- Page 1 AU-211P CAC/PIV Solution Network Configuration Guide...
- Page 2 Thank you for choosing this device. This guide provides descriptions of the installation, operating procedures and precautions for using Authentication Unit (IC Card Type) AU-211P. Carefully read this User’s Guide before using this device. The actual screens that appear may be slightly different from the screen images used in this User’s Guide.
-
Page 3: Safety Information
For disclaimers and warranty and liability details, refer to the User’s Guide Authentication Unit (IC Card Type AU-211P). - This product is designed, manufactured and intended for general business use. Do not use it for applications requiring high reliability and which may have an extreme impact on lives and property. - Page 4 Product Type Authentication Unit (IC Card Type) Product Name AU-211P (This device complies with Part 15 of the FCC Rules.) Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.
- Page 5 This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. AU-211P...
-
Page 6: Getting Started
This document is intented for authorized Konica Minolta service and networking representatives. This guide will outline the installation, network configuration and use of the Konica Minolta CAC/PIV PKI card solution with the designated bizhub Multifunction Printers (MFP). CAC = Common Access Card (DoD) PIV = Personal Identity Verification Card (US Gov’t) - Page 7 Getting Started Before Installation Begins This installation process must be completed by a trained Konica Minolta Service Technician and/or Network Engineer. Before beginning this installation procedure the individual performing this install must meet the technical requirements and complete the on-line training module. Please refer to the service training area of the Learning Place.
-
Page 8: Network Configuration
C353 series MFP Generic Screen Settings If during the reboot of the MFP you see the generic ‘Globes’ screen instead of the Blue Konica Minolta Logo you will need to make a soft switch setting change. - Enter Service Mode - Enter System 2->... - Page 9 Installation Survey & Checklist and the Ping Confirmation Test which is performed during the network configuration process. - Bit 1 = Enable LDAP w/SSL - Bit 5= Enable Scan to Me and Scan to Home - Bit 6= Enable Scan to Me and SMB AU-211P...
- Page 10 When directly specifying the IP address, enter the IP address of the MFP. Subnet Mask When directly entering the IP address, specify the subnet mask for the connected network. Default Gateway When directly entering the IP address, specify the default gateway for the connected network. AU-211P...
- Page 11 If they are not you will have to disable auto retrieval and manually enter the domain name. Click OK to exit Item Description Domain Name Auto Select whether to automatically retrieve the domain Retrieval name. This item is available when using DHCP. AU-211P...
- Page 12 A department, group or division name can be used. Select Server Type - Active Directory Enter the Fully Qualified Domain Name. Select Close Item Description Server Name Specify the name of the external server (up to 32 characters). AU-211P...
- Page 13 Select ON to activate the Time Adjustment Feature. Select Host Address and enter the NTP server IP Address. Proceed to Date/Time Settings. Item Description ON/OFF Select [ON]. Host Address Specify the host address of the NTP server associated with Active Directory. AU-211P...
- Page 14 Register the DNS server associated with Active Directory in the MFP. DNS Server Settings (IPv4) On the MFP control panel, press the [Utility/Counter] key, and then [Administrator Settings] - [Network Settings] - [TCP/IP Settings] - [DNS Server Settings (IPv4)]. AU-211P...
- Page 15 Specify the IPv4 address of the secondary DNS server and 2 associated with Active Directory. DNS Server Settings (IPv6) On the MFP control panel, press the [Utility/Counter] key, and then [Administrator Settings] - [Network Settings] - [TCP/IP Settings] - [DNS Server Settings (IPv6)]. AU-211P...
- Page 16 To enable LDAP the folllowing settings will need to be entered. Verify all settings and functions with the Installation Survey and Checklist and an IT admin. On the MFP control panel, press the [Utility/Counter] key, and then [Administrator Settings] - [Network Settings] - [LDAP Settings] . AU-211P...
- Page 17 You will see that the PIV mode is default. This setting will allow for both cards. Start with this setting and move to CAC only if any login issues persist. The CAC settings will allow for CAC card only. AU-211P...
- Page 18 Configure the certificate verification settings that will be used to verify the Active Directory certificate when the MFP is communicating with Active Directory. Certificate Verification Setting On the MFP control panel, press the [Utility/Counter] key, and then [Administrator Settings] - [User Authentication/Account Track] - [Certificate Verification Setting]. AU-211P...
- Page 19 CRL (Certificate Revocation List). Check OCSP Expiration Select whether to check that the certificate is not expired in the OCSP service. For details on how to configure the OCSP service setting, refer to "Cert Verification Setting" (page 65). AU-211P...
- Page 20 To check the expiration date via a proxy server, enter the proxy server address. If the DNS server is specified, you can enter the host name instead. If "IPv6" is set to "ON", you can also specify the IPv6 address. AU-211P...
