Summary of Contents for Philips 109B

  • Page 1 2:52:36 PM...

  • Page 2: Safety And Troubleshooting Information

    Do not place objects on top of the monitor cabinet, objects could fall into vents or cover them and prevent proper cooling of the monitor's electronic devices. To avoid the risk of shock or permanent damage to the set, do not expose the monitor to rain or excessive moisture.
  • Page 3 Other Documents You May Need About This Guide This electronic user's guide is intended for anyone who uses the Philips Color Monitor. It describes the monitor's features, setup, operation and all other information, which is the same exact information described in our printed version.

  • Page 4: Notational Descriptions

    About This Electronic User's Manual Philips Color Monitor Quick Start Guide which summarizes the steps for setting up the monitor. This is included with this product. Notational Descriptions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type.
  • Page 5 About This Electronic User's Manual ©2004 Koninklijke Philips Electronics N.V. All rights reserved. Reproduction, copying, usage, modifying, hiring, renting, public performance, transmission and/or broadcasting in whole or in part is prohibited without written consent of Philips Electronics N.V. file:///D|/EDFU/crt_19/edoc/english/109B/ABOUT/ABOUT.HTM (3 of 3)7/19/2004 2:53:36 PM...

  • Page 6: Product Information

    FCC, CE (in selected countries only) and ISO9241, ISO14001 certified LightFrame™ for Windows Introduction Philips LightFrame™ feature enriches the experience of pictures and video on a Philips CRT (picture tube) monitor. LightFrame™ will boost the brightness and sharpness of photos and videos on the monitor screen.
  • Page 7 It is recommended that you install this software only on a Philips monitor designed to use it. These monitors can be identified by the LightFrame™ logo on the front of the monitor.
  • Page 8 LightFrame™ Q: Is LightFrame™ 2 compatible with LightFrame™ 3? A: No. If you run LightFrame™ 1 or 2 software with a Philips LightFrame™ 3 monitor, nothing will happen. Q:Can I use LightFrame™ 3 software on my LightFrame™ 1 / 2 monitor.
  • Page 9 A:To check which version of LightFrame™ is supported by your monitor check the LightFrame logo which you will find on the top, right-hand corner of the monitor. If this logo has a small 3 in it, your monitor is ready for LightFrame™ 3. Otherwise you should use the LightFrame™ 1 or 2 software.
  • Page 10 A:Nothing is wrong. The effect which you see is due to the sharpness enhancement that LightFrame™ is doing on your monitor. This sharpness improves a photo or video significantly however on black text on a light background the effect is less favorable. Please keep in mind that LightFrame™ is developed to file:///D|/EDFU/crt_19/edoc/english/109B/PRODUCT/PRODUCT.HTM (5 of 11)7/19/2004 2:53:38 PM...
  • Page 11 Q: How can I tell if my monitor comes with LightFrame™ 3? A: All Philips LightFrame™ 3 monitors display this logo on their front bezel: Q: How do I use the LightFrame™ 3 control bar that appears at the top my screen? A: The control bar is another upgrade that helps you run all LightFrame™...
  • Page 12 - Sync • Input signal levels • Sync input signal • Sync polarities WHITE COLOR TEMPERATURE file:///D|/EDFU/crt_19/edoc/english/109B/PRODUCT/PRODUCT.HTM (7 of 11)7/19/2004 2:53:38 PM RETURN TO TOP OF THE PAGE 19 inch / 46 cm ; 90° deflection angle 0.25 mm 0.21 mm...
  • Page 13 Using a standard unified color space, sRGB will help represent pictures taken by an sRGB compatible device correctly on your sRGB enabled Philips monitors. In that way, the colors are calibrated and you can rely on the correctness of the colors shown on your screen.
  • Page 14 109B Product Information other input device is detected, the monitor will automatically "wake up". The following table shows the power consumption and signaling of this automatic power saving features: VESA's Mode Video Active Blanked This monitor is NERGY determined that this product meets the Physical Specifications 17.3"...
  • Page 15 Identical output - connected to pin 10 Ground Red video ground Green video ground Blue video ground Views file:///D|/EDFU/crt_19/edoc/english/109B/PRODUCT/PRODUCT.HTM (10 of 11)7/19/2004 2:53:38 PM RETURN TO TOP OF THE PAGE Assignment No pin Logic ground Identical output - connected to pin 10 Serial data line (SDA) H.

  • Page 16: Front View

    109B Product Information Follow the links to see various views of the monitor and its components. Front View Rear View file:///D|/EDFU/crt_19/edoc/english/109B/PRODUCT/PRODUCT.HTM (11 of 11)7/19/2004 2:53:38 PM RETURN TO TOP OF THE PAGE...

  • Page 17: Installing Your Monitor

    • 6G3B11 Multimedia Base (option) Front View Power button switches your monitor on. OK button which when pressed will take you to the OSD controls Contrast hotkey. When the "-" button is pressed, the adjustment controls for the CONTRAST will show up.

  • Page 18: Rear View

    Installing your Monitor "-" and "+" buttons, are used for adjusting the OSD of your monitor. RETURN TO TOP OF THE PAGE Rear View file:///D|/EDFU/crt_19/edoc/english/install_6/INSTALL.HTM (2 of 3)7/19/2004 2:53:39 PM...
  • Page 19 Installing your Monitor 1. Power in - attach power cable here. 2. Video In - this is a cable which is already attached to your monitor. Connect the other end of the cable to your PC. file:///D|/EDFU/crt_19/edoc/english/install_6/INSTALL.HTM (3 of 3)7/19/2004 2:53:39 PM...

  • Page 20: Description Of The On-Screen Display

    Description of the On Screen Display What is the On-Screen Display? This is a feature in all Philips monitors which allows an end-user to adjust screen performance of monitors directly through an on-screen instruction window. The user interface provides user- friendliness and ease-of-use when operating the monitor.
  • Page 21 Below is an overall view of the structure of the On-Screen Display. You can use this as reference when you want to later on work your way around the different adjustments. Your monitor may not include all the items in the OSD tree shown below. file:///D|/EDFU/crt_19/edoc/english/OSD_3/OSDDESC.HTM (2 of 4)7/19/2004 2:53:39 PM...
  • Page 22 On-Screen Display file:///D|/EDFU/crt_19/edoc/english/OSD_3/OSDDESC.HTM (3 of 4)7/19/2004 2:53:39 PM...
  • Page 23 On-Screen Display RETURN TO TOP OF THE PAGE file:///D|/EDFU/crt_19/edoc/english/OSD_3/OSDDESC.HTM (4 of 4)7/19/2004 2:53:39 PM...

  • Page 24: Customer Care And Warranty

    Customer Care and Warranty Customer Care & Warranty PLEASE SELECT YOUR COUNTRY/AREA TO READ THE WARRANTY COVERED: WESTERN EUROPE: Austria • Belgium • Cyprus • Denmark • France • Germany • Greece • Finland • Ireland • Italy • Luxembourg • the Netherlands • Norway • Portugal • Sweden • Switzerland •...

  • Page 25: Frequently Asked Questions

    Increasingly, monitors include USB hub functionality. But not all users need or want a USB hub. To give users freedom of choice, Philips provides an optional USB hub (type number PCUH411). The USB hub consists of two parts that are normally connected: one is functional, the other aesthetic. The aesthetic element is a removable cover.
  • Page 26 Frequently Asked Questions What models are Mac compatible? All listed Philips monitors are Mac compatible. BUT, you may need an adapter to connect the monitor to your Mac system. Please contact your dealer/reseller for details. What is TCO? TCO is a Swedish abbreviation for the Swedish Confederation of Professional Employees.
  • Page 27 Go to 'My Computer' and select 'Control Panel' followed by 'Monitor Control.' Select "All default selection' and choose your Philips monitor model from the default driver list. Plug and Play will automatically enable the EPA tick box for you. In DOS or Windows 3.1, you must first make sure your PC supports power saving.
  • Page 28 "Refresh rate" describes the number of times an entire screen is vertically scanned each second. In other words: If a monitor's refresh rate is 85 Hz, its screen is refreshed - or vertically scanned - 85 times per second. A higher the refresh rate means better image stability and less flicker. A high refresh rate helps users who work long hours in front of a monitor avoid eye fatigue and stress.
  • Page 29 18. Why is LightFrame important to me? With LightFrame , selected Philips monitors deliver TV quality video and photo display while maintaining monitor performance for text-based applications. The result is that movies and other video are brighter and livelier;...
  • Page 30 Frequently Asked Questions 19. Will anyone else have this? LightFrame was invented, developed and patented by Philips. It is a unique feature that you will find exclusively in Philips monitors. 20. Will LightFrame shorten the life of a monitor? No. Extensive testing has confirmed LightFrame does not adversely affect monitor life. Today's state-of- the-art Philips monitors employ improved phosphors and are designed for high light output.
  • Page 31 25. What is Philips monitors' solution for audio? Not all users need multimedia capabilities. To give users freedom of choice, Philips provides an optional Multimedia Base (type number: 6G3B10). The Multimedia Base replaces the easily removable standard pedestal of the monitor.
  • Page 32 Only the monitor's height is increased by only 3 centimeters. 29. Where can I buy a multimedia base to incorporate with my Philips monitor? Please contact your dealer/reseller for details.
  • Page 33 With Auto Calibrate, it takes a monitor's luminance 33 percent longer to deteriorate to the 50 percent level that marks the end of a display device's useful life. Thanks to Auto Calibrate, a monitor with a normal life of 10,000 hours, for example, would last for 13,300 hours, a full one third longer.
  • Page 34 37. Why does my monitor display "Out of Range"? The video card installed in your computer may be too high for the monitor 's specifications. Please contact your computer manufacturer for details on how to lower resolution for your operating system.
  • Page 35 This is an intentional design and is an industry standard, not just for Philips monitors. Please be aware that not all models in the Philips range has this manual degauss function. Some models are built with an auto degauss feature which automatically degausses the monitor when it is switched on.
  • Page 36 Adjust Brightness and/or Contrast via the monitor 's OSD. Some models have a Video Input Select under Advanced Controls in the monitor 's OSD. Most computers require it to be set at 0.7V. Please review the following for possible solutions:...
  • Page 37 Frequently Asked Questions 45. I have noticed two thin horizontal lines on the screen of my Philips monitor. Is this normal? This phenomenon can occur with Philips 107P, 109P and 201P monitors and is normal. Your monitor is using an Aperture Grille, which consists of fine vertical wires to align the electron beams with the phosphors on the screen.
  • Page 38 50. Why does the picture disappear after I press the on/off button quickly? This is a unique Philips feature designed to preserve the life of your monitor. Please allow 5 seconds between powering off and on your monitor, your picture will then be restored.
  • Page 39 L M N O P Autoscan A microprocessor-based feature of Philips Brilliance monitors is able to detect automatically horizontal and vertical frequencies of input signals with those of the installed video card. An autoscan monitor can thus operate with a wide range of video cards. MultiSync, a registered trademark of NEC, provides a similar function.

  • Page 40: Color Temperature

    A way of describing the color of a radiating source in terms of the temperature (in degrees Kelvin) of a black body radiating with the same dominant frequency as the source. Most Philips monitors offer the possibility of setting the color temperature to any desired value. Contrast The ratio between the brightness of the brightest and darkest parts of a picture.
  • Page 41 Glossary a picture is set by the brightness of the unexcited phosphor, which is governed by the degree with which ambient light is reflected. Contrast is therefore reduced in conditions of high ambient light levels. Black Matrix tubes reflect less ambient light so exhibit higher contrast than other tubes. Convergence error Bean misalignment causing one or more of the three beams passing through the wrong aperture in the shadow mask and striking a phosphor dot in the wrong triad.
  • Page 42 DDC is implemented as part of the new Plug & Play approach introduced into the PC market to increase user friendliness. The three levels developed for Plug & play are: (1) DDC1, monitor send data to the PC; (2) DDC2B, PC can request information from monitor; and (3) DDC2Bi which is a two-way communication - monitor can be addressed and PC or graphics board can give commands to monitor.

  • Page 43: Digital Control

    This is a very advanced feature that allows the user to switch to any required mode at any instant without having to spend time readjusting the picture. It is currently available in most Philips monitors. Dot pitch The shortest distance between two phosphor dots of the same color on the screen.
  • Page 44 Glossary Dot rate Frequency in MHz of the dot clock. It is a measure of the speed with which data is transferred between the video card and subsequent processing circuitry. Also known as video dot rate. Electromagnetic radiation standards International standards set to limit electromagnetic emissions from monitors. There are currently file:///D|/EDFU/crt_19/edoc/english/GLOSSARY/GLOSSARY.HTM (6 of 22)7/19/2004 2:53:45 PM RETURN TO TOP OF THE PAGE...
  • Page 45 MPR-II defines maximum permitted electrostatic, magnetic and electric field levels measured at a distance of 50 cm from the center of the monitor (see table). In 1991, the Swedish Tjänstemannens Central Organization (TCO, Swedish confederation of Professional Employees ) set a standard even more severe than MPR-II, especially for alternating electric fields (AEF).
  • Page 46 Glossary problem can, however, be eliminated by increasing the refresh rate (number of frames/second) of the monitor to a value above around 70 Hz. Sensitivity to flicker appears to diminish with increasing age. Hertz The unit of frequency named after the physicist Heinrich Hertz (1857-1894). 1 hertz (Hz) is equal to 1 cycle/second.
  • Page 47 Glossary INF file (Information File) Information (INF) files store information in a specific format. The set-up functions retrieve information from the INF file to use when performing installation operations. Examples of the type of information stored in an INF file include INI and registry changes, file names, and locations of the source files on source media.

  • Page 48: Line Frequency

    The degree to measure the actual location of a pixel on the screen corresponds with its intended location. ( see figure ) Line frequency See Horizontal scanning frequency. Low-emission monitor A monitor that complies with international standards on radiation. See Electromagnetic radiation standards. Low-frequency electric and magnetic fields file:///D|/EDFU/crt_19/edoc/english/GLOSSARY/GLOSSARY.HTM (10 of 22)7/19/2004 2:53:45 PM...
  • Page 49 A fringe pattern arising from the interference between two superimposed line patterns. In a monitor it comes from the interference between the shadow mask pattern and the video information (video moiré), and between the shadow mask pattern and the horizontal line pattern (scan moiré).
  • Page 50 Glossary Non-interlaced See Interlaced/non-interlaced. OSD (On Screen Display) The feature that allows an end user to adjust screen performance and parameters of monitors directly through an on-screen instruction window. See CustoMax in CrystalClear section. Overscan The practice in which areas without useful video information are scanned outside the visible screen area in order to make maximum use of the screen for display of active video information.
  • Page 51 (the size of the triad). Thus, a monitor with a large electron spot covering several triads can exhibit poor resolution even though its dot pitch is small.
  • Page 52 Rotation function The feature that allows users to adjust the whole screen rotating to be horizontal. Because of the magnetic field of earth, the screen of monitor will be tilt when the screen faces toward the different direction. file:///D|/EDFU/crt_19/edoc/english/GLOSSARY/GLOSSARY.HTM (14 of 22)7/19/2004 2:53:46 PM...
  • Page 53 Screen coatings Anti-Static coatings Due to bombardment by beam electrons, monitor screens become electrically charged when in use. Electrically charged screens surfaces can attract dust particles. An Anti-Static coating is a conductive coating deposited on the screen (or on a glass panel immediately in front of the screen) that conducts away the charge and prevents screen dust build-up.

  • Page 54: Self-Test Function

    AGRAS (Anti-Glare anti-Reflection Anti-Static) coating. A combined anti-reflection, anti-glare, anti-static coating. Self-test function A monitor equipped with hardware or software to automatically detect cable connection status. Shape Deviation of a reproduced picture from its intended shape. The following types of distortion are most...
  • Page 55 SOG (Synchronization On Green) A properly functioning color monitor requires five kinds of signals: horizontal sync pulse, vertical sync pulse, red color signal, green color signal and blue color signal. Signals from a PC are transmitted to a monitor using one of three methods: 1.

  • Page 56: Tilt Function

    With TTL driving, the red, green and blue signals can only be switched on or off or provided with an intensity signal. A TTL-driven monitor can thus display a maximum of 64 colors. Video standards such as MDA, CGA and EGA are based on TTL level.
  • Page 57 The controller provides the interface registers to allow communication to/from the host. Hub specific status and control commands permit the host to configure a hub and to monitor and control its ports. Device A logical or physical entity that performs a function. The actual entity described depends on the context of the reference.
  • Page 58 Upstream ports receive downstream data traffic. UPS (Universal Power Supply) The monitor with UPS feature can work in different countries with various mains voltage. file:///D|/EDFU/crt_19/edoc/english/GLOSSARY/GLOSSARY.HTM (20 of 22)7/19/2004 2:53:46 PM RETURN TO TOP OF THE PAGE...
  • Page 59 Glossary Vertical dot pitch See Dot pitch. Vertical scanning frequency Expressed in Hz, this is the number of fields written to the screen every second in interlaced mode. In non-interlaced mode vertical scanning frequency is the number of frames (complete pictures) written to the screen every second (also known as refresh rate).
  • Page 60 For example, the VIS of a 17-inch monitor is only about 16 inches. It depends on the useful screen size of CRT and the opening of a monitor's front cabinet.

  • Page 61: Download And Print

    3. Choose where you would like to save the image; click 'Save' (if prompted to save as either 'text' or 'source', choose 'source'). Printing instructions: To print the manual: 1. With the manual file open, follow your printer's instructions and print the pages you need. 109B.pdf 109E.pdf 109F.pdf 109P.pdf 201B.pdf file:///D|/EDFU/crt_19/edoc/english/DOWNLOAD/DOWNLOAD.HTM (1 of 2)7/19/2004 2:53:46 PM...
  • Page 62 Download and Print 202F.pdf 202P.pdf file:///D|/EDFU/crt_19/edoc/english/DOWNLOAD/DOWNLOAD.HTM (2 of 2)7/19/2004 2:53:46 PM...

  • Page 63: Troubleshooting

    No Picture (Power LED is green) Screen doesn't show when you turn on the monitor file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/saf_troub.htm (1 of 3)7/19/2004 2:54:08 PM • Troubleshooting • Regulatory Information Check these items Make sure the Power cable is plugged into the power outlet and back of the monitor.
  • Page 64 Picture is not sharp. Unstable Picture Problem with On Screen Display file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/saf_troub.htm (2 of 3)7/19/2004 2:54:08 PM If you are using a non-VESA-DDC standard video card, turn the DDC1 / 2B feature Off. The picture may need degaussing. Remove any nearby magnetic objects.
  • Page 65 Troubleshooting For further assistance, refer to the distributor. file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/saf_troub.htm (3 of 3)7/19/2004 2:54:08 PM Consumer Information Centers RETURN TO TOP OF THE PAGE list to contact your local Philips...

  • Page 66: Regulatory Information

    The main problem, as far as computers and other electronics equipment are concerned, is that environmentally harmful substances are used both in the products and during their manufacture. Since it is not so far possible to satisfactorily file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (1 of 17)7/19/2004 2:54:11 PM • •...
  • Page 67 Below you will find a brief summary of the environmental requirements met by this product. The complete environmental criteria document may be ordered from: TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (2 of 17)7/19/2004 2:54:11 PM...

  • Page 68: Flame Retardants

    The relevant TCO' 99 requirement states that batteries may not contain any mercury. It also demands that mercury is not present in any of the electrical or electronics components associated with the labeled unit. file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (3 of 17)7/19/2004 2:54:11 PM http://www.tco-info.com/ RETURN TO TOP OF THE PAGE...
  • Page 69 Some of the features of the TCO'03 Display requirements. file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (4 of 17)7/19/2004 2:54:11 PM RETURN TO TOP OF THE PAGE...
  • Page 70 1980s TCO has been involved in influencing the development of IT equipment in a more user-friendly direction. Our labelling system started with displays in 1992 and is now requested by users and IT-manufacturers all over the world. file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (5 of 17)7/19/2004 2:54:11 PM For more information, please visit www.tcodevelopment.com...
  • Page 71 Philips establishes technically and economically viable objectives to optimize the environmental performance of the organization's product, service and activities. From the planning, design and production stages, Philips emphasizes the important of making products that can easily be recycled. At Philips, end-of-life management primarily entails participation in national take-back initiatives and recycling programs whenever possible, preferably in cooperation with competitors.
  • Page 72 Tel: +1 865 521 4322 CE Declaration of Conformity Philips Consumer Electronics declare under our responsibility that the product is in conformity with the following standards - EN60950:2000 (Safety requirement of Information Technology Equipment) - EN55022:1998 (Radio Disturbance requirement of Information Technology Equipment)

  • Page 73: Federal Communications Commission (Fcc) Notice (U.s. Only)

    One Step s an NERGY meets the We recommend you switch off the monitor when it is not in use for quite a long time. Federal Communications Commission (FCC) Notice (U.S. Only) file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (8 of 17)7/19/2004 2:54:11 PM PHILIPS 109B5*...

  • Page 74: Commission Federale De La Communication (Fcc Declaration)

    Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Use only RF shielded cable that was supplied with the monitor when connecting this monitor to a computer device.
  • Page 75 N'utiliser que des câbles RF armés pour les connections avec des ordinateurs ou périphériques. CET APPAREIL NUMERIQUE DE LA CLASSE B RESPECTE TOUTES LES EXIGENCES DU REGLEMENT SUR LE MATERIEL BROUILLEUR DU CANADA. EN 55022 Compliance (Czech Republic Only) file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (10 of 17)7/19/2004 2:54:11 PM RETURN TO TOP OF THE PAGE...
  • Page 76 Interference. Install and use the equipment according to the instruction manual. Class B ITE MIC Notice (South Korea Only) Class B Device file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (11 of 17)7/19/2004 2:54:11 PM RETURN TO TOP OF THE PAGE RETURN TO TOP OF THE PAGE...

  • Page 77: Polish Center For Testing And Certification Notice

    Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, monitor, printer, and so on) should have the same power supply source.
  • Page 78 Regulatory Information North Europe Information (Nordic Countries) Placering/Ventilation VARNING: FÖRSÄKRA DIG OM ATT HUVUDBRYTARE OCH UTTAG ÄR LÄTÅTKOMLIGA, NÄR DU STÄLLER DIN UTRUSTNING PÅPLATS. file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (13 of 17)7/19/2004 2:54:11 PM RETURN TO TOP OF THE PAGE...
  • Page 79 SIJOITA LAITE SITEN, ETTÄ VERKKOJOHTO VOIDAAN TARVITTAESSA HELPOSTI IRROTTAA PISTORASIASTA. Plassering/Ventilasjon ADVARSEL: NÅR DETTE UTSTYRET PLASSERES, MÅ DU PASSE PÅ AT KONTAKTENE FOR STØMTILFØRSEL ER LETTE Å NÅ. BSMI Notice (Taiwan Only) file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (14 of 17)7/19/2004 2:54:11 PM RETURN TO TOP OF THE PAGE...
  • Page 80 Inbetriebnahme hinweist, da die Vorschriften über die Bauart von Störstrahlern nach Anlage III ¤ 5 Abs. 4 der Röntgenverordnung erfüllt sind. Damit Ihr Monitor immer den in der Zulassung geforderten Werten entspricht, ist darauf zu achten, daß Reparaturen nur durch Fachpersonal durchgeführt werden.
  • Page 81 Regulatory Information Please find out about the local regulations on how to dispose of your old monitor from your local Philips dealer. Information for UK only file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (16 of 17)7/19/2004 2:54:11 PM RETURN TO TOP OF THE PAGE WARNING - THIS APPLIANCE MUST BE EARTHED.
  • Page 82 Regulatory Information file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/regs/regulat.htm (17 of 17)7/19/2004 2:54:11 PM How to connect a plug The wires in the mains lead are coloured in accordance with the following code: BLUE - "NEUTRAL" ("N") BROWN - "LIVE" ("L") GREEN & YELLOW - "EARTH" ("E") 1.

  • Page 83: Other Related Information

    Use a Cord Set consisting of a minimum 18 AWG cord and grounding type attachment plug rated 15 A, 250 V. The Cord Set should have the appropriate safety approvals for the country in which the equipment will be installed and / or be marked HAR. file:///D|/EDFU/crt_19/edoc/english/109B/SAFETY/saf_other.htm7/19/2004 2:54:11 PM • Troubleshooting •...
  • Page 84 6G3B11 Multimedia Base (option) 6G3B11 Multimedia Base (option) Front View • Rear View • Technical Specifications Multimedia Base • Power adapter Installation Technical Specifications* • Output power • Bass Boost • Headphone connection • Microphone in/out • Includes • Dimension •...
  • Page 85 6G3B11 Multimedia Base (option) Installing your Multimedia Pedestal file:///D|/EDFU/crt_19/edoc/english/install_6/mm_pede/mm_inst.htm (2 of 5)7/19/2004 2:54:18 PM Attach your headphones here. The loudspeakers will automatically switch off once headphones are connected. Attach your microphone here. Connect this to the audio output of your PC. Connect this to the microphone output of your PC.
  • Page 86 Slide the pedestal, aligning with the holes on the side. Then click the back hook into the corresponding hole on the bottom plate of your monitor. 2. To UN-INSTALL Lift the back hook from the hole on the bottom plate of your monitor.
  • Page 87 6G3B11 Multimedia Base (option) Multimedia Base DC input Note: Please keep least 50 cm ) to avoid cansing unstable monitor picture. file:///D|/EDFU/crt_19/edoc/english/install_6/mm_pede/mm_inst.htm (4 of 5)7/19/2004 2:54:18 PM PC power cord. Transformer Power outlet transformer away from monitor as far as possible ( at...
  • Page 88 6G3B11 Multimedia Base (option) RETURN TO TOP OF THE PAGE file:///D|/EDFU/crt_19/edoc/english/install_6/mm_pede/mm_inst.htm (5 of 5)7/19/2004 2:54:18 PM...
  • Page 89 Philips helpdesk directly to benefit from your Philips F1rst Choice Warranty. This three-year service warranty entitles you to a swap model on-site if your monitor turns out to be faulty or defective.Philips aims at a swap within 48 hours of your call being received.
  • Page 90 Note that products that are not originally designed, manufactured, approved and/or authorized for usage within the Philips F1rst Choice countries, do not apply to the Philips F1rst Choice Warranty. In these cases the Philips global warranty terms are valid.
  • Page 91 Your proof of purchase indicating: date of purchase, dealer name, model and product serial number. The full address to which the faulty monitor has to be collected and the swap model should be delivered. Philips' customer help desks are located worldwide. Click here to access the Information.

  • Page 92: Your International Guarantee

    In the event you require service whilst in another country a dealer address can be given to you by the Philips Consumer Help Desk in that country, the telephone and fax number of which can be found in the relevant part of this booklet.
  • Page 93 International Guarantee http://www.philips.com Website: file:///D|/EDFU/crt_19/edoc/english/WARRANTY/war_intl.htm (2 of 2)7/19/2004 2:54:25 PM...
  • Page 94 Philips F1rst Choice Warranty Thank you for purchasing this Philips monitor. All Philips monitors are designed and manufactured to high standards and deliver high-quality performance, ease of use and ease of installation. Should you encounter any difficulties while installing or using this product, please contact Philips directly to benefit from your Philips F1rst Choice Warranty.
  • Page 95 Where IS SERVICE AVAILABLE? Warranty service is available in all countries where the product is officially distributed by Philips Consumer Electronics. In countries where Philips Consumer Electronics does not distribute the product, the local Philips service organization will attempt to provide service (although there may be a delay if the appropriate spare parts and technical manual(s) are not readily available).
  • Page 96 Please contact Philips at: (800) 479-6696 Three years free parts and three years free labor will be provided at Philips Canada depot or any one of its authorized service centers. (In Canada, this warranty is given in lieu of all other warranties. No other warranties are expressed or implied, including any implied warranties of merchantability or fitness for a particular purpose.
  • Page 97 United States Guarantee This warranty gives you specific legal rights. You may have other rights which vary from state/ province to state/province. Before contacting Philips, please prepare the following details so we can solve your problem quickly. Philips type number...

  • Page 98: F1Rst Choice Contact Information

    F1rst Choice Contact Information F1rst Choice Contact Information Telephone numbers: Austria 01 546 575 603 Belgium 02 275 0701 Cyprus 800 92256 Denmark 35 25 87 61 France 03 8717 0033 Germany 0696 698 4712 Greece 00800 3122 1223 Finland 09 2290 1908 Ireland 01 601 1161...

  • Page 99: Consumer Information Centers

    Consumer Information Centers Consumer Information Centers Antilles • Argentina • Australia Czech Republic • Dubai • Egypt India• Indonesia • Japan • Paraguay • Peru • Philippines Thailand • Turkey • Uruguay Eastern Europe CZECH REPUBLIC Xpectrum Lužná 591/4 CZ - 160 00 Praha 6 Tel: 800 100 697 Email:info@xpectrum.cz www.xpectrum.cz...
  • Page 100 Türk Philips Ticaret A.S. Yukari Dudullu Org.San.Bolgesi 2.Cadde No:22 34776-Umraniye/Istanbul Tel: (0800)-261 33 02 Latin America ANTILLES Philips Antillana N.V.Kaminda A.J.E. Kusters 4 Zeelandia, P.O. box 3523-3051 Willemstad, Curacao Phone: (09)-4612799 Fax : (09)-4612772 file:///D|/EDFU/crt_19/edoc/english/WARRANTY/warcic.htm (2 of 12)7/19/2004 2:55:00 PM...
  • Page 101 Consumer Information Centers ARGENTINA Vedia 3892 Capital Federal CP:1430 Buenos Aires Phone: (011)-4544 2047 Fax: (011)-4544 2928 BRASIL Philips da Amazonia Ind. Elet.Ltda. Av.Luis Carlos Berrini, 1400-Sao Paulo-SP Phone: 0800-7010-203 CHILE Philips Chilena S.A. Avenida Santa Maria 0760 P.O. box 2687Santiago de Chile...
  • Page 102 Consumer Information Centers PARAGUAY Philips del Paraguay S.A. Avenida Artigas 1513 Casilla de Correos 605 Asuncion Phone: (021)-211666 Fax : (021)-213007 PERU Philips Peruana S.A. Customer Desk Comandante Espinar 719 Casilla 1841 Limab18 Phone: (01)-2136200 Fax : (01)-2136276 URUGUAY Ind.Philips del Uruguay S.A.
  • Page 103 3 Figtree Drive Homebush Bay NSW 2140 Phone: CIC:1300 363 391, PCE Service:1 300-361 392 Fax:+61 2 9947 0063 NEW ZEALAND Philips New Zealand Ltd. Consumer Help Desk 2 Wagener Place, Mt.Albert P.O. box 1041 Auckland Phone: 0800 477 999 (Toll Free)
  • Page 104 Consumer Information Centers CHINA SHANHAI No. 1102 wuding road, jing an district, 200040 Shanghai, P.R. China Phone: 800 820 5128 (Toll Free) Fax:21-65610647 NANJING No. 12-2 dong da ying bei, zhu jiang road, 210018 Nanjing, P.R. China Phone: 800 820 5128 (Toll Free) Fax:21-65610647 HANGZHOU No.
  • Page 105 Yi huan road, 410061 Chengdu, P.R. China Phone: 800 820 5128 (Toll Free) Fax:21-65610647 HONG KONG Philips Hong Kong Limited Consumer Information Centre 16/F Hopewell Centre 17 Kennedy Road, WANCHAI Phone: 2619-9663 Fax: 2481 5847 file:///D|/EDFU/crt_19/edoc/english/WARRANTY/warcic.htm (7 of 12)7/19/2004 2:55:00 PM...
  • Page 106 68, Shivaji Marg New Dehli 110 015 Phone: (020)-712 2048 ext 2765 Fax: (020)-712 1558 INDONESIA Philips Group of Companies in Indonesia Consumer Information Centre Jl.Buncit Raya Kav. 99-100 12510 Jakarta Phone: (021)-7940040 7984255 Ext 1612 Fax : (021)-7947511 / 7947539...
  • Page 107 46200 Petaling Jaya, Selagor. P.O.box 12163 50768 Kuala Lumpur. Phone: (03)-7950 5501/02 Fax:(03)-7954 8504 PAKISTAN KARACHI Philips Electrical Ind. of Pakistan Consumer Information Centre F-54, S.I.T.E, P.O.Box 7101 75730 KARACHI Phone: (021)-773 1927 Fax:(021)-772 1167 Philips Consumer Service Centre 168-F, Adamjee Road...
  • Page 108 Fax:(021)-772 1167 PHILIPPINES Philips Electronics and Lighting Inc. 106 Valero St., Salcedo Village Makati, Metro Manilla. Phone: (02)-888 0572 , Domestic Toll Free:1-800-10-PHILIPS or 1-800-10-744 5477 Fax:(02)-888 0571 SINGAPORE Philips Singapore Private Ltd. Consumer Service Dept. Lorong 1,Toa Payoh., P.O. box 340...
  • Page 109 S.V. Div. 195 Main R.D. Martindale., Johannesburg P.O.box 58088 Newville 2114 Phone: (011)-4715000 Fax : (011)-4715020 Middle East DUBAI Philips Middle East B.V. Consumer Information Centre P.O.Box 7785 DUBAI Phone: (04)-3353666 Fax : (04)-3353999 EGYPT Philips Egypt Consumer Information Centre 10, Abdel Rahman El Rafei Mohandessin - Cairo, P.O.Box 242...
  • Page 110 Consumer Information Centers file:///D|/EDFU/crt_19/edoc/english/WARRANTY/warcic.htm (12 of 12)7/19/2004 2:55:00 PM...

  • Page 111: Protect Your Investment

    Year Mail This Card Today To Get The Most From Your Purchase! ❏ No, I do not want to receive personalized offers about Philips products or other information from Philips in the future. 3135 015 07803 WARRANTY VERIFICATION OWNER CONFIRMATION MODEL REGISTRATION w w w .

  • Page 112: Warranty Registration Card

    PHILIPS Warranty Card 8/16/02 12:38 PM Page 2 !1375415338! 13754-1533 DEPOSIT 1533 Promptly! Open Please MATERIAL TIME-DATED STAMP CLASS FIRST APPLY PLEASE IMPORTANT Warranty Registration Card RETURN THE ATTACHED CARD WITHIN TEN DAYS TO ENSURE YOUR: ✓ Warranty Verification ✓ Owner Confirmation See Inside For ✓...
