PORTFOLIO
HOUSING
6"
H7601TMRI
H7701TMRI
H7603TMRI (Wall Wash)
HOUSING
H7601TMRI=Non-Ferrous Incandescent, Shallow Plenum
H7601TMRICP=Non-Ferrous Incandescent, Shallow Chicago Plenum
H7701TMRI=Non-Ferrous Incandescent, Shallow Plenum
H7701TMRICP=Non-Ferrous Incandescent, Shallow Chicago Plenum
(use H7701TMRI & H7701TMRICP Housings with 1640BA Baffle Trim only)
H7603TMRI=Non-Ferrous Incandescent, Shallow Plenum
H7603TMRICP=Non-Ferrous Incandescent, Shallow Chicago Plenum
(use H7603TMRI & H7603TMRICP Housings with 1660/1661 and 1670/1671 Open Wall Wash Trims only)
TRIM
Open Downlight
A19 100W Max
A21 150W Max
Medium Beam
H7601TMRI
Open Downlight
A19 100W Max
A21 150W Max
Medium Beam
H7701TMRI
Open Wall Wash
A19 100W Max
A21 150W Max
H7603TMRI
Ordering Example
Housing, Trim, Accessories and Lamps ordered as separate line items.
850
COOPER LIGHTING
™
6" Non-Ferrous Shallow
Downlight
A19/21
Shallow plenum open downlight for MRI suites. Low profile
allows use where vertical clearance is limited. Medium
distribution for general lighting from single horizontally
mounted incandescent lamp. Socket adjusts and locks in
position for two lamp sizes. Rated for DC operation.
TRIM
1641=Self Flanged
1640=Molded Trim Ring,
White
TRIM
1640=Molded Trim Ring,
White
TRIM
1661=Single Wall Wash,
Self Flanged
1660=Single Wall Wash,
Molded Trim Ring, White
1671=Double Wall Wash,
Self Flanged
1670=Double Wall Wash,
Molded Trim Ring, White
ACCESSORIES
TRR6=Rimless Trim Ring, White
*Not compatible with Self Flange
FINISH
OPTIONS
LI=Low Iridescent Clear
WF=White
H=Haze
Painted Flange
WMH=Warm Haze
(Self Flanged
G=Gold
only)
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
FINISH
BA=Low Iridescent Clear Specular Upper
Reflector with Black Baffle
FINISH
OPTIONS
LI=Low Iridescent Clear
WF=White
H=Haze
Painted Flange
WMH=Warm Haze
(Self Flanged
G=Gold
only)
WH=Wheat
B=Black
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
Housing
Trim
H7601TMRI
1641GPH
Dimensions
Length
Width
Standard Housing
12"
11-1/2"
Chicago Plenum
12"
11-1/2"
Add 1/4" height to H7603TMRI housings
*
DERATED
WATTAGE
LABEL
DR
=DeRated,
*
Specify
Wattage
DERATED
WATTAGE
LABEL
DR
=DeRated,
*
Specify
Wattage
DERATED
WATTAGE
LABEL
DR
=DeRated,
*
Specify
Wattage
Accessories
Height
Cutout
6"
6-3/8"
6"
5-11/16"
7-1/4"
5-11/16"
7-1/4"
5-11/16"
7-1/4"
