Summary of Contents for Radialight ONSEN
- Page 1 ONSEN Please retain these instructions in a safe place for further reference.
- Page 2 Volume Volume Volume 50cm 15cm 15cm 15cm 30cm...
- Page 3 Ø:6mm / L:35mm...
-
Page 4: For Your Safety
ENGLISH INSTALLATION AND OPERATING MANUAL Before operating the heater, please read these instructions thoroughly to avoid damage and hazardous situations. Any use of this heater other than that stipulated in this instruction manual may cause fire, electric shock or injury, and voids all warranties. -
Page 5: Your Product
INSTALLED WITHIN THE PERIMETER OF BATH TUBS OR SHOW- ERS. This means that it cannot be installed in the areas marked as VOLUME 1 in picture 2. • During function, place the heater in a safe position: at least 1m far from inflammable objects or furnitures; leaving not less than 1m of free space in front of the heater;... - Page 6 • Always make observe the minimum distances from walls, furniture and/or objects, as indicated in picture 4. Never install the product so that the distance between the floor and the lower side of the product is less than 30cm: Remove the wall-mounting bracket fixed to the back of the radiator, by releasing the 2 lower springs; Use a pencil to mark the position of the fixing points (picture 5).
-
Page 7: Using The Heater
6. Using the heater STAND-BY BUTTON Use the button to turn on or put the product in Stand-by. When the product is in Stand-by, two white dashes appear on the display: When the product is turned on, it activates in Automatic mode. The message "AU" is shown for 3 seconds on the display and, after, the set temperature is shown: 3"... - Page 8 SETTINGS The buttons allow you to set the current time and day, the Comfort temperature and to activate or deactivate the detection of the opening of a window. Day "1" corresponds to MONDAY. 3" Press the button for at least 3 seconds to view/ change the settings starting from the time.
- Page 9 DISPLAY / CHANGE THE COMFORT TEMPERATURE The Comfort temperature is shown in the Automatic mode and can be changed by pressing the key. The Eco temperature, used in programmed mode, cannot be changed and is always the same as the Comfort temperature -3.5°C.
- Page 10 WEEKLY PROGRAM The Programmed mode allows to set, for every hour of day and for every day of the week independently, the desired tempe- rature choosing between the Comfort, Eco (equal to that of Comfort decreased by 3.5 ° C) or Frost-free. To activate the Programmed mode, press the key until the display shows "Pr".
-
Page 11: Troubleshooting
BOOST FUNCTION The Boost function allows you to activate timed operation at maximum power without the thermostat control. At the end of this forced operation, the heater returns to the operating mode prior to activation. To activate the function press and at the same time the buttons . - Page 12 Information requirements for electric local space heaters Model identifier(s): ONSEN Item Symbol Value Unit Item Unit Heat output Type of heat input, for electric storage local space heaters only (select one) Nominal heat manual heat charge control, with integrated thermostat...
