JVC GM-P420PCE Operating Instructions Manual

Plasma display monitor
Hide thumbs Also See for GM-P420PCE:

Advertisement

Quick Links

OPERATING INSTRUCTIONS
PLASMA DISPLAY MONITOR
BEDIENUNGSANLEITUNG : PLASMABILDSCHIRM
MANUEL D'INSTRUCTIONS : MONITEUR DE VISUALISATION PLASMA
MANUALE D'ISTRUZIONI : MONITOR CON SCHERMO AL PLASMA
MANUAL DE INSTRUCCIONES : MONITOR DISPLAY DE PLASMA
PLASMA DISPLAY MONITOR
GM-P420E
GM-P420PCE
GM-P420PCE
GM-P421PCE
GM-P421PCE
GM-P420E
Downloaded from:
https://www.usersmanualguide.com/
INSTRUCTIONS
MENU INPUT
POWER
LCT1150-001B
Apr. 2002 No. 51953
GM-P420PCE
GM-P421PCE
GM-P420E

Advertisement

Table of Contents
loading

Summary of Contents for JVC GM-P420PCE

  • Page 1 GM-P420PCE GM-P421PCE GM-P420E OPERATING INSTRUCTIONS PLASMA DISPLAY MONITOR BEDIENUNGSANLEITUNG : PLASMABILDSCHIRM MANUEL D'INSTRUCTIONS : MONITEUR DE VISUALISATION PLASMA MANUALE D'ISTRUZIONI : MONITOR CON SCHERMO AL PLASMA MANUAL DE INSTRUCCIONES : MONITOR DISPLAY DE PLASMA PLASMA DISPLAY MONITOR GM-P420E INSTRUCTIONS GM-P420PCE...
  • Page 2: Table Of Contents

    TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. This instruction manual refers to the GM-P420E, GM-P420PCE, and GM-P421PCE. The explanations and illustrations used in this instruction manual are of the GM-P420E unless otherwise stated.
  • Page 3: Parts Identification

    3 VIDEO A, VIDEO B, COMPO./RGB B and RGB A buttons PANORAMIC ZOOM Do not connect any plugs to the terminal other than JVC’s recommended optional parts. (page 14) 8 POWER button (page 14) Use these buttons to switch between inputs.
  • Page 4: Monitor: Front View

    1 RGB A input terminals (page 11) 3 AUDIO OUT terminals (pin jack) (page 11) green. It glows orange in standby mode. • Only for GM-P420PCE and GM-P421PCE: Only RGB A Connect to the audio input terminals of external • D-sub, 15 pin input can be used.
  • Page 5: Preparations

    Checking the Accessories Note: The following accessories are included with the Monitor. Check for them. If any item is missing, please contact the dealer where * GM-P420PCE and GM-P421PCE do not have you purchased the Monitor. the following input terminals—VIDEO A, VIDEO B, and COMPONENT/RGB B.
  • Page 6: Installation

    “COMPO.” on the menu (see page 23). Front View Side View (For GM-P420PCE and GM-P421PCE, to input the above signals, you need to install the video input unit (IF-C422P1G), which is separately purchased.) Computer signals (Preset) This Monitor has 13 preset video modes for the most popular industrial standard, and the signals of the following image resolutions can be input to the RGB input terminals.
  • Page 7: Connection Diagrams

    Connections (Continued) Connection Diagrams AV connections These terminals are not available for GM-P420PCE and GM-P421PCE. To use them, you need to install video input unit (IF-C422P1G), which is separately purchased. Typical connections VCR 1 VCR 2 DVD player, etc Personal computer...
  • Page 8 GM-P420PCE GM-P421PCE GM-P420E Connecting an external control unit When connecting the external control unit to the MAKE terminal, you can operate the following functions through the MAKE terminal; • Turn on or off the Monitor. Preparation: The POWER switch on the rear must be set to ON (so that the Monitor is in standby mode).
  • Page 9: Basic Operations

    RGB A or COMPONENT/RGB B input terminals * Only for GM-P420PCE and GM-P421PCE: You need to copyright law, which requires your special attention. You can select only REGULAR and FULL.
  • Page 10: Video Adjustments

    Video Adjustments For video adjustments, use menus. Adjusting the Screen Size and Position Press 2/3 to make adjustments. You can use the buttons either on the remote control or on Monitor for menu operations. The screen size and position can be adjusted. Press MENU/EXIT (or MENU on the •...
  • Page 11: Adjusting The Color Temperature

    Video Adjustments (Continued) Adjusting the Color Temperature Adjusting the White Balance Press 2/3 to adjust the selected item. The adjusted setting applies to all inputs. G GAIN, B GAIN and R GAIN can be finely adjusted Note: separately for “HIGH” and “LOW” settings of the color •...
  • Page 12: Changing The Picture Mode

    Video Adjustments (Continued) To make an adjustment while viewing the adjustment Changing the Picture Mode Changing the Aspect Ratio bars After step 3 on page 19, proceed as follows: When one of the following signals comes in through the RGB The setting adjusted applies to all inputs.
  • Page 13: Setting The Receivable Signal Types

    Video Adjustments (Continued) Setting the Receivable Signal Types Setting the COMPONENT/RGB B Input Resetting the Function Selection Menu Settings You can set the receivable signal types. Normally, select After connecting the playback device such as a PC or a DVD You can reset all the Function Selection Menu settings at a “AUTO.”...
  • Page 14: Other Convenient Functions

    A D J U S T : S E L E C T : E X I T : M E N U For GM-P420PCE and GM-P421PCE: “REMOTE SWITCH” does not appear on the menu unless the video input unit (IF-C422P1G) is separately purchased and installed.
  • Page 15: Setting The Remote-Controllable Input

    MAKE terminal, you need to set the desired input to use, which you can select from the connected external control unit. Press MENU/EXIT while holding • For GM-P420PCE and GM-P421PCE: You cannot use this VOLUME – to display the Setup Menu. function unless the video input unit (IF-C422P1G) is Setting the High-Definition Signal Types separately purchased and installed.
  • Page 16: Using The Power Save Function

    : M O D E 1 H D S I G N A L M O D E : 1 0 8 0 i For GM-P420PCE and GM-P421PCE: W H I T E B A L A N C E To cancel the Refresh function “REMOTE SWITCH”...
  • Page 17: Resetting All The Menu Settings

    Adjustable when the RGB15K-50, RGB15K-60, or VGA480-60 signal comes in. Adjustable when VIDEO A, VIDEO B, or COMPONENT input is selected. For GM-P420PCE and GM-P421PCE: Not adjustable when viewing the following component signals—720p, and 1080i (1035i). “REMOTE SWITCH” does not appear on the menu Adjustable when RGB B or COMPONENT input is selected.
  • Page 18: Menu Classifications

    Adjusts the vertical screen position. CLOCK PHASE* Adjusts to eliminate stripes or flickering. Normally, no adjustment is needed. For GM-P420PCE and GM-P421PCE: Appears r e s e t sub menu Displays the fine adjustment bar. only when the video input (IF-C422P1G) is...
  • Page 19: Troubleshooting

    GM-P420PCE GM-P421PCE GM-P420E Troubleshooting Solutions to common problems related to the Monitor are described here. If none of the solutions presented here solves the problem, unplug the Monitor and consult an authorized dealer or service center. Symptom Probable cause Corrective action Page Power is not supplied.
  • Page 20: Self-Diagnostic Indication

    GM-P420PCE GM-P421PCE GM-P420E If the trouble still persists, follow the procedure below: Self-diagnostic Indication Check which lamps are lighting or flashing. When something abnormal occurs with the Monitor, this function informs you of the condition of the Monitor with On the Self-diagnostic Report Sheet (below), check the box self-diagnostic lamps, allowing for smooth service work.
  • Page 21: Specifications

    500 mV(rms), high impedance GM-P420PCE and GM-P421PCE do not have the following input terminals – VIDEO A, VIDEO B, and COMPONENT/RGB B. You need to install the video input unit (IF-C422P1G), which is separately purchased, to select “VIDEO A,” “VIDEO B,” and “COMPONENT (or RGB B)”...
  • Page 22 IF-C422P1G (Only for GM-P420PCE and GM-P421PCE) Cooling Fan Unit TS-C01FANG Notice on transportation This Monitor is precision equipment and needs dedicated packing material for transportation. Never use any packing material supplied from other than JVC or JVC-authorized dealers. 1-22 No.51953 Downloaded from: https://www.usersmanualguide.com/...
  • Page 23 GM-P420PCE GM-P421PCE GM-P420E Specifications (Continued) Pin assignment (Specifications for terminals) • Y/C terminal • RS-232C terminal This is a female type connector. 4 3 2 1 Pin number Signal name Pin number Signal name Pin number Signal name GND (Y) GND (C) •...
  • Page 24 GM-P420PCE GM-P421PCE GM-P420E VICTOR COMPANY OF JAPAN, LIMITED Printed in Japan 0302-Y-M-VP © 2002 VICTOR COMPANY OF JAPAN, LIMITED VP0204 DP1058 Downloaded from: https://www.usersmanualguide.com/...
