Features

Technology: Dual input technology allowing both analog and digital inputs off
ambix+ ™
of one connector (DVI-I) as well as additional legacy analog support off of a traditional
15-pin VGA connector. Provides traditional MultiSync technology compatibility for
®
analog as well as DVI-based digital compatibility for digital inputs. DVI-based digital
interfaces include DVI-D,DFP and P&D.
DVI-I: The integrated interface ratified by the Digital Display Working Group (DDWG)
that allows both digital and analog connectors off of one port. The "I" stands for integra-
tion for both digital and analog, The digital portion is DVI-based.
DVI-D: The digital-only subset of DVI ratified by the Digital Display Working Group
(DDWG) for digital connections between computers and displays. As a digital-only
connector, analog support is not provided off a DVI-D connector. As a DVI-based digital
only connection, only a simple adapter is necessary for compatibility between DVI-D and
other DVI-based digital connectors such as DFP and P&D.
DFP (Digital Flat Panel): An all-digital interface for flat panel monitors which is signal
compatible with DVI. As a DVI-based digital only connection, only a simple adapter is
necessary for compatibility between DFP and other DVI-based digital connectors such as
DVI and P&D.
P&D (Plug and Display): The VESA standard for digital flat panel monitor interfaces. It is
more robust than DFP since it allows for other options off a signal connector (options like
USB, analog video and IEEE-1394-995). The VESA committee has recognized that DFP is
a subset of P&D. As a DVI-based connector (for the digital input pins), only a simple
adapter is necessary for compatibility between P&D and other DVI-based digital connec-
tor such as DVI and DFP.
Pivoting Stand: Allows users to adjust the monitor to the orientation that best fits their
application, either Landscape orientation for wide documents, or portrait orientation for
the ability to preview a full page on one screen at one time. The Portrait orientation is also
perfect for full screen video conferencing.
Reduced Footprint: Provides the ideal solution for environments requiring superior image
quality but with size and weight limitations. The monitor's small footprint and low weight
allow it to be moved or transported easily from one location to another.
Control Systems: Six color presets select the desired color setting (sRGB and
AccuColor ®
NATIVE color presets are standard and cannot be changed). Color temperature increases
or decreases, in each preset. R,Y,G,C,B,M,S: Increases or decreases Red, Yellow, Green,
Cyan, Blue, Magenta and Saturation depending upon which is selected. The change in
color will appear on screen and the direction (increase or decrease) will be shown by the
color bars. NATIVE: Original color presented by the LCD panel that is unadjustable.
OmniColor™ control system with sRGB color-matching uses 6-axis color data to ensure
true-to-life color reproduction for still images and real-time videos.
OSM (On-Screen Manager) Controls: Allow you to quickly and easily adjust all elements
®
of your screen image via simple to use on-screen menus.
Features: Enhance human ergonomics to improve the working environment,
ErgoDesign ®
protect the health of the user and save money. Examples include OSM controls for quick
and easy image adjustments, tilt base for preferred angle of vision, small footprint and
compliance with MPRII and TCO guidelines for lower emissions.
15
