Please read these instructions carefully before using this product and save this manual for future use.
OPERATING INSTRUCTIONS
Contents
Getting Started
.................................................2
..............................................3
Useful Information
Troubleshooting
Appendix
............................................29
Personal Computer
CF-74
Model No.
.....................................11
.....................................13
.......................................17
.............................18
....................................20
................................23
..............27
..................................32
series
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Panasonic Toughbook CF-74JCL02AM
Summary of Contents for Panasonic Toughbook CF-74JCL02AM
-
Page 1: Table Of Contents
For further information about the com- puter, you can refer to the on-screen manual. To access the on-screen manual page 17 “On-screen Manual” Please read these instructions carefully before using this product and save this manual for future use. OPERATING INSTRUCTIONS Contents Getting Started ...2... -
Page 2: Introduction
Introduction Thank you for purchasing this Panasonic computer. For optimum performance and safety, please read these instruc- tions carefully. Terms and illustrations in these instructions CAUTION NOTE Enter : Fn + F5 : (Start) - [All Programs]: [start] - [Run] :... -
Page 3: Read Me First
Connect the equipment into an outlet on a circuit differ- ent from that to which the receiver is connected. Consult the Panasonic Service Center or an experi- enced radio/TV technician for help. Warning To assure continued compliance, use only shielded inter- face cables when connecting to a computer or peripheral. - Page 4 Read Me First 8. This equipment may not be used on coin service pro- vided by the telephone company. Connection to party lines is subject to state tariffs. 9. The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other elec- tronic device to send any message via a telephone fax machine unless such message clearly contains in a mar- gin at the top or bottom of each transmitted page or on...
- Page 5 R&TTE, please contact our web address: http://www.doc.panasonic.de Contact and pursuant to at the directive 2004/108/EC, article 9 (2) Panasonic Testing Centre Panasonic Service Europe, a division of Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg, Germany Network connection.
- Page 6 Read Me First Information to the User / Informations destinées aux utilisateurs <Only for model with wireless LAN/Bluetooth> This product and your Health This product, like other radio devices, emits radio fre- quency electromagnetic energy. The level of energy emit- ted by this product however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones.
- Page 7 Failure to comply with these precautions violates safety standards of design, manufacture and intended use of the product. Panasonic assumes no liability for customer failure to comply with these precautions When in a hospital or other health care facility, observe the restrictions on the use of mobiles.
- Page 8 Read Me First Lithium Battery / Pile au lithium Lithium Battery! This computer contains a lithium battery to enable the date, time, and other data to be stored. The battery should only be exchanged by authorized service personnel. Warning! A risk of explosion from incorrect installation or misapplication may possibly occur.
- Page 9 Panasonic cannot be held responsible in any way for any damages or loss resulting from the use of this unit in these types of equipment, devices or systems, etc.
- Page 10 Use only the specified battery pack ( product. Use of battery packs other than those manufac- tured and supplied by Panasonic may present a safety hazard (generation of heat, ignition or rupture). When the battery pack has become degraded, replace...
-
Page 11: Description Of Parts
Description of Parts A :Speaker Reference Manual “Key Combinations” B :USB port Reference Manual “USB Devices” C :Stylus holder D :Multimedia pocket Reference Manual “Multimedia Pocket” E : Hard disk drive Reference Manual “Hard Disk Drive” F : Carrying handle G :Wireless LAN antenna <Only for model with wireless LAN>... - Page 12 Description of Parts Right side EX PC Rear side A :ExpressCard slot Reference Manual “PC Card / ExpressCard” B :PC Card slot Reference Manual “PC Card / ExpressCard” C :Smart Card slot <Only for model with Smart Card slot> Reference Manual “Smart Card” D :USB port Reference Manual “USB Devices”...
-
Page 13: First-Time Operation
First-time Operation Preparation A Check and identify the supplied accessories. If you do not find the described accessories, contact Panasonic Technical Support ( • AC Adaptor ..1 • AC Cord ..1 Model No: CF-AA5803A •... -
Page 14: Insert The Battery Pack
CPU. Wait until the computer cools down, and then turn the power on again. If the computer does not power on even after cooling down, contact Panasonic Technical Support ( Setup Windows. A Follow the on-screen instructions. - Page 15 CAUTION You cannot choose the following words for user name and password: CON, PRN, AUX, CLOCK$, NUL, COM1 to COM9, LPT1 to LPT9. You can change the user name, password, image and security setting after setup of Windows. Remember your password. If you forget the password, you cannot use the Win- dows.
- Page 16 First-time Operation NOTE PC Information Viewer This computer periodically records the management information of the hard disk, etc. The maximum data volume for each record is 1024 bytes. This information is only used for estimating the cause when the hard disk goes down by any possibility.
-
Page 17: On-Screen Manual
(Start) - [All Programs] - [Panasonic] - [On-Line Manuals] - [Important Tips]. Double-click Alternatively click [start] - [All Programs] - [Panasonic] - [On-Line Manuals] - [Important Tips]. NOTE When Adobe Reader update notice is displayed, we recommend you follow the on-screen procedure and update. -
Page 18: Handling And Maintenance
Handling and Maintenance Operation Environment Place the computer on a flat stable surface. Do not place the computer upright or turn it over. If the computer is exposed to an extremely strong impact, it may become inoperable. Temperature: Operation Storage Humidity: Operation Storage... - Page 19 Maintenance To clean the LCD panel Use the soft cloth included with the computer. (For further information, refer to “Suggestions About Cleaning the LCD Surface” that comes with the soft cloth.) To clean areas other than the LCD panel Wipe with a soft dry cloth such as gauze. When using detergent, dip a soft cloth in water-diluted detergent and wring it thoroughly.
-
Page 20: Reinstalling Software
Enter At the confirmation message, select [Yes] and press Enter. Press while [Panasonic] boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password. Set the Product Recovery DVD-ROM into the CD/DVD drive. - Page 21 Turn on the computer. If the password is requested, enter the Supervisor Password. Perform the “First-time Operation” ( Start the Setup Utility and change the settings as necessary. Perform Windows Update. page 14).
- Page 22 Reinstalling Software Reinstalling Windows XP NOTE This computer is provided the license of Microsoft ® ® Microsoft Windows XP Professional). Perform step 1-8 in “Reinstalling Windows Vista” ( Press to execute [1. [Recovery]]. The License Agreement screen appears. To cancel partway, press 0. Press to select [1.
-
Page 23: Troubleshooting (Basic)
You have forgotten the Supervisor Password or User Password: Contact Panasonic Technical Support password. Administrator password: • If you have a password reset disk, you can reset the administrator password. Set •... - Page 24 B Click [Tools] - [Check Now]. C Select the option in [Check disk options] and click [Start]. Start the computer in Safe Mode and check the error details. When the [Panasonic] at startup, press and hold F8 until the Windows Advanced boot screen disappears Options Menu is displayed.
- Page 25 Entering Password On the [Enter Password] The computer may be in ten-key mode. screen, a beep sounds and If the NumLk indicator the password cannot be input. entered. Even after entering the The computer may be in ten-key mode. password, [Type your pass- If the NumLk indicator word] is displayed again.
- Page 26 Troubleshooting (Basic) Touch Pad/Touchscreen The cursor does not work. Cannot input using the touch pad. Cannot input using the touchscreen. Cannot point the correct posi- tion using the included stylus. Reference Manual The Reference Manual is not displayed. Reinstalling B’s Recorder/B’s CLiP A serial number is requested when reinstalling.
-
Page 27: Limited Use License Agreement
DEEMED TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE. Panasonic Corporation (PC) has developed or otherwise obtained the Programs and hereby licenses their use to you. You assume sole responsibility for the selection of the Product (including the associated Programs) to achieve your intended results, and for the installation, use and results obtained therefrom. - Page 28 En utilisant les logiciels, vous vous engagez de manière définitive à respecter les termes, clauses et conditions des présentes. Panasonic Corporation (PC) a mis au point ou obtenu les Logiciels et vous en concède l’utilisation par les présentes. Vous assumez l’entière responsabilité du choix de ce Produit (y compris des Logiciels associés) pour obtenir les résultats escomptés, ainsi que de l’installation, de l’utilisation et des résultats obtenus.
-
Page 29: Specifications
Specifications This page provides the specifications for the basic model. The model number is different according to the unit configu- ration. To check the model number: Check the bottom of the computer or the box the computer came in at the time of purchase. To check CPU speed, memory size and the hard disk drive (HDD) size: Run the Setup Utility ( Reference Manual “Setup Utility”) and select [Information] menu. - Page 30 Specifications Main Specifications Model No. Card PC Card Slot Slots ExpressCard Slot SD Memory Card Slot Smart Card Slot RAM Module Slot Interface Keyboard / Pointing Device Fingerprint Reader Power Supply AC Adaptor Battery Pack Operating Time Charging Time Power Consumption ×...
- Page 31 1 GB = 1,000,000,000 bytes. Your operating system or some application software will report as fewer GB. Data transfer speeds indicate values measured by Panasonic Corporation. The data transfer rate of DVD per 1X speed is 1,350 KB/s. The data transfer rate of CD per 1X speed is 150 KB/s.
-
Page 32: Limited Warranty
Panasonic Computer Solutions Company (referred to as “Panasonic”) will repair the products listed below with new or rebuilt parts, free of charge in the U.S.A. or other Panasonic approved location for the period specified below from the date of original purchase in the event of a defect in materials or workmanship. - Page 33 This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state. For technical support or to arrange for service on your Panasonic computer product, call our toll-free hotline at 1-800-LAPTOP5.
