W/8 6741W 4888C 1998VC 1195 1224A 1200 UT1010 UT1020 1595 1595...
  • Page 21 4888C 230V 1998VC 1195 NO C 1224A 1200 12V~ 230V~ 1 2 3 4 1 2 3 4 1595 1595 120-230 V 120-230 V SE NO NC SE NO NC UT1010 UT9200 UT1020 UT9200 Video entry system riser (see: “VIDEO ENTRY SYSTEM RISER”) 20 m MAX.

  • Page 22: Video Entry System With 1 Main Entrance, 3 Secondary Video Units And Porter Switchboard

    Video entry system with 1 main entrance, 3 secondary video units and porter switchboard 6601W 6601W 2738W 2738W 2738W/A 2738W/A 6801W 6801W 6721W 6741W 6701W 6701W 6701W/8 6701W/8 4888C 4888C 1224A 1224A UT1020 UT1020 1595 1595 4834/9 1998VC 1195 UT1020 1595...
  • Page 23 1224A 1224A 4888C 4888C ~ 230V 230V 1595 1595 120-230 V 120-230 V SE NO NC SE NO NC UT1020 UT9200 UT1020 UT9200 4834/9 1998VC 1195 NO C 1595 120-230 V SE NO NC UT1020 UT9200 Video entry system riser (see: “VIDEO ENTRY SYSTEM RISER”) 20 m MAX.

  • Page 24: Video Entry System With 2 Main Entrances, 3 Secondary Audio Units And Porter Switchboard

    Video entry system with 2 main entrances, 3 secondary audio units and porter switchboard 6601W 6601W 2738W 2738W 2738W/A 2738W/A 6801W 6801W 6721W 6741W 6701W 6701W 6701W/8 6701W/8 4888C 4888C 1224A 1224A UT1010 UT1010 1595 1595 4834/9 1998VC 1195 1200 1224A UT2020 1595...
  • Page 25 1224A 4888C 1224A 4888C ~ 230V 230V 1595 1595 120-230 V 120-230 V SE NO NC SE NO NC UT1010 UT9200 UT1010 UT9200 4834/9 1998VC 1195 NO C 1224A 1200 12V~ 230V~ 1 2 3 4 1 2 3 4 1595 1595 120-230 V...

  • Page 26: Simplebus Top Video Entry Phone System With 1 Main Entrance, 4 Secondary Entrances And The Corresponding Secondary Porter Switchboards

    Simplebus TOP video entry phone system with 1 main entrance, 4 secondary entrances and the corresponding secondary porter switchboards 6601W 6601W 2738W 2738W 2738W/A 2738W/A 6801W 6801W 6721W 6741W 6701W 6701W 6701W/8 6701W/8 4888C 4888C 1998VC 1998VC 1424 1424 1195 1195 UT1020 UT1020...
  • Page 27 4888C 230V TOP 2 SECONDARY 1998VC 1195 NO C 1424 LPin LPout 1 2 3 4 1 2 3 4 TOP 3 1595 1595 120-230 V 120-230 V SE NO NC NO NC UT1020 UT1020 UT9200 UT9200 4888C ~ 230V TOP 2 SECONDARY 1998VC...

  • Page 28: Simplebus Top Video Entry Phone System With 2 Main Entrances, 4 Secondary Entrances And Main Porter Switchboard

    Simplebus TOP video entry phone system with 2 main entrances, 4 secondary entrances and main porter switchboard 6601W 6601W 6801W 6801W 6721W 6741W 6701W 6701W 6701W/8 6701W/8 4888C 4888C 1424 1424 UT1020 UT1020 1595 1595 4834/9 1998VC 1195 1200 1424 UT1020 UT1020 1595...
  • Page 29 4888C 4888C 230V ~ 230V TOP 1 TOP 1 1424 1424 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 LPin LPout LPin LPout 1595 1595 1595 1595 120-230 V 120-230 V 120-230 V 120-230 V SE NO NC NO NC...

  • Page 30: Simplebus Top Video Entry Phone System With 2 Main Entrances, 1 Main Porter Switchboard, 2 Secondary Entrances And Corresponding Porter Switchboards

    Simplebus TOP video entry phone system with 2 main entrances, 1 main porter switchboard, 2 secondary entrances and corresponding porter switchboards 6601W 6601W 2738W 2738W 2738W/A 2738W/A 6801W 6801W 6741W 6721W 6701W 6701W 6701W/8 6701W/8 4888C 4888C 1998VC 1998VC 1424 1424 1195 1195...
  • Page 31 1÷100 4888C 230V TOP 2 1195 SECONDARY 1424 1998VC NO C LPin LPout 1 2 3 4 1 2 3 4 1595 1595 120-230 V 120-230 V SE NO NC NO NC UT1020 UT1020 UT9200 UT9200 1÷100 4888C ~ 230V TOP 2 1195 SECONDARY...

  • Page 32: Simplebus Top Video Entry Phone System With 1 Main Entrance, 4 Secondary Entrances And 2 Main Porter Switchboards In Series

    Simplebus TOP video entry phone system with 1 main entrance, 4 secondary entrances and 2 main porter switchboards in SERIES 6601W 6601W 2738W 2738W 2738W/A 2738W/A 6801W 6801W 6721W 6741W 6701W 6701W 6701W/8 6701W/8 4888C 4888C 1224A 1224A UT1010 UT1010 1595 1595 4933...
  • Page 33 1224A 1224A 4888C 4888C ~ 230V 230V 1595 1595 120-230 V 120-230 V SE NO NC SE NO NC UT1010 UT9200 UT1010 UT9200 4933 1 2 3 4 1998VC 1195 NO C 1998VC 1195 NO C 1595 1595 120-230 V 120-230 V SE NO NC NO NC...
  • Page 34 Simplebus TOP video entry phone system with 1 main entrance, 3 secondary entrances and 2 main porter switchboards in PARALLEL 6601W 6601W 2738W 2738W 2738W/A 2738W/A 6801W 6801W 6721W 6741W 6701W 6701W 6701W/8 6701W/8 4888C 4888C 1200 1200 1424 1424 1200 1424 1998VC...
  • Page 35 1÷100 4888C 230V TOP 1 1424 1200 12V~ LPin LPout 230V~ 1 2 3 4 1 2 3 4 1÷100 4888C 230V TOP 1 1424 1200 12V~ LPin LPout 230V~ 1 2 3 4 1 2 3 4 1424 1200 12V~ TOP 3 LPin...

  • Page 36: Switching Devices In Top1 Mode, Branched Kit 8461/8451, External Unit In Top Mode

    Switching devices in TOP1 mode, branched KIT 8461/8451, external unit in TOP mode 8461X - unit 4 8461M - unit 3 6801W 6701W 6701W/8 1216 1214/2C 1404 1404 1214/2C 1214/2C 1209 1209 4893M 4893M 8461I - unit 1 8451V - unit 2 6601W 6741W 1404...
  • Page 37 6701W 6801W/ 6701W/BM 6801W/BM 6701W/8 1 2 3 4 5 6 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 TOP 1 1404 TOP 1 1404 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4...

  • Page 38: Switching Devices In Standard Mode, Branched Kit 8461/8451

    Switching devices in STANDARD mode, branched KIT 8461/8451 8461X - unit 4 8461M - unit 3 6801W 6701W 6701W/8 1216 1214/2C 1404 1404 1214/2C 1214/2C 1209 1209 4893M 4893M 8461I - unit 1 8451V - unit 2 6601W 6741W 1404 1404 1214/2C 1214/2C...
  • Page 39 6701W 6801W/ 6801W/BM 6701W/8 1 2 3 4 5 6 6701W/BM 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1404 1404 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4...

  • Page 40: Switching Devices In Standard Mode And Kit 8461/8451 In Cascade Connection

    Switching devices in STANDARD mode and KIT 8461/8451 in cascade connection 8461I - unit 1 8461X - unit 2 8451V - unit x 6601W 6801W 6741W 1404 1404 1404 1209 1209 1209 4893M 4893M 4893M 4888C UT1020 1595 6741W 6601W/ 6801W/ 6741W/BM 6601W/BM...

  • Page 41: Switching Devices In Top1 Mode And Kit 8461/8451 In Cascade Connection, With External Unit In Top Mode

    Switching devices in TOP1 mode and KIT 8461/8451 in cascade connection, with external unit in TOP mode 8451V - unit x 8461I - unit 1 8461X - unit 2 6601W 6801W 6741W 1404 1404 1404 1209 1209 1209 4893M 4893M 4893M 4888C UT1020...

  • Page 42: Addition Of Remote Camera Module Art. 1409

    Addition of remote camera module Art. 1409 6601W 6801W 6701W 6721W 6701W/8 6741W 1409 1200 4888C UT1020 1595 1409 1200 12V~ 230V~ IN IN 1 2 3 4 4888C To be powered separately.

  • Page 43: Addition Of Remote Camera Module Art. 1259C

    Addition of remote camera module Art. 1259C 6601W 6801W 6701W 6721W 6701W/8 6741W 4888C 1259C 1200 UT1020 1595 4888C 1200 1259C 12V~ 230V~ IN IN 1 2 3 4 UT1020 To be powered separately.

  • Page 44: System With Remote Camera Module Art. 1259C In Generic Actuator Mode And Porter Switchboard

    System with remote camera module Art. 1259C in generic actuator mode and porter switchboard 1216 6801W 1214/2C 2738W 2738W/A 1214/2C 6750W 1214/2C 6701W 6721W 1214/2C 6701W/8 6601W 1214/2C 6741W 4888C 1259C 1200 1998VC 1195 UT1020 1595...
  • Page 45 4888C 230V 1200 1259C 12V~ 230V~ IN IN 1 2 3 4 1195 NO C 1595 1595 120-230 V 120-230 V SE NO NC NO NC UT1020 UT1020 UT9200 UT9200 1998A 1195 0 2 1 4 2 Video entry system riser (see: “VIDEO ENTRY SYSTEM RISER”) 20 m MAX.
