Installation Manual for
Monobloc Air-to-Water Heat Pump System
No. 0150562494
• This product must only be installed or serviced by qualified personnel.
• Please read this manual carefully before installation. This appliance is filled with R32.
• Keep this manual for future reference.
Original instructions
AW052MUCHA
AW072MUCHA
AW092MUCHA
AW11NMXCHA
AW14NMXCHA
AW16NMXCHA
AW112MXCHA
AW142MXCHA
AW162MXCHA
Advertisement
Table of Contents
Related Manuals for Haier AW052MUCHA
Summary of Contents for Haier AW052MUCHA
- Page 1 Installation Manual for Monobloc Air-to-Water Heat Pump System AW052MUCHA AW072MUCHA AW092MUCHA AW11NMXCHA AW14NMXCHA AW16NMXCHA AW112MXCHA AW142MXCHA AW162MXCHA No. 0150562494 • This product must only be installed or serviced by qualified personnel. • Please read this manual carefully before installation. This appliance is filled with R32.
- Page 2 EUROPEAN REGULATIONS CONFORMITY FOR THE MODELS DISPOSAL REQUIREMENTS: All the products are in conformity with the following Your air conditioning product is marked with European provision: this symbol.This means that electrical and -Low voltage Directive electronic products shall not be mixed with -Electomagnetic Compatibility unsorted household waste.Do not try to dismantle the system yourself:the dismantling...
-
Page 3: Table Of Contents
Contents Contents Definitions ..................................1 Safety ....................................2 Accessories ..................................16 Transportation and lifting ..............................17 Installation instruction ..............................19 Electric wiring and the application ...........................26 Installation and debugging...............................31 Failure code ..................................32 Trial operation and the performance ..........................34 Move and scrap the air conditioning ..........................35 Warning •... -
Page 4: Definitions
No part of this publication may be reproduced, copied, filed or transmitted in any shape or form without the permission of Haier. Within the policy of continuous improvement of its products, Haier reserves the right to make changes at any time without prior notification and without being compelled to introducing them into products subsequently sold. This document may therefore have been subject to amendments during the life of the product. -
Page 5: Safety
• The air conditioner can not be discarded or scrapped Randomly If you need please contact customer service personnel of Haier to scrap in order to obtain the correct disposal methods. • Reusable mechanical connectors and flared joints are not allowed indoor. - Page 6 Safety Loading and Unloading/Transporting Management/Storage Requirements Loading and Unloading Requirements 1) The products shall be carefully handled during loading and unloading. 2) Rude and barbarous handling such as kicking, throwing, dropping, bumping, pulling and rolling is not allowed. 3) The workers engaged in loading and unloading must be subject to necessary trainings on the potential hazards caused by barbarous handling.
- Page 7 Safety Unpacking Inspection Outdoor unit: the leak detection equipment shall be extended into the packing box of the outdoor unit, to check whether the refrigerant is leaking. If the refrigerant leakage is identified, installation is not allowed, and the outdoor unit shall be delivered to the maintenance department.
