Smart Array 3200 Controller
Reference Guide
Second Edition (
January 1999)
Part Number
340862-002
Compaq Computer Corporation

Advertisement

Table of Contents
loading

Related Manuals for Compaq 3200

Summary of Contents for Compaq 3200

  • Page 1 Smart Array 3200 Controller Reference Guide Second Edition ( January 1999) Part Number 340862-002 Compaq Computer Corporation...
  • Page 2 MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, GOOD TITLE AND AGAINST INFRINGEMENT. This publication contains information protected by copyright. No part of this publication may be photocopied or reproduced in any form without prior written consent from Compaq Computer Corporation. 1998 Compaq Computer Corporation.

  • Page 3: Table Of Contents

    Moving Drives...2-6 Moving Arrays...2-7 Restoring an Array to Its Original Controller ...2-10 Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: A-FRNT.DOC Last Saved On: 12/7/98 1:56 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 4 Create Drive Array Screen ...5-25 Create Logical Drive Screen ...5-26 Error and Warning Messages...5-29 Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: A-FRNT.DOC Last Saved On: 12/7/98 1:56 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 5 Creating the EFS Diskettes...6-29 Accessing the Information...6-29 Updating the Compaq Insight Manager Agents...6-30 Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: A-FRNT.DOC Last Saved On: 12/7/98 1:56 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 6 Compliance with International Regulations...A-6 Laser Product Label...A-6 Laser Information ...A-7 Battery Replacement Notice ...A-8 Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: A-FRNT.DOC Last Saved On: 12/7/98 1:56 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 7 Online Capacity Expansion or Extension ... E-21 Disk Drive Upgrades ... E-21 Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: A-FRNT.DOC Last Saved On: 12/7/98 1:56 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 8 Automatic Data Recovery ...H-4 Automatic Data Recovery Failure ...H-5 Compromised Fault Tolerance...H-6 Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: A-FRNT.DOC Last Saved On: 12/7/98 1:56 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 9 Appendix J Questions and Answers Index Compaq Smart Array 3200 Controller Reference Guide Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: A-FRNT.DOC Last Saved On: 12/7/98 1:56 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 10: About This Guide

    DRIVE NAMES Type Enter Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: A-FRNT.DOC Last Saved On: 12/7/98 1:56 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Keys appear in boldface. A plus sign (+) between two keys indicates that they should be pressed simultaneously.

  • Page 11: Symbols In Text

    These icons may be located on equipment in areas where hazardous conditions may exist. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: A-FRNT.DOC Last Saved On: 12/7/98 1:56 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 12: Getting Help

    Compaq Website The Compaq website has information on this product as well as the latest drivers and Flash ROM images. You can access the Compaq website by logging on to the Internet at http://www.compaq.com.

  • Page 13: Features

    Chapter 1 Features The Smart Array 3200 Controller is a dual-channel, 32-bit array controller that offers advanced features (see below). The Smart Array 3200 Controller supports Wide-Ultra2 SCSI technology for improved data transfer rates and is backward- compatible with other SCSI devices. It also includes optional daughterboards for customizing combinations of internal and external connections (two external, two internal, or one internal and one external).

  • Page 14: Other Features

    Drive and array movement in any order Multiple logical drives per array Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: B-CH01.DOC Last Saved On: 12/7/98 8:24 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 15: About The Smart Array 3200 Controller

    It provides a high-speed (up to 132 MB/sec) path between the system board and the controller. The Smart Array 3200 Controller is a PCI Bus Master device and conforms to Rev. 2.1 of the PCI Local Bus Specification.

  • Page 16: Using The Array Accelerator

    This data is then read into the array accelerator from the drives. When the Smart Array 3200 Controller receives a read request for the cached data, the data can be brought into the system at memory speeds and avoid the latency of a disk access.

  • Page 17: Wide-Ultra2 Scsi Technology

    (see Figure 1-1). For information on daughterboards, see the Smart Array 3200 Controller Installation Guide. Although controller failure is not anticipated, the Array accelerator can be detached from a Smart Array 3200 Controller and attached to a replacement Smart Array 3200 Controller. If the...

  • Page 18: The Array Configuration Utility

    “Running the Array Configuration Utility,” for information on configuring your drive arrays. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: B-CH01.DOC Last Saved On: 12/7/98 8:24 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 19: Using Fault Tolerance

    Configuration Utility,” in Chapter 5, and the section, “Adding Storage Capacity” in Appendix E. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: B-CH01.DOC Last Saved On: 12/7/98 8:24 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 20: Drive Movement

    Fast SCSI-2 drives are supported by the Smart Array 3200 Controller using the appropriate cable adapter. Operating System Drivers The latest drivers for Compaq products can be obtained from the World Wide Web at http://www.compaq.com. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: B-CH01.DOC Last Saved On: 12/7/98 8:24 AM...

  • Page 21: Guidelines For Making Changes To Current Installation

    Current Installation Multiple Smart Array 3200 Controller Installations If you will be installing or replacing drives in your Compaq server, keep in mind that: Each Smart Array 3200 Controller has two independent SCSI channels, each of which supports up to 15 drives per SCSI bus.
  • Page 22 8 to 15 for each SCSI bus (ID7 is reserved for the controller). Consult the documentation that came with the drive for instructions on setting the SCSI ID. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: C-CH02.DOC Last Saved On: 12/7/98 8:33 AM...

  • Page 23: Determining The Maximum Storage

    Server specifications are also available at the Compaq website at http://www.compaq.com. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: C-CH02.DOC Last Saved On: 12/7/98 8:33 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 24: Expanding Or Extending The Capacity Of An Array

    Compaq Array Configuration Utility to reconfigure your drive array and make use of the added capacity. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: C-CH02.DOC Last Saved On: 12/7/98 8:33 AM...

  • Page 25: Changing The Fault Tolerance (Raid Level) Of An Array

    Your system automatically redistributes the data according to the new striping factor. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: C-CH02.DOC Last Saved On: 12/7/98 8:33 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 26: Moving Drives

    Run the Array Configuration Utility to view the new drive configuration (optional). Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: C-CH02.DOC Last Saved On: 12/7/98 8:33 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED CAUTION: Back up all data before removing drives or changing configurations.

  • Page 27: Moving Arrays

    “Restoring an Array to Its Original Controller.” Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: C-CH02.DOC Last Saved On: 12/7/98 8:33 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 28 Figure 2-1. Configuration with two arrays and two controllers Controller 1 Figure 2-2. Arrays consolidated to one controller Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: C-CH02.DOC Last Saved On: 12/7/98 8:33 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 29 Run the Array Configuration Utility to view the new drive configuration or to assign spare drives (optional). Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: C-CH02.DOC Last Saved On: 12/7/98 8:33 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 30: Restoring An Array To Its Original Controller

    Figure 2-3. Arrays A and B both attached to Controller 1 Controller 1 Figure 2-4. Interim four-array state Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: C-CH02.DOC Last Saved On: 12/7/98 8:33 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 31 Run the Array Configuration Utility and remove the appropriate failed arrays. Reboot the system. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: C-CH02.DOC Last Saved On: 12/7/98 8:33 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 32: Updating The Firmware

    Chapter 3 Updating the Firmware The ROMs on all Compaq servers and most Compaq options can be updated easily. By programming the ROM using a special Compaq utility called ROMPaq, the existing contents of the ROM are replaced with another version stored in a disk file.

  • Page 33: Materials Needed

    Ten to fifteen blank diskettes for SystemsROMPaq and Options ROMPaq Access to a server or workstation with a bootable CD-ROM drive. This can be the system in which you are installing the Smart Array 3200 Controller. Creating Diskettes To create ROMPaq diskettes: Boot the server from the Compaq SmartStart and Support Software CD.

  • Page 34: Running Systems Rompaq

    System ROMPaq on all servers when installing a new Smart Array 3200 Controller. If you purchased your server with Smart Array 3200 Controller already installed, you do not need to run System ROMPaq at the time of server installation.
  • Page 35 Remove the System ROMPaq diskette and reboot the server by cycling the power (cold boot). If you have not installed your new Smart Array 3200 Controller, install it now. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: D-CH03.DOC Last Saved On: 12/7/98 1:19 PM...

  • Page 36: Running Options Rompaq

    Options ROMPaq updates the firmware on Compaq options. Since it is difficult to determine when to update the firmware, Compaq recommends that you run the latest Options ROMPaq on all Smart Array 3200 Controllers whenever new versions are released. The Smart Array 3200 Controller firmware version on the Compaq SmartStart and Support Software CD has already been installed;...
  • Page 37 Updating the Firmware If the ROM firmware for the Smart Array 3200 Controller is the same or newer than that on the Options ROMPaq diskette, you will get the message: Press Enter to go to step 9. If the ROM firmware for the Smart Array 3200 Controller is older than...
  • Page 38 (cold boot). To upgrade additional options in the server, repeat Steps 2 through 9 by booting from each Options ROMPaq diskette in succession. The Smart Array 3200 Controller ROM has been updated. If there are any new or increased capabilities, they have been enabled with the new firmware.

  • Page 39: System Configuration Utility

    CD; it is the latest one that supports the Smart Array 3200 Controller. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: E-CH04.DOC Last Saved On: 11/30/98 5:33 PM...
  • Page 40 3200 Controller option kit) At least four blank diskettes Access to a server or workstation with a bootable CD-ROM drive. This may be the system in which you are installing Smart Array 3200 Controller. Creating Diskettes To create System Configuration Utility diskettes: Boot the computer from the Compaq SmartStart and Support Software CD.
  • Page 41 Reboot the server. During the boot process, several messages appear. Among these are a notice that one or more Smart Array 3200 Controllers were detected in option slots and a recommendation to run the System Configuration Utility. Press F1 to resume booting, if prompted.

  • Page 42: Configuring The Controller

    When installing a Smart Array 3200 Controller, you must determine if the boot disk is to be handled by a Smart Array 3200 Controller or the integrated SCSI controller. If this Smart Array 3200 Controller will be the primary controller, choose First;...

  • Page 43: Online Recovery Server Status

    When installing a Smart Array 3200 Controller in a system with an existing array controller, you can either place the new controller at the end of the controller order or reorder the controllers. Reordering changes the current drive letter assignments for all drives on the system. To avoid changing drive letter assignments, place the new controller at the end of the controller order.

  • Page 44: Configuration Steps

    Remove the CD or System Configuration diskette and verify that the server boots normally without POST errors. System hardware configuration is complete. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: E-CH04.DOC Last Saved On: 11/30/98 5:33 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 45: Running The Array Configuration Utility

    The Array Configuration Utility is located on the SmartStart and Support Software CD. The utility uses a graphic interface to help you configure the Smart Array 3200 Controller. You can use it to configure the Smart Array 3200 Controller initially, to add additional disk drives to an existing configuration, or to reconfigure an array controller.
  • Page 46 Uses wizards that guide you through the configuration process Suggests optimal configuration and fault tolerance for unconfigured controllers Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED CAUTION: The write cache on the drives is not backed up by batteries.

  • Page 47: Before You Begin

    Compaq Array Configuration Utility offline. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM...

  • Page 48: Smartstart And Support Software Cd

    Configuration Wizards When you start the Array Configuration Utility, the software checks the configuration of the Smart Array 3200 Controller and its drive arrays. If the arrays are unconfigured or if the configuration is less than optimal, the configuration wizard guides you through the configuration process. The configuration wizard recognizes the following conditions: Unconfigured controller —...

  • Page 49: Configuration Procedures

    Distributed Data Guarding. The fault-tolerance method for all logical drives on Array B is RAID 1, Drive Mirroring. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 50 Select the correct operating system on the controller settings screen. Figure 5-3. Controller settings screen Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 51 NOTE: Given the reliability of a particular generation of hard drive technology, the probability of an array experiencing a drive failure increases with the number of drives in an array. Compaq recommends the number of drives in an array be limited to 14.
  • Page 52 Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 53 Array Configuration Utility. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM...
  • Page 54 See the section titled “Create Logical Drive Screen” later in this chapter for a detailed description. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 55 10. The Configuration View screen should look like Figure 5-8. Figure 5-8. Example array - Configuration View screen with two arrays Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM...

  • Page 56: Capacity Expansion

    Create a new logical drive to use the extra space on the expanded array. See the following example. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 57 Click the Expand button. Select the unassigned 4.3-GB drive. Click Assign Drive(s) to Array button. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 58 NOTE: Logical drive 2 will not be accessible until the capacity expansion process has completed on logical drive 1. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM...

  • Page 59: Capacity Extension

    Increase the size of the logical drive by clicking the slider control on the screen. Click Done. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 60 NOTE: You cannot reduce the size of the logical drive from this screen. Click Done. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 61: Online Migration

    Choose a RAID level. Choose a stripe size. Click Done. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Compaq Smart Array 3200 Controller Reference Guide...
  • Page 62 In this example, 16 KB is selected. 6. Click Done. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 63: Array Configuration Utility Screens

    View box providing that option. Figure 5-13. Compaq Array Configuration Utility screen Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 64 View Configuration list box. Figure 5-14. Controller Selection Box Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 65 Configuration View box to select the Physical or Logical view. Figure 5-15 shows the physical view of a Smart Array 3200 Controller in Slot 1. Listed below the controller are two unassigned drives: one 9.1-GB drive and one 4.3-GB drive.
  • Page 66 Array button to display the Create Array screen (see the section titled “Create Drive Array Screen” later in this chapter). Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM...
  • Page 67 Figure 5-19. Logical Drive button Compaq Smart Array 3200 Controller Reference Guide Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 68: Controller Settings Screen

    Some applications may perform better with a larger write cache; others may perform better with a larger read cache. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM...

  • Page 69: Create Drive Array Screen

    Always group physical drives of the same size. If you mix drive sizes, the Smart Array 3200 Controller treats all the drives as the same size as the smallest drive in the array. This results in wasted capacity in the larger drives.

  • Page 70: Create Logical Drive Screen

    NOTE: Given the reliability of a particular generation of hard drive technology, the probability of an array experiencing a drive failure increases with the number of drives in an array. Compaq recommends the number of drives in an array be limited to 15.
  • Page 71 RAID level in many applications. However, your application may benefit from setting the stripe size to a different value. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM...
  • Page 72 Online RAID Level and Stripe-Size Migration screen. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 73: Error And Warning Messages

    Compaq Smart Array 3200 Controller Reference Guide Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 74: Running The Array Configuration Utility Continued

    NLM for configuring your drive arrays without shutting down your server. CPQONLIN also provides information about the status of drives attached to the Smart Array 3200 Controller. It indicates drive failure, expansion, or waiting for expansion or rebuild (queued). Before loading CPQONLIN.NLM, you must load the appropriate device driver CPQARRAY.HAM.

  • Page 75: Custom Configuration

    Use online help for instructions to complete configurations. The following sections discuss CPQONLIN functions. Compaq Smart Array 3200 Controller Reference Guide Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 76 Priority Settings To set the drive rebuild priority, highlight the Smart Array 3200 Controller and select the Controller Settings. If you chose low priority for drive rebuilding (the default), rebuild takes place only when the Smart Array 3200 Controller is not busy handling normal I/O requests.
  • Page 77 Accelerator Ratio The Smart Array 3200 Controller has an onboard cache, called an Array Accelerator, that performs both write-posting and read-ahead caching. The setting in CPQONLIN determines the amount of memory allocated to the read and write caches. For example, if the Accelerator Ratio is set to Read 75% - Write 25%, then 75% of Array Accelerator cache is dedicated to read-ahead cache and 25% is dedicated to the write-posting cache.
  • Page 78 (the devices are reactivated automatically). If you have a backup of the data, restore the data now. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM...

  • Page 79: Handling Disk Drive Failures

    NetWare considers the data to be is still valid and accessible during the rebuilding process. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 80: Optimizing Array Controller Performance

    INSTALL.NLM. If you installed NetWare using SmartStart, it is not necessary to run this utility. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 81 Use the DOS FDISK utility to create the smallest DOS partition allowed. Start the server and load CPQDAOPT.NLM again. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 82 Option to change the size of the Hot Fix Redirection Area using the formula provided by CPQDAOPT. Create your volume(s). Restore your data. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: F-CH05.DOC Last Saved On: 12/7/98 1:22 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 83: Installing The Operating System Drivers

    Chapter 6 Installing the Operating System Drivers This chapter outlines driver installation steps to set up the Smart Array 3200 Controller in a server running any of the following operating systems: Novell NetWare 3.2, 4.2, and 5.0 Microsoft Windows NT 3.51 and 4.0 SCO OpenServer 5 SCO UnixWare 2.x and 7.x...

  • Page 84: Installation Requirements

    World Wide Web Go to http://www.compaq.com Materials Needed To install the Smart Array 3200 Controller driver on your server, you will need: Compaq SmartStart and Support Software CD (supplied in the Smart Array 3200 Controller option kit) Up to three blank diskettes...

  • Page 85: Creating Novell Ssd Diskettes

    Follow the instructions on the screen to create the Novell SSD diskette(s). Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 86: Additional Information

    Select the file(s) to read or print. Important readme files include: READ1ST.RDM STORAGE.RDM Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 87 Otherwise, Compaq recommends that you abort this installation and install the intraNetWare Support Pack first. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 88: Updating The Compaq Insight Manager Agents

    SmartStart. You will not need to update the agents. If you did not use SmartStart 4.22 or later as part of your Smart Array 3200 Controller installation, you must manually update the Insight Agents. The correct agents can be obtained from your local Compaq Reseller or authorized Compaq Service Provider.

  • Page 89: Handling Disk Drive Failures

    Follow the instructions in the following sections for replacing a drive in your server configuration. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 90 Compaq recommends that your DOS partition be at least 15 MB. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 91 You can now start your NetWare server. You may need to create your STARTUP.NCF file. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 92 If the failed drive is hot-pluggable, Skip to step 6. Otherwise, schedule server down time, take the server offline, and power-off the unit. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM...
  • Page 93 Out of Sync partition should match the previously failed device number. Select the Out of Sync partition. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM...
  • Page 94 A console message indicates successful completion of the resynchronization step. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 95 Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM...
  • Page 96 Locate the recent back-up media and restore the data to this server volume. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 97: Microsoft Windows Nt 3.51 And 4.0

    After that, the utility can be used online to change the array configuration. Materials Needed To install the Smart Array 3200 Controller Windows NT driver on your server, you will need: Compaq SmartStart and Support Software CD (supplied in the Smart...

  • Page 98: Creating The Windows Nt Ssd Diskettes

    Installing the Operating System Drivers Creating the Windows NT SSD Diskettes The Windows NT driver for the Smart Array 3200 Controller is located on the Compaq SmartStart and Support Software CD that was supplied in the Smart Array 3200 Controller option kit. To access the driver, create the Compaq SSD for Windows NT diskettes.

  • Page 99: Additional Information

    Updating the Compaq Drive Array Driver Removing the Compaq Drive Array Driver Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 100: Installation Procedures

    Program Installation Method The Compaq SSD for Windows NT Setup program installation method uses device drivers installed with the Setup program located on the Compaq SSD for Windows NT. The Setup program identifies hardware components installed in the machine and suggests device drivers needing installation.
  • Page 101 A:\scsi\array Select Continue. 10. Select Compaq Drive Array from the list of drivers to install. Click OK. 11. After the driver has been copied to the system, Setup returns to the SCSI Adapter Setup dialog box. Compaq Drive Array should appear in the list of installed SCSI controllers.
  • Page 102 Controller Driver During Windows NT Installation This section describes how to install the driver using the Compaq SSD for Windows NT utility during the initial installation of Windows NT 3.51 or 4.0. To install the driver after Windows NT has already been installed, see the section, “Installing the Smart Array 3200 Controller Driver after Windows NT...
  • Page 103 Enter. After the driver has been loaded into memory, the Setup program returns to the screen displayed in Step 4. Compaq Drive Array should appear in the list of recognized mass storage devices. To install additional device support, repeat Steps 4 through 7. Otherwise, continue with Step 8.
  • Page 104 A:\scsi\array Click Continue. 10. Select Compaq Drive Array from the list of drivers to install. Select OK. 11. After the driver is copied to the system, Setup returns to the SCSI Adapter Setup dialog box. Compaq Drive Array should appear in the list of installed SCSI controllers.
  • Page 105 IMPORTANT: Do not remove this driver if the system is booting from a device attached to a Smart Array 3200 Controller. You will get a dialog box stating that the selected controller is marked as a boot device. Removing it may cause the system not to boot.
  • Page 106 Remove the Windows NT SSD diskette, shut down Windows NT, and reboot the system to load the driver. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 107: Updating The Compaq Insight Manager Agents

    SmartStart; you will not have to manually update the agents. If you did not use SmartStart 4.22 or later as part of your Smart Array 3200 Controller installation, you must manually update the Insight Agents. The correct agents can be obtained from your local Compaq Reseller or authorized Compaq Service Provider.

  • Page 108: Sco Openserver 5

    The latest drivers and support files for SCO OpenServer 5 and information about installing the driver are on the Compaq SmartStart and Support Software CD supplied with the Smart Array 3200 Controller option kit. To access these files, create a set of Compaq EFS for OpenServer 5 diskettes from the Compaq SmartStart and Support Software CD.

  • Page 109: Accessing The Information

    Use a text editor or other DOS utility to read the INSTALL.TXT file on the diskette. Follow the instructions in this file to install the Smart Array 3200 Controller driver in a server running SCO OpenServer 5 from Compaq. Servers Running Non-Compaq SCO...

  • Page 110: Updating The Compaq Insight Manager Agents

    SmartStart; you will not have to manually update the agents. If you did not use SmartStart 4.22 or later as part of your Smart Array 3200 Controller installation, you must manually update the Insight Agents. The correct agents can be obtained from your local Compaq Reseller or authorized Compaq Service Provider.

  • Page 111: Materials Needed

    Materials Needed To create a set of Compaq EFS for SCO UnixWare diskettes, you will need: Compaq SmartStart and Support Software CD (supplied in the Smart Array 3200 Controller option kit) Blank diskettes Access to a server or workstation with a bootable CD-ROM drive. This may be the system in which you are installing the Smart Array 3200 Controller.

  • Page 112: Updating The Compaq Insight Manager Agents

    SmartStart; you will not have to manually update the agents. If you did not use SmartStart 4.22 or later as part of your Smart Array 3200 Controller installation, you must manually update the Insight Agents. The correct agents can be obtained from your local Compaq Reseller or authorized Compaq Service Provider.

  • Page 113: Creating Ssd Diskettes

    Creating SSD Diskettes The OS/2 driver for the Smart Array 3200 Controller is located on the Compaq SmartStart and Support Software CD (supplied in the Smart Array 3200 Controller option kit). To access the driver, create the OS/2 SSD diskettes.

  • Page 114: Additional Information

    Select the files to read or print. Important files include: README.1ST WHATSNEW.RDM ADDARRAY.RDM HISTORY.RDM Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 115: Installing The Driver

    Then type: Ddinstal Click the Change button to change the source directory to A:/ADD. Select Compaq Array Driver for OS/2 from the list of drivers. Click OK to continue. The CPQARRAY.ADD driver file will be copied to the x:\os2 directory (where x is the boot drive).

  • Page 116: Controller Ordering

    If booting from a Compaq Smart Array 3200 Controller, the statement BASEDEV = CPQARRAY.ADD must be present. Since a Compaq IAES Controller cannot be primary if it is the only other controller installed in the system, the system must boot from the Smart Array 3200 Controller (controller order = First).

  • Page 117: Partitioning

    OS/2 may allow the creation of partitions beyond these boundaries; adhere to these limits, however, to ensure proper functionality. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM...

  • Page 118: Booting Os/2 From A Smart Array 3200 Controller

    Installing the Operating System Drivers Booting OS/2 from a Smart Array 3200 Controller This section includes information on booting a system from a Smart Array 3200 Controller. The CPQARRAY.ADD driver must be present when booting from a Smart Array 3200 Controller (the Compaq IAES is not a bootable device).

  • Page 119: Command Line Switches

    This command line switch is a non-standard switch implemented for the CPQARRAY.ADD to modify the performance characteristics of the driver when using a Smart Array 3200 Controller. Under heavy disk use, this command switch enables greater performance based on the number associated with the [memory blocks] parameter.
  • Page 120 [unit parameters] This ADD only supports the /I parameter to ignore a controller. The following unit parameter is available: /I Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM...
  • Page 121 ADD driver. The following statement would prevent the ADD driver from claiming Adapter 2. BASEDEV=CPQARRAY.ADD /A:2 /I Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: G-CH06.DOC Last Saved On: 12/7/98 9:23 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 122: Updating The Compaq Insight Manager Agents

    SmartStart. You will not have to manually update the agents. If you did not use SmartStart 4.22 or later as part of your Smart Array 3200 Controller installation, you must update the Insight Agents manually. The correct agents can be obtained from your local Compaq Reseller or authorized Compaq Service Provider.

  • Page 123: Creating The Peripheral Adapter Support Software Diskettes

    (a single Compaq driver supports the Smart Array series of controllers) and includes a procedure for installing the Smart Array 3200 Controller driver. To access this file, follow the instructions on the diskette label. Installing the Driver To install the Smart Array 3200 Controller driver, follow the installation procedures specified in the README.SSD file.

  • Page 124: Regulatory Compliance Notices

    Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: H-APPA.DOC Last Saved On: 12/7/98 1:34 PM...

  • Page 125: Class B Equipment

    1-800-652-6672 (1-800-OK COMPAQ). (For continuous quality improvement, calls may be recorded or monitored.) Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: H-APPA.DOC Last Saved On: 12/7/98 1:34 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 126: Modifications

    Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: H-APPA.DOC Last Saved On: 12/7/98 1:34 PM...

  • Page 127: Class B Equipment

    EN50082-1 (IEC801-2, IEC801-3, IEC801-4) - Electromagnetic Immunity EN60950 (IEC950) - Product Safety Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: H-APPA.DOC Last Saved On: 12/7/98 1:34 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 128: Japanese Notice

    Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: H-APPA.DOC Last Saved On: 12/7/98 1:34 PM...

  • Page 129: Laser Safety Warnings

    The following label or equivalent is located on the surface of the Compaq supplied laser device. Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: H-APPA.DOC Last Saved On: 12/7/98 1:34 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 130: Laser Information

    Divergence Angle Output Power Polarization Numerical Aperture Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: H-APPA.DOC Last Saved On: 12/7/98 1:34 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Semiconductor GaAIAs 780 nm +/- 35 nm 53.5 degrees +/- 0.5 degrees...

  • Page 131: Battery Replacement Notice

    Compaq Authorized Reseller or your Authorized Service Provider. Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: H-APPA.DOC Last Saved On: 12/7/98 1:34 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 132: Appendix B Electrostatic Discharge

    Always be properly grounded when touching a static-sensitive component or assembly. Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: I-APPB.DOC Last Saved On: 12/7/98 1:35 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 133: Grounding Methods

    Authorized Compaq Service Provider or refer to the Maintenance and Service Guide. Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: I-APPB.DOC Last Saved On: 12/7/98 1:35 PM...

  • Page 134: Appendix C Specifications

    PCI Bus Transfer Rate (maximum) SCSI Bus Termination SCSI Port Connectors (internal and external) Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: J-APPC.DOC Last Saved On: 11/30/98 5:06 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 135: Wide Scsi Connector Pin Assignments

    EXTSCSI.AI, A-6.EPS Figure C-1. Wide SCSI Connector 68-Pin Wide SCSI Connector Pin Assignments Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: J-APPC.DOC Last Saved On: 11/30/98 5:06 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 136 Ground Ground Ground Ground * - Active low signals Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: J-APPC.DOC Last Saved On: 11/30/98 5:06 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED continued Signal DB7*...

  • Page 137: Things You Should Know

    SCSI cabling SCSI cable connectors Migrating to/from other controllers Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: K-APPD.DOC Last Saved On: 12/7/98 1:37 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Compaq Smart Array 3200 Controller Reference Guide...

  • Page 138: Smart Array 3200 Controller Option Kit Contents

    Compaq Smart Array 3200 Controller Reference Guide; Compaq Smart Array 3200 Controller Installation Guide Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: K-APPD.DOC Last Saved On: 12/7/98 1:37 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 139: Scsi Termination

    Compaq storage systems should not contain bus termination. SCSI IDs The Smart Array 3200 Controller contains two SCSI buses (ports), each of which supports up to 15 drives. The internal and external connectors reside on separate SCSI buses; peripherals attached to either connector must have a unique SCSI ID in the ranges of 0 to 6 and 8 to 15.

  • Page 140: Scsi Cabling

    D-4 Things You Should Know SCSI Cabling The cables available from Compaq that connect your Smart Array 3200 Controller option board to SCSI drives in any Compaq server or external SCSI product can be found: In the Smart Array 3200 Controller Installation Guide At www.compaq.com...

  • Page 141: Scsi Cable Connectors

    SCSI Cable Connectors To help identify the SCSI cables required for a Smart Array 3200 Controller installation in the various configurations of Compaq servers, refer to Figure D-2. Keep in mind these characteristics of SCSI cables: External SCSI cables have a round wire with securable connectors.

  • Page 142: Migrating To/From Other Controllers

    FW Upgrade: Destination controller should be upgraded to firmware version 3.04 or higher, using Options ROMPaq before attaching drives. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: K-APPD.DOC Last Saved On: 12/7/98 1:37 PM...

  • Page 143: Understanding Drive Arrays

    Drive 1 Daz-9-12.EPS Figure E-1. Drive array with two logical drives Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Physical...
  • Page 144 Daz-9-16.EPS Figure E-3. Drive array with six physical drives and two logical drives Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 145: Drive Arrays

    Important drive array characteristics of the Smart Array 3200 Controller include: A single array cannot span more than one Smart Array 3200 Controller. A single Smart Array 3200 Controller can control multiple arrays. Arrays must have at least one physical drive and may have up to 30 physical drives.

  • Page 146: Logical Drives

    (RAID levels). The portion of a logical drive on each physical drive is the same size. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 147: Drive Array Benefits

    Drive Array Benefits Using drive arrays with the Smart Array 3200 Controller has several important benefits: Data Protection Performance Enhancement Capacity Changes Data Reliability Data Protection The Smart Array 3200 Controller provides several options to produce data redundancy for a more reliable system including distributing data, fault- tolerance methods, assigning online spares, and rebuilding data.
  • Page 148 RAID 0 offers the best of both parameters. However, RAID 0 has no data protection and you will have to rely on backups in the event of hardware failure. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM...
  • Page 149 NOTE: Given the reliability of a particular generation of hard drive technology, the probability of an array experiencing a drive failure increases with the number of drives in an array. Compaq recommends the number of drives in an array be limited to 14.
  • Page 150 NOTE: Given the reliability of a particular generation of hard drive technology, the probability of an array experiencing a drive failure increases with the number of drives in an array. Compaq recommends the number of drives in an array be limited to 14.
  • Page 151 WAR2-051.AI, 9-1.EPS Figure E-7. Drive mirroring stores identical copy of the data Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 152 You can install up to four online spares for each Smart Array 3200 Controller. To provide an online spare, you must have at least one installed but unassigned physical drive and the system must be running some type of fault-tolerance method (RAID 1, RAID 4, or RAID 5).

  • Page 153: Performance Enhancement

    Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 154 For example, consider an operating system that typically requests data in 32-sector blocks (a sector contains 512 bytes of data). The Smart Array 3200 Controller distributes the data so that the first 32 sectors of data are on the first drive in the array.

  • Page 155: User Selectable Stripe-Size

    = 1792 sectors), the least common multiple of a full stripe would require 8960 sectors (4480 KB) available in the Array Accelerator. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM...

  • Page 156: Array Accelerator

    Array Accelerator By serving as a posted write cache and read-ahead cache, the Smart Array 3200 Controller Array Accelerator dramatically improves the performance of Read and Write commands. The Array Accelerator is particularly useful for increasing performance in database and fault-tolerant configurations.
  • Page 157 Array Accelerator can be removed from one Smart Array 3200 Controller and installed on another. If there is any data in the Array Accelerator that has not been written to the hard drive, it can be transferred to another Smart Array 3200 Controller.
  • Page 158 IMPORTANT: It is possible for the batteries to be depleted when you install a new Smart Array 3200 Controller. It can take up to 36 hours of system operation to fully charge the batteries. In this case, only the Array Accelerator is affected;...

  • Page 159: Concurrent I/O Request Servicing

    Concurrent I/O Request Servicing The Smart Array 3200 Controller can service hundreds of I/O requests at a time. For example, if you request data that resides on the first drive and another end user requests data that resides on the second drive, the controller delivers both pieces of information concurrently.

  • Page 160: Bus Master Data Transfers

    E-18 Understanding Drive Arrays Bus Master Data Transfers The Smart Array 3200 Controller is a bus master device that takes control of the PCI bus during high-speed transfers. This allows the system processor to handle application processing or other types of tasks. Data transfer occurs at rates of up to 133 MB/sec for the PCI bus.
  • Page 161 Figure E-11. Expanded array storage capacity with a second logical drive Example: Assume you have two ProLiant Storage Systems with a total of 10 drives and you want to expand this to 14 drives (the Smart Array 3200 Controller supports up to 30 drives). With the Array Configuration Utility running, simply install four matching drives in the empty drive bays.
  • Page 162 E-20 Understanding Drive Arrays The Smart Array 3200 Controller equally redistributes the data to all the drives, using the same fault-tolerance method as the original configuration. The first logical drive remains first, but it now spans 14 drives instead of 10. The Array...

  • Page 163: Online Capacity Expansion Or Extension

    Online Capacity Expansion or Extension In certain cases, the Smart Array 3200 Controller and the Array Configuration Utility also facilitate storage capacity changes online, without downing the server or storage system. These cases are: Windows NT Hot-plug drives Because the Array Configuration Utility reconfigures the Smart Array 3200 Controller, online reconfiguration can only take place if the Array Configuration Utility is running in the same environment as the normal server applications.

  • Page 164: Other Fault-Management Features

    Hot-plug drives (Compaq ProLiant Storage System, Compaq ProLiant Server, Rack-Mountable Compaq ProLiant Storage System or Rack- Mountable Compaq ProLiant Server) The following functions are not Smart Array 3200 Controller features, but can be supported by the operating system: Controller duplexing...

  • Page 165: Auto-Reliability Monitoring

    Drive parameter tracking enables the Smart Array 3200 Controller to detect drive problems and predict drive failure before they actually occur. It also makes pre-failure warranty possible on Compaq disk drives.

  • Page 166: Interim Data Recovery

    Smart Array 3200 Controller; they function independently of the operating system. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM...

  • Page 167: Hot Pluggable Drives

    “failed.” This could result in permanent data loss when the Storage System is turned back on. If a drive fails, the service-required LED on the front panel of the Compaq ProLiant lights, indicating that a problem has occurred. Refer to your server documentation for more information on replacing drives.
  • Page 168 DO NOT remove drive DO NOT remove drive Figure E-12. Hot-plug drive replacement conditions Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 169: Controller Duplexing

    Smart Array 3200 Controllers. With duplexing, the two controllers each have their own drives that contain identical data. In the unlikely event of a Smart Array 3200 Controller failure, the remaining drives and the Smart Array 3200 Controller service all requests.

  • Page 170: Software-Based Drive Mirroring

    See Chapter 5 for information on your drive array(s) and fault tolerance. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: L-APPE.DOC Last Saved On: 12/7/98 9:30 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 171: Replacing The Array Accelerator

    The memory is Error Checking and Correcting (ECC), providing error detection and correction reliability. It can be moved to another Smart Array 3200 Controller to complete the data transfer should the original Smart Array 3200 Controller fail. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: M-APPF.DOC Last Saved On: 12/2/98 2:08 PM...

  • Page 172: Removing The Array Accelerator

    Figure F-1. Removing Array Accelerator board from the Smart Array 3200 Array Controller Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: M-APPF.DOC Last Saved On: 12/2/98 2:08 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED WARNING: Do not abuse, recharge, disassemble, dispose of in fire or heat above 90 C, incinerate, or expose to water or fire.

  • Page 173: Installing The Array Accelerator

    Align the plastic standoff on the Array Accelerator board with the slot in the Smart Array 3200 Controller board. Push it through and rotate the top of the standoff 90 to lock the board in place 2.
  • Page 174 This appendix provides upgrade instructions for moving arrayed drives from either the SMART or SMART-2 (SMART-2/E, SMART-2/P, SMART-2SL, and SMART-2DH) Controllers to the Smart Array 3200 Controller. All end user data and configuration information will be retained after the upgrade process.

  • Page 175: G-2 Upgrading From The Smart-2 And Smart Scsi Array Controllers

    Compaq ProLiant Storage Systems. There is no Y cable used with the SMART-2DH Controller. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: N-APPG.DOC Last Saved On: 12/8/98 11:15 AM...
  • Page 176 There is no Y cable required for the Smart Array 3200 Controller. Compaq Smart Array 3200 Controller Reference Guide Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: N-APPG.DOC Last Saved On: 12/8/98 11:15 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 177 SMART-2 Controller Figure G-1. Cable and Connector configurations for SMART and SMART-2 Array Controllers Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: N-APPG.DOC Last Saved On: 12/8/98 11:15 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 178 Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: N-APPG.DOC Last Saved On: 12/8/98 11:15 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 179 G-6 Upgrading from the SMART-2 and SMART SCSI Array Controllers The Smart Array 3200 Controller uses two VHDCI external and two 68- pin Fast-Wide SCSI-2 internal connectors on optional daughterboards; therefore: If you are connecting to Fast-SCSI-2 internal drives, you must attach...
  • Page 180 After completing these steps, the upgrade process is complete. You can now use the Smart Array 3200 Controller. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: N-APPG.DOC Last Saved On: 12/8/98 11:15 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 181: Recovering From Drive Failure

    The purpose of fault-tolerant configurations on the Smart Array 3200 Controller is to protect against data loss due to drive failure. Although the Smart Array 3200 Controller firmware is designed to protect against normal drive failure, it is imperative that the correct actions are performed to recover from a drive failure without inadvertently inducing any additional drive failures.

  • Page 182: Fault Tolerance And Drive Failure

    “rebuilding” condition following a drive failure if a spare drive was previously assigned and is being rebuilt. In any RAID 1 logical drive on the Smart Array 3200 Controller tht has N physical drives in the array (not including spare drives), the first N/2 physical drives are normally mirrored in consecutive order to the second N/2 physical drives.

  • Page 183: Spare Drives

    SCSI ID conflicts that could compromise the fault tolerance. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: O-APPH.DOC Last Saved On: 12/7/98 1:47 PM...

  • Page 184: Automatic Data Recovery

    20 minutes/GB for 14 drives (using 9-GB wide- ultra hard drives). Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: O-APPH.DOC Last Saved On: 12/7/98 1:47 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED CAUTION: If the Smart Array 3200 Controller has a failed drive, replace this drive with a new or known-good replacement drive.

  • Page 185: Automatic Data Recovery Failure

    In this case, the replacement drive should be removed and replaced. Compaq Smart Array 3200 Controller Reference Guide Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: O-APPH.DOC Last Saved On: 12/7/98 1:47 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...

  • Page 186: Compromised Fault Tolerance

    Because of the risk that fault tolerance may be compromised at some point in the future, make regular backups of all logical drives. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: O-APPH.DOC Last Saved On: 12/7/98 1:47 PM...
  • Page 187 NOTE: SCSI Port 1 refers to internal or external drives attached to the internal Port 1 connector. SCSI Port 2 refers to external drives installed in a Compaq ProLiant Storage System attached to the external Port 2 connector.
  • Page 188 1726 Slot x Drive Array - Array Accelerator Memory Size Change Detected. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: P-APPI.DOC Last Saved On: 12/7/98 9:35 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 189 Auto-configuration failed: Too many logical drives. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: P-APPI.DOC Last Saved On: 12/7/98 9:35 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 190 8-bit Option ROM due to EISA bus limitations. Please remove or reconfigure your ISA card. (RESUME = F1 KEY) Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: P-APPI.DOC Last Saved On: 12/7/98 9:35 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 191 1768 Slot x Drive Array - Resuming logical drive expansion process Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: P-APPI.DOC Last Saved On: 12/7/98 9:35 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Recommended Action Run the latest version of Systems ROMPaq.
  • Page 192 (RESUME = F1 KEY) Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: P-APPI.DOC Last Saved On: 12/7/98 9:35 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 193 1778 Slot x Drive Array resuming Automatic Data Recovery process Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: P-APPI.DOC Last Saved On: 12/7/98 9:35 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Recommended Action The termination power signal for the specified SCSI port was shorted to ground.
  • Page 194 SCSI drive(s) should be replaced: SCSI Port (y) SCSI ID ( x ) Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: P-APPI.DOC Last Saved On: 12/7/98 9:35 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 195 Select F2 to continue without starting Automatic Data Recovery data to drive . Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: P-APPI.DOC Last Saved On: 12/7/98 9:35 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Recommended Action 1.
  • Page 196 If this message was not due to a bad power cable connection and the drive was not replaced, this could indicate a defective SCSI cable. Contact your Authorized Compaq Service Provider. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 continued...
  • Page 197 Configuration Error. Data does not correspond to this drive array. Array Accelerator is temporarily disabled. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: P-APPI.DOC Last Saved On: 12/7/98 9:35 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 198 Select F2 to accept data loss and to re-enable logical drives. Writer: Rickard Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: P-APPI.DOC Last Saved On: 12/7/98 9:35 AM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Recommended Action The Array Accelerator is not responding.
  • Page 199 Q. I installed the hard drives in my server. Must I now terminate each drive? A. No; if you install hard drives in a server with a Smart Array 3200 Controller, all termination requirements are met by the controller and the SCSI signal cable.
  • Page 200 J-2 Questions and Answers Q. I have several hard drives in my server and in the Compaq ProLiant Storage System. What SCSI IDs do I assign for these drives? A. Each hard drive must have a unique SCSI ID for each controller port. If...
  • Page 201 Smart Array 3200 Controller because both SCSI ports will be used externally. You can add an additional Smart Array 3200 Controller to your server to control any internal drives.
  • Page 202 H , “POST Error Messages,” for information on each POST error message. If you still do not know what to do, run the Array Diagnostics Utility. Q. Can I use third-party (not Compaq) drives on the Smart Array 3200 Controller? A.
  • Page 203 Windows NT support 5-3 wizards 1-6 arrays configuration, two arrays, table Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: R-INDX.DOC Last Saved On: 12/7/98 2:14 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Index-1...
  • Page 204 Compaq website xiii compromised fault tolerance H-6 concurrent request servicing E-17 Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: R-INDX.DOC Last Saved On: 12/7/98 2:14 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 205 6-2 standard Windows NT installation methods 6-20 updating 1-8, 6-2 Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: R-INDX.DOC Last Saved On: 12/7/98 2:14 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Index-3...
  • Page 206 FILE NAMES xi firmware, updating 3-1 FORMAT 6-8 Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: R-INDX.DOC Last Saved On: 12/7/98 2:14 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED general information D-1...
  • Page 207 ECC See ECC memory Microsoft Windows NT additional information, NTREADME.HLP 6-17 Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: R-INDX.DOC Last Saved On: 12/7/98 2:14 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Index-5...
  • Page 208 NTREADME.HLP 6-17 NWADMIN 6-7, 6-13 NWPA driver support 6-5 Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: R-INDX.DOC Last Saved On: 12/7/98 2:14 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED online help 5-4...
  • Page 209 Redundant Arrays of Inexpensive Disks See RAID replacing a failed drive H-3 Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: R-INDX.DOC Last Saved On: 12/7/98 2:14 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED...
  • Page 210 4-2 features 4-1 running 4-3 System ROMPaq 3-3 Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: R-INDX.DOC Last Saved On: 12/7/98 2:14 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED telephone numbers xiii...
  • Page 211 5-4 write cache 1-4 www.compaq.com xiii, 1-8, 2-3, 6-2, Writer: Rebecca Wiggins Project: Compaq Smart Array 3200 Controller Reference Guide Comments: 340862-002 File Name: R-INDX.DOC Last Saved On: 12/7/98 2:14 PM COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED Index-9...

Table of Contents
