SERVICE MANUAL
MODEL
CONTENTS
SHARP CORPORATION
- 1 -
MINI COMPONENT SYSTEM
CD-M8000W
SPEAKER SYSTEM
CP-M8000
MODEL
• In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
CD-M8000W/CP-M8000
No. S4228CDM8000W
Page
Advertisement
Table of Contents
Related Manuals for Sharp CD-M8000W
Summary of Contents for Sharp CD-M8000W
-
Page 1: Table Of Contents
CD-M8000W/CP-M8000 SERVICE MANUAL No. S4228CDM8000W MINI COMPONENT SYSTEM CD-M8000W MODEL SPEAKER SYSTEM CP-M8000 MODEL • In the interests of user-safety the set should be restored to its original condition and only parts identical to those specified be used. CONTENTS Page SAFETY PRECAUTION FOR SERVICE MANUAL ...................... -
Page 2: Safety Precaution For Service Manual
CD-M8000W/CP-M8000 SAFETY PRECAUTION FOR SERVICE MANUAL WARNINGS THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN CLASS 1 BUT THE LASER COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT FOR CLASS 1. THEREFORE IT IS IMPORTANT THAT THE FOLLOWING PRECAUTIONS ARE OBSERVED DURING SERVICING TO PROTECT YOUR EYES AGAINST EXPOSURE TO THE LASER BEAM. -
Page 3: Specifications
CD-M8000W/CP-M8000 FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER TO THE OPERATION MANUAL. SPECIFICATIONS CP-M8000 CD-M8000W General Type 4-way type speaker system Power source AC 110/127/220/230 - 240 V, 50/60 Hz Power consumption 180 W Super Tweeter 10 cm (4") Tweeter... -
Page 4: Names Of Parts
CD-M8000W/CP-M8000 NAMES OF PARTS CD-M8000W Front panel 1. Disc Tray 2. Timer Set Indicator 3. On/Stand-by Button 4. Tuner (Band) Button 5. CD Button 6. Headphone Socket 7. Microphone Level Control 8. Microphone Socket 9. Tape (1 2) Button 10. Video/Auxiliary Button 11. - Page 5 CD-M8000W/CP-M8000 CD-M8000W Rear panel 1. Cooling Fan 2. AC Voltage Selector 3. AC Power Lead 4. Transport Screw 5. FM 75 Ohms Aerial Terminal 6. FM Aerial Earth Terminal 7. AM Loop Aerial Socket 8. Span Selector Switch 9. Video/Auxiliary (Audio Signal) Input Sockets 10.
-
Page 6: Disassembly
CD-M8000W/CP-M8000 DISASSEMBLY CD-M8000W Caution on Disassembly Top Cabinet Follow the below-mentioned notes when disassembling Front the unit and reassembling it, to keep it safe and ensure (A1)x2 Panel ø3x12mm excellent performance: 1. Take cassette tape and compact disc out of the unit. - Page 7 CD-M8000W/CP-M8000 Tape (E2)x1 (E3)x1 Mic PWB (M2)x1 Mechanism (E3)x1 (E3)x1 Turntable Power PWB Front Panel (G2)x1 Loading Transformer Tray (M1)x2 Main PWB (G2)x1 Main PWB (E3)x1 Amp. CD Player Unit Figure 7-1 (F1)x4 (F1)x1 ø3x6mm Figure 7-4 ø3x10mm (F2)x1 Headphones...
- Page 8 CD-M8000W/CP-M8000 (Q2)x2 Mechanism (Q1)x1 (Q1)x1 Loading Tray Figure 8-1 CP-M8000 STEP REMOVAL PROCEDURE FIGURE Front Panel/ 1. Net Ass'y ....(A1) x1 Supper Tweeter 2. Catching Holder ..(A2) x4 3. Screw ..... (A3) x4 4. Screw ..... (A4) x2 Woofer 1.
-
Page 9: Removing And Reinstalling The Main Parts
CD-M8000W/CP-M8000 REMOVING AND REINSTALLING THE MAIN PARTS TAPE 2 TAPE MECHANISM SECTION Clutch Ass'y Perform steps 1 to 7 and 10 of the disassembly method to Record/Playback Head remove the tape mechanism. How to remove the record/playback and erase heads (TAPE 2) (See Fig. 9-1) 1. -
Page 10: Adjustment
CD-M8000W/CP-M8000 CD MECHANISM SECTION Loading Motor Perform steps 1, 2, 3, 12, 13, 14 and 15 of the disassembly CD Loading Loading method to remove the CD mechanism. Motor PWB Tray How to remove the loading motor (See Fig. 10-1) - Page 11 CD-M8000W/CP-M8000 TUNER SECTION CD SECTION fL: Low-range frequency • Adjustment fH: High-range frequency Since this CD system incorporates the following automatic • AM IF/RF adjustment functions, readjustment is not needed when replacing the pickup. Therefore, different PWBs and pickups Signal generator: 400 Hz, 30%, AM modulated can be combined freely.
- Page 12 CD-M8000W/CP-M8000 TEST MODE • Setting the test mode Any one of test mode can be set by pressing several keys as follows. <X-BASS> + <CD> + <POWER> TEST:CD operation test Function:-CD test mode. -Enter test mode. T E S T IL isn't done OPEN/CLOSE operation is using manual.
- Page 13 CD-M8000W/CP-M8000 Standard Specification of Stereo System Error Message Display Contents Error Contents DISPLAY Notes TAPE Mechanism Error. 'ER-TA**' 00: Tape Mechanism Error. 01: Initial Error. Pickup Mechanism Error. 'ER-CD**' 01: PU-IN SW Detection NG. CD Changer Mechanism Error. 'ER-CD**' 10: Changer Error.
-
Page 14: Notes On Schematic Diagram
CD-M8000W/CP-M8000 NOTES ON SCHEMATIC DIAGRAM • Resistor: • The indicated voltage in each section is the one measured To differentiate the units of resistors, such symbol as K and by Digital Multimeter between such a section and the chas- M are used: the symbol K means 1000 ohm and the symbol sis with no signal given. -
Page 15: Block Diagram
CD-M8000W/CP-M8000 DISC CLAMP NUMBER OPEN/ CLOSE T/T UP DOWN LOADING TO MAIN SECTION TO DISPLAY SECTION MOTOR – 9 10 CNP8 CNP7 LC78645NE CD SERVO XOUT 17 25 CONT5 SLDO SPDO VCC4 M63001FP VCC1 FOCUS/TRACKING/ VCC2 SPIN/SLED +3.3V DRIVER VCC3 +3.3V... - Page 16 CD-M8000W/CP-M8000 IC301 ZD351 ANTENNA TA7358AP SO301 5.1V FM ANTENNA FM FRONT END FM IF 10.7 MHz TERMINAL T302 CF303 BF301 X351 CF351 456 kHz B.P.F T351 CF352 AM IF FM RF L312 T301 AM LOOP ANTENNA OSC BUFF IC302 Q302...
- Page 17 CD-M8000W/CP-M8000 FL701 FL DISPLAY TO CD SECTION TAPE MECHANISM Q705 ASS'Y X351 6 kHz RX701 56 52 51 30 25 13 REMOTE SENSOR VLOAD AVDD IC701 SW701-SW707 IX0532AW SW711-SW720 SYSTEM SW723-SW726 MICROCOMPUTER 1 2 4 5 6 7 8 11 12...
-
Page 18: Schematic Diagram / Wiring Side Of P.w.board
CD-M8000W/CP-M8000 CD SERVO PWB-C CD SIGNAL PICKUP UNIT PICKUP HPC1LX VREF VREF 8.2K 1.2K 8.2K 0.047 80 79 78 77 76 75 74 73 8.2K EFMIN 0.001 RFVDD 0.0027 SLCO RSVSS SLCI FIN1 A 47/25 FIN2 B 22P(CH) TIN1 E... - Page 19 CD-M8000W/CP-M8000 100P(CH) 0.022 100P(CH) 100P(CH) 56P(CH) 100P(CH) 0.022 CD RES CLAMP SW 2.2K DISC NO 2.2K 8 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 LRCK ASDFIN ASDACK DATA SLCO ASLRCK...
- Page 20 CD-M8000W/CP-M8000 SYSTEM C613 R607 IC601 MUTE 10/50 LC75341 IC601 AUDIO LC75341 R613 R621 R615 PROCESSOR R609 2.2K 2.2K C606 C635 C615 100/16 0.001 0.001 VREF + – Q863 C616 INTERFACE KTC3199 GR C609 LOUT ROUT 0.001 R879 C610 C607 0.22 0.22...
- Page 21 CD-M8000W/CP-M8000 MAIN PWB-A(1/2) FM SIGNAL CD SIGNAL VIDEO SIGNAL PLAYBACK SIGNAL C602 VREF 22/25 MIC SIGNAL RECORD SIGNAL R608 C614 10/50 ROUT R633 C610 C608 R606 0.22 3.9K 0.22 L-CH R631 C631 RBASS C612 8.2K 390P JK601 0.0015 VIDEO/AUX R634...
- Page 22 CD-M8000W/CP-M8000 SPAN LED B PWB-B4 FL701 FL DISPLAY R794 BI703 CNP703 LED704 Q710 A503BC2E +10V KRC102 M C707 1/50 C706 Q705 47/25 KTC3199 GR BI704 R793 LED703 A503BC2E CNP704 8 1 82 83 84 85 86 87 8 8 89 9 0 91 92 93...
- Page 23 CD-M8000W/CP-M8000 DISPLAY PWB-B1 SPAN R795 C701 1/50 87 8 8 89 9 0 91 92 93 94 95 96 97 9 8 99 10 0 R763 –20dBATT SUB-CE/DSA_STB R702 T-BIAS R703 T_T1/T2 R704 REC/PLAY R705 CD RESOUT R706 R707 SPAN...
- Page 24 CD-M8000W/CP-M8000 IC901 – STK41217 POWER AMP. C911 100P R969 Q903 KTC3199 R903 C915 ZD902 ZD901 47/50 C959 DZ150BSB DZ150BSB 0.22 C916 C960 47/50 C921 0.22 R951 R952 100/50 3.9K 3.9K R972 R907 R908 R971 R936 10(1/2W) 10(1/2W) C919 100/100 C920...
- Page 25 CD-M8000W/CP-M8000 AMP. PWB-H1 FM SIGNAL SO901 SPEAKER TERMINAL RL901 L902 3.0µH Q903 R-CH KTC3199 GR R926 10(1/2W) R-CH C928 R928 0.22 10(1/2W) L-CH R929 C930 L-CH 0.22 R954 R932 LG901 R923 C925 (1/2W) (1/2W) 47/50 CHASSIS R930 R953 R931 10(1/2W)
- Page 26 CD-M8000W/CP-M8000 AM LOOP ANTENNA SO301 FM ANTENNA TERMINAL CNP301 MAIN PWB-A (2/2) BF301 C314 B.P.F. D305 DS1SS133 0.0047 C303 C308 4.7P(CH) 10P(CH) FM RF IC301 C304 L312 0.01 C309 TA7358AP C315 0.0047 R311 100K 0.001 C316 0.022 FM FRONT END...
- Page 27 CD-M8000W/CP-M8000 MIC PWB-G MIC SIGNAL CK48 220P RK47 CK41 8.2K CK53 100/16 47/25 RK46 ICK1 DS1SS133 CK50 M65856SP CK46 100P MIC AMP. 2.2/50 RK45 RK11 6.8K DATA MICSW DS1SS133 CK35 0.01 CK51 RK10 RK49 MCLKCONT CLOCK 1/50 CK34 IC903 CK49...
- Page 28 CD-M8000W/CP-M8000 CNP701 CNPK1 DISPLAY PWB MIC PWB P31 12 - D P27 9 - H CNS602 1 2 3 4 5 6 7 8 9 10 11 FFC701 MAIN PWB-A R378 X352 R388 R359 1 2 3 4 5 6 7 8 9...
- Page 29 CD-M8000W/CP-M8000 CNP701 CNP7 FROM CD SERVO PWB TAPE 1 P34 4 - A PLAYBACK HEAD P35 10 - F CNS11 1 2 3 4 5 6 7 8 Q122 R156 B C E C146 R140 R146 R158 C142 R132 R154...
- Page 30 CD-M8000W/CP-M8000 LED B PWB-B4 RX701 REMOTE SENSOR C716 5 6 7 8 9 10111213141516171819 LED704 R783 R707 R793 R792 Q705 R763 B C E FL701 R702 BI703 C703 D714 D713 R703 R704 5 10 Q709 CNS703 3 2 1 C714...
- Page 31 CD-M8000W/CP-M8000 LED A PWB-B3 R771 LED703 LED701 RD01 SW701 27 28 29 30 31 32 33 34 3536 37 38 39 40 41 STAND-BY R798 R799 R792 BI704 R800 Q702 Q701 FL701 R753 R754 C706 5 10 Q710 CNP701 IC701...
- Page 32 CD-M8000W/CP-M8000 M903 FAN MOTOR CNS907 FW901 CNS902 CNP907 FW901 CNS903 CNP705 FW901A RFM940 JK701 HEADPHONES R943 C952 HEADPHONES PWB-B2 ZD951 R950 R949 C904 D913 C918 DFM922 C917 R905 D902 C915 R969 R965 C911 C905 C913 R966 D901 R903 R944 C916...
- Page 33 CD-M8000W/CP-M8000 P30 1 - F FROM DISPLAY PWB CNS705 CNP905 1 2 3 4 R807 R806 R803 R810 R819 R811 ZD804 ZD801 ZD802 Q803 C823 C819 B C E PT801 TRANSFORMER PWB-H3 R805 POWER TRANSFORMER D809 R802 D810 C824 D806...
- Page 34 CD-M8000W/CP-M8000 P30 1 - E P29 8 - A FROM DISPLAY PWB FROM MAIN PWB CNS701 CNS11 CD SERVO PWB-C CNP7 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 CNP8...
- Page 35 CD-M8000W/CP-M8000 P30 3 - H TAPE MECHANISM TO DISPLAY PWB ASSEMBLY CNP702 FFC702 TAPE MECHANISM PWB-F 8 10 SOLENOID SOLENOID TAPE MOTOR TAPE 1 PLAYBACK HEAD CD LOADING MOTOR PWB-E TAPE 2 RECORD/PLAYBACK/ERASE HEAD OPEN/CLOSE T/T UP/DOWN LOADING MOTOR 1 2 3 4 5 6...
-
Page 36: Voltage
CD-M8000W/CP-M8000 VOLTAGE IC101 IC302 IC601 IC701 VOLTAGE VOLTAGE VOLTAGE VOLTAGE VOLTAGE VOLTAGE VOLTAGE VOLTAGE 2.4 V 4.23 V 1.6 V 3.7 V 1.7 V 4.14 V 1.0 V 3.7 V 1.7 V 0.5 V 4.6 V 1.6 V 1.8 V 5.3 V... -
Page 37: Waveforms Of Cd Circuit
CD-M8000W/CP-M8000 WAVEFORMS OF CD CIRCUIT Stopped Stopped 1999/04/07 09:51:15 CH1=500 mV CH3=500 mV 500 ms/div CH1=200 mV CH2=500 mV 500 ms/div DC 10:1 DC 10:1 (500 ms/div) DC 10:1 DC 10:1 (500 ms/div) NORM:20 kS/s NORM:20 kS/s IC1 21 IC1 21... -
Page 38: Troubleshooting
CD-M8000W/CP-M8000 TROUBLESHOOTING When the CD does not function When the CD section does not operate when the objective lens of the optical pickup is dirty, this section may not operate. Clean the objective lens, and check the playback operation. When this section does not operate even after the above step is taken, check the following items. - Page 39 CD-M8000W/CP-M8000 Stopped (1) Focus-HF system check. CH1=500 mV CH3=500 mV 500 ms/div DC 10:1 DC 10:1 (500 ms/div) NORM:20 kS/s Although a CD is inserted and the cover is closed, "NO DISC" is displayed. Press the OPEN/CLOSE switch (SW1) without inserting a disc, and try starting the playback operation.
- Page 40 CD-M8000W/CP-M8000 (2) Tracking system check. Check the TE waveform at pin 15 on IC1. The tracking servo is not activated. If the waveform shown in Figure 40-1 appears and soon after Check the peripheral circuits at pins 14, 15 and 20 on IC1, and NO DISC appears ? CNS1A/B.
- Page 41 CD-M8000W/CP-M8000 (4) PLL system check. Stopped 1999/04/05 17:33:17 CH1=500 mV CH3=1 V CH4=1 V 500 ms/div DC 10:1 DC 10:1 DC 10:1 (500 ms/div) NORM:20 kS/s When a disc is loaded, start play operation. PDO1 The HF waveform is normal, but the TOC data cannot be PDO2 read.
-
Page 42: Function Table Of Ic
CD-M8000W/CP-M8000 FUNCTION TABLE OF IC IC1 VHiLC78645NE1: CD Servo (LC78645NE) (1/2) Terminal Name Input/Output Setting in Reset Pin No. Function SLCO Output — Control output. For slice level SLCIST Input — Resistor connection terminal for SLCO output current setting. control. - Page 43 CD-M8000W/CP-M8000 IC1 VHiLC78645NE1: CD Servo (LC78645NE) (2/2) Terminal Name Input/Output Setting in Reset Pin No. Function RVSS — — GND for Right channel. Must be connected to 0 V. Right channel RCHO Output LVDD /2 Right channel output. D/A converter...
- Page 44 CD-M8000W/CP-M8000 IC1 VHiLC78645NE1: CD Servo (LC78645NE) 75 74 72 71 69 68 66 65 63 62 SLCO DATA SLCIST EFMIN LRCK ASDFIN RFVDD ASDACK RFVSS ASLRCK FIN1 16MOUT FIN2 EFLG TIN1 TIN2 XVSS LC78645NE VREF FSX/16MIN REF1 XOUT XVDD RVDD...
- Page 45 CD-M8000W/CP-M8000 IC601 VHiLC75341/-1: Audio Processor (LC75341) ROUT LOUT LBASS RBASS LTRE RTRE LSEL0 RSEL0 R1 R2 24 23 22 21 20 19 18 17 16 15 14 13 LC75341 10 11 12 Figure 45 BLOCK DIAGRAM OF IC – 45 –...
- Page 46 CD-M8000W/CP-M8000 IC701 RH-iX0532AWZZ: System Microcomputer (IX0532AW) (1/2) Pin No. Port Name Terminal Name Input/Output Function Input (+) Power supply. -20dBATT Output -20dB Attenuator. SUB_CE Output MP3 sub microcomputer. T_BIAS Output Tape record bias. T_T1/T2 Output Tape T1/T2 change. T_REC/PLY Output Tape REC/PLAY change.
- Page 47 CD-M8000W/CP-M8000 IC701 RH-iX0532AWZZ: System Microcomputer (IX0532AW) (2/2) Pin No. Port Name Terminal Name Input/Output Function P120 O/C SW Input CD OPEN/CLOSE SW. P117 MIC SW Input Mic switch input. P116 KARA_LATCH Output Karaoke latch. P115 NO USE Output Open P114...
- Page 48 CD-M8000W/CP-M8000 ICK1 VHiM65856SP-1: Mic Amp. (M65856SP) (1/2) Pin No. Port Name Input/Output Function MIC SW Input Microphone SW L: MIC OFF, H: MIC ON MCLKCONT — Clock Control. Controls built-in clock generation circuit with external R. VALC — ALC operating voltage setting terminal.
- Page 49 CD-M8000W/CP-M8000 ICK1 VHiM65856SP-1: Mic Amp. (M65856SP) (2/2) Pin No. Port Name Input/Output Function KEYCONIN Input Monaural input for external KEYCONTROL IC. Input/Output interface terminal for external KEYCONTROL IC. SOURCEOUT Output Monaural input for external KEYCONTROL IC. Input/Output interface terminal for external KEYCONTROL IC.
-
Page 50: Fl Display
CD-M8000W/CP-M8000 FL DISPLAY FL701 VVKNA09SS29-1 GRID ASSIGNMENT X-BASS REC ST SLEEP TP TI PTYIPTY MHz TA MEMORY h j k (1G~8G) ANODE CONNECTION X-BASS PTYI MEMORY PRO LOGIC SLEEP – 50 –... - Page 51 “HOW TO ORDER REPLACEMENT PARTS” To have your order filled promptly and correctly, please furnish the For U.S.A. only following information. Contact your nearest SHARP Parts Distributor to order. 1. MODEL NUMBER 2. REF. No. 3. PART NO. 4. DESCRIPTION For location of SHARP Parts Distributor, Please call Toll-Free;...
- Page 52 CD-M8000W/CP-M8000 PRICE PRICE PART CODE DESCRIPTION PARTS CODE DESCRIPTION RANK RANK VHEDZ3R9BSB-1 AC Zener,3.9V,DZ3.9BSB CD-M8000W ZD351 VHEDZ5R1BSB-1 AC Zener,5.1V,DZ5.1BSB ZD604 VHEDZ6R2BSA-1 AB Zener,6.2V,DZ6.2BSA INTEGRATED CIRCUITS ZD801 VHEDZ300BSB-1 AB Zener,30V,DZ30BSB ZD802 VHEDZ6R2BSA-1 AB Zener,6.2V,DZ6.2BSA ZD804 VHEDZ6R2BSA-1 AB Zener,6.2V,DZ6.2BSA VHILC78645NE1 AY CD Servo,LC78645NE...
- Page 53 CD-M8000W/CP-M8000 PRICE PRICE DESCRIPTION DESCRIPTION PART CODE PARTS CODE RANK RANK VCCCCY1HH101J J AA 100 pF (CH),50V C369 VCCUMN1HJ270J AA 27 pF (UJ),50V AB 1 µF,50V,Electrolytic VCCCCY1HH101J J AA 100 pF (CH),50V C370~372 VCEAZA1HW105M J AA 0.018 µF,16V VCCCCY1HH101J J...
- Page 54 CD-M8000W/CP-M8000 PRICE PRICE PART CODE DESCRIPTION PARTS CODE DESCRIPTION RANK RANK AB 0.22 µF,50V,Electrolytic C917,918 VCEAZA1HW224M J R111 VRD-ST2CD153J AA 15 kohms,1/6W AE 100 µF,100V,Electrolytic C919,920 VCEAZV2AW107M J R112 VRD-MN2BD153J AA 15 kohms,1/8W AC 100 µF,50V,Electrolytic C921,922 VCEAZA1HW107M J R113,114...
- Page 55 CD-M8000W/CP-M8000 PRICE PRICE DESCRIPTION DESCRIPTION PART CODE PARTS CODE RANK RANK R625~627 VRD-ST2CD102J AA 1 kohm,1/6W R903,904 VRD-ST2CD563J AA 56 kohms,1/6W R631,632 VRD-MN2BD822J AA 8.2 kohms,1/8W R905,906 VRD-ST2CD102J AA 1 kohm,1/6W R633,634 VRD-MN2BD393J AA 39 kohms,1/8W R907,908 VRD-ST2CD561J AA 560 ohms,1/6W...
- Page 56 CD-M8000W/CP-M8000 PRICE PRICE PART CODE DESCRIPTION PARTS CODE DESCRIPTION RANK RANK 1 SW801 CNP3A 92LCONE6P53254 J AC Plug,6Pin QSOCE0010AWZZ J AH Switch,Slide Type CNP4 QCNCM705FAFZZ J AB Plug,6Pin [Voltage Selector] CNP7 92LCONE8P53254 J AC Plug,8Pin CNP8 92LCONEAP53254 J AD Plug,10Pin...
- Page 57 CD-M8000W/CP-M8000 PRICE PRICE DESCRIPTION DESCRIPTION PART CODE PARTS CODE RANK RANK LANGK0110AWFW J AE Bracket,Cassette Lock,Tape 1 ACCESSORIES/PACKING PARTS LANGK0111AWFW J AE Bracket,Cassette Lock,Tape 2 LANGK0317AWFW J AF Bracket,Fan Support QANTL0008AWZZ J AH AM Loop Antenna LBSHC0002AWZZ J AD Bushing,AC Power Supply Cord...
- Page 58 CD-M8000W/CP-M8000 CD-M8000W 306-2 306-1 306-3 703x2 305x2 PWB-D Figure 7 CD MECHANISM EXPLODED VIEW – 7 –...
- Page 59 CD-M8000W/CP-M8000 CD-M8000W BELT CONNECTION 202-1 616x3 IC853 FF/REW Tape FF/REW PWB-A IC852 ROLLER Motor ROLLER ASS'Y ASS'Y IC851 604x2 FLYWHEEL FLYWHEEL ASS'Y ASS'Y MAIN BELT TAPE2 TAPE1 614x12 Silicon 610x5 Grease 614x3 614x2 202-2 230 611x2 PWB-F PWB-B3 272x2 PWB-B4...
- Page 60 CD-M8000W/CP-M8000 CD-M8000W 609x2 MECHANISM 609x2 PWB-E 619x2 PWB-C Figure 9 CABINET EXPLODED VIEW (2/2) – 9 –...
- Page 61 CD-M8000W/CP-M8000 CP-M8000 (with Capacitor C1, 916x2 916x2 C2, C3, C4) 917x2 913x4 914x4 917x2 920x3 919x4 912x2 915x4 918x4 918x4 WOOFER 912x2 MIDRANGE TWEETER SUPER TWEETER SP7 SUPER TWEETER Capacitor (N.P.) Electrolytic TWEETER C4 Capacitor (N.P.) Capacitor (N.P.) Capacitor (N.P.) MIDRANGE 6.8 µF,250 V...
- Page 62 CD-M8000W/CP-M8000 –– MEMO –– – 11 –...
- Page 63 CD-M8000W/CP-M8000 –– MEMO –– – 12 –...
- Page 64 CD-M8000W/CP-M8000 © COPYRIGHT 2002 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
