AutoScan Color Monitor
English
Français
Appendix
English
Français
Deutsch
For Customer Use:
Enter below the Serial No. which is located on the
back of the cabinet. Retain this information for
future reference.
Model No. 15B1322Q11
Serial No.
CAUTION TO REDUCE THE RISK OF ELECTRICAL SHOCK DO NOT REMOVE COVER(OR BACK)
NO USER SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
This "bolt of lightning" indicates that uninsulated material
within your unit may cause an electrical shock. For the safety
of everyone, do not remove product covering.
This "exclamation point" calls attention to a feature for which
you should read the enclosed literature carefully to prevent operating
and maintenance problems.
IB7948B001
15B1322Q11
Operating Instructions .................... 2 - 23
Mode d'emploi
Information for Users in the U.S. ........ A1
Declaration FCC
Warranty/address
TCO'95
ENERGY DECLARATION
Declaration FCC
Hinweis/GS/ACHTUNG
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
ATTENTION
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
.................. 24 - 45
........ A2
........ A3
A6 ........ A7
........ A8
........ A4
........ A5
E
N
1
Advertisement
Table of Contents
Related Manuals for Philips 15B1322Q
Summary of Contents for Philips 15B1322Q
- Page 1 15B1322Q11 AutoScan Color Monitor English Operating Instructions ... 2 - 23 Français Mode d'emploi Appendix English Information for Users in the U.S..A1 Declaration FCC Warranty/address TCO'95 ENERGY DECLARATION Français Declaration FCC Deutsch Hinweis/GS/ACHTUNG For Customer Use: Enter below the Serial No. which is located on the back of the cabinet.
-
Page 2: Feature Highlights
Introduction The PHILIPS 105B colour monitor displays sharp and brilliant images of text and graphics with a maximum resolution up to 1280x1024 pixels. It is optimal for Windows, CAD / CAM / CAE, desktop publishing, spread sheets, multi-media, and any other application which demands large screen size and high resolutions. - Page 3 Note: If you experienced your monitor display is changing from color to mono, it's possible that you are using a non-VESA-DDC-standard video card. Please consult with your local Philips dealer for more information. As an Energy Star partner, PHILIPS, has determined that this product meets the Energy Star guidelines for energy effficiency.
-
Page 4: Safety Precautions And Maintenance
Safety precautions and maintenance Disconnect the monitor from the mains supply if the monitor is not to be used for an extended period of time. Do not attempt to remove the back cover, as you will be exposed to a shock hazard. The back cover should only be removed by qualified service personnel. -
Page 5: Installation
Keep away from any magnetic objects, such as speakers, electric motors, transformers, ...etc. When positioning this monitor, make sure that the mains plug and socket are easily accessible. Pedestal With the built-in pedestal you can tilt and / or swivel the monitor for a most comfortable viewing angle. - Page 6 1. IBM PC, PC/XT, PC/AT, PS/2, or the compatibles: • Connect the monitor to the computer using the supplied interface cables. Connection with computer system other than IBM PC or Apple computers may need different type of adapters. Please consult your computer supplier for these adapters.
- Page 7 2. Earphone Connection : Connect your earphone plug (must be mini Jack type) to the earphone connector on the left side of the monitor. The speakers will be switched off when earphone is plugged in. 3. External Microphone Connection : Connect your microphone plug to the microphone connector on the left side of the monitor.
-
Page 8: Control Locations And Functions
• Activate/terminate contrast OSD menu. • Activate/terminate OSD main menu. • Activate/terminate brightness OSD menu. • Activate/terminate volume OSD menu. Monitor control panel CONT R AS T 4 5 % B R I GHTNE S S & CONT RA S T... - Page 9 OSD main menu tree structure First level BRIGHTNESS & CONTRAST SIZE & POSITION GEOMETRY COLOR TEMPERATURE SPECIAL RECALL PRESETS ROTARY DEFAULT LANGUAGE DISPLAY MODE AUDIO EXIT Second level Third level BRIGHTNESS CONTRAST SAVE CANCEL HORIZONTAL SIZE HORIZONTAL POSITION VERTICAL SIZE VERTICAL POSITION SAVE CANCEL...
-
Page 10: On-Screen Display
On-Screen-Display Activating the On-Screen-Display The monitor controls are accessed by pressing button OSD (On-Screen-Display). The main menu will be displayed as follows. Each Sub-Menu (1-10) is selected by highlighting it via the rotary control and pressing button bottom of the main menu and press select button... -
Page 11: Size & Position
CONTRAST : Adjusts contrast between foreground and background. CONT R AS T SAVE : Save user adjustment and return to main menu. CANCEL : Abandon setup and return to main menu. Sub Menu-2: SIZE & POSITION HORIZONTAL SIZE : Adjusts image width HOR I ZONTAL S I Z E HORIZONTAL POSITION : Moves image left or right... - Page 12 VERTICAL SIZE : Adjusts image height V E RT I CA L S I Z E VERTICAL POSITION : Moves image up or down V E R T I CA L POS I T I ON SAVE : Save user adjustment and return to main menu. CANCEL : Abandon setup and return to main menu.
-
Page 13: Color Temperature
PICTURE ROTATION : Tilts the image clockwise or counter- P I C TUR E ROTAT I ON P I C TUR E SAVE : Save user adjustment and return to main menu. CANCEL : Abandon setup and return to main menu. Sub Menu-4: COLOR TEMPERATURE 9300 K : Factory preset color temperature of 9300 K. - Page 14 USER 1 : User set 1 for color temperature then select R, G or : Adjusts red intensity. : Adjusts green intensity. : Adjusts blue intensity. U S E R 1 9300ºK 6500ºK 8 6 % 7 5 % 7 3 % USER 2 : User set 2 for color temperature then select R, G or : Adjusts red intensity.
- Page 15 DEGAUSS : Discoloration of the image can be caused by gradual magnetization of the monitor components. This is particularly likely to occur when the monitor is moved or rotated. The monitor may "buzz" momentarily when the user control is selected and the image will change color and wobble for a few seconds.
-
Page 16: Recall Presets
Sub Menu-6: RECALL COLOR TEMPERATURE : Recall color temperature R E CA L L COL OR RECALL SIZE & POSITION : Recall size and position presets. R E CA L L RECALL ALL PRESETS : Recall all presets and return to SAVE : Save user adjustment and return to main menu. -
Page 17: Rotary Default
Sub Menu-7: ROTARY DEFAULT DEFAULT - BRIGHTNESS : Define rotary knob as the trigger D E F AU LT - B R I GHTN E S S DEFAULT - CONTRAST : Define rotary knob as the trigger D E F AUL T - CONT R A S T DEFAULT - VOLUME : Define rotary knob as the trigger D E F AU L T - VOL UM E SAVE : Save user adjustment and return to main menu. - Page 18 Sub Menu-8: ENGLISH: Select English as the OSD language. FRANÇAIS: Select French as the OSD language. DEUTSCH: Select German as the OSD language. ITALIANO: Select Italian as the OSD language. ESPAÑOL: Select Spanish as the OSD language. SAVE : Save user adjustment and return to main menu. CANCEL : Abandon setup and return to main menu.
-
Page 19: Display Mode
Sub Menu-9: DISPLAY MODE DISPLAY MODE: Display monitor resolution and scanning frequency. D I S P L A Y MOD E 1 0 2 4 x 7 6 8 6 9 K 8 5H z Sub Menu-10: AUDIO VOLUME: Adjusts speaker volume. -
Page 20: Data Storage
User can adjust the parameters via OSD, as preceding procedures which already described on "Adjustment via On-Screen-Display" section. (C) New mode The monitor is reversed for 4 new modes in case non-standard video modes are used. Frequence Resolution H(KHz) -
Page 21: Automatic Powersaving
AS AN ENERGY STAR PARTNER, PHILIPS, HAS DETERMINED T H AT T H I S P RO D U C T M E E T S T H E E N E R G Y S TA R GUIDELINES FOR ENERGY EFFICIENCY. -
Page 22: Specification
Specification* (I) General Screen size Focusing method Dot pitch Phosphor Screen treatment Display area Factory preset Maximum usable Scanning frequency Horizontal (line) Vertical (frame) Input power Power consumption Input signal Video Audio Sync Pedestal Tilt Swivel Physical Unit dimension (WxHxD) Net weight Operating condition Temperature... - Page 23 (II) Pin assignment: (1) The 15-pin D-sub connector (male) of the signal cable (IBM systems): Pin No. Assignment Red video input Green video input Blue video input Identical output - Connected to pin 10 Ground Red video ground Green video ground Blue video ground (2) The 15-pin D-sub connector (male) of the adapter ( Apple Macintosh systems):...
