4K Network Video Recorder
Installation Manual
DRN-116-4TB shown
Model
Channels
DRN-104-2TB
4 channels
DRN-108-2TB
8 channels
DRN-116-4TB
16 channels
*Other HDD sizes available by special order, including 1/2/4/6/8/10 TB
The ENFORCER Network Video Recorder offers 4K and H.265 High Efficiency Video Coding, reducing
bandwidth and storage requirements without giving up video quality. These NVRs are perfect for a wide range
of applications due to their cost-effectiveness and simple-to-install design.
• Compatible with 8MP (4K) IP Camera
• QR code and Wizard assistance for easier first-time setup
• Plug-and-Play
• Built-in PoE Ports (IEEE 802.3af/at)
• VGA and HDMI
®
output up to 4K resolution
• ONVIF
®
Profile S conformant
• Live view recording and playback up to 4K@30FPS
• P2P for simple remote connection using PC or mobile device
• Supports up to 9 AI functions, up to 12 when used with EV-N2806-2W4WQ
DRN-116-4TB Additional Features
• Supports up to two (2) HDDs
• Live view recording and playback up to 4K@45FPS
• 8 Sensor inputs, 1 alarm relay output
ONVIF
®
is a trademark of ONVIF, Inc
Included HDD*
2TB SATA
2TB SATA
4TB SATA
Internal storage capacity
1 SATA, up to 10TB
1 SATA, up to 10TB
2 SATA, up to 10TB each
Advertisement
Table of Contents
Related Manuals for SECO-LARM ENFORCER DRN-104-2TB
Summary of Contents for SECO-LARM ENFORCER DRN-104-2TB
- Page 1 4K Network Video Recorder Installation Manual DRN-116-4TB shown Model Channels Included HDD* Internal storage capacity DRN-104-2TB 4 channels 2TB SATA 1 SATA, up to 10TB DRN-108-2TB 8 channels 2TB SATA 1 SATA, up to 10TB DRN-116-4TB 16 channels 4TB SATA 2 SATA, up to 10TB each *Other HDD sizes available by special order, including 1/2/4/6/8/10 TB The ENFORCER Network Video Recorder offers 4K and H.265 High Efficiency Video Coding, reducing...
-
Page 2: Parts List
2 SATA HDD, up to 1 SATA HDD, up to 10TB capacity 10TB General Power supply 48VDC@1.2A 48VDC@1.5A 48VDC@3.75A Power consumption "x13 "x2" Dimensions "x8 "x2 " (300x227x53 mm) (378x340x50 mm) Operating temperature 32°~104°F (0°~40°C) Humidity Less than 90%RH SECO-LARM U.S.A., Inc. - Page 3 • Alarm – Connect to an external alarm output device such as a strobe or siren • Sensor (8~1, G) – Connect to external alarm sensors • Audio Out – Connect to speakers • Audio In – Connect to a microphone • RS485 – Connect to an RS485 device SECO-LARM U.S.A., Inc.
-
Page 4: Hard Drive Installation
2. Carefully flip the NVR and secure the hard drive with screws (4 screws for each hard drive). CAUTION: DO NOT install or remove the hard drive while the unit is powered on. Startup Wizard Click the Start Wizard to proceed to the next step. NOTE: Screen images in this manual are simulated. SECO-LARM U.S.A., Inc. -
Page 5: Network Configuration
• DNS1 – Set primary DNS server. • DNS2 – Set secondary DNS server. • Web Port – Default: 80 • Client Port – Default: 9000 • RTSP Port – Default: 554 • UPNP – Set On/Off. SECO-LARM U.S.A., Inc. - Page 6 • Time Offset – Select the amount of time offset. • DST Mode – Choose to set the DST in weeks or days. • Start Time/End Time – set the Start Time and End Time for DST. SECO-LARM U.S.A., Inc.
- Page 7 For the first time setup, the HDD must be formatted. Select the HDD and then click Format HDD. Overwrite – Overwrite the oldest recordings on the HDD when HDD is full. • Record on ESATA – Does not apply and is disabled. • SECO-LARM U.S.A., Inc.
- Page 8 IMPORTANT: Users and installers of this product are responsible for ensuring this product complies with all national, state, and local laws and statutes related to monitoring and recording audio and video signals. SECO-LARM will not be held responsible for the use of this product in violation of any current laws or statutes.
