OPA 1410/1710/2110 RLTM4FPQD(-Z) (Econex Pro)
Air Cooled Packaged Units - Reverse Cycle - R32
CONTENTS
1. GENERAL ..............................................................................1
2. INSTALLATION ......................................................................2
3. REFRIGERATION SYSTEM ...................................................2
4. WIRING ..................................................................................3
5. ECONOMISER .......................................................................3
6. START-UP PROCEDURE ......................................................3
7. OPERATION ...........................................................................7
8. MAINTENANCE .....................................................................9
9. TROUBLESHOOTING ...........................................................9
10. WARRANTY .........................................................................9
APPENDIX I : CONTROLS SET-UP IP ADDRESS ................10
APPENDIX II : MASTER CONTROLLER - SYSTEM INFO .....11
APPENDIX III : UC8 PROTECTION FUNCTIONS ...................12
APPENDIX IV: AIR HANDLING PERFORMANCE ................14
COMMISSIONING CHECK LIST .............................................15
Installation & Maintenance
Page
- 1 -
1. GENERAL
Temperzone OPA Outdoor Air Cooled Packaged units.
Follow these instructions to ensure the optimum performance,
reliability and durability.
Units must be installed in accordance with all national and
regional regulations and bylaws. National Health and Safety
regulations must be followed to avoid personal injuries.
The appropriate local permits must be acquired and
adhered to.
Local regulations on maximum boundary noise need to
be considered when positioning the unit.
The accompanying 'R32 Handling Ducted Packaged Units'
pamphlet forms part of these Installation & Maintenance
instructions.
! WARNING
These units use R32 refrigerant (Class A2L) which is mildly
flammable.
The system shall be installed, operated and stored in a well
ventilated space. If the refrigerant gas comes into contact with
fire, a poisonous gas may occur. Be aware that R32 does not
contain an odour.
If indoors, the appliance shall be stored in a room away from
continuously operating sources known to cause ignition of R32
refrigerant (for example an operating gas appliance or operating
electric heater)
2. INSTALLATION
2.1 Clearances & Service Access
Refer to Specification Sheet supplied for minimum
clearances. If multiple units are to be placed side-by-side
then allow at least 2m between coil faces.
Filter slides are fitted within the unit. Access to the filter
access door should be considered when designing return
and supply air ductwork.
2.2 Mounting
The unit should be fastened to a firm flat horizontal base
using the holes supplied in the mounting channels. When
the unit is being installed on a roof it is recommended that
the unit is installed on a substantial structure with vibration
isolating pads or mounts. If placed on the ground or
concrete pad, use rubber pads or mounts to give 20mm min.
ground clearance.
Flexible duct connections are recommended between the
supply and return ducts and the unit.
Unit is shipped with plastic wedges installed under the
compressors. Ensure these wedges are removed from
the compressor feet prior to starting the unit
(not required for operation).
003-000-262 05/23
Advertisement
Table of Contents
Related Manuals for TemperZone OPA 1410 RLTM4FPQD
Summary of Contents for TemperZone OPA 1410 RLTM4FPQD
-
Page 1: Table Of Contents
Installation & Maintenance CONTENTS 1. GENERAL Page 1. GENERAL ................1 Temperzone OPA Outdoor Air Cooled Packaged units. 2. INSTALLATION ..............2 Follow these instructions to ensure the optimum performance, reliability and durability. 3. REFRIGERATION SYSTEM ...........2 Units must be installed in accordance with all national and 4. -
Page 2: General
2.3 Condensate Drains 4.3 Sensors & Inputs The condensate drains should be ‘U’ trapped outside the See table below for sensors and inputs required for each unit. The traps should have a vertical height of at least 100 control method. mm. -
Page 3: Economiser
Power supply Multiple units using a network switch: ECONOMISER OPTION Fig. 4.g The Economiser package that is factory fitted consists of two opposed blade dampers, one for the fresh air and the The procedure for earthing the shield is described in the corresponding other for the return air. They come complete with individual paragraph. - Page 4 Main Menu: Note: Setting the indoor fan speed too low can bring risk of frost forming on the indoor coil with potential nuisance frost protection trips on cooling, possibly even unit lock-out, and/ or HP trips on heating. Setting the indoor fan speed too high can bring a risk of blowing moisture off the fins of the indoor coil and into the supply air duct.
-
Page 5: Operation
Air flow l/s setpoint Setpoint BACnet license pre-installed in temperzone factory. 7.2 BMS Modbus For information regarding using Modbus commands, please ask temperzone. 7.3 Stand Alone Unit Master controller site set-up: Press Program button .to bring up the Main Menu Press (↓), then select ‘B. - Page 6 Skip past this page (↓) unless you want to change the factory setting. The mode of the unit can be limited to heating only or cooling only, if required to suit the application. Setpoints Use Up/Down (↑/↓) keys to adjust the value or press enter key (↵) to move to the next value.
- Page 7 11. Scroll down (↓) to the next page. 12. Scroll down (↓) to the next page. Quick access to a daily schedule to set the Unoccupied hours. Return to the Main Menu (↵) Indoor Fan Configuration 13. Main Menu/Settings/Indoor Fan Config./Fan Control Method (1).
- Page 8 Note: Spill Air option is only applicable to downward discharge/upward return air units supplied with a Spill Air damper. Return to the Main Menu (↵) 16. Main Menu/Settings/Optimization Quick settings for how the unit operates and controls the coil temperatures during each of the comfort modes.
-
Page 9: Maintenance
& fault diagnostics information or visit 2. Check air supply at all diffusers www.temperzone.biz; model search ‘UC8 Controller’. 3. Check for excessive noise and vibration and correct • Press the Alarm button on the pGD to list the most recent as necessary. -
Page 10: Appendix Icontrols Set-Up : Ip Address
Scroll to ‘Settings’ and press Enter button Scroll to ‘TCP/IP settings’ and press Enter button Select Settings: Default: Static (refer Temperzone for a change to DHCP) IP: Enter an address in the same subnet set on the PC, for example: IP: 192.168.1.1... - Page 11 APPENDIX II MASTER CONTROLLER : SYSTEM INFORMATION Press Program button .to bring up the Main Menu Select ‘A. Information’. Select ‘UC8’. There are up to four separate UC8 controllers in an OPA 1410/1710/2110 – one per refrigeration system. UC8 Info.screens. These show the UC8 controller variables such as suction superheat, expansion valve position, etc.
-
Page 12: Appendix Iii : Uc8 Protection Functions
“UC8 Troubleshooting”, capacity (40%) to 10K at nominal capacity (100%). available at This protection function is disabled when a compressor www.temperzone.biz website; model search ‘UC8’. operates at less than standard mode minimum capacity (< 40%). High pressure protection (HP) - Page 13 Other alarms The Master Controller performs many other protection functions. For example: • Signals from sensors and transducers must remain inside normal operating range. • Modbus RTU communications with Carel c.pCO and Carel Power+ inverter) must continue uninterrupted. • Modbus RTU communications with a controller such as a BMS that is controlling the unit must continue uninterrupted.
-
Page 14: Appendix Iv Air Handling Performance
APPENDIX IV AIR HANDLING PERFORMANCE Note: Airflows are for a dry coil. Refer Airflow Selection below. As filters thickness varies, the fan air flows given are for units installed without filters. No allowance for Reheat coil option. OPA 1410RLTMFPQ l/s - Pa 4000 5000 6000... -
Page 15: Commissioning Check List
°C °C Compressor 4 amps : Required Capacity: Expansion Valve 1: Expansion Valve 2: NOTE: This document to be kept with the unit. Failure to provide this completed page on request by Temperzone may affect unit warranty. - 15 -... - Page 16 Phone: (07) 3308 8333 Email: chch@temperzone.com Email: qldsales@temperzone.com.au Perth Phone: (08) 6399 5900 Email: reception@airskill.com.au AS/NZS ISO 9001: 2015 Materials and specifications are subject to change without notice due to the manufacturer’s ongoing research and development programme. © temperzone ltd 2023 05/23...
