Cobra 602-1103B Instruction Manual

Items Supplied >
1 - Sissy Bar w/ Pad
2 - Mount Brackets (Left/Right)
2 - 5/16"-18 x 1-1/2" Buttonhead Bolts
2 - 5/16"-18 x 1-3/4" Buttonhead Bolts
4 - M8 x 16mm Buttonhead Bolts
Instruction Manual >
Read all instructions carefully before installing your new Cobra
If the motorcycle is equipped with rear reflectors on the fender rail cover than they must be removed
1.
along with any remaining adhesive left on the motorcycle. Save the reflectors for reuse.
Remove the bolts, washers, locknuts and clipnut from the right side fender rail. Save the locknuts and
2.
clipnut for reuse.
Remove the chrome fender rail cover with the turn signal attached (for wire slack, you may need to
3.
disconnect the turn signal wires from the retaining clip under the fender).
Install right sissy bar mounting bracket between the fender rail and fender (part # facing inward).
4.
NOTE: Be careful not to scratch the fender paint when positioning the sissy bar mounting bracket.
Make sure the turnsignal wiring passes through the cutout (slot). Align all the holes and reinstall
chrome fender rail cover into place. See Figure 1.
Insert the supplied 5/16"-18 x 1-1/2" buttonhead bolt through the rear hole of the chrome cover/fender
5.
rail, sissy bar mount bracket, and fender; secure with the stock clipnut. Insert the supplied 5/16"-18 x
1-3/4" buttonhead bolt through the front hole of the chrome cover/fender rail, sissy bar mount bracket,
and fender; secure with the stock locknut. Secure the turnsignal stud with the stock locknut. DO NOT
TIGHTEN AT THIS TIME.
Repeat Steps 2–5 on left side.
6.
Install the sissy bar between the brackets using the four (4) supplied M8 x 16mm buttonhead bolts.
7.
Align sissy bar and torque all bolts to their appropriate values.
8.
Reinstall turn signal wiring into retaining clip. Attach the rear reflectors onto the chrome covers
9.
DECORATIVE BACKREST INSERTS AVAILABLE AT COBRAUSA-HD.COM OR YOUR LOCAL COBRA DEALER
To clean your black accessory use a liquid based soap detergent, such as dishwashing soap applied with a soft cloth and
rinse with clean water. Note: Avoid abrasive cleaning methods such as granular or dry cleansers, simple green, Scotch-
Brite or steel wool pads. Abrasives may breach the coating and shorten life.
* Cobra recommends you always wear a helmet while riding. Please never operate your motorcycle while under
®
the influence of alcohol and/or drugs. Enjoy the new look of your motorcycle and please ride safely.
DOCUMENT NO. 0017 REV. B
04/17
23801 E. La Palma Ave., Yorba Linda, Ca 92887 Ph. 714.692.8180 Fax. 714.692.5016
®
602-1103B / 602-1153B / 602-1203B
Application(s) >
HARLEY SPORTSTER
www.cobrausa-hd.com
2004 - 2017
Page 1 of 1
