Nedis RDFM2100 Series - FM Radio Manual

Parts and Features

On/off button	Press and hold the button to switch the device on or off. When the device is switched on, press the button to enter standby mode and view the date and time. When the alarm sounds, press the button to stop the alarm.
Volume + button	Press the button to increase the volume.
Volume - button	Press the button to decrease the volume.
Tuning + button	Press buttons to manually tune to the required frequency.
Tuning - button	Press and hold the buttons to search the for radio stations automatically.
Mode button	Press the button to set the mode: FM / USB / Memory card.
Preset + button Next button (USB)	FM: Press the button to preset radio stations. Press and hold the button to view the radio station list.
Preset - button Previous button (USB)	USB: Press the button to select tracks.
Play/pause button Program button	Press the button to play or pause a track. Press the button to confirm a memory location.
Digit buttons	Press one of the buttons to select a preset radio station.
Display
USB port	Connect a USB device (max. 32GB) with MP3 music files to the USB port. The device automatically starts to play the MP3 music files.
Memory card slot (SD)	Insert the SD card (max. 32GB) with MP3 music files. The device automatically starts to play the MP3 music files.
Headphone jack	Connect the headphones to the headphone jack. Note: Do not use headphones at high volume levels to prevent hearing damage.
DC input	To charge the device, connect the USB cable to the DC input of the device and to the USB interface or charger.
Battery compartment	Open the battery compartment. Insert the batteries (3.7 V Li-ion) into the battery compartment. Close the battery compartment.
Antenna	Extend the antenna for best possible radio reception.

Use

Presetting radio stations

Manually presetting:

Press the program button to enter programming mode.
Tune to your desired radio station.
Press the program button to confirm the selected radio station.
Press the preset +/- buttons to select the memory location.
Press the program button to confirm the selected memory location.

Automatically presetting:

Press and hold the program button until the frequency on the display starts to run.

Safety

General safety

Read the manual carefully before use. Keep the manual for future reference.
The manufacturer is not liable for consequential damages or for damages to property or persons caused by nonobservance of the safety instructions and improper use of the device.
Only use the device for its intended purposes. Do not use the device for other purposes than described in the manual.
Do not use the device if any part is damaged or defective. If the device is damaged or defective, replace the device immediately.
The device is suitable for indoor use only. Do not use the device outdoors.
The device is suitable for domestic use only. Do not use the device for commercial purposes.
Do not use the device in locations with high humidity, such as bathrooms and swimming pools.
Do not use the device near bathtubs, showers, basins or other vessels containing water.
Do not use a timer or a separate remote-control system that switches on the device automatically.
Do not cover the device.
Place the device on a stable, flat surface.
Keep the device away from flammable objects.

Electrical safety

RISK OF ELECTRIC SHOK! DO NOT OPEN!

To reduce risk of electric shock, this product should only be opened by an authorized technician when service is required.
Disconnect the product from the mains and other equipment if a problem should occur.
Do not use the device if the mains cable or mains plug is damaged or defective. If the mains cable or mains plug is damaged or defective, it must be replaced by the manufacturer or an authorised repair agent.
Before use, always check that the mains voltage is the same as the voltage on the rating plate of the device.
Do not move the device by pulling the mains cable. Make sure that the mains cable cannot become entangled.
Do not immerse the device, the mains cable or the mains plug in water or other liquids.
Do not leave the device unattended while the mains plug is connected to the mains supply.
Do not use an extension cable.

Cleaning and maintenance

Before cleaning or maintenance, always switch off the device, remove the mains plug from the wall socket and wait until the device has cooled down.
Do not use cleaning solvents or abrasives.
Do not clean the inside of the device.
Do not attempt to repair the device. If the device does not operate correctly, replace it with a new device.
Do not immerse the device in water or other liquids.
Clean the outside of the device using a soft, damp cloth. Thoroughly dry the device with a clean, dry cloth.
Clean the ventilation openings using a soft brush.
