Operating Instructions

for advanced features
Digital Camera
DMC-F2
Model No.
Before connecting, operating or
adjusting this product, please read the
instructions completely.
QuickTime and the QuickTime logo are trademarks or registered
trademarks of Apple Inc., used under license therefrom.
VQT2T59

Advertisement

Table of Contents
loading

Related Manuals for Panasonic Lumix DMC-F2

Summary of Contents for Panasonic Lumix DMC-F2

  • Page 1: Operating Instructions

    Operating Instructions for advanced features Digital Camera DMC-F2 Model No. Before connecting, operating or adjusting this product, please read the instructions completely. QuickTime and the QuickTime logo are trademarks or registered trademarks of Apple Inc., used under license therefrom. VQT2T59...
  • Page 2 Before Use Dear Customer, Thank you for choosing Panasonic! You have purchased one of the most sophisticated and reliable products on the market today. Used properly, we’re sure it will bring you and your family years of enjoyment. -  -...

  • Page 3: Information For Your Safety

    Information for Your Safety Carefully observe copyright laws. Recording of pre-recorded tapes or discs or other published or broadcast material for purposes other than your own private use may infringe copyright laws. Even for the purpose of private use, recording of certain material may be restricted.
  • Page 4 Care of the camera  • Do not strongly shake or bump the camera by dropping it etc. This unit may malfunction, recording pictures may no longer be possible or the lens or the LCD monitor may be damaged. • We strongly recommend you do not leave the camera in your trousers pocket when you sit down or forcefully insert it into a full or tight bag etc.

  • Page 5: Table Of Contents

    Contents Before Use Information for Your Safety ... 3 Quick Guide ... 7 Standard Accessories... 8 Names of the Components ... 9 Preparation Charging the Battery ... 11 • About the Battery (charging/ number of recordable pictures) ... 12 Inserting/Removing the Battery/Card (Optional) ...
  • Page 6 • g [PICTURE SIZE]... 70 • h [QUALITY] ... 71 • j [SENSITIVITY] ... 71 • k [WHITE BALANCE] ... 72 • $ [AF MODE] ... 74 • & [BURST] ... 76 • ' [DIGITAL ZOOM] ... 77 • ( [COLOR MODE] ... 77 •...

  • Page 7: Before Use

    Quick Guide This is the overview of the procedure to record pictures with this camera. For each operation, be sure to refer to the corresponding pages. Charge the battery. (P11) • The battery is not charged when the camera is shipped. Charge the battery before use.

  • Page 8: Standard Accessories

    • If any of the accessories are lost, customers in the USA and Puerto Rico should contact Panasonic’s parts department at 1 800 833-9626 and customers in Canada should contact 1 800 99-LUMIX (1-800-995-8649) for further information about obtaining replacement parts.

  • Page 9: Names Of The Components

    Names of the Components 1 Zoom lever (P35) 2 Shutter button (P29) 3 Camera ON/OFF switch (P18) 4 Microphone (P62) 5 Speaker (P25, 83) 6 Self-timer indicator (P50) AF assist lamp (P78) 7 Flash (P44) 8 Lens part 9 Lens barrel 10 LCD monitor (P42, 121) 11 Recording/playback switch (P20) 12 Cursor buttons...
  • Page 10 20 Card/Battery door (P14) 21 DC coupler cover (P15) • When using an AC adaptor, ensure that the Panasonic DC coupler (optional) and AC adaptor (optional) are used. For connection details, refer to P15. 22 Release lever (P14)

  • Page 11: Preparation

    The dedicated battery supports this function. The only batteries suitable for use with this unit are genuine Panasonic products and batteries manufactured by other companies and certified by Panasonic. (Batteries which do not support this function cannot be used). Panasonic cannot in any way guarantee the quality, performance or safety of batteries which have been manufactured by other companies and are not genuine Panasonic products.

  • Page 12: About The Battery (Charging/Number Of Recordable Pictures)

    Detach the battery after charging is completed. When the [CHARGE] indicator flashes  • The battery temperature is excessively high or low. The charging time will be longer than normal. Also, charging may not be completed. • The terminals of the charger or the battery are dirty. In this case, wipe them with a dry cloth.
  • Page 13 Recording conditions by CIPA standard • Temperature: 23 °C (73.4 °F)/Humidity: 50% when the LCD monitor is on. • Using a Panasonic SD Memory Card (32 MB) • Starting recording 30 seconds after the camera is turned on. • Recording once every 30 seconds, with full flash every second recording.

  • Page 14: Inserting/Removing The Battery/Card (Optional)

    Inserting/Removing the Battery/Card • Check that the camera is turned off. • We recommend using a Panasonic card. Slide the release lever in the direction of the arrow and open the card/battery door. • Always use genuine Panasonic batteries. • If you use other batteries, we cannot guarantee the quality of this product.
  • Page 15 Using any other equipment may cause damage. Note • Always use a genuine Panasonic AC adaptor (optional). • Some tripods cannot be attached when the DC coupler is connected. • Make sure to unplug the AC adaptor when you open the card/battery door.

  • Page 16: About The Built-In Memory/The Card

    About the Built-in Memory/the Card The following operations can be performed using this unit. • When a card has not been inserted: Pictures can be recorded in the built-in memory and played back. • When a card has been inserted: Pictures can be recorded on the card and played back.
  • Page 17 • You can only use cards with SDHC logo (indicating compliance with the SD standard) if using cards with 4 GB or more capacity. • Please confirm the latest information on the following website. http://panasonic.jp/support/global/cs/dsc/ (This Site is in English only.) Note •...

  • Page 18: Setting Date/Time (Clock Set)

    Setting Date/Time • The clock is not set when the camera is shipped. Turn the camera on. A [MENU/SET] button B Cursor buttons • (When the language select screen is not displayed " step 4 ) Press [MENU/SET]. Press e / r to select the language, and press [MENU/SET].
  • Page 19 1 Press [MENU/SET] in Normal Picture Mode. 2 Press e/r to select [CLOCK SET]. 3 Press q and perform steps 5 and 6 for setting. 4 Press [MENU/SET] to close the menu. • You can also set the clock in the [SETUP] menu. (P25) Note •...

  • Page 20: About The Mode And Menu Operation

    About the Mode and Menu Operation Slide the recording/playback switch A to (right) or (left). 1 : Recording Mode 5 : Playback Mode Press [MODE] to display the mode selection screen. (Example: Normal Picture Mode) Press e / r to select a mode and press [MENU/SET] to close the menu. Refer to corresponding page for more details on each mode.

  • Page 21: About The Menu Operation

    List of Recording Modes  ; Auto Scene Mode 1 Normal Picture Mode 5 Scene Mode 6 Motion Picture Mode List of Playback Modes  9 Normal Play Mode 8 Slide Show Mode z Favorite Play Mode The camera comes with menus that allow you to set the settings for taking pictures and playing them back just as you like.
  • Page 22 How to use the menu  Press [MENU/SET] to display the menu. • You can switch menu screens by the page from any menu item by rotating the zoom lever. (Example: Selecting the Normal Picture Mode [ 1 ]) Press e / r to select a menu item. (Example: Selecting [AF MODE]) •...
  • Page 23 Preparation Switching to the [SETUP] menu When the camera shows the menu screen after step 1 on “How to use the menu” (P22): 1 Press w to move the menu icon. 2 Press r to select the [SETUP] menu icon [e]. 3 Press q to move to the menu item list.

  • Page 24: Using The Quick Menu

    Using the quick menu, some of the menu items can be easily found. • Some of the menu items cannot be set by the modes. Press and hold [Q.MENU] when the camera is in the Recording Mode. Press e / r / w / q to select the menu item and its setting and then press [MENU/ SET] to close the menu.

  • Page 25: About The [Setup] Menu

    Perform these settings if you need to. About the [SETUP] Menu [CLOCK SET], [POWER SAVE] and [AUTO REVIEW] are important items. Check their settings before using them. • In the Auto Scene Mode, only [CLOCK SET], [WORLD TIME], [BEEP] and [LANGUAGE] can be set.
  • Page 26 P [POWER SAVE] • Press the shutter button halfway or turn the camera off and on to cancel [POWER SAVE]. • [POWER SAVE] is set to [5MIN.] in the Auto Scene Mode [ ; ]. • [POWER SAVE] does not work in the following cases: –...
  • Page 27 For USA and Puerto Rico assistance, please call: 1-800-211-PANA (7262) or, contact us via the web at: http://www.panasonic.com/contactinfo 9 [LANGUAGE] • When you set to other language by mistake, select [9] from the menu icons to set the desired language.

  • Page 28: Basic

    Recording Mode: ; Taking Pictures Using the Automatic Function (Auto Scene Mode) The camera automatically sets the appropriate settings according to the subject and recording condition. This mode is recommended for beginners to take pictures easily. • The following functions are activated automatically.
  • Page 29 Press the shutter button halfway to focus. • Refer to “Focusing” (P33) for details. • The focus indication E lights green when the subject is focused. • The AF area F is displayed around the subject’s face by the face detection function. In other cases, it is displayed at the point on the subject which is in focus.

  • Page 30: Scene Detection

    When the camera identifies the optimum scene, the icon of the scene concerned is displayed in blue for 2 seconds, after which its color changes to the usual red. ; " 3 [i-PORTRAIT] 4 [i-SCENERY] 2 [i-MACRO] 5 [i-NIGHT PORTRAIT] [i-NIGHT SCENERY] •...

  • Page 31: About The Flash

    • When [ q ] is selected, [ w ], [ e ] or [ r ] is set depending on the type of subject and brightness. • When [ e ] or [ r ] is set, the flash is activated twice. Only the following functions can be set in this mode.

  • Page 32: Taking Pictures With Your Favorite Settings (Normal Picture Mode)

    Recording Mode: 1 Taking Pictures with Your Favorite Settings (Normal Picture Mode) This mode allows you to take pictures freely as more options are available than Auto Scene Mode [ ; ] (P28). Slide the recording/playback switch to [ and press [MODE]. A Recording/playback switch Press e / r to select [NORMAL PICTURE] and press [MENU/SET].

  • Page 33: Focusing

    To adjust the exposure and take pictures at times when the image appears too  dark (P51) To adjust the colors and take pictures at times when the image appears too red  (P72) Aim the AF area at the subject, and then press the shutter button halfway. C Focus indication D AF area (normal) E AF area (when using the digital zoom or when it is dark)

  • Page 34: Preventing Jitter (Camera Shake)

    Subjects and recording conditions which are difficult to focus  • Fast-moving subjects, extremely bright subjects or subjects without contrast • When recording subjects through windows or near shiny objects • When it is dark or when jitter occurs • When the camera is too close to the subject or when taking a picture of both distant and near subjects (when the recordable range display has appeared in red).

  • Page 35: Taking Pictures With The Zoom

    Recording Mode: ; 1 5 6 Taking Pictures with the Zoom Using the optical zoom/ the extended optical zoom (EZ)/ the digital zoom You can make people and subjects appear closer with the optical zoom, and landscapes can be recorded in wide angle. To make subjects appear even closer [maximum of 7.1×], set the [PICTURE SIZE] to 3M or less.
  • Page 36 Types of zooms  Feature Optical zoom Maximum 4× magnification Picture quality No deterioration Conditions None Screen display • When using the zoom function, an estimate of the focus range will appear in conjunction with the zoom display bar. (Example : 0.5 m (1.64 feet) -7) ...

  • Page 37: Playing Back Pictures (Normal Playback Mode)

    Playback Mode: 9 Playing Back Pictures Slide the recording/playback switch A to [ 5 ]. • Normal playback is set automatically in the following cases: – When the mode was switched to the Playback Mode. – When the camera was turned on while the recording/ playback switch was at [5].

  • Page 38: Displaying Multiple Screens (Multi Playback)

    Displaying multiple screens (Multi Playback) Rotate the zoom lever towards [ 6 ] (W). 1 screen"12 screens"30 screens"Calendar screen display (P84) A Number of the selected picture and the total number of recorded pictures • Rotate the zoom lever towards [7] (T) to return to the previous screen.

  • Page 39: Using The Playback Zoom

    Rotate the zoom lever towards [ 1  "2  "4  "8  "16  • When you rotate the zoom lever towards [6] (W) after enlarging the picture, the magnification becomes lower. • When you change the magnification, the zoom position indication A appears for about 1 second, and the position of the enlarged section can be moved by using e/r/w/q.

  • Page 40: Deleting Pictures

    Playback Mode: 9 z Deleting Pictures Once deleted, pictures cannot be recovered. • Pictures on the built-in memory or the card, which are being played back, will be deleted. Select the picture to be deleted, and then press [ 4 ]. Press w to select [YES] and then press [MENU/SET].

  • Page 41: To Delete Multiple Pictures (Up To 50) Or All The Pictures

    To delete multiple pictures (up to 50) or all the pictures Press [ 4 ]. Press e / r to select [DELETE MULTI] or [DELETE ALL] and then press [MENU/SET]. • [DELETE ALL] " step 5 . Press e / r / w / q to select the picture and then press [DISPLAY] to set.

  • Page 42: Advanced-Shooting

    About the LCD Monitor Press [DISPLAY] to switch the screen to be used. A LCD monitor • When the menu screen appears, the [DISPLAY] button is not activated. • During playback zoom, while playing back motion pictures and during a slide show, you can only select “Normal display”...

  • Page 43: Display In Large Size

    Advanced-Shooting Display in large size Select [LARGE] in the [DISPLAY SIZE] in [SETUP] menu. (P25) • In the Recording Mode, Recording Mode icon is displayed in large size. • In the menu screen, the items you selected will be displayed in large size. Recording Screen Menu Screen -  -...

  • Page 44: Taking Pictures Using The Built-In Flash

    Recording Mode: ; 1 5 Taking Pictures Using the Built-in Flash A Photo flash • Switching to the appropriate flash setting Set the flash to match the recording. Press q [ t ]. Press e / r to switch the flash setting. •...
  • Page 45 Item q : AUTO The flash is automatically activated according to the recording condition. The flash is automatically activated according to the recording condition. It is activated once before the actual recording to reduce the red-eye @ : AUTO/Red-eye phenomenon (eyes of the subject appearing red in the picture) and ...
  • Page 46 Available flash settings by Recording Mode  The available flash settings depend on the Recording Mode. ( ○ : Available, — : Not available, ◎ : Scene Mode initial setting) ; ○  2 — — ○ ○ ○ ○ ◎...
  • Page 47 The available flash range to take pictures  • The available flash range is an approximation. sensitivity i.AUTO 30 cm (0.99 feet) to 6.3 m (20.67 feet) 50 cm (1.64 feet) to 3.0 m (9.84 feet) ISO80 30 cm (0.99 feet) to 1.7 m (5.85 feet) ISO100 30 cm (0.99 feet) to 2.0 m (6.56 feet) ISO200...
  • Page 48 Shutter speed for each flash setting  Flash setting q : AUTO @ : AUTO/ Red-eye reduction t : Forced ON ` : Forced ON/Red-eye reduction [ : Slow sync./Red-eye reduction o : Forced OFF  1 When [i.AUTO] is set •...

  • Page 49: Taking Close-Up Pictures

    Recording Mode: 1 6 Taking Close-up Pictures This mode allows you to take close-up pictures of the subject, e.g. when taking pictures of flowers. You can take pictures approaching the subject at a distance up to 5 cm (0.17 feet) from the lens by rotating the zoom lever upmost to Wide (1 ×).

  • Page 50: Taking Pictures With The Self-Timer

    Recording Mode: ; 1 5 Taking Pictures with the Self-timer Press w [ s ]. Press e / r to select the time. • You can also press w [ s ] to select. Press [MENU/SET]. • You can also press the shutter button halfway to finish. •...

  • Page 51: Compensating The Exposure

    Recording Mode: 1 5 6 Compensating the Exposure Use this function when you cannot achieve appropriate exposure due to the difference of brightness between the subject and the background. Underexposed Compensate the exposure toward positive. Press e [ d ] to display [EXPOSURE] and press w / q to compensate the exposure.

  • Page 52: Taking Pictures That Match The Scene Being Recorded (Scene Mode)

    Recording Mode: 5 Taking Pictures that Match the Scene being Recorded (Scene Mode) When you select a Scene Mode to match the subject and recording situation, the camera sets the optimal exposure and hue to obtain the desired picture. Slide the recording/playback switch to [ 1 ]. Press [MODE] to display the mode selection screen.

  • Page 53: Q [Portrait]

    The person stands out with a healthier complexion. Technique for Portrait Mode  To make this mode more effective: 1 Rotate the zoom lever to Tele as far as possible. 2 Move close to the subject. Note • Suitable for outdoors in the daytime. •...

  • Page 54: R [Scenery]

    The camera focuses on distant subjects to allow you to take pictures of wide landscapes. Note • Flash is fixed to Forced flash OFF [ o ]. • The focus range is 5 m (16.41 feet) to 7. Allows you to shoot fast moving subjects (e.g. outdoor sports). Note •...

  • Page 55: U [Night Scenery]

    The nightscape can be recorded vividly. Technique for Night Scenery Mode  • The shutter speed may slow down up to 8 seconds. We recommend using the tripod and the self-timer for best results. Note • Flash is fixed to Forced flash OFF [ o ]. •...

  • Page 56: O [Party]

    Use to take pictures at wedding receptions, indoor parties, etc. Both the people and the background can be shot with natural brightness using the flash and slow shutter speed. Technique for Party Mode  • Use the flash. (You can set to [ [ ] or [ ` ].) •...

  • Page 57: A [Baby1] / S [Baby2]

    This takes pictures of a baby with a healthy complexion. When you use the flash, the light from it is weaker than usual. It is possible to set different birthdays and names for [BABY1] and [BABY2]. You can select to have these appear at the time of playback, or have them stamped on the recorded image using [TEXT STAMP] (P87).

  • Page 58: D [Pet]

    Suitable for taking pictures of your pet. This allows you to set the birthday (age) and name of your pet. For details on how to set age and birthday, see [BABY1]/[BABY2]. (P57) Note • [i.AUTO] is activated. • The initial setting for the AF assist lamp is [OFF]. •...

  • Page 59: Hi-Speed Burst]

    This is a convenient mode for shooting rapid movement or a decisive moment. Picture size  1 Press e/r to select the picture size and then press [MENU/SET] to set. • 3M (4:3), 2.5M (3:2) or 2M (16:9) is selected as the picture size. 2 Take pictures.

  • Page 60: C [Starry Sky]

    Take clear pictures of the night sky or other dark subjects. Setting the shutter speed  Choose a shutter speed; 15, 30, or 60 seconds. 1 Press e/r to select the shutter speed and then press [MENU/ SET]. • The shutter speed can also be changed in quick menu (P24). 2 Take a picture.

  • Page 61: B [Beach]

    Prevents underexposure of the subject under strong sunlight to allow you to take pictures on a beach. Note • The initial setting for [AF MODE] is [ 3 ]. • Do not touch the camera with wet hands. • Sand or seawater may cause the camera to malfunction. Make sure that sand or seawater does not get into the lens or terminals.

  • Page 62: Motion Picture Mode

    Recording Mode: 6 Motion Picture Mode Slide the recording/playback switch to [ 1 ]. Press [MODE] to display the mode selection screen. Press e / r to select [MOTION PICTURE] and then press [MENU/SET]. Press the shutter button halfway to focus and then press it fully to start recording.
  • Page 63 Changing the settings for the picture quality When you set the picture quality to [WVGA] or [VGA], we recommend using a high-speed card with “10MB/s” or greater displayed on the package for shooting motion pictures. Press [MENU/SET]. Press e / r to select [REC QUALITY] and then press q .
  • Page 64 • This camera has improved sound quality so motion pictures recorded on this camera cannot be played back on a Panasonic Digital Camera (LUMIX models) that was sold in June 2008 or before. (However, motion pictures recorded on previous models can be played back on this camera.)

  • Page 65: Useful Functions At Travel Destinations

    Recording Mode: ; 1 5 6 Useful Functions at Travel Destinations Recording which day of the vacation you take the picture If you set the departure date or the travel destination of the vacation in advance, the number of days that have passed since the departure date (which day of the vacation it is) is recorded when you take the picture.
  • Page 66 Press e / r / w / q to set the return date (year/month/ day), and then press [MENU/SET]. • If you do not want to set the return date, press [MENU/SET] while the date bar is displayed. Press r to select [LOCATION] and then press q . Press r to select [SET] and then press [MENU/ SET].
  • Page 67 Canceling the travel date  The travel date is cleared if the current date is after the return date. If you want to cancel part way through the setting, select [OFF] in step 3 or 7 and press [MENU/SET] twice. If the [TRAVEL SETUP] is set to [OFF] in step 3 , [LOCATION] will be also set to [OFF].

  • Page 68: Recording Date/Time At Overseas Travel Destinations (World Time)

    Recording date/time at overseas travel destinations (World time) You can display the local time at the travel destinations and record them on the pictures you take. • Select [CLOCK SET] to set the current date and time in advance. (P18) Select [WORLD TIME] from the [SETUP] menu, and then press q .
  • Page 69 Press e to select [DESTINATION] and then press [MENU/SET]. C Depending on the setting, the time at the travel destination area or the home area is displayed. Press w / q to select the area the travel destination is in and then press [MENU/SET] to set.

  • Page 70: Using The [Rec] Menu

    Using the [REC] Menu For details on [REC] menu settings, refer to P21. Set the number of pixels and aspect ratio of the pictures. Select a higher number of pixels for clearer pictures. Select a lower number of pixels to store more pictures. Applicable modes: ;...

  • Page 71: H [Quality]

    For details on [REC] menu settings, refer to P21. Set the compression rate at which the pictures are to be stored. Applicable modes: 1 5 [ h ]: Fine (when giving priority to the picture quality) [ 8 ]: Standard (when giving priority to the number of pictures to be recorded without changing the number of pixels) Note •...

  • Page 72: K [White Balance]

    For details on [REC] menu settings, refer to P21. This function allows you to reproduce a white color closer to the tone in real life on the pictures recorded under sunlight, halogen lighting, etc. in which the white color may appear reddish or bluish.
  • Page 73 Auto White Balance (AWB)  Depending on the conditions prevailing when pictures are taken, the pictures may take on a reddish or bluish tinge. Furthermore, when a multiple number of light sources are being used or there is nothing with a color close to white, Auto White Balance may not function properly. In a case like this, set the white balance to a mode other than [AWB].

  • Page 74: [Af Mode]

    For details on [REC] menu settings, refer to P21. This allows the focusing method that suits the positions and number of the subjects to be selected. Applicable modes: 1 5 [ 3 ]: Face detection [ \ ]: 9-area-focusing [ 2 ]: 1-area-focusing Advanced-Shooting $ [AF MODE] The camera automatically...
  • Page 75 About [ 3 ] (Face detection)  The following AF area frames are displayed when the camera detects faces: Yellow: When the shutter button is pressed halfway, the frame turns green when the camera is focused. White: Displayed when more than one face is detected. Other faces that are the same distance away as faces within the yellow AF areas are also focused.

  • Page 76: [Burst]

    For details on [REC] menu settings, refer to P21. When you press and hold the shutter button several pictures are taken in succession. Applicable modes: ; 1 5 Burst speed (pictures/second) Number of recordable pictures  The burst speed is constant regardless of the transfer speed of the card. •...

  • Page 77: [Digital Zoom]

    For details on [REC] menu settings, refer to P21. This can enlarge subjects even more than the optical zoom or extended optical zoom. Applicable modes: 1 5 6 [OFF]/[ON] Note • Refer to for details. • When the Digital zoom is [ON], the motion detection does not function in [i.AUTO] setting. For details on [REC] menu settings, refer to P21.

  • Page 78: W [Af Assist Lamp]

    For details on [REC] menu settings, refer to P21. Illuminating the subject with the AF assist lamp allows the camera to focus on the subject in low light conditions. Applicable modes: 1 5 [OFF]: The AF assist lamp does not turn on. [ON]: When taking pictures in dark places, the AF assist lamp lights while the shutter button is pressed halfway.

  • Page 79: Advanced-Viewing

    Playback Mode: 8 Playing Back Pictures in Sequence You can play back the pictures you have taken in synchronization with music, and you can do this in sequence while leaving a fixed interval between each of the pictures. Furthermore, you can play back only those pictures you have set as favorites as a slide show.
  • Page 80 Advanced-Viewing Operations performed during slide show  The cursor displayed during playback corresponds to e/r/w/q. • The menu screen is restored when [4] is pressed. A Play/Pause B Stop  C Back to previous picture  D Ahead to next picture ...

  • Page 81: Item Settings

    Changing the slide show settings  You can change the settings for slide show playback by selecting [EFFECT] or [SETUP] on the slide show menu screen. [EFFECT] This allows you to select the screen effects or music effects when switching from one picture to the next picture. [NATURAL], [SLOW], [SWING], [URBAN], [OFF] •...

  • Page 82: Selecting Pictures And Playing Them Back

    Playback Mode: z Selecting Pictures and Playing Them Back You can play back the pictures put in the favorites list only. (When [FAVORITE] is set to [ON] and there is more than one picture in the favorites list.) Refer to [FAVORITE] (P91) to put a picture on your favorites list or to remove it from the list.

  • Page 83: Playing Back Motion Pictures

    Playback Mode: 9 z Playing Back Motion Pictures Press w / q to select a picture with a motion picture icon (such as [ - ]), and then press e to play back. A The motion picture recording time B Motion picture icon C Motion picture playback icon •...

  • Page 84: Using The [Playback] Menu

    Playback Mode: 9 Using the [PLAYBACK] Menu You can use various functions in Playback Mode to rotate pictures, set protection for them etc. • With [TEXT STAMP] or [RESIZE], a new edited picture is created. A new picture cannot be created if there is no free space on the built-in memory or the card so we recommend checking that there is free space and then editing the picture.

  • Page 85: Y [Title Edit]

    You can add text (comments) to pictures. After text has been registered, it can be included in prints using [TEXT STAMP] (P87). (Only alphabetical characters and symbols can be entered.) Select [TITLE EDIT] on the [PLAYBACK] menu. (P21) Press e / r to select [SINGLE] or [MULTI] and then press [MENU/SET].
  • Page 86 Delete the title  [SINGLE] setting In step 4 , delete all the texts, select [EXIT], and press [MENU/SET]. Press [4]. Press [MENU/SET] to close the menu. [MULTI] setting In step 4 , delete all the texts, select [EXIT], and press [MENU/SET]. Press [MENU/SET] to close the menu.

  • Page 87: S [Text Stamp]

    You can stamp the recording date/time, age, travel date or title onto the recorded pictures. It is suitable for regular size printing. (Pictures larger than 3M will be resized when stamping the date etc. on them.) Select [TEXT STAMP] on the [PLAYBACK] menu. (P21) Press e / r to select [SINGLE] or [MULTI] and press [MENU/SET].
  • Page 88 Press [MENU/SET]. • If you set [TEXT STAMP] for a picture larger than 3M, the picture size will become smaller as shown below E / T " C Y " M K " U • The picture becomes slightly rougher. Press e to select [YES] and press [MENU/SET].

  • Page 89: F [Resize] Reducing The Picture Size (Number Of Pixels)

    f [RESIZE] Reducing the picture size (number of pixels) This function is useful if you want to reduce the file size of the picture in cases when it needs to be attached to an e-mail or uploaded to a website. Select [RESIZE] on the [PLAYBACK] menu.

  • Page 90: J [Rotate]

    This mode allows you to rotate pictures manually in 90° increments. Select [ROTATE] on the [PLAYBACK] menu. (P21) Press w / q to select the picture and then press [MENU/SET] . • Motion pictures and protected pictures cannot be rotated. Press e / r to select the direction to rotate the picture and then press [MENU/SET].

  • Page 91: Z [Favorite]

    You can do the following if a mark [z] has been added to pictures and they have been set as favorites. • Play back the pictures set as favorite. ([FAVORITE PLAY]) • Play back only the pictures set as favorites as a slide show. •...

  • Page 92: [Print Set]

    When you want to use a photo printing store to print pictures recorded on the built-in memory, copy them to a card (P95) and then set the print setting. For more information please visit: http://panasonic.jp/dc/dpof_110/white_e.htm Select [PRINT SET] on the [PLAYBACK] menu. (P21) Press e / r to select [SINGLE] or [MULTI] and then press [MENU/SET].
  • Page 93 Canceling all the [PRINT SET] settings  Select [CANCEL] on the screen shown in step 2 and then press [MENU/SET]. Press e to select [YES] and then press [MENU/SET]. Press [MENU/SET] to close the menu. • You cannot select [CANCEL] if no picture has been set for printing. To print the date ...

  • Page 94: C [Protect]

    You can set protection for the pictures you do not want to delete to prevent them from accidental erasure. Select [PROTECT] on the [PLAYBACK] menu. (P21) Press e / r to select [SINGLE] or [MULTI] and then press [MENU/SET]. Select the picture, and then press [MENU/SET] to set.

  • Page 95: B [Copy]

    • It may take time to copy the picture data. • Only pictures recorded with a Panasonic digital camera (LUMIX) will be copied. (Even if the pictures were recorded with a Panasonic digital camera, you may not be able to copy them if they were edited on a PC.) •...

  • Page 96: Connecting To Other Equipment

    Connecting to a PC You can acquire recorded pictures to a PC by connecting the camera and the PC. • You can easily print out or mail the pictures you have imported. Use of the “PHOTOfunSTUDIO” bundled software on the CD-ROM (supplied) is a convenient way of doing this.
  • Page 97 Press e / r to select [PC], and then press [MENU/SET]. Double-click on [Removable Disk] in [My Computer]. • When using a Macintosh, the drive is displayed on the desktop. (“LUMIX”, “NO_NAME” or “Untitled” is displayed.) Double-click [DCIM] folder. Using a drag-and-drop operation, move the pictures you want to acquire or the folder storing those pictures to any different folder on the PC.

  • Page 98: Using A Pc With An Sd Memory Card Slot Or A Card Reader

    • Proceed with the hardware removal using “Safely Remove Hardware” on the task tray of the PC. If the icon is not displayed, check that [ACCESS] is not displayed on the LCD monitor of the digital camera before removing the hardware. Note •...

  • Page 99: Printing The Pictures

    Printing the Pictures By connecting the camera directly to a printer supporting PictBridge via the USB connection cable (supplied), you can select the pictures to be printed or start printing on the LCD monitor. Preparations: Turn on the camera and the printer. Remove the card before printing the pictures in the built-in memory.

  • Page 100: Selecting A Single Picture And Printing It

    Press e / r to select [PictBridge(PTP)], and then press [MENU/SET]. Note • We recommend placing a soft cloth under this unit to prevent scratching. • Turn the camera off before connecting or disconnecting the AC adaptor (optional). • Before inserting or removing a card, turn the camera off, and disconnect the USB connection cable.

  • Page 101: Selecting Multiple Pictures And Printing Them

    Selecting multiple pictures and printing them Press e . Press e / r to select an item and then press [MENU/ SET]. • If the print check screen has appeared, select [YES], and print the pictures. Item Multiple pictures are selected at once for printing. •...

  • Page 102: Print Settings

    Select and set the items on the screen in step 2 of the “Selecting a single picture and printing it” or in step 3 of the “Selecting multiple pictures and printing them”. • When you want to print pictures in a paper size or a layout which is not supported by the camera, set [PAPER SIZE] and [PAGE LAYOUT] to [h] and then set the paper size or the layout on the printer.
  • Page 103 Item Description of settings Settings on the printer are prioritized. [L/3.5˝ × 5˝ ] 89 mm × 127 mm [2L/5˝ × 7˝ ] 127 mm × 178 mm [POSTCARD] 100 mm × 148 mm [16:9] 101.6 mm × 180.6 mm [A4] 210 mm ×...

  • Page 104: Using A Printer With An Sd Memory Card Slot

    [PAGE LAYOUT] (Layouts for printing that can be set with this unit) Item Settings on the printer are prioritized. 1 page with no frame print 1 page with frame print 2 pages print on 1 page 4 pages print on 1 page •...

  • Page 105: Playing Back Pictures On A Tv Screen

    • Do not use any other AV cables except the supplied one. (Only for DMC-F2PU/ DMC-F2PR). • Do not use any other cables except a genuine Panasonic AV cable (DMW-AVC1: optional). (Only for DMC-F2P/DMC-F2PC) 1 Yellow: to the video input socket 2 White: to the audio input socket A Align the marks, and insert.

  • Page 106: Playing Back Pictures On A Tv With An Sd Memory Card Slot

    Note • Depending on the [PICTURE SIZE], black bands may be displayed on the top and bottom or the left and right of the pictures. • Read the operating instructions for the TV. • When you play back a picture vertically, it may be blurry. •...

  • Page 107: Screen Display

    Screen Display In recording  Recording in Normal Picture Mode [ 1 ] (Initial setting) Recording mode (P21) Flash mode (P45) Macro shooting (P49) AF area (P29, 33) Focus indication (P29, 33) Picture size (P70) Quality (P71) Battery indication (P12) Remaining number of recordable pictures (P127) 10 1: Built-in memory (P16)
  • Page 108 In recording (after settings)  16 White balance (P72) 17 ISO sensitivity (P33, 71) 18 Color mode (P77) 19 Recording Quality (P63) 20 Available recording time in Motion Picture Mode e.g. : 21 Self-timer (P50) 22 Travel date (P65) 23 Elapsed recording time (P62) 24 Name (P57, 58) This is displayed for about 5 seconds when this unit is turned on in [BABY1]/[BABY2] or [PET] in Scene Mode.
  • Page 109 In playback  Playback mode (P21) Protected picture (P94) Favorites indicator (P91) : z Text stamp complete indicator (P87) Picture size (P70) Motion picture icon (P83) Quality (P71) Battery indication (P12) Folder/File number (P98) 1: Built-in memory (P16) Elapsed playback time (P83) : Picture number/Total pictures 10 Motion picture recording time (P83) : 11 Compensating the Exposure (P51)

  • Page 110: Cautions For Use

    Cautions for Use Take care not to drop or knock the unit or put a lot of pressure on it. • Take care not to knock or drop the bag/case that you inserted the camera in as the shock may cause damage to the camera, lens or LCD monitor. •...
  • Page 111 Before cleaning the camera, remove the battery or the DC coupler (optional), or disconnect the power plug from the outlet. Then wipe the camera with a dry soft cloth. • When the camera becomes dirty, clean it with a soft, slightly damp cloth. Then wipe the camera with a dry cloth.
  • Page 112 The battery is a rechargeable lithium ion battery. Its ability to generate power comes from the chemical reaction that takes place inside it. This reaction is susceptible to the surrounding temperature and humidity. If the temperature is too high or too low, the operating time of the battery will become shorter.
  • Page 113 • Information containing private information may be changed or lost due to operation mistake, static electricity, accident, malfunction, or repair. Panasonic assumes no liability for direct/indirect damage resulting from change or loss of information including private information. For service or transfer/disposal •...
  • Page 114 • Recorded data may be damaged or lost if the camera breaks down due to inappropriate handling. Panasonic will not be liable for any damage suffered due to loss of recorded data. • When you use a tripod, make sure the tripod is stable when this unit is attached to it.

  • Page 115: Message Display

    Message Display Confirmation messages or error messages will be displayed on the screen in some cases. The major messages are described below as examples. [THIS MEMORY CARD IS LOCKED] " The Write-Protect switch on the SD Memory Card and the SDHC Memory Card are moved to [LOCK].
  • Page 116 [NOT ENOUGH SPACE ON BUILT-IN MEMORY]/[NOT ENOUGH MEMORY ON THE CARD] • There is no space left on the built-in memory or the card. – When you copy pictures from the built-in memory to the card (batch copy), the pictures are copied until the capacity of the card becomes full.
  • Page 117 [THIS BATTERY CANNOT BE USED] • The battery cannot be recognized by the camera. " Use a genuine Panasonic battery. If this message is displayed even when a genuine Panasonic battery is used, contact the dealer or your nearest Service Center.

  • Page 118: Troubleshooting

    Troubleshooting First, try out the following procedures (P118–126). If the problem is not resolved, it may be improved by selecting [RESET] (P26) on the [SETUP] menu when taking pictures. The camera cannot be operated even when it is turned on. •...

  • Page 119: Shooting

    The picture cannot be recorded. • Is the mode correctly set? (P20) • Is there any memory capacity left on the built-in memory or the card? " Before recording, delete some pictures. (P40) The recorded pictures are pale. • The picture can become whitish if there is dirt e.g. fingerprints on the lens. "...
  • Page 120 The recorded picture looks rough. Noise appears on the picture. • Is the ISO sensitivity high or the shutter speed slow? (When set to [i.AUTO], ISO sensitivity increases for indoor and other shooting occasions.) " Reduce ISO sensitivity. (P71) " Set [COLOR MODE] to [NATURAL]. (P77) "...

  • Page 121: Lcd Monitor

    The LCD monitor turns off although the camera is turned on. • When the camera is not operated for a while, [POWER SAVE] is activated. (P26) [This does not happen when using the AC adaptor (optional).] If the remaining battery power is low, it may take longer for the flash to be charged, and the time during which the LCD monitor is turned off may become longer.

  • Page 122: Flash

    • Is this a non-standard picture, a picture which has been edited using a PC or a picture which was taken by another make of digital camera? • Did you remove the battery immediately after picture-taking or did you take the picture using the battery with a low remaining charge? "...
  • Page 123 White round spots like soap bubbles appear on the recorded picture. • If you take a picture with the flash in a dark place or indoors, white round spots may appear on the picture caused by the flash reflecting of particles of dust in the air. This is not a malfunction. A characteristic of this is that the number of round spots and their position differ in every picture.

  • Page 124: Tv, Pc And Printer

    The picture does not appear on the television. • Is the camera connected to the TV correctly? " Set the TV to Video Input Mode. (P105) The display areas on the TV screen and the camera’s LCD monitor are different. •...

  • Page 125: Others

    An unreadable language was selected by mistake. " Press [MENU/SET], select the [SETUP] menu icon [e] and then select the [9] icon to set the desired language. (P27) When the shutter button is pressed halfway, a red lamp turns on sometimes. •...
  • Page 126 File numbers are not created in order. • Certain operations cause pictures to be saved in folders with different numbers. (P98) The file numbers are recorded in ascending order. • If the battery is inserted or removed without first turning the camera’s power off, the folder and file numbers for the pictures taken will not be stored in the memory.

  • Page 127: Available Recording Time

    Number of Recordable Pictures and Available Recording Time • The number of recordable pictures and the available recording time are an approximation. (These vary depending on the recording conditions and the type of card.) • The number of recordable pictures and the available recording time vary depending on the subjects.
  • Page 128 3:2 [9M] Picture size (3648 × 2432 pixels) Quality Built-in Memory (Approx. 50 MB) 32 MB 64 MB 128 MB 256 MB 512 MB 1 GB Card 2 GB 4 GB 6 GB 1320 8 GB 1770 12 GB 2680 16 GB 3580 32 GB...
  • Page 129 16:9 [7.5M] Picture size (3648 × 2056 pixels) Quality Built-in Memory (Approx. 50 MB) 32 MB 64 MB 128 MB 256 MB 512 MB 1 GB 2 GB Card 4 GB 1030 6 GB 1560 8 GB 2090 12 GB 3160 16 GB 4220...
  • Page 130 Available recording time (In Motion Picture Mode)  Picture quality setting Built-in Memory (Approx. 50 MB) 32 MB 64 MB 128 MB 256 MB 512 MB 1 GB Card 2 GB 4 GB 6 GB 8 GB 12 GB 16 GB 32 GB (DMC-F2P/DMC-F2PC/DMC-F2PU) •...

This manual is also suitable for:

Dmcf2 - digital still cameraDmcfs4kDmc-fs42 lumixDmc-fs4 lumix

Table of Contents
