- Page 1 G212A-FR Powered Guitar Cabinet...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 03.05.2022, ID: 489515 (V2)
-
Page 3: Table Of Contents
1.2 Notational conventions........................7 1.3 Symbols and signal words....................... 7 Safety instructions..........................10 Features............................... 14 Installation and starting up........................ 15 Connections and operating elements................... 16 Technical specifications........................22 Plug and connection assignment....................24 Cleaning............................... 27 Protecting the environment......................28 G212A-FR Powered Guitar Cabinet... - Page 4 G212A-FR Powered Guitar Cabinet...
-
Page 5: General Information
Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. G212A-FR Powered Guitar Cabinet... -
Page 6: Further Information
Our online guides provide detailed information on technical basics Online guides and terms. Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. G212A-FR Powered Guitar Cabinet... -
Page 7: Notational Conventions
The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. G212A-FR Powered Guitar Cabinet... - Page 8 NOTICE! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – high-voltage. G212A-FR Powered Guitar Cabinet...
- Page 9 General information Warning signs Type of danger Warning – danger zone. G212A-FR Powered Guitar Cabinet...
-
Page 10: Safety Instructions
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices. G212A-FR Powered Guitar Cabinet... - Page 11 If this is not possible, keep a greater distance or use sufficient ear protectors. NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. G212A-FR Powered Guitar Cabinet...
- Page 12 NOTICE! Possible damage due to installation of a wrong fuse The use of different types of fuses can cause serious damage to the unit. Fire hazard! Only fuses of the same type may be used. G212A-FR Powered Guitar Cabinet...
- Page 13 The plasticiser contained in the rubber feet of this product may possibly react with the coating of your surface and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the surface and use a suitable underlay if neces‐ sary, i.e. felt-pad floor protectors or similar. G212A-FR Powered Guitar Cabinet...
-
Page 14: Features
Operating modes: LINK mono, stereo Volume, Resonance and Presence adjustable per channel 2 × 12" speaker and 2 × 1" high frequency driver Fanless operation Can be set up or used as a tilt-back floor monitor MDF case with handle G212A-FR Powered Guitar Cabinet... -
Page 15: Installation And Starting Up
Take care when running the cables to prevent tripping hazards. NOTICE! Possible property damage by magnetic fields Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate distance to devices that can be adversely affected or damaged by an external magnetic field. G212A-FR Powered Guitar Cabinet... -
Page 16: Connections And Operating Elements
Connections and operating elements Connections and operating elements Front panel INPUTS MONO(LINK) SIGNAL PEAK MUTE PEAK SIGNAL POWER MONO STEREO (LINK) VOLUME RESONANCE PRESENCE VOLUME RESONANCE PRESENCE G212A-FR ACTIVE CABINET ö # $ & + - . G212A-FR Powered Guitar Cabinet... - Page 17 5 [RESONANCE] Resonance control for channel A 6 [PRESENCE] Presence control for channel A 7 [SIGNAL] Indicator LED (green). This LED lights up when the device is turned on and a signal is present in channel A. G212A-FR Powered Guitar Cabinet...
- Page 18 12 [SIGNAL] Indicator LED (green). This LED lights up when the device is turned on and a signal is present in channel B. 13 [VOLUME] Volume control for channel B 14 [RESONANCE] Resonance control for channel B G212A-FR Powered Guitar Cabinet...
- Page 19 Connections and operating elements 15 [PRESENCE] Presence control for channel B 16 [POWER ON | OFF] Main switch to turn the device on and off G212A-FR Powered Guitar Cabinet...
- Page 20 Connections and operating elements Rear panel PUSH PUSH 230V 50Hz 0.5A T2.5AL250V LINE IN B LINE OUT A GROUND LINE OUT B LINE IN A 5 6 7 G212A-FR Powered Guitar Cabinet...
- Page 21 21 [GROUND] Switch to disconnect the ground from the balanced output 22 [LINE OUT B] Output socket for connecting a power amp or another active box (channel B), designed as XLR panel plug, 3-pin (bal‐ anced) G212A-FR Powered Guitar Cabinet...
-
Page 22: Technical Specifications
LINE: 1 V (RMS), INPUTS: 200 mV (RMS) Output power 2 × 100 W (RMS) @ 8 Ω Frequency response (-3 dB) 120 Hz to 5 kHz Sound pressure level (SPL), 124 dB/130 dB (peak) max. Beam angle H:60°, V:40° G212A-FR Powered Guitar Cabinet... - Page 23 5 mm × 20 mm, 2 A, 250 V, slow-blow Dimensions (W × H × D) 706 mm × 356 mm × 518 mm Weight 22.5 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20 %…80 % (non-condensing) Further information Stereo G212A-FR Powered Guitar Cabinet...
-
Page 24: Plug And Connection Assignment
In addition to the conduc‐ tors ‘Ground’ and ‘Signal’, in a balanced transmission a second core is added. This also transfers the signal, but phase-shifted by 180°. G212A-FR Powered Guitar Cabinet... - Page 25 The result is a pure signal without any noise inter‐ ference. 1/4" TS phone plug (mono, unbalanced) Signal Ground, shielding 1/4" TRS phone plug (stereo, unbalanced) Signal (left) Signal (right) Ground G212A-FR Powered Guitar Cabinet...
- Page 26 The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please refer to the drawing and table below for the pin assignment of a suitable XLR plug. Configuration Ground, shielding Signal inverted (DMX–, ‘cold signal’) Signal (DMX+, ‘hot signal’) G212A-FR Powered Guitar Cabinet...
-
Page 27: Cleaning
The fan grids of the device must be cleaned of any contamination, such as dust, etc. on a reg‐ ular basis. Before cleaning, switch off the device and disconnect mains-operated devices from the mains. Only use pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit with a slightly damp lint-free cloth. G212A-FR Powered Guitar Cabinet... -
Page 28: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. G212A-FR Powered Guitar Cabinet... - Page 29 Notes G212A-FR Powered Guitar Cabinet...
- Page 30 Notes G212A-FR Powered Guitar Cabinet...
- Page 32 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
